KÖNIG PC TO TV CONVERTER
(s. 20)
CONVERTISSEUR KÖNIG PC VERS TV
(p. 38)
CONVERSOR KÖNIG DE PC A TV
(p. 56)
KÖNIG PC-TV ÁTALAKÍTÓ
(s. 74)
KÖNIG PC- TILL TV-OMVANDLARE
(p. 92)
CONVERTOR KÖNIG PC LA TV
CMP-TELVIEW2
(s. 11)
KÖNIG-PC-ZU-TV-KONVERTER
(p. 29)
KÖNIG PC NAAR TV OMZETTER
(p. 47)
CONVERSOR KÖNIG DE PC A TV
(s. 65)
KÖNIG PC - TV MUUNNIN
(s. 83)
PŘEVODNÍK PC DO TV, KÖNIG
Advertisement
Summary of Contents for Konig CMP-TELVIEW2
- Page 1 CMP-TELVIEW2 (p. 2) (s. 11) KÖNIG PC TO TV CONVERTER KÖNIG-PC-ZU-TV-KONVERTER (s. 20) (p. 29) CONVERTISSEUR KÖNIG PC VERS TV KÖNIG PC NAAR TV OMZETTER (p. 38) (p. 47) CONVERSOR KÖNIG DE PC A TV CONVERSOR KÖNIG DE PC A TV (p.
- Page 2 1. Introduction The KÖNIG PC to TV converter provides automatic conversion of PC desktop images to high quality video images for standard television viewing. Support Mode and Resolution IPC Compatible Apple MAC G4,G4 Apple iMac, iMac DV VGA mode Cubic,G3 Resolution Vertical frequency (Hz) 640x480...
- Page 3 System Requirements a. IBM PC Compatible or notebook or Apple MAC. b. Supports NTSC or PAL video standard TV or VCR. c. Provides composite video output, S-Video output, and Y.Cb.Cr terminal output 2. Package Contents a. Remote control. b. User’s Manual. c.
-
Page 4: Hardware Connection
3. Hardware Connection PROJECT HDTV Progressive TV Plasma TV Y.Cb.Cr IN Video IN S-Video IN USB Power cable Connect to PC VGA DC IN S-Video IN Video Out Connect to PC or TV Y Cable Y.Cb.Cr OUT Connect to LCD or CRT Monitor Remote Control... - Page 5 HDTV Connection a. Connect to Standard TV Input Y.Cb.Cr output to TV (15.75KHz) b. Connect to HDTV Input Y.Cb.Cr output to TV (15.75KHz) HDTV/Plasma TV Deinterlace to 31.5KHz 4. Function 4.1 Input/Output ZOOM MENU NTSC/PAL POWER RESET U/Cb V/Cr UP, DOWN, LEFT, RIGHT Y.Vb.Cr/RGB/CVBS SCAN CNVTR S-VIDEO...
- Page 6 Connections a. SCAN CNVTR: VGA signal input/output. Connect to the Y cable. b. RGB OUT: Output RGB signal. c. S-VIDEO OUT: Output S-VIDEO signal connects to TV or VCR. d. VIDEO OUT: Output VIDEO signal, connects to TV or VCR. e.
- Page 7 4.3 Remote Control a. POWER: Power switch. b. RESET: Resets all functions to factory standard settings. c. N/P: NTSC/PAL button switches between different TV Standards. d. ZOOM: Switches on-screen video from normal to 2x zoom. e. M: Displays the OSD menu on screen. Main menu controls: H-SIZE, V-SIZE, FREEZE, BRIGHTNESS, CONTRAST, HUE, SATURATION, FLICKER, OSD BACKGROUND, RESET.
- Page 8 4.4 OSD MENU 1. H-SIZE: Adjusts the horizontal size of on-screen video. 2. V-HIZE: Adjust the vertical size of on-screen video. 3. FREEZE: Freezes current TV screen. 4. BRIGHTNESS: Adjusts the video brightness 64 degrees. (Default value is 32). 5. CONTRAST: Adjusts the video contrast 64 degrees. (Default value is 32). 6.
- Page 9 Nedis B.V. De Tweeling 28 5215MC ’s-Hertogenbosch The Netherlands Tel.: 0031 73 599 1055 Email: info@nedis.com Declare that product: Name: KÖNIG CMP-TELVIEW2 Model: CMP-TELVIEW2 Description: PC TO TV CONVERTER Is in conformity with the following standards EMC: EN55022:1998+A1:2000+A2:2003 Class B EN55024:1998+A1:2001+A2:2003 Following the provisions of the EMC Directive 89/336/EEC.
- Page 10 Safety precautions: To reduce risk of electric shock, this product should ONLY be CAUTION opened by an authorized technician when service is required. RISK OF ELECTRIC SHOCK DO NOT OPEN Disconnect the product from mains and other equipment if a problem should occur.
