BAY-38HV
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
Printed in U.S.A. Copyright 2001,
Heat-N-Glo, a division of Hearth Technologies Inc.
20802 Kensington Boulevard, Lakeville, MN 55044
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
GUIDE
WARNING: IMPROPER INSTALLA-
TION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAM-
AGE. REFER TO THIS MANUAL. FOR
ASSISTANCE OR ADDITIONAL INFOR-
MATION CONSULT A QUALIFIED IN-
STALLER, SERVICE AGENCY, OR THE
GAS SUPPLIER.
1. This appliance may be installed in an af-
termarket, permanently located, manufac-
tured (mobile) home, where not prohibited
by local codes.
2. This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
Please contact your Heat-N-Glo dealer for any
questions or concerns. For the number of your
nearest Heat-N-Glo dealer, please call 952-985-6000.
1
Installers Guide
Underwriters
Laboratories Listed
INSTALLERS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAY-38HV and is the answer not in the manual?

Questions and answers

Summary of Contents for Heat & Glo BAY-38HV

  • Page 1 Model: Installers Guide BAY-38HV Underwriters Laboratories Listed INSTALLERS WARNING: IF THE INFORMATION GUIDE IN THESE INSTRUCTIONS IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUS- WARNING: IMPROPER INSTALLA- ING PROPERTY DAMAGE, PER- TION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN SONAL INJURY, OR DEATH.
  • Page 2: Safety And Warning Information

    SAFETY AND WARNING INFORMATION READ and UNDERSTAND all instructions carefully These units MUST use one of the vent systems before starting the installation. FAILURE TO FOLLOW described in the Installing the Fireplace section of the these installation instructions may result in a possible Installers Guide.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Safety and Warning Information ..........2 Service Parts Lists ..............4 Section 1: Approvals and Codes ..........6 Appliance Certification..............6 Installation Codes ................6 High Altitude Installations ............... 6 Section 2: Getting Started ............7 Introducing the Heat-N-Glo Gas Fireplaces ........7 Pre-installation Preparation ............
  • Page 4: Section 1: Approvals And Codes

    Approvals and Codes High Altitude Installations Appliance Certification Installers Guide Certification Installation Codes Heat-N-Glo Quality Systems registered by SGS ICS...
  • Page 5: Section 2: Getting Started

    Getting Started Introducing the Heat-N-Glo Gas Fireplaces Installers Guide Pre-install Preparation Installers Guide...
  • Page 6 16 7/8 (429mm) Ø6 5/8 (168mm) 35 1/8 38 3/4 34 5/8 (892mm) (983mm) 29 1/8 (880mm) (739mm) 20 7/8 31 1/8 (790mm) (530mm) 33 3/4 (858mm) 24 15/16 (634mm) TOP STANDOFFS VENT COLLAR VENT COLLAR GRILL GLASS DOOR BOTTOM GRILL ELECTRICAL ACCESS...
  • Page 7: Section 3: Installing The Fireplace

    Installing the Fireplace 36” 36” Constructing the Chase 36” CAUTION: TREATMENT OF FIRESTOP SPACERS AND CONSTRUCTION OF THE CHASE MAY VARY WITH THE TYPE OF BUILDING. THESE INSTRUCTIONS ARE NOT SUBSTITUTES FOR THE REQUIREMENTS OF LOCAL BUILDING CODES. THEREFORE, YOUR LOCAL BUILD- ING CODES MUST BE CHECKED TO DETERMINE THE REQUIREMENTS FOR THESE STEPS.
  • Page 8: Step 2 Framing The Fireplace

    Step 2. Framing the Fireplace Vertical Vent Runs 1” (25mm) PIPE CLEARANCE CAUTION: MEASURE FIREPLACE DIMENSIONS AND VERIFY FRAMING METHODS AND WALL COVERING DETAILS BEFORE FRAMING. Shows center of 10” x 10” vent framing hole. The center of the hole is one inch (25.4mm) above the center of the hori- zontal vent pipe.
  • Page 9 6 1/2 6 3/8 9 1/4 6 1/2 9 5/8 6 3/8 6 5/8 SL-45D 6 5/8 9 5/8 SL-90D 17-24 6 1/2 11 3/4 5 3/4 6 5/8 SL-17/24D (SL17-24D) SL-12D SL-06D 47 3/4 35 3/4 23 3/4 12-17 8 3/4 SL-09D SL-12/17D (SL12-17D)
  • Page 10: Step 3 Installing The Vent System

    VERTICAL TERMINATION STORM COLLAR ROOF FLASHING HORIZONTAL TERMINATION HORIZONTAL PIPE SUPPORT Termination Kits PIPE LENGTH WALL FIRESTOP WALL BRACKET CEILING SLK-01D FIRESTOP 90 DEGREE SLK-TVCD ELBOW PVK-80 SLK-01TRD Step 3. Installing the Vent System VERTICAL BAFFLE KIT (BAF-VERT) Installers Guide Identifying Vent Components...
  • Page 11 Max. Run 24" (610 mm)
  • Page 13 VENTING WITH TWO (2) 90° ELBOWS...
  • Page 14 VENTING WITH TWO (2) 90° ELBOWS H + H 1´ MIN. (305 mm) 2´ MAX. (610 mm) 2´ MAX. (610 mm) 2´ MIN. (610 mm) 2´ MAX. (610 mm) 4´ MAX. (1.22 m) 3´ MIN. (914 mm) 2´ MAX. (610 mm) 6´...
  • Page 15 VENTING WITH THREE (3) 90° ELBOWS H + H 1´ MIN. (305 mm) 2´ MAX. (610 mm) 2´ MAX. (610 mm) 2´ MIN. (610 mm) 2´ MAX. (610 mm) 4´ MAX. (1.22 m) 3´ MIN. (914 mm) 2´ MAX. (610 mm) 6´...
  • Page 16 VENTING WITH THREE (3) 90° ELBOWS...
  • Page 17: Installing Vent Components

    B. Installing Vent Components STARTING COLLAR STOVE SEALANT BEAD FIRST VENT COMPONENT 1 INCH (25.4mm)
  • Page 18 NOTE: Model SLK-01TRD does not need an exterior firestop on an exterior combustible wall. The firestop is built into the cap. NOTE: The center of the hole is one (1) inch (25.4mm) above the center of the horizontal vent pipe. WALL BRACKET 10"...
  • Page 19 JOIST CEILING NAILS (4 REQUIRED) CEILING FIRESTOP NOTE: Keep insulation away from the vent pipe at least 1 inch (25mm). 10" (254mm) 10" (254mm) CHIMNEY HOLE NAILS (4 REQUIRED) EXISTING CEILING JOISTS FRAMING MEMBERS CEILING RAFTER CEILING CEILING FIRESTOP...
  • Page 20: Vent Termination

    C. Vent Termination ROUND CAP TERMINATION PERFORATION CANNOT BE INSIDE THE WALL 7 1/2" (191mm) MINIMUM TRAPEZOID CAP TERMINATION 7 1/4" (184mm)
  • Page 21 openable fixed closed J or K 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS NECESSARY TO INSTALL THE VINYL PROTECTOR KIT TO THE TOP OF THE EXTERIOR FIRESTOP (FOR ALL ROUND TERMINATION CAPS).
  • Page 22 HORIZONTAL OVERHANG 2 FT. 2 FT. MIN. VERTICAL MIN. WALL LOWEST DISCHARGE OPENING TERMINATION ROOF PITCH IS X/ 12 H (MIN.) - MINIMUM HEIGHT FROM ROOF TO LOWEST DISCHARGE OPENING NOTE: This also pertains to vertical vent systems in- stalled on the outside of the building.
  • Page 23: Step 5 The Gas Control Systems

    Step 4. Positioning, Leveling, and Step 5. The Gas Control Systems Securing the Fireplace Standing Pilot Ignition Direct Spark Ignition (DSI). 3/8” 3/8” (10mm) (10mm)
  • Page 24: Step 6 The Gas Supply Line

    Step 7. Gas Pressure Requirements Step 6. The Gas Supply Line Pressure requirements for Heat-N-Glo gas fireplaces are shown in the table below. Pressure Natural Gas Propane Minimum 5.0 inches 11.0 inches Inlet Pressure w.c. w.c. Maximum Inlet 14.0 inches 14.0 inches Gas Pressure w.c.
  • Page 25: Step 8 Wiring The Fireplace

    BLACK S2 REMOTE SWITCH 3/16” PIGGYBACK CONNECTOR PIGTAIL ON/OFF WHITE T2 SWITCH GAS VALUE RED T1 THERMOPILE THERMOCOUPLE OPTIONAL WALL SWITCH, BLACK S1 THERMOSTAT OR REMOTE Step 8. Wiring the Fireplace CAUTION: DISCONNECT REMOTE CONTROLS IF AB- SENT FOR EXTENDED TIME PERIODS. THIS WILL PRE- VENT ACCIDENTAL FIREPLACE OPERATION.
  • Page 26 CAUTION: LABEL ALL WIRES PRIOR TO DISCONNEC- TION WHEN SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS OPERATION. VERIFY PROPER OPERATION AFTER SERVICING. 476-500 DSI CONTROL VALVE OPTIONAL REMOTE, WALL SWITCH (NEUTRAL) OR THERMOSTAT (ON CERTIFIED UNITS ONLY) 100-254A OPTIONAL JUNCTION 459-591...
  • Page 27: Step 9 Finishing

    Step 9. Finishing CAUTION: IF JOINTS BETWEEN THE FINISHED WALLS AND THE FIREPLACE SURROUND (TOP AND SIDES) ARE SEALED, A 300° F. MINIMUM SEALANT MATE- RIAL MUST BE USED. THESE JOINTS ARE NOT RE- QUIRED TO BE SEALED. ONLY NON-COMBUSTIBLE MATERIAL (USING 300°...
  • Page 28: Step 10 Installing Trim, Logs, And Ember Material

    Step 10. Installing Trim, Logs, and Ember Material PILOT ASSEMBLY FIRST GRATE BAR EMBER MATERIAL DO NOT PLACE EMBER MATERIAL ON FIRST INCORRECT SECTION OF PORTS EMBER PLACEMENT FROM THE PILOT TO CORRECT THE FIRST GRATE BAR. EMBER PLACEMENT MESH CLIP CAUTION: IT IS STRONGLY RECOMMENDED THAT TRIM DOORS WITH OPTIONAL MESH SCREENS BE...
  • Page 29: Glass Specifications

    GLASS SPECIFICATIONS: 30 1/8” x 20 5/8” 20 5/8” x 18 3/4” TEMPERED Step 12. Lighting the Fireplace Step 11. Before Lighting the Fireplace Installers Guide After the Installation...
  • Page 30: Section 4: Maintaining And Servicing Your Fireplace

    Maintaining and Servicing Your Fireplace Fireplace Maintenance MAKE SURE THE FLAMES ARE STEADY—NOT LIFTING OR FLOATING.
