Service
Manual
HIGH POWER CD PLAYER WITH RDS TUNER
DEH-2330R
DEH-2300RB
DEH-2300R
- This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-958
CRT2423
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................3
4. PCB CONNECTION DIAGRAM ................................26
5. ELECTRICAL PARTS LIST ........................................34
6. ADJUSTMENT..........................................................38
PIONEER CORPORATION
PIONEER ELECTRONICS SERVICE INC.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2000
DEH-2330R/X1M/EW
Mech. Module Remarks
S8.1
CD Mech. Module:Circuit Description, Mech.Description, Disassembly
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
X1M,X1N/EW
X1M,X1N/EW
7. GENERAL INFORMATION .......................................42
7.1 DIAGNOSIS ........................................................42
7.1.1 TEST MODE ..............................................42
7.1.2 DISASSEMBLY .........................................45
7.1.3
7.2 PARTS .................................................................50
7.2.1 IC................................................................50
7.2.2 DISPLAY ....................................................57
7.3 OPERATIONAL FLOW CHART ...........................58
8. OPERATIONS AND SPECIFICATIONS.....................59
K-ZZA. OCT. 2000 Printed in Japan
ORDER NO.
CRT2561
X1M,X1N/EW
.......49
