  • Page 2 4Ch H.264 hardware codec - Network DVR Installation & Safeguards INSTALLATION & SAFEGUARDS All the safety and operating instructions should be read before the unit is operated. Environment Condition for Installation 1. To prevent electric shock or other hazard, do not expose units to rain, moisture, or dust. 2.

  • Page 3: Table Of Contents

    4Ch H.264 hardware codec - Network DVR Contents Contents CHAP. 1 Features & Package Contents ---------------------------------------------------------------- 1-1. Features ---------------------------------------------------------------- 1-2. Package Contents ---------------------------------------------------------------- CHAP. 2 Function of Each Button ---------------------------------------------------------------- 2-1. Front ---------------------------------------------------------------- 2-2. Rear ---------------------------------------------------------------- CHAP. 3 Installation ---------------------------------------------------------------- 3-1.
  • Page 4 4Ch H.264 hardware codec - Network DVR Contents Contents 5-3. Record ---------------------------------------------------------------- Record Setup ---------------------------------------------------------------- Schedule Setup ---------------------------------------------------------------- 5-4. Configuration ---------------------------------------------------------------- HDD Management ---------------------------------------------------------------- Time/Date Setup ---------------------------------------------------------------- Camera Setup ---------------------------------------------------------------- Motion Setup ---------------------------------------------------------------- Interval Setup ---------------------------------------------------------------- Alarm Setup ---------------------------------------------------------------- Password Setup ---------------------------------------------------------------- Buzzer Setup ----------------------------------------------------------------...

  • Page 5: Chap. 1 Features & Package Contents

    4Ch H.264 hardware codec - Network DVR CHAP 1. Features & Package Contents CHAP 1. Features & Package Contents 1-1. Features Live Display Real time display per camera Auto Sequence PIP (Picture in picture) Digital Zoom of display (2X ZOOM) Freeze Simple playback mode Simple PTZ camera control...

  • Page 6: Package Contents

    4Ch H.264 hardware codec - Network DVR CHAP 1. Features & Package Contents 1-2. Package Contents NETWORK DVR POWER HDD ACTIVE 2. Remote Controller 1. DVR Main Unit 3. Power Cable 6. Software CD 4. Power Adapter 5. User’s Manual 7.

  • Page 7: Chap. 2 Function Of Each Button

    4Ch H.264 hardware codec - Network DVR CHAP 2. Function of Each Button CHAP 2. Function of Each Button 2-1. Front Name Function ① USB HOST Used for Data Backup and Firmware Update (Only USB memory stick should be used.) ②...

  • Page 8: Rear

    4Ch H.264 hardware codec - Network DVR CHAP 2. Parts name & functions 2-2. Rear FUNCTION RS 485 D- RS 485 D+ CH 1 MONITOR RELAY COM CAUTION RELAY NC AUDIO RISK O F ELECTRIC RELAY NO SHO CK . DO NO T O PEN ! RLARM GND CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK.

  • Page 9: Chap.3 Installation

    4Ch H.264 hardware codec - Network DVR CHAP. 3 Installation CHAP.3 Installation 3-1. Installation configuration...

  • Page 10: Hdd (Hard Disk Drive)

    4Ch H.264 hardware codec - Network DVR CHAP. 3 Installation 3-1. Installation 1) HDD MAIN BOARD 1. Connect Main Board and HDD using SATA data cable and HDD power cable. 2. Stick the HDD absorber (included in package) on the bottom of case and then install the HDD on top of them by using the bolts (included in package).

  • Page 11: Monitor

    4Ch H.264 hardware codec - Network DVR CHAP. 3 Installation 3) Monitor Connect the video output marked MONITOR to Video-In of Main monitor. 4) Power DC over 12V adapter...

  • Page 12: Other External Device

    4Ch H.264 hardware codec - Network DVR CHAP. 3 Installation 5) Other External Device AUDIO ETHERNET RS-485 : Controls external device like PTZ camera. (Pin No.1 & No.2) RELAY Output : Relay Output (Pin No.3 & No.5). SENSOR Input : Sensor Input – Alarm Input (Pin No.6 ~ No.10). ETHERNET: Connection to LAN, WAN Audio Input: Connection to a microphone Audio Output: Connection to a speaker...

  • Page 13: Chap. 4 Operation

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-1. System Log-In GENERAL USE OF MOUSE Mouse buttons Functions Mouse Wheel Increases or decreases setup value on the Menu mode Right Decreases setup value on the Menu mode Increases setup value on the Menu mode Left Execute all of the functions (clicking icons) * Please use a mouse pad for proper operation of the mouse.
  • Page 14 4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 1) HDD Clear You can see HDD Model name, serial number, number of blocks and size of HDD. In order to clear HDD, click ‘CLEAR’ at the bottom as shown below. (1) Please refer to 4-1.
  • Page 15 4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 2) Factory Default Factory default setting initializes DVR system. (1) Please refer to 4-1. System Log in again. (2) Click ‘FACTORY DEFAULT’. Then, click ‘ENTER’. DVR LOG-IN MAIN MENU DISPLAY SETUP RECORD USER ID ADMIN...

  • Page 16: Display Configuration

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-3. Display Configuration Emergency Record & Schedule record [RED] ETHERNET connection status icon Stop Recording [GREEN] Audio On [Gray] Disconnected Connected Audio Off [Blue Green] HDD space display Network search (Possible recording days) Volume Off OVERWRITE status icon...

  • Page 17: Live View Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-4. Live View Setup 1) Full / Multiple View CHAP. 4 사용방법 Move the cursor onto [4 - split icon] in the icon bar and click it to view 4 channel division. To enlarge each channel, click 1,2,3,4 Icon.

  • Page 18: Record

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-5. Record It basically records as a setting made in Schedule Record mode except for emergency record mode. - Emergency Record Once you click this icon , it keeps recording continuously regardless of schedule setting. - Schedule Record (Continuous, Motion, Alarm and Motion/Alarm) Go to MAIN MENU->...

  • Page 19: Search

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-7. Search There are three search methods controlled by a mouse wheel button, left and right button of a mouse. When you click [SEARCH] icon , then you see a window shown as below. Select a target data by using the mouse.

  • Page 20: Ptz Camera Operation

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-8. PAN/TILT/ZOOM Camera Operation Click [PTZ] icon in the icon bar, then you can see ‘arrow’ keys & ‘+/-’ key shown below. Click these arrow keys to move a PTZ camera to each direction. By using ‘+/-’ key, you can control ZOON IN/OUT function.
  • Page 21 4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation (4) To set start time of back-up and back-up data size in MEDIA sub-menu, use the mouse (left/right/wheel button). ※ End time of back-up will be calculated automatically as per start time & date and the back-up data size you set.

  • Page 22: Chap. 5 Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup CHAP 5. Setup 5-1. General Operation Click the [MENU] icon and input user password to log in. (1) Please refer to 4-1. System Log in again. Then, click ‘ENTER’. DVR LOG-IN USER ID ADMIN USER PW...

  • Page 23: Display Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5-2. Display Setup This is setup menu for display on the screen. If you click ‘DISPLAY SET UP’, then you change setting values for display as shown below. DISPLAY SETUP VGA SETUP SCREEN DISPLAY OSD SETUP...

  • Page 24: Screen Display Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 2) Screen Display Setup SCREEN DISPLAY VERTICAL POSITION HORIZONTAL POSITION BOARDER ENABLE BOARDER COLOR GRAY DEFAULT VERTICAL POSITION : -5 ~ 5 HORIZONTAL POSITION : -31 ~ 31 BORDER ENABLE : ON/OFF BORDER COLOR : COLOR SELECT 3) OSD Setup OSD SETUP...

  • Page 25: Record

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5-3. Record This is the most important configuration of the DVR. When you select ‘RECORD SETUP’ in the main menu, you can see the window as shown below. RECORD RECORD SETUP SCHEDULE SETUP 1) Record Setup RECORD SETUP...

  • Page 26: Schedule Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 2) Schedule Setup DVR system records in Schedule Recording mode. In Schedule Recording mode, you can choose four different types of recording modes and schedule by 2 hour interval from Sunday to Saturday. Default recording mode is continuous recording.

  • Page 27: Configuration

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5-4. Configuration When you click ‘CONFIGURATION’ on the CONFIGURATION main menu, you can go to ‘CONFIGURATION’ menu as shown on the right. HDD MANAGEMENT CAMERA SETUP MOTION SETUP ALARM SETUP INTERVAL SETUP TIME/DATE SETUP PASSWORD SETUP...

  • Page 28: Time/Date Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 2) Time/Date Setup In this setup, you can select date/time of DVR TIME/DATE SETUP system and display format. You can adjust values by using the mouse wheel DATE JUN/15/2007 or left/right button of the mouse. TIME 15:41 :45 ※...

  • Page 29: Motion Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 4) Motion Setup MOTION SETUP CHANNEL SENSITIVITY DURATION SIZE ALL-DEFAULT DEFAULT MOTION SETUP: You can change values by mouse wheel and left/right button of the mouse. - SENSITIVITY: Adjust sensitivity of a movement. You can adjust level 1 ~ level 7. [DEFAULT : 6] - DURATION : Whenever motion is detected (set in Motion Recording mode), DVR records for a certain time from the point when motion is detected.

  • Page 30: Interval Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5) Interval Setup See the switching time interval for SEQ or PIP function. INTERVAL SETUP (1 sec. ~99 sec. ） SEQUENCE SCREEN :Set the sequencing switch time SEQUENCE SCREEN 01 SEC interval in live full screen.

  • Page 31: Buzzer Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 8) Buzzer Setup BUZZER SETUP KEY TONE You can select Buzzer OFF/ON on this setup menu. VIDEO LOSS ALARM ACTIVE MOTION DETECT DEFAULT 5-5. External Device Setup Please refer to 4-1. System Log in again. Click ‘EXTERNAL DEVICE’...
  • Page 32 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup (1) IP Setup : IP SETUP MAC ADDRESS 00-0A-A2-00-FD-63 Shows the network information assigned to DHCP MODE MANUAL the DVR unit. If the DHCP setup status is IP DETECT AUTOMATIC, you can set the IP port only. If the DHCP setup status is MANUAL, you IP PORT 50000...
  • Page 33 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup B. Dynamic IP Internet Cable Modem (Dynamic IP) (Server) This contrasts with a Dynamic IP address, wherein an IP address is assigned to a computer, usually by a remote server which is acting as a Dynamic Host Configuration Protocol server. IP addresses assigned using DHCP may change depending on the addresses available in the set scope.
  • Page 34 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup C. Dynamic IP of PPPoE (DSL) Router or DSL Modem Gateway (Dynamic IP) (Server) (IP Share) DVR doesn’t support DSL (PPPoE), user will need to set NETWORK with IP SHARE in order to access DVR remotely.
  • Page 35 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup If you are using a router, please setting up DMZ and Port Forwarding instructions below. [How to set DMZ] - Set DMZ as per router manual, if you want to connect a DVR by using one internet line. - Setting procedure and name of DMZ may be various from router manufacturers.
  • Page 36 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup D. Direct connect to DVR (Server) When you try to connect to DVR directly, you must use DIRECT CABLE. a. PC’s TCP/IP Setting 1. For WindowsXP/2000, Click [start] – [Control Panel] click 2.
  • Page 37 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 3. Right-button click [Local Area Connection] 4. Click [General] – [Internet Protocol (TCP/IP)] ‘Properties’...
  • Page 38 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5. IP Address Setting IP Address : AAA.BBB.CCC.DDD AAA.BBB.CCC is identical with DVR’s setting DDD with DVR’s setting is not same Subnet mask must be 255.255.255.0 Default gateway is AAA.BBB.CCC.1 AAA.BBB.CCC is identical with HUB’s Address DNS Server is different in the country and ISP Supplier.
  • Page 39 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup DDNS SETUP (2) DDNS Setup : DDNS ENABLE Please refer to CH.8 DDNS Setup DNS SERVER 192.168.063.001 INTERVAL D-00 H-00 N-20 for more information. REGISTER DDNS STATUS Refer to CH7-2 DDNS set up in DVR on page 53. IP ADDRESS IP PORT REMAIN TIME...

  • Page 40: Pan/Tilt Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 2) Pan/Tilt Setup PAN/TILT SETUP COMMAND SETUP CHANNEL COMMAND SETUP MODEL PELCO-D PTZ Camera setup SPEED SETUP PTZ ID PTZ Speed setup BAUDRATE 002400 BPS CMD DELAY 1 MSEC COMMAND PAN/TILT STOP PAN/TILT SETUP LENGTH...

  • Page 41: Firmware Upgrade

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5-6. Firmware Upgrade When it comes to firmware upgrade, you may ask your local dealer. FIRMWARE UPGRADE CURRENT VER 9046 / V 0.35_08 UPGRADE VER FW1 Version FW2 Version CHECH USB UPGRADE 5-7.

  • Page 42: Chap. 6 Irs

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS CHAP 6. IRS (Integrated Remote Station) MAIN INTERFACE Exit IRS SETUP Inputs information for IRS network connection. DVR SETUP Changes DVR setting over a network. VIEWER Enables to show live image display. SEARCH Enables to search and show recorded image display.

  • Page 43: Irs Setup

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6-1. IRS Setup MANUAL Select “Manual” to input IP address and port number manually. DDNS Select “DDNS” to use IP address and port number that you already registered in DDNS server.

  • Page 44: Dvr Setup

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6-2. DVR Setup You can change some settings of DVR listed below over a network. (Alarm, Buzzer, Interval, Record Configuration, Record Schedule, Audio) MANUAL Input IP address and port number of DVR manually. ADDRESS Input IP address of DVR manually.

  • Page 45: Viewer

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6-3. Viewer DVR connection setup : Input network information to connect. (IP / PORT / ID / PW) System information : Displays connection status and operating information. Screen display a) SCREEN DIVISION : Selects full screen mode or 4-split mode b) CHANNEL : Displays full screen for each channel.

  • Page 46: Search

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6-4. Search DVR connection setup : Input network information to connect. (IP / PORT / ID / PW) Screen display a) SCREEN DIVISION : Selects full screen mode or 4-split mode b) CHANNEL : Displays full screen for each channel.

  • Page 47: Backup

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6-5. Backup 1) To execute BACKUP, input IP Address & Port and click ‘Connect Test’ button. 2) After Connect Test is done, you can see ‘Success Connect Test!’ message. Then, click ‘lock’ button and click ‘Set Backup Time’...
  • Page 48 4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 3) Now you set ‘Start Backup Time’, ‘End Backup Time’, ‘Save File Path’, ‘File Size’ and click ‘Apply’. 4) After finishing time setting, click ‘Start Backup’ to start backup. Then, you can see the backup file on the path that you chose.

  • Page 49: Player

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6-6. Player Time display : Displays current time. Recorded data display : Displays start time & end time of recorded data. Also, displays operating status during playback. Screen display a) SCREEN DIVISION : Selects full screen mode or 4-split mode b) CHANNEL : Displays full screen for each channel.
  • Page 50 4Ch H.264 hardware codec - Network DVR CHAP 6. IRS Image EDIT Click “EDIT” to go to image edit mode. EDIT TOOL : User can adjust color tone of copied images using this buttons. - Contrast : make bright part of image brighter and dart part of image darker : To reduce light and shade, lower contrast a little.
  • Page 51 4Ch H.264 hardware codec - Network DVR CHAP 6. IRS AVI SAVE Click “AVI SAVE” to go to AVI saving mode. OPTION : Used to save data in AVI file format. - CHANNEL : Selects channel - FRAMERATE : Decides frames per second of data to be saved. - SIZE : Decides the size of data to be saved automatically.

  • Page 52: Chap. 7 Ddns Web-Server

    4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server CHAP 7. DDNS Web-server 7-1. Registering DVR for DDNS (DDNS Web-server) 1) Please access www.h264ip.com and click Register Member ID. 2) Please click ‘DVR Add’ or ‘MY DVR Register’ to register DVR. ※...
  • Page 53 4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 3) Please click confirm after inputting DVR information (DVR Name and MAC Address only). Then, Click “Confirm” button. 4) Now, DVR is listed on DDNS web server without IP and Port number. ※...

  • Page 54: Ddns Set Up In Dvr

    4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 7-2. DDNS set up in DVR * The following setting is a sample for a cable modem connected to DVR directly. 1) Go to Menu 2) Go to IP SETUP menu, if you set DHCP AUTOMATIC then it detects IP address automatically. IP SETUP MAC ADDRESS 00-0A-A2-00-00-00...
  • Page 55 4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 4) Set DDNS ON/OFF ‘ON’. IP address which is assigned from DHCP server is automatically input on DNS SERVER. DDNS SETUP DDNS ENABLE DNS SERVER 168.126.063.001 INTERVAL D-00 H-00 M-20 REGISTER DDNS STATUS REGISTER OK...
  • Page 56 4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 6) Go to your computer again after you see “SUCCESS TO REGISTER DVR INFO” and then Click ‘refresh’ button. Then, DDNS server automatically catches your DVR’s IP address and Port number.
  • Page 57 4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server ③ ④ ⑤ Click ⑥ www.h264ip.com Leave this check box empty ⑦...

  • Page 58: Web Program

    4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 7-3. Web program Some functions of IRS (Integrated Remote Station) such as Viewer, Search, Backup and Player are also available on the web. *If ActiveX control installation is required for the first time access, please click ‘Yes’. Click and input information needed for Click these icons, then it connects to DVR internet connection to DVR manually.

  • Page 59: Chap. 8 Specification

    CHAP 8. Specifications CHAP. 8 Specifications • H.264 Hardware Codec • Real time live display in all channels • Triplex ( Playback / Recording / Ethernet ) NETWORK DVR • Web monitoring POWER HDD ACTIVE • Easy control by Mouse •...

  • Page 60: Chap. 9 Remote Controller

    4Ch H.264 hardware codec - Network DVR CHAP 10. Remote Controller CHAP. 9 Remote Controller PTZ On/Off SEARCH Search Menu Menu On/Off MENU No function Select Ch. / Input number Input number 5~9,0 Control Icon On/Off FUNC Emergency Record On/Off AUDIO AUDIO Output Mute On/Off MODE...
