Order no. 65150821 13 Part no. 2045845300 Edition A 2015

GLK

Operator's Manual

Table of Contents

Advertisement

Chapters

Table of Contents

Need help?

Need help?

Do you have a question about the 2015 GLK and is the answer not in the manual?

Questions and answers

Summary of Contents for Mercedes-Benz 2015 GLK

Page 1 Operator's Manual É2045845300(ËÍ 2045845300 Order no. 65150821 13 Part no. 2045845300 Edition A 2015...
Page 2 Several of these symbols in succes- Bluetooth ® is a registered trademark of sion indicate an instruction with sev- Further information about Mercedes-Benz Bluetooth SIG Inc. eral steps. vehicles and about Daimler AG can be found DTS is a registered trademark of DTS, Inc.
Page 3 Welcome to the world of Mercedes-Benz We urge you to read this Operator's Manual carefully and familiarize yourself with the vehicle before driving. For your own safety and a longer vehicle life, follow the instruc- tions and warning notices in this manual.
Page 5: Contents
Contents Index ............4 At a glance ........... 31 Introduction ......... 22 Safety ........... 41 Opening and closing ......77 Seats, steering wheel and mirrors ..99 Lights and windshield wipers ..115 Climate control ......... 131 Driving and parking ......147 On-board computer and displays ..
Page 6: Table Of Contents
Index Additives (engine oil) ......377 1, 2, 3 ... Air bags 115 V socket ........285 Display message ......242 12 V socket Front air bag (driver, front see Sockets passenger) ........46 360° camera Important safety notes ....44 Function/notes ......
Page 7 ..........226 Display message ......245 Audio system Bag hook ..........278 see separate operating instructions Ball coupling Authorized Mercedes-Benz Center Installing ........214 see Qualified specialist workshop Removing ........217 Authorized workshop Storing ........... 217 see Qualified specialist workshop BAS (Brake Assist System) ....
Page 8 Index Brake fluid Roof lining ........312 Seat belt ........312 Display message ......238 Seat cover ........311 Notes ..........377 Sensors ......... 309 Brake lamps Steering wheel ....... 311 Display message ......244 Tail pipes ........309 Brakes Trim pieces ........
Page 9 Index Child seat Climate control system LATCH-type (ISOFIX) child seat Automatic engine start ....153 anchors ..........64 Automatic engine switch-off ..153 Top Tether ........65 Deactivating/activating ....153 Cigarette lighter ........ 284 General information ....... 153 Important safety notes ....152 Cleaning Introduction ........
Page 10 Calling up (on-board computer) ..235 see Doors Driving systems ......251 Driving abroad Engine ..........247 Mercedes-Benz Service ....305 General notes ........ 235 Symmetrical low beam ....116 Hiding (on-board computer) ... 235 Driving lamps KEYLESS-GO ........259 see Daytime running lamps Lights ..........
Page 11 Index BAS PLUS (Brake Assist System Symmetrical low beam ....116 PLUS) ..........69 Towing a trailer ......212 EBD (electronic brake force distri- Wet road surface ......172 bution) ..........73 DVD video (on-board computer) ..227 ® (Electronic Stability Pro- gram) ..........
Page 12 Index Starting the engine with the Storing settings (memory func- SmartKey ........151 tion) ..........112 Starting with KEYLESS-GO ..... 151 Storing the parking position ..111 Switching off ........168 Tow-starting (vehicle) ..... 328 Engine electronics Filler cap Problem (malfunction) ....155 see Fuel filler flap Engine jump starting Flat tire...
Page 13 Index Fuse allocation chart (vehicle tool High-beam headlamps kit) ............314 Changing bulbs ......124 Fuses Display message ......245 Switching on/off ......119 Allocation chart ......328 Hill start assist ........152 Before changing ......328 Dashboard fuse box ....... 328 HOLD function Fuse box in the cargo compart- Deactivating ........
Page 14 Index Setting the brightness of the dis- play/switch (on-board computer) .. 231 KEYLESS-GO Standing lamps ......118 Convenience closing feature .... 93 Switching the daytime running Display message ......259 lamps on/off (on-board com- Locking ..........79 puter) ..........231 Start/Stop button ......
Page 15 Index Matte finish (cleaning instruc- Preparing the vehicle ..... 356 tions) ..........307 Raising the vehicle ......357 Removing a wheel ......358 mbrace Securing the vehicle against roll- Call priority ........291 ing away ........356 Display message ......238 Downloading destinations Operation ........
Page 16 Index Panorama roof with power tilt/ Odometer ........... 223 sliding panel Off-road system Important safety notes ....94 4MATIC .......... 185 Opening/closing ......95 Opening/closing the roller sun- see Engine oil blind ..........96 On-board computer Problem (malfunction) ..... 96 Assistance menu ......
Page 17 Index Rear window defroster ® PRE-SAFE (anticipatory occupant Problem (malfunction) ....143 protection) Switching on/off ......142 Display message ......238 Rear window wiper Operation ......... 54 Replacing the wiper blade ....128 ® PRE-SAFE Brake Switching on/off ......127 Activating/deactivating ....
Page 18 Index Route guidance (navigation) .... 225 Service Center see Qualified specialist workshop Service menu (on-board com- puter) ..........230 Safety Service products Child restraint systems ....61 Brake fluid ........377 Occupant Classification System Coolant (engine) ......378 (OCS) ..........49 DEF special additives .....
Page 19 Index Snow chains ........335 Steering wheel paddle shifters ..160 Sockets Stowage areas ........275 Center console ......285 Stowage compartments General notes ........ 284 Armrest (under) ......275 Rear compartment ......285 Cup holders ........282 Spare wheel Glove box ........
Page 20 Index Information ........372 Reached (TIREFIT) ......318 Tires/wheels ......... 360 Recommended ....... 336 Trailer loads ........381 Tire pressure monitor Vehicle data ........380 Checking the tire pressure elec- TELEAID tronically ........341 Call priority ........291 Function/notes ......339 Downloading destinations General notes ........
Page 21 Index Maximum loaded vehicle weight Towing a trailer (definition) ........353 Active Parking Assist ..... 193 Maximum load on a tire (defini- Cleaning the trailer tow hitch ..310 tion) ..........354 Coupling up a trailer ...... 215 Maximum permissible tire pres- Decoupling a trailer .......
Page 22 Index Trip odometer Vehicle emergency locking ....85 Calling up ........223 Vehicle identification number Resetting (on-board computer) ..224 see VIN Turn signals Vehicle identification plate ....372 Changing bulbs (front) ....124 Vehicle maintenance Display message ......244 see ASSYST PLUS Switching on/off ......
Page 23 Index Tightening torque ......359 Wheel size/tire size ....... 360 Window curtain air bag Display message ......240 Operation ......... 49 Windows see Side windows Windshield Defrosting ........141 Windshield washer fluid see Windshield washer system Windshield washer system ....303 Notes ..........
Page 24: Protection Of The Environment General Notes
Fuel consumption and the rate of engine, transmission, brake and tire wear are affected by these factors: Genuine Mercedes-Benz parts operating conditions of your vehicle your personal driving style Environmental note You can influence both factors. You should...
Page 25: Service And Warranty Information
This could lead to malfunctions in safety-rel- Service and vehicle operation evant systems, e.g. the brake system. Use only genuine Mercedes-Benz parts or parts of Service and literature equal quality. Only use tires, wheels and accessories that have been specifically The implied warranty for your vehicle applies approved for your vehicle.
Page 26: Maintenance
Always have the Service and Warranty Book- sonable number of repair attempts let with you when you bring the vehicle to an Mercedes-Benz USA, LLC and/or its author- authorized Mercedes-Benz Center. The ser- ized repair or service facilities fail to fix one or...
Page 27: Important Safety Notes
Delivery Program. For details, consult an carried out, this can result in malfunctions or authorized Mercedes-Benz Center or write to system failures. There is a risk of an accident. one of the following addresses.
Page 28: Declarations Of Conformity
Introduction parts of the exhaust system, they can catch When driving off road or on unpaved roads, fire. check the vehicle's underside regularly. In In such situations, have the vehicle particular, remove parts of plants or other checked and repaired immediately at a flammable materials which have become qualified specialist workshop.
Page 29: Customer Relations Department
If the problem is not resolved to ing the main inspection. your satisfaction, please discuss the problem again with a Mercedes-Benz Center or con- tact us at one of the following addresses. Qualified specialist workshop In the USA...
Page 30: Limited Warranty
The EDR in this vehicle is designed to record culpable contraventions against these such data as: instructions is not covered either by the Mercedes-Benz Limited Warranty or by the how various systems in your vehicle are New or Used-Vehicle Warranty. operating...
Page 31: Copyright
Mercedes-Benz USA, LLC ("MBUSA") expressly disclaims any and all lia- bility arising from the extraction of this infor- mation by unauthorized Mercedes-Benz per- sonnel. MBUSA will not share EDR data with others without the consent of the vehicle owners or, if the vehicle is leased, without the consent of the lessee.
Page 33 Cockpit ..........32 Instrument cluster ......33 Multifunction steering wheel ..... 35 Center console ........36 Overhead control panel ...... 38 Door control panel ......39...
Page 34: Cockpit
Cockpit Cockpit Function Page Function Page Steering wheel paddle Adjusts the steering wheel shifters manually Combination switch Adjusts the steering wheel electrically Instrument cluster Cruise control lever Horn Parking brake PARKTRONIC warning dis- play Diagnostics connection Overhead control panel Opens the hood Operates the climate con- Releases the parking brake trol systems...
Page 35: Instrument Cluster
Instrument cluster Instrument cluster Displays and controls Function Page Function Page Fuel gage Multifunction display Coolant temperature Tachometer Speedometer with seg- ments Adjust the instrument cluster lighting using the on-board computer page 231).
Page 36: Warning And Indicator Lamps
Instrument cluster Warning and indicator lamps Function Page Function Page % Diesel engine: pre- ® ÷ ESP glow · Distance warning ? Coolant ® å ESP K High-beam head- $ Brakes (USA only) lamps J Brakes (Canada only) L Low-beam head- lamps #! Turn signals T Parking lamps...
Page 37: Multifunction Steering Wheel
Multifunction steering wheel Multifunction steering wheel Function Page Function Page Multifunction display Selects a menu Audio/COMAND display; see the separate operating Selects a submenu or instructions scrolls through lists Switches on the Voice Con- Confirms your selection trol System; see the sepa- Hides display messages rate operating instructions Back...
Page 38: Center Console
Center console Center console Center console, upper section Function Page Function Page £ Hazard warning c Seat heating lamps ¤ ECO start/stop func- ATA indicator lamp tion 45 Indicator lamp c PARKTRONIC ® å ESP Audio system/COMAND; see the separate operating instructions...
Page 39: Center Console Lower Section
Center console Center console, lower section Function Page Function Page Stowage compartment Stowage compartment with Media Interface Ashtray Cigarette lighter Audio/COMAND control- Socket ler; see the separate oper- ating instructions Cup holder...
Page 40: Overhead Control Panel
Overhead control panel Overhead control panel Function Page Function Page u Switches the rear- Rear-view mirror compartment interior light- Buttons for the garage door ing on/off opener | Switches the auto- Microphone for mbrace matic interior lighting con- (emergency call system), trol on/off telephone and the Voice p Switches the right-...
Page 41: Control Panel
Door control panel Door control panel Function Page Function Page Opens the door 7 Adjusts the exterior mirrors %& Unlocks/locks the vehicle W Opens/closes the front side windows Adjusts the seats electri- cally W Opens/closes the rear side windows r45= Stores settings for the seat, n Activates/deacti- exterior mirrors and steer-...
Page 43 Useful information ......42 Panic alarm .......... 42 Occupant safety ........42 Children in the vehicle ......61 Pets in the vehicle ......67 Driving safety systems ....... 68 Protection against theft ..... 74...
Page 44: Useful Information
Occupant safety Useful information Occupant safety Overview of occupant safety This Operator's Manual describes all models and all standard and optional equip- In this section, you will learn the most impor- ment of your vehicle available at the time of tant facts about the restraint system compo- publication of the Operator's Manual.
Page 45: Safety Guidelines
SRS warning lamp must also be checked. Only use seat belts installed or supplied by an authorized WARNING Mercedes-Benz Center. If SRS is malfunctioning, restraint system Air bags and pyrotechnic Emergency Ten- components may be triggered unintentionally sioning Devices (ETDs) contain perchlorate...
Page 46: Important Safety Notes
(driver's and front- injuries resulting from air bag deployment. passenger front air bags and driver's knee If you sell your vehicle, Mercedes-Benz bag) strongly recommends that you inform the side impacts (side impact air bags, window...
Page 47: Occupant Safety
If the driver and front passenger do not wear Mercedes-Benz Center. their seat belts, it is not possible for the air do not lean your head or chest close to the bags to provide their supplemental protec- steering wheel or dashboard.
Page 48 Occupant safety In the event of other types of impacts and They are deployed: impacts below air bag deployment thresh- at the start of an accident with a high rate of olds, the air bags will not deploy. The driver vehicle acceleration or deceleration in a and passenger will then be protected to the longitudinal direction...
Page 49: Knee Bag
You should only use seat covers that have been approved for the respective seat by the PASSENGER AIR BAG OFF indicator Mercedes-Benz. lamp on the center console is not lit page 49) WARNING the air bag control unit predicts a high-...
Page 50: Pelvis Air Bag
Mercedes-Benz. lateral vehicle deceleration or acceleration, e.g. in a side impact Pelvis air bag deployment enhances the level...
Page 51: Tor Lamp
Occupant safety mines that deployment can offer additional if the vehicle rolls over and the system protection to that provided by the seat belt. determines that window curtain air bag deployment can offer additional protection Pelvis air bags : will not deploy in side to that provided by the seat belt impacts which do not exceed the system's preset deployment thresholds for lateral...
Page 52 6 seconds when the engine is mends that you only use seat accessories started and then, depending on occupant that have been approved by Mercedes-Benz. weight sensor readings from the front- Both the driver and the front passenger passenger seat, remain illuminated or go out.
Page 53 Occupant safety toddler restraint, or booster seat recommen- make sure that the 45 indicator ded for the size and weight of the child. lamp is illuminated. If the 45 indi- cator lamp goes out or remains out, do not The infant or child restraint must be properly transport a child on the front-passenger secured with the vehicle's seat belt, the seat seat until the system has been repaired.
Page 54: System Self-Test
You soon as possible. Contact an authorized must contact an authorized Mercedes-Benz Mercedes-Benz Center. Center before seating any child on the front Only have the seat repaired or replaced at an passenger seat.
Page 55 Occupant safety Problems with the Occupant Classification System Problem Possible causes/consequences and M M Solutions The PASSENGER AIR The OCS is malfunctioning. BAG OFF indicator Make sure that the front passenger is sitting in a correct, upright lights up and remains position.
Page 56 Occupant safety WARNING If the 45 indicator lamp does not illuminate or remains out with the weight of a typical 12- month-old child in a standard child restraint or less, or is unoccupied, on the front-passenger seat, do not transport a child on the front-passenger seat until the system has been repaired. If you are driving faster than approximately ®...
Page 57 Firmly push the NECK-PRO head restraint forward and can no longer be adjusted. cushion back in the direction of arrow = Mercedes-Benz recommends that you have until the cushion engages. the NECK-PRO head restraints/NECK-PRO Repeat this procedure for the second luxury head restraints checked at a qualified NECK-PRO head restraint.
Page 58 Canadian provinces shop. Even where this is not required by law, all vehicle occupants should correctly fasten Only use seat belts that have been approved their seat belts before starting the journey. for your vehicle by Mercedes-Benz. Any such...
Page 59 Occupant safety modifications could invalidate the vehicle's Never wear the shoulder belt under your general operating permit. arm, across your neck or off your shoulder. The use of seat belts and child restraint sys- In a frontal crash, your body would move tems is required by law in: too far forward.
Page 60: Fastening
Occupant safety Never place your feet on the instrument panel, dashboard, or on the seat. Always keep both feet on the floor in front of the seat. When using a seat belt to secure infant restraints, toddler restraints, or children in booster seats, always follow the child seat manufacturer's instructions.
Page 61: Releasing
Occupant safety Seat belt adjustment Slide the belt sash guide downwards. Release belt sash guide release : and The seat-belt adjustment function adjusts the make sure that the belt sash guide has driver's and front-passenger seat belt to the engaged. upper body of the occupants.
Page 62: Function
Occupant safety Belt warning for the driver and front For more information on the 7 seat passenger belt warning lamp, see "Warning and indi- cator lamps in the instrument cluster, seat Regardless of whether the driver's and front- belts" ( page 261).
Page 63: Children In The Vehicle
Important safety notes the front-passenger side Mercedes-Benz recommends that you always The ETDs on the outside seats in the rear properly secure all infants and children with a compartment are triggered independently of child or infant seat restraint system for the the lock status of the seat belts.
Page 64 Children in the vehicle possible. Regardless of seating position, chil- that you always place a child in a rear-facing dren 12 years old and under must be seated child restraint in a backseat. and properly secured in an appropriate infant If you must install a rear-facing child restraint, toddler restraint, or booster seat restraint on the front passenger seat...
Page 65 Children in the vehicle designed for them. Only replace damaged not properly secured in the vehicle and/or the covers with genuine covers. child is not properly secured in the child restraint. WARNING Children that are too large for a child restraint If the child restraint system is installed incor- must travel in seats using normal seat belts.
Page 66: Special Seat Belt Retractor
Children in the vehicle Activating the special seat belt retractor: WARNING Pull the seat belt out fully and let the seat If the child restraint system is subjected to belt retractor retract it again. direct sunlight, parts may get very hot. Chil- While the seat belt is retracting, you should dren may burn themselves on these parts, particularly on the metal parts of the child...
Page 67: Top Tether
Children in the vehicle Top Tether Install the child restraint system in accord- ance with the manufacturer's instructions. WARNING Attach the child restraint system to both If the rear seat backrests are not locked, they securing rings. could fold forwards in the event of an acci- An incorrectly installed child restraint system dent, heavy braking or sudden changes of could come loose during an accident and seri-...
Page 68: Child-Proof Locks Important Safety Notes
Children in the vehicle Child-proof locks Important safety notes WARNING If children are traveling in the vehicle, they could: open doors, thus endangering other people or road users exit the vehicle and be caught by oncoming traffic Move head restraint : upwards. operate vehicle equipment and become Install the LATCH-type (ISOFIX) child trapped...
Page 69: Pets In The Vehicle
Pets in the vehicle Override feature for the rear side win- WARNING dows If the child restraint system is subjected to direct sunlight, parts may get very hot. Chil- dren may burn themselves on these parts, particularly on the metal parts of the child restraint system.
Page 70: Important Safety Notes
Driving safety systems Driving safety systems ABS (Anti-lock Braking System) Overview of driving safety systems General information In this section, you will find information about ABS regulates brake pressure in such a way the following driving safety systems: that the wheels do not lock when you brake. This allows you to continue steering the vehi- ABS (Anti-lock Braking System) cle when braking.
Page 71: Driving Safety Systems
Driving safety systems The pulsating brake pedal can be an indica- With the help of the radar sensor system, BAS tion of hazardous road conditions, and func- PLUS can detect obstacles that are in the tions as a reminder to take extra care while path of your vehicle for an extended period of driving.
Page 72: Ets/4Ets (Electronic Traction System)
Driving safety systems Recognition by the radar sensor system is ® tection measures (PRE-SAFE ) are activa- also impaired in the event of: ted simultaneously. there is dirt on the sensors or anything else Keep the brake pedal depressed until the covering the sensors emergency braking situation is over.
Page 73: Deactivating/Activating
Driving safety systems Important safety notes ® Characteristics of ESP Observe the "Important safety notes" sec- General information tion ( page 68). If the ÷ ESP warning lamp goes out before WARNING ® beginning the journey, ESP is automatically active. ®...
Page 74: Trailer Stabilization
Driving safety systems The spinning of the wheels results in a cut- ® It may be best to deactivate ESP in the fol- ting action for better traction on loose sur- lowing situations: faces. when using snow chains traction control is still activated. in deep snow ®...
Page 75: Pre-Safe ® Brake
Driving safety systems ® EBD (electronic brake force distribu- well as by automatic braking. PRE-SAFE tion) Brake cannot prevent a collision without your intervention. General information Important safety notes EBD monitors and controls the brake pres- sure on the rear wheels to improve driving WARNING stability while braking.
Page 76: Immobilizer
Protection against theft In the event of snowfall or heavy rain, the rec- ognition can be impaired. the vehicle speed is between approx- Recognition by the radar sensor system is imately 4 mph (7 km/h) and 124 mph also impaired in the event of: (200 km/h) At speeds of up to approximately 40 mph there is dirt on the sensors or anything else...
Page 77: Protection Against Theft
In the event that the engine cannot be star- ted (yet the vehicle's battery is charged), the system is not operational. Contact an authorized Mercedes-Benz Center or call 1-800-FOR-MERCedes (in the USA) or To arm: lock the vehicle with the SmartKey 1-800-387-0100 (in Canada).
