  • Page 1 TRACE MATE ELECTRONIC THERMOSTAT OPERATOR’S MANUAL...

  • Page 2: Table Of Contents

    TRACE MATE Contents 1 Product Overview ........................1.1 Introduction ..................................1.1 Using this Manual ................................1.1 Features and Benefits ............................... 1.1 Conventions ..................................1.1 Specifications ..................................1.2 2 Installation ..........................2.1 Unpacking the Controller ..............................2.1 Control Module .................................. 2.1 Mounting the Controller ..............................

  • Page 3: Trace Mate

    Product Overview Introduction Features and Benefits The TraceMate solid state heat tracing control is an electronic thermostat designed to maintain a single heater R e q ui re m e nts Tra c e M a te F e a ture s at a desired setpoint temperature.

  • Page 4: Specifications

    TRACE MATE Product Overview Specifications Enclosure Temperature Range Type: E5: Nema-4X steel, painted black Range: -50°C to 500°C, -58°F to 932°F Size: Single-pole: 8”Hx6”Wx4”D Hysteresis: ±2°C, ±3.2°F Dual-pole: 10”Hx8”Wx4”D Absolute Accuracy: ±2.5°C, ±4.5°F Features: Quick release latches to open door Repeatability: ±1°C, ±1.8°F One 3/4”...

  • Page 5: Installation

    Refer to Typical Wiring Diagram, for Carefully remove the TraceMate from the shipping box. power, heater and RTD field connections. Inspect face plate for shipping damage and check • T1 Form C Alarm Dry Contacts: Both NO (terminals electronics for loose wiring or damage.
  • Page 6 TRACE MATE Chapter 2 Installation Figure 2.1 TraceMate Controls and Indicators Figure 2.2 Typical Wiring Diagram...

  • Page 7: Mounting The Controller

    Wire Size (AWG) Current Load (A) Temperature (°C) Conduit and Cabling TraceMate comes with one 3/4” and 1/2” conduit RTD Sensor Wiring knockouts located on the bottom of the enclosure. Conduit hubs should be NEMA-4X rated, such as T&B RTD sensors should be 3-wire, 100 ohm, platinum to H050-0.5 and H075-0.75 or Myers equivalent, to...

  • Page 8: Alarm Wiring

    Warning - Explosion Hazard - Do not Alarm Wiring disconnect equipment unless power has TraceMate has a form c dry alarm contact and an active been switched off or the area is known to be alarm output for driving an LED alarm indicator. The non-hazardous.

  • Page 9: Applications

    RTD mounted on the pipe and connect the existing heater and power wires to the TraceMate as shown in Figure 3.1. A green alarm status light, visible to maintenance personnel, is connected to the TraceMate LED alarm output and should be always on.

  • Page 10: Operation

    S11 towards its ON position ( dormant systems with the TraceCheck feature, which refer to Figure 2.1 ) even if the TraceMate is at control turns on the heaters for several seconds every 24 hours, with power applied.
  • Page 11 TRACE MATE Chapter 4 Operation Heater Setpoint: If the jumper on JP1 is at SP position, the Setpoint Number generated by S1-9 is interpreted as the heater setpoint. Whether the setpoint is in °C or °F depends on the position of S10 ( refer to Figure 2.1 ). The factory default value is 20°C.

  • Page 12: Calibration

    This is a tedious task because the controls are often high off the ground in inaccessible areas. Since the TraceMate control uses an RTD, it can be mounted in a convenient ground level location near other controls for easy access. Indicator lights for HEATER ON and POWER indicate the system status.

  • Page 13: Ground Fault Testing

    1 and 4. 3. Disconnect all wires to the terminals. 4. Remove any screws holding the TraceMate Follow these steps to test the ground fault circuit: controller and return it to the factory for repair.

  • Page 14: Warranty

    Warranty The manufacturer warrants each control that it manufactures to be free from defective material or workmanship for a period of 12 months from date of purchase. Under this warranty, the obligation of the manufacturer is limited to repairing or replacing the defective control at its option, when returned to the manufac- turer’s factory with shipping charges prepaid.
  • Page 15 TRACE MATE ELECTRONIC THERMOSTAT Nextron Limited 6120 11 Street S.E., Calgary, Alberta, T2H 2L7, Tel:(403) 735-9555, Fax: (403) 735-9559 P/N: 1501-0012_1 TMII 02/09 Printed in Canada...
