3/8" REVERSIBLE
AIR DRILL
Specifications
Free Speed:: ....................................1,800 RPM
Chuck Capacity: ......................................... 3/8"
Air Inlet: ..............................................1/4" NPT
Min. Hose Size: ........................................ 3/8"
Avg. Air Consumption: .........................3.5 CFM
Weight: .............................................. 2.42 Lbs.
Length: ................................................... 7.76"
SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION
ACTIVITIES CONTAINS CHEMICALS KNOWN TO CAUSE CANCER, BIRTH DEFECTS OR OTHER REPRODUCTIVE
HARM. SOME EXAMPLES OF THESE CHEMICALS ARE:
• LEAD FROM LEAD-BASED PAINTS,
• CRYSTALLINE SILICA FROM BRICKS AND CEMENT AND OTHER MASONRY PRODUCTS, AND
• ARSENIC AND CHROMIUM FROM CHEMICALLY-TREATED LUMBER.
YOUR RISK FROM THESE EXPOSURES VARIES, DEPENDING ON HOW OFTEN YOU DO THIS TYPE OF WORK.
TO REDUCE YOUR EXPOSURE TO THESE CHEMICALS: WORK IN A WELL VENTILATED AREA, AND WORK
WITH APPROVED SAFETY EQUIPMENT, SUCH AS THOSE DUST MASKS THAT ARE SPECIALLY DESIGNED TO
FILTER OUT MICROSCOPIC PARTICLES.
776-9264
WARNING
1
776-9264
WARNING
ALWAYS READ
INSTRUCTIONS BEFORE
USING POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
WEAR HEARING
PROTECTION
AVOID PROLONGED
EXPOSURE TO VIBRATION
Rev. 06/16/10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Evercraft 776-9264
-
Page 1: Specifications
776-9264 3/8" REVERSIBLE AIR DRILL Specifications WARNING Free Speed:: ........1,800 RPM ALWAYS READ INSTRUCTIONS BEFORE Chuck Capacity: ......... 3/8" USING POWER TOOLS Air Inlet: ..........1/4" NPT ALWAYS WEAR SAFETY GOGGLES Min. Hose Size: ........3/8” WEAR HEARING Avg. Air Consumption: ......3.5 CFM PROTECTION Weight: .......... - Page 2 Failure to do so could result in injury. • Whip hoses can cause serious injury. Always check for damaged, frayed or loose hoses and fittings, and replace immediately. Do not use quick detach couplings at tool. 776-9264 Rev. 06/16/10...
-
Page 3: Air Supply
Place drill bit tip in punch mark. Hold drill square with work and start motor. Apply steady, even pressure. Do not force. Too much pressure can cause bit to break or overheat. Too little pressure will keep bit from cutting and cause it to overheat. Reduce pressure just before bit cuts through the work. When bit has penetrated work and is spinning freely, take it from the work while the motor is 776-9264 Rev. 06/16/10... - Page 4 776-9264 - Parts List and Drawing Ref. No. Part No. Description Qty. Ref. No. Part No. Description Qty. Housing End Plate O-Ring Rotor O-Ring Rotor Blades O-Ring Cylinder Valve Bushing Front Plate O-Ring Washer Reverse Valve RS926425 Planet Gear Spring...
-
Page 5: Troubleshooting
TOOL DOESN’T RUN, RATCHET HEAD INDExES CRISPLY BY HAND— This is prob a bly caused by: dirt or sludge build-up in motor parts. YOU SHOULD: Pour a generous amount of air tool oil into air inlet. Operate throttle in short bursts. With socket engaged on bolt, alternately tighten and loosen bolt by hand. 776-9264 Rev. 06/16/10... - Page 6 CHISEL STUCk IN NOzzLE— This is prob a bly caused by: the end of the shank is misshapen. YOU SHOULD: See 90 day limited warranty. NOTE: Disassembly of this tool by other than an authorized service center WILL VOID the war r an t y on this tool. 90 DAY LImITED WARRANTY: EVERCRAFT air tools are warranted to be free from defects in material and workmanship. If any unit proves to be defective in material or workmanship within 90 days from the original date of purchase, it will be replaced free of charge. In the unlikely event a replacement is required, return the unit to the place of purchase for a free replacement. To obtain service after the 90-day limited warranty, please visit www.toolwarrantyrepair.com for a complete list of authorized air tool centers. Any...
-
Page 7: Especificaciones
776-9264 TALADRO NEUMÁTICO REVERSIBLE 3/8" ADVERTENCIA Especificaciones Velocidad sin libre: ......1,800 RPM LEA SIEMPRE LAS INSTRUCCIONES ANTES DE Capacidad del mandril: ......3/8" USAR HERRAMIENTAS NEUMÁTICAS. Entrada de aire: ........1/4" NPT USE SIEMPRE GAFAS DE SEGURIDAD. Tamaño mín. de manguera: ...... 3/8"... - Page 8 • Las mangueras que azotan pueden causar lesiones graves. Verifique siempre para detectar mangueras gastadas, usadas o flojas y reemplacel as inmediatamente. No utilice los acoplamientos de conexión rápida con esta herramienta. Vea las instrucciones para conocer el modo de instalación adecuado. 776-9264 Rev. 06/16/10...
-
Page 9: Instrucciones De Operación
Ubique el centro de un agujero nuevo al usar un punzón de centro. Coloque la punta de la broca del taladro en el marco del punzón. Sostenga el taladro emparejado con el trabajo y prenda el motor. Aplique una presión uniforme y firme. No lo fuerce. 776-9264 Rev. 06/16/10... -
Page 10: Problemas Y Soluciones
LA HERRAmIRENTA NO SE APAGA: La causa probable: Un anillo “O” de la válvula de aceleración está gastado, fuera de su posición o el eje de la válvula de aceleración está doblado o atascado con partículas de suciedad. 776-9264 Rev. 06/16/10... - Page 11 15 cm y un diámetro de 3 mm dentro de la boquilla y golpee ligeramente para aflojar el émbolo hacia atrás. Vuelva a conectar el abastecimiento del aire y repita las etapas anteriores. 776-9264 Rev. 06/16/10...
- Page 12 NOTA: Desensamblado de esta herramienta que se haga por otro, que no sea un centro autorizado de servicio INVaLIdaRÁ la garatía para esta herramienta. GARANTÍA LImITADA DE 90 DÍAS: Las herramientas neumáticas de EVERCRAFT son garantizadas contra defectos en cuanto a material y mano de obra se refiere. Si cualquier unidad demuestra ser defectuosa en cuanto al material o mano de obra, a partir de los primeros 90 días posteriores a la fecha...
-
Page 13: Spécifications
776-9264 PERCEUSE PNEUMATIQUE RÉVERSIBLE DE 3/8 PO Spécifications AVERTISSEMENT TOUJOURS LIRE LES Vitesse max: ......... 1 800 tr/min DIRECTIVES AVANT L’UTILISATION D’OUTILS Taille du mandrin : ........3/8 po ÉLECTRIQUES TOUJOURS PORTER DES Entrée d'air ........NPT 1/4 po LUNETTES DE SÉCURITÉ... - Page 14 • Évitez de forcer l’outil en l’utilisant au-delà de sa source d’alimentation. Une négligence sur ce plan pourrait puissance nominale. causer des blessures. Les tuyaux souples peuvent causer de graves blessures • N’enlevez aucune étiquette. Remplacez toute étiquette • abîmée. Les tuyaux souples peuvent causer de graves blessures. Vérifiez toujours les boyaux et les raccords et remplacez-les 776-9264 Rev. 06/16/10...
-
Page 15: Alimentation En Air
à base d’huile ou un mélange similaire de la manguera en la conexión más cercana del SAE no 10 et de kérosène. abastecimiento del aire; después, haga funcionar la herramienta. Una sobrecarga provocará una reducción de la potencia de la herramienta. 776-9264 Rev. 06/16/10... -
Page 16: Diagnostic De Pannes
L’OUTIL N’ARRêTE PAS DE FONCTIONNER. Ce problème est probablement causé par le bris ou la mauvaise position du joint torique du registre d’air, ou par le gauchissement ou le coincement de la tige du registre d’air en raison de particules de saleté. 776-9264 Rev. 06/16/10... - Page 17 90 jours. mARTEAUx PNEUmATIQUES L’OUTIL NE FONCTIONNE PAS — Ce problème est probablement causé par l’obstruction de la valve à fonctionnement cyclique ou du registre en raison d’une accumulation de saleté ou de boue. 776-9264 Rev. 06/16/10...
- Page 18 REMARQUE: Le démontage de cet outil par une partie autre qu’un centre de réparation autorisé aura pour effet d’annuler la garantie. GARANTIE LImITéE DE 90 JOURS : Les outils pneumatiques EVERCRAFT sont garantis contre les défauts de matériel ou de fabrication. Toute unité présentant un défaut de matériel ou de fabrication dans les 90 jours suivant l’achat initial sera remplacée gratuitement.
