Summary of Contents for Freeview 15/4

  • Page 1 15’’ LCD TV Model: 15/4, 15/6 USER GUIDE...
  • Page 5 WARNINGS Thank you for purchasing this television. For your safety, please take time to read these instructions carefully in order to familiarise yourself with the operation of the appliance and the important safety information. We strongly recommend that this product is installed by a competent person. If in doubt, refer to the retailer or the manufacturer helpline.
  • Page 6 WARNINGS Screen Burn A characteristic of Plasma and LCD TV Panels is that displaying the same image for a long time may cause a permanent after-image to remain on the screen. This is called screen burn. Most pictures shown on your TV will be constantly moving and fill the screen.
  • Page 7: Table Of Contents

    What is included in the box with the TV ............... 4 How to set up the TV for the first time Tuning into Digital / Freeview TV Stations ............5 Tuning into Analogue TV Stations (i.e 1 - 5) ............5 TV &...
  • Page 8: What Is Included In The Box With The Tv

    GETTING STARTED - INCLUDED ACCESSORIES Accessories Included with this TV are the following accessories: 1x - User Guide Book 1x - Remote control NICAM MENU MENU BACK AV/TV SUBT INFO TEXT HOLD PGDN PGUP INDEX SIZE REVEAL SUBPAGE GREEN YELLOW CYAN SLEEP LAST P- MODE...
  • Page 9: Tuning Into Digital / Freeview Tv Stations

    In the event of poor reception in either Analogue TV or Digital TV (DVB) it may be necessary to install a signal ‘booster’ to enhance reception. For Digital/Freeview TV (DVB) you may need to upgrade your aerial to a High...
  • Page 10: Tv & Remote Control Buttons

    16 INFO To display system information 29 P-MODE To adjust the picture mode 17 TEXT To open the function of the TV of TELETEXT 30 DVB Menu Opens DVB Menu TOP PANEL BUTTONS 15/4 INPUT MENU VOL- VOL+ PRO- PRO+ POWER...
  • Page 11: Connecting Power Supply

    TV BUTTONS & CONNECTIONS FRONT PANEL BUTTONS 15/6 REAR CONNECTIONS 15/4 POWER DC 12V Power input VGA input SCART input SCART S-VIDEO S-Terminal Video input VIDEO AUDIO Audio input for Video and S-Video PC Audio input PC-AUDIO Earphone output H.PHONE...
  • Page 12: Rear Connections

    CONNECTIONS & SELECTING SOURCE REAR CONNECTIONS Selecting Input Source To switch between the different connections is very easy. 1) Press [TV/AV] - The following will appear 2) Press [\/] or [/\] to select the input you S-VIDEO require. SCART 3) Press [OK] PC-RGB...
  • Page 13: Adjusting The Picture Settings

    DVB-T MODE MENU OPERATION PICTURE SETTINGS Adjusting Colour Lets you adjust the brightness, contrast Increase or decrease the Red, Green & Blue which colour and sharpness to enhance make up the picture the viewing experience. 1) Press [MENU] to enter menu Adjusting Brightness 2) Press [\/] 3 times to select Colour Increase or decrease the brightness...
  • Page 14: Adjusting The Sound Settings

    DVB-T MODE MENU OPERATION SOUND SETTINGS Lets you adjust the balance and audio presets to enhance the viewing experience. Adjusting Balance To switch the sound between the left and right speakers 1) Press [MENU] to enter menu 2) Press [>] to go to Sound menu 3) Press [\/] twice to select Balance 4) Then press [>] or [<] to increase or decrease the balance...
  • Page 15: Adjusting The General Settings

    DVB-T MODE MENU OPERATION GENERAL SETTINGS Adjusting Input Source You may wish to change the input which is being used Adjusting Blue Screen Changes the background when there is no 1) Press [MENU] to enter menu input between clear and a blue 2) Press [>] twice to go to General menu background 3) Press [\/] 3 times to select Input Source...
  • Page 16: Adding / Deleting / Naming For Digital Channels

    DVB-T CHANNEL SETTINGS MENU Within Digital (DVB-T) mode there is also Create/Edit Favourite List a channel settings menu. This is provided so you can search for new channels, 1) Press [DVB MENU] create favourite lists and apply a pin code 2) Press [\/] to select favourite list to limit access.
  • Page 17: Reinstalling Digital Tv / Radio Stations

    DVB-T CHANNEL SETTINGS & ADJUSTING THE PICTURE FORMAT / SIZE Picture Size / Format System Settings 1) Press [DVB MENU] Your television has been factory set to show the correct picture format depending on the signal being 2) Press [\/] 3 times to select System received by the broadcast TV station.
  • Page 18: Using Electronic Programme Guide (Epg)

    ELECTRONIC PROGRAM GUIDE (EPG) The Electronic Program Guide is available in DVB-T mode. It is a 7 day TV guide and provides information about forthcomming programs (where supported by the broadcasted channel). You can view the start and end time of all programs and on all channels for the next 7 days.
  • Page 19: Tuning Analogue Tv

    TV MODE MENU OPERATION TUNING SETTINGS Skip If there is a channel that you do not wish Tuning Program to view you can add ‘Skip’ to that channel. You may wish to do some additional When you press P+ or P- it will skip past tuning.
  • Page 20: Naming Channels

    TV MODE MENU OPERATION Program Edit / Changing Channel Auto Search Position Scan for all channels based on the current You can change the channel position to settings suit your requirements. 1) Press [MENU] to enter menu 1) Press [MENU] to enter menu 2) Press [>] twice to go to Tuning menu 2) Press [>] twice to go to Tuning menu 3) Press [\/] 4 times to select Auto Search...
  • Page 21: Using Teletext

    TV MODE TELETEXT OPERATION Teletext is a service offered by some broadcasters which is provided with the video and audio signals. Teletext Operation 1) Press [TEXT], after a few seconds teletext page 100 should appear. Here is an example of BBC1 2) You can now navigate to the page you require in a number of ways: a) Press the page you require using...
  • Page 22: Installing To Use On A Windows Xp Pc

    CONNECTING TO A PC - WINDOWS XP 4) Left mouse click on Settings, this screen will IMPORTANT— Before connecting to appear. Check the Screen Resolution is set a PC you must ensure that the settings to 1024 by 768 pixels, if it is not change to this. of the PCs output are correct for the new LCD Monitor.
  • Page 23: Pc Picture Settings

    PC MODE MENU OPERATION (VGA) Within PC mode there is an additional Adjusting Colour Settings menu. This can be operated in the Choose between 9300k, 6500k or User following way. 1) Press [MENU] to enter menu PC SETTINGS 2) Press [\/] 3 times to select colour settings 3) Then press [<] or [>] to switch between Adjusting Brightness 9300k, 6500k or USER.
  • Page 24: Configuration For Pc Use

    PC MODE MENU OPERATION (VGA) PC SETTINGS Phase To adjust delay time of phase in order to reduce Auto Configuration of Screen the noise of picture Let you automatically configure the television 1) Press [MENU] to enter menu to be used as a computer monitor 2) Press [>] to select PC settings 1) Press [MENU] to enter menu 3) Press [\/] 4 times to select Phase...
  • Page 25: Wall Mounting

    WALL MOUNTING IMPORTANT— BEFORE 15/4 Instructions DRILLING ANY HOLES IN THE To remove the stand WALL ENSURE YOU ARE NOT DRILLING WHERE THERE 1) Remove the two highlighted COULD BE ANY ELECTRIC WIRES, WATER OR GAS PIPES THIS TV REQUIRES A VESA...
  • Page 26: Using With Sky Digital (B Sky B)

    USING WITH SKY DIGITAL You may wish to use your TV with a Sky Digital or universal Remote Control. Manually tune until you locate the Sky channel. If it stops press [>] There are a number of connection options, again and search will continue. (Often, the the best being connecting via SCART required is 847.25 mhz, depending on cable.
  • Page 27: Frequently Asked Questions

    1) Ensure that the RF cable is connected to DVB RF In Question: I have a 15/4 and I am trying 2) Check you are in an area that can to tilt the TV on the stand. How do I do this? receive Freeview.
  • Page 28: Technical Specification

    TECHNICAL SPECIFICATIONS 15/4 Type Horizontal frequency: 20-70KHz PC-RGB Vertical frequency: 60Hz 75 ohm Antenna / PAL-SECAM Input signal 1 AV/Composite RCA, 1 S-Video Video 1 SCART Audio 1 pair 3.5mm Phone Jack for PC, 1 pair RCA for AV/S 3,5” jack audio in...
  • Page 29: Warranty - Helpline Information

    WARRANTY / SERVICE SUPPORT Warranty / Service support This television has a 12 month return to manufacturer warranty. Your warranty starts from Date of Purchase. In the event that your TV requires to be repaired, we may replace the item at our discretion if we believe the item is uneconomical to be repaired or if we feel a permanent repair is not possible.
  • Page 30: Index

    Teletext Delete channels - DVB mode Delete channels - TV mode Tuning in Analogue TV Stations Electronic Program Guide (EPG) Tuning in Digital / Freeview TV Stations TV Buttons 6 - 7 Favourite list Universal Remote controls Fine Tuning - TV mode...
  • Page 32 M15/MAN/0001 M15/4/6 - Version 1 Manual...
