11.Looping recording:

There are four video clip lengths available for looping recording,
they are 1 minute, 3 minutes, 5 minutes and 10 minutes, the
default is OFF, you can set it by following these steps:
Please find the "VideoClipTime=1 ;Video clip time, 0: Off loop
record, 1:1min, 2:3min 3:5min, 4:10min [Min:0, Max:4] " on the
"usercfg" file, for example, if you need 3 munite clip, please fill in
the digit "2" to the "VideoClipTime=" and save it. To disable this
function, please fill in 0.

12.Video- OUT:

1)Plug VW898 to TV set via the supplied AV cable, when the TV
set is in AV mode, it enters into webcam mode automatically,
press the MODE button to change between video playback mode
and webcam mode.
2) To play back the recorded video, briefly press the ON/OFF
button to select video, then press the SHUTTER button to start
playing.
3) To pause or continue playing, please press the SHUTTER button,
press the ON/OFF button briefly to play it at the speed of 2 times
or 4 time or 8 times.
4) To press the MODE button to quit playing and turn back to the
front page.
5) To power off VW898 to quit the Video-Out function.
6) The supported AV system is NTSC/PAL(defaut)

13.Reset

To reset VW898,please get a small pin to press the RESET button
when VW898 gets halted.
Sensor
Effective Sensor
Storage
Sensitivity
Lens

Technical Parameters:

1/2.7"CMOS
1920*1080
Micro SD Card above class 4 upto 32GB
1080P 30fps(100M/minute)
720P 60fps(80M/minute)
720P30fps(60M/minute)
Auto
6G+IR 135°wide angle
