Page 1: Troubleshooting
Installation Operation Maintenance Troubleshooting Model: CSG24 Add-on Clamshell® Hood Star Manufacturing International 10 Sunnen Drive St. Louis, MO 63143 Part Number: 2M-W361 Phone: 800-438-5264 Fax: 314-781-2714 March 10, 2010 Rev. C WWW.LANGWORLD.COM... - Page 2 THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE. POST IN A PROMINENT LOCATION INSTRUCTIONS TO BE FOLLOWED IN THE EVENT USER SMELLS GAS.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER PAGE READ FIRST ......................... 4 EQUIPMENT DESCRIPTION..................6 UNPACKING ......................... 7 INSTALLATION ......................8 INITIAL START-UP ....................... 10 OPERATION........................11 SEQUENCE OF OPERATION ..................12 CLEANING & MAINTENANCE PROCEDURES ............13 TROUBLESHOOTING ....................14 10. PARTS LISTS........................ 16 11. -
Page 4: Read First
IMPORTANT READ FIRST IMPORTANT NOTICE: If the Clamshell® is to be attached to a griddle/ charbroiler in the field – it is recommended to complete the installation of mounting adapter before un-crating the Clamshell®. CAUTION: UNIT IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE... - Page 5 DO NOT USE YOUR HAND TO CHECK GRIDDLE/CHARBROILER TEMPERATURE. NOTICE: Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your LANG authorized service agent directory or call the factory at 1-800-438-5264, or WWW.LANGWORLD.COM for the service agent nearest you.
-
Page 6: Equipment Description
2.4 Griddle Gas and Voltage Specifications The Lang Clamshell® can be connected to any 120 Volt source. In applications where multiple clamshells are installed on the same griddle, they all need to be plugged into the same receptacle circuit. -
Page 7: Unpacking
3. UNPACKING 3.1 Receiving the Clamshell® Upon receipt, check for freight damage, both visible and concealed. Visible damage should be noted on the freight bill at the time of delivery and signed by the carrier's agent. Concealed loss or damage means loss or damage which does not become apparent until the merchandise has been unpacked. -
Page 8: Installation
1/2 an inch. NOTE: If this Clamshell® is received already mounted on a Lang griddle no further installation is required. If this Clamshell® is a separate unit proceed to section 4.3 below. - Page 9 4. INSTALLATION CONT’D 4.3 Installation Instructions Refer to the Installation instructions provided with the adapter kit, on how to connect this Clamshell® to the griddle/charbroiler. Figure 1 CSG24 CSG24 Manual Shut-off Legend: Valve ACV = Automatic Cut-off Valve A = 1” Pipe B = Reduction to 3/4”...
-
Page 10: Initial Start-Up
5. INITIAL START UP 5.1 Initial Lighting Procedure for an Clamshell® WARNING: DURING INITIAL USE, OR USE AFTER SERVICE, IF THE PILOT DOES NOT IGNITE ON FIRST TRY THE MAIN GAS VALVE MUST BE TURNED OFF FOR AT LEAST FIVE MINUTES. NOTICE: While cooking, the Clamshell®... -
Page 11: Operation
6. OPERATION 6.1 Clamshell® Operation CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM COMBUSTIBLE MATERIALS. CAUTION: KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR FALLS. NOTICE: While cooking, the Clamshell®... -
Page 12: Sequence Of Operation
7. SEQUENCE OF OPERATION 7.1 Power On • When the Clamshell® is plugged in, 115 Volts is applied to the blower motor. The Clamshell® is designed to have a constantly running blower motor. • The air switch then senses the blower motor, closes, and applies the 115 Volts to a 24 VAC transformer. •... - Page 13 8. MAINTENANCE & CLEANING WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC. CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE CLOTHING.
- Page 14 If you cannot turn a screw to the left or counter-clockwise, then do not do anything further with that screw. • If you can turn a screw to the left or counter-clockwise, then use the Lang kit, part number PS-60101-W8, provided to you at no charge to rework the screw.
-
Page 15: Troubleshooting
TROUBLESHOOTING 9.1 Symptoms What follows is a chart of Symptoms and Possible Causes to aid in diagnosing faults with the Clamshell®. Refer to the Symptoms column to locate the type of failure then to the Possible Cause for the items to be checked. - Page 16 9. TROUBLESHOOTING CONT’D 9.2 TESTS NOTICE: Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your LANG authorized service agent directory or call the factory at 1-800-807-9054, or WWW.STAR-MFG.COM For the service agent nearest you.
- Page 17 NOTE: 2H-60106-66 must be sold with Item #21 Model: CSG24 GAS 24” CLAMSHELL SK2476, Rev. -...
-
Page 18: Parts Lists
Description Application K9-60101-851 HOOD WRAP ASSY, w/DIE CAST LOGOS 2M-60301-W2 LANG CLAMSHELL LOGO K9-70603-24 AGC HOOD HANDLE ASSY COMPLETE K9-60301-43-1 SATIN CHRM-LANG DIE CAST 2K-70801-19 BUSHING HEYCO 5/8#2077 2P-51002-11 HOOD SPRING 2P-51002-05 SPRING GAS HOOD 2K-70101-50 BRAS TBE TEE 3/8CC-3/8CC-1/4CC... - Page 19 12 13 Model: CSG24 GAS 24” CLAMSHELL, FRAME ASSY SK2477, Rev. -...
-
Page 20: Parts List
October 29, 2012, Rev. - Gas Clamshell Frame Parts List Fig No Part No Description Application K9-103-702-W2 LEFT OUTER STANCHION - ASSY CSG24 K9-103-702-1 LEFT OUTER STANCHION CSG24B K9-103-701 BLOWER DUCT - SPOT 2U-30200-44 MOTOR & BLOWER ASSY FOR AGC... - Page 21 26 GRN 22 TAN 25 GRN 1 TAN 32 RED 35 GRN 4 TAN 19 BLU 18 BLK 3 TAN 10 BLK 12 YEL 2 TAN 31 WHT 9 WHT 16 BLU 15 BRN...
- Page 24 STAR INTERNATIONAL HOLDINGS INC. COMPANY Star - Holman - Lang - Wells - Bloomfield - Toastmaster 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (800) 807-9054 (314) 781-2777 Parts & Service (800) 807-9054 www.star-mfg.com...
