MWR C1004 Product Overview

Stand Alone 4/8/16 CH Network triplex DVR

1.1 Product overview

This recorder is a kind of digital surveillance product designed for the security area. It adapts
embedded processor and operation system. What else, many kinds of the latest technologies in IT
area are benefit to our product: H.264, video/ audio compression, a large HDD recording, and
TCP/IP network technology. It can be used in safety and protection of bank, telecommunication,
electric power, justice, traffic, district, factory, storehouse, resource, water conservancy facilities and
other fields or parts.
1.2. Product Functions/ Features
High speed embedded CPU and real time embedded control operation system are
adapted with the product, it provide operation stability, no hang-up error, more reliability
and easy for maintain
Operation with front panel and remote control, menu language also available for
English/ Chinese (Simplified), security with double password lock. System
management require for authority code in order to provide safety system
Using with hardware H.264 encode to provide better streaming quality, it also support
CIF resolution, as well as adjustable frame rate and provide space efficiency with
compact video size
Storage used with FAT32 format, suitable for 1/2 SATA hard drive connections, there
are 3 types of store method can use in here: individual, compound and mixed
Provide multi-channels operation, such as:
1/2 channels alarm output with programmable setting, relating PTZ.
4/8/16 channels alarm input with programmable setting
With kinds of surveillance display screen (1/4/9/16 windows per screen) and each
individual display screen with audio surveillance function
4/8/16 channels video input capture
2 channels video output
1 channel VGA output(Option)
4/8/16 channels audio input
1 channels audio output
1
C1004 Embedded DVR
