Kenwood KS-205HT Service Manual

FRONT ,CENTER ,REAR SPEAKER SYSTEM
KS-205HT/205HT-S
SERVICE MANUAL

FRONT, CENTER, REAR SPEAKER

DISASSEMBLY FOR REPAIR

How to remove the speaker unit
1.
Remove 6 screws from rear side.
2.
Remove screws fixing the speaker unit.

SPECIFICATIONS

System
Enclosure
Loudspeaker
Nominal Impedance
Peak Input Power
Maximum Input Power
Sensitivity
Frequency Response
Dimensions
Net Weight
* Achieved when both the front speaker and subwoofer SW-05HT driven.
Note:
KENWOOD follows a policy of continuous advancements in development. For this reason specifications
may be changed without notice.
Full-range
(T07-0506-05): FRONT
(T07-0507-05): CENTER
(T07-0508-05): REAR
Dressing panel assy
(A21-3444-08):205HT
(A21-3445-08):205HT-S
Front speaker
1 way
(Magnetically shielded)
Bass-Reflex
100 mm(4") Cone type
(Full Range type)
8 Ω
-
100 W(*)
83 dB / W at 1 m(*)
100 Hz~20,000 Hz(*)
Width 128 mm(5-1/16")
Height 198 mm(7-13/16")
Depth 126 mm(4-15/16")
1.0 kg

2001-4/B51-5726-00 (Z/K)1828
Center speaker Rear speaker
1 way
(Magnetically shielded)
Bass-Reflex Bass-Reflex
100mm(4") Cone type 100 mm(4") Cone typ
(Full Range type) (Full Range type)
8 Ω
100W
60W
83 dB / W at 1 m 83 dB / W at 1 m
100 Hz~20,000 Hz 100 Hz~20,000 Hz
128 mm(5-1/16") 128 mm(5-1/16")
198 mm(7-13/16") 198 mm(7-13/16")
126 mm(4-15/16") 126 mm(4-15/16")
1.0 kg
Pan head
tapping screw
(N83-3512-45)x6
Push terminal*
(E21-)
*Refer to parts list
1 way
8 Ω
100 W
60W
0.8 kg
