- Page 1 REN/PLUS Versión: 3.0 Instruction manual More information go to www.rilo.com.ar/products...
-
Page 2: Note To The Installer
Instruction manual Welcome to RILO NOTE TO THE INSTALLER: READ CAREFULLY. The worksurface should have the apropiate size to place both the coffee machine and grinder. It should also have enough space underneath the worksurface to acom- modate the pump – in case that is is not a built-in pump- comfortably, the dechlori- nating filter or water softener and the and the knock boxes. - Page 3 C: MACHINE HEIGHT: 480mm (48cm) D: ROOM FOR GRINDER: 300mm (30cm) E: MAXIMUM HEIGHT OF THE WORKSPACE: 950mm (95cm) F: MINIMUM HEIGHT OF THE WORKSPACE: 850mm (85cm) REN PLUS MACHINE A: MACHINE WIDTH : 2 gr. 670mm (67cm) 3 gr. 810mm (81cm)
-
Page 4: Installation
Instruction manual Welcome to RILO INSTALLATION A. WATER DRAINING A lead or plastic pipe of 1½” at least, should be attached to a ½” hose coming from the drain box of the machine. B. WATER SUPPLY It Should end with a water valve with a screw top or a thread of ½”.If the machine has a built-in pump connect to the valve an 8 mm rubber hose.In case the engine should... - Page 5 It might happen unexpectedly or for any reason, that your water supply service is in- terrupted, what would affect the normal functioning of your RILO coffee machine. In order to avoid that certain components suffer serious damages, your RILO ma- chine has been equiped with the innovative BA-3 system...
- Page 6 Instruction manual Welcome to RILO The BA-3 it’s an alarm system and cut-off time control, which interrupts the the fuc- tioning of the pump and emits a sound signal when there is a lack of the water supply/ mains. This system was programed to cutt off the filling process at 90 seconds. Hence, the...
- Page 7 Instruction manual Welcome to RILO GET TO KNOW YOUR RILO COFFEE MACHINE 1. Coffee groups. 2. Coffee filter-holders 3. Boiler manomenter 4. Electropump manometer 5. Hot water tap 6. Steam wand 7. Group switch 8. Red light boiler resistance (**) 9.
- Page 8 Instruction manual Welcome to RILO SPECIAL CARE AT THE BEGINING OF THE OPERATION Verify that the water leve is always on the middle of the glass tube(12). Before start the daily operation of the machine, let hot water run through the groups (1) with the filter holders (2) on to promote the warming of the set and the rinsing of them.
- Page 9 Instruction manual Welcome to RILO INSTRUCTIONS FOR THE TECHNICIAN ON THE GAS REGULATION - PILOT + TEMPERA- + PI LOT - TEMPERATURE...
- Page 10 Instruction manual Welcome to RILO MAXIMUM TEMPERATURE CALIBRATION. 1. Cut off the electricity between the coffee machine and the main electricity sup- ply. 2. Remove the lid of the pressure switch pulling from the superior edge of the lid. 3. Connect again the machine to the main electricity supply. At this point and after some time the machine will start raising steam pressure in the boiler until it stops.
- Page 11 Instruction manual Welcome to RILO Important: The pressure switches are delivered already calibrated, nevertheless, if you want to regultae it yourself, please follow the previous steps. CALIBRATION OF THE DIFFERENTIAL OF THE SYSTEMS OF MAXIMUM IGNITION (disconnection) AND MINIMUM (re-connection) .
- Page 12 Instruction manual Welcome to RILO DESCRIPTION OF THE ELECTRIC CONNECTIONS From the electric point of view the pressure switch it’s a tri-polar interruptor –which uses only 2 poles- that allows the controlling of the connection and disconnection of the resistance that heats the boiler.
- Page 13 Instruction manual Welcome to RILO To take note: The central pole of the pressure switch it’s not connected. If the fault is verified in one of the two poles in use, you have the possibility to change the posi- tions of the wires from the faulty pole connecting them to the central pole.
- Page 14 Concordia 1178/86 (C1487DIX) Cuidad Autonoma de Buenos Aires Tel. (54 11) 46710852 (rotativas) Fax. (5411) 4636 1072 e-mail: rilo@dd.com.ar www.rilo.com.ar...
