2013 Owner's Manual

HUMMER H3

Electric Golf Cart (eGC)

This Manual is effective as of May 15, 2012

Table of Contents

Need help?

Do you have a question about the 2013 HUMMER H3 and is the answer not in the manual?

Questions and answers

Summary of Contents for American Custom Golf Cars 2013 HUMMER H3

Page 1 2013 Owner’s Manual HUMMER H3 Electric Golf Cart (eGC) This Manual is effective as of May 15, 2012...
Page 2 (909) 597-2885 (909) 597-7183 fax www.acgcars.com Copyright 2009-2013 American Custom Golf Cars, Inc. American Custom Golf Cars, Inc., ACG and California Roadster Are registered trademarks of American Custom Golf Cars, Inc. HUMMER and H3 Are registered trademarks of General Motors Corporation.
Page 3: Notice
Notice The American Custom Golf Cars, Inc., herein known as ACG, Limited Warranty for owners of the ACG HUMMER H3 is included with this manual. No other warranties, expressed or implied, are contained herein. ACG and your authorized representative checked this vehicle before it was delivered to you.
Page 4: Table Of Contents
Parking and Leaving the Vehicle…………………………………………… Batteries……………………………………………………………………………….. Battery Care…………………………………………………………………… Battery Inspection & Maintenance………………………………………….. INSPECTION………………………………………………………………….. CLEANING………………………………………………………………………. WATERING……………………………………………………………………. Charging Batteries……………………………………………………………. Battery Replacement…………………………………………………………. Battery Disposal……………………………………………………………. Periodic Maintenance………………………………………………………………… DAILY TASKS…………………………………………………………………. MONTHLY TASKS……………………………………………………………. Cleaning………………………………………………………………………………… Specifications………………………………………………………………………….. Warranty……………………………………………………………………………….. Page 4 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 5: Foreword
ACG HUMMER H3 Thank you for choosing the for your golf and community transportation needs. American Custom Golf Cars, Inc. would like to welcome you to the new revolution in the Custom Golf Cart Industry. Please protect your investment to make sure that your California Roadster will provide you with years of reliable performance.
Page 6: Introduction
All information and specifications in this “Owner’s Manual” are current at the time of printing. However, due to ACG’s policy of continuous product improvement, we reserve the right to make changes, at any time, without written notice or obligation. Page 6 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 7: Insurance Notice
Dealer or Distributor of American Custom Golf Cars, Inc. products, provided that the “Warranty Registration Card” is received by American Custom Golf Cars, Inc. within 45 Days of the purchase date of the vehicle. If the “Warranty Registration Card”...
Page 8: General Warnings
10. Prior to servicing Vehicle: a. Chock the wheels. b. Turn the “Key Switch” to “OFF“ position and remove the key. c. Disconnect battery cables, negative (--) cable first. Page 8 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 9 4. To avoid unintentionally starting or rolling the vehicle: A). Set the “Parking Brake”, B). Turn the “Key Switch” to the “OFF” position, C). Remove keys prior to leaving the vehicle. Page 9 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 10: Safe Ownership Of Acg
ACG vehicle that is not sufficient in wire gauge (AWG) could create a fire hazard. Please consult “Charging Procedures Manual” for the proper extension cord gauge which depends on its length. Page 10 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 11: Notes
Indicates an immediate hazard, which could result in an accident causing bodily injury. “CAUTION!” Identifies something that could result in damage to your vehicle. “NOTE” Notes are for your information and to make procedures more easily understood. Page 11 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 12: Controls And Indicators
Never turn the “Key Switch” to the “OFF” position while the vehicle is in motion. This could lead to loss of speed control and loss of control of the vehicle. This can cause a serious accident. Page 12 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 13: Forward-Neutral-Reverse Switch
Neutral and will not move when the accelerator pedal is depressed. Switch shown in Reverse position CAUTION! Always bring the vehicle to a complete stop before changing the position of the “Forward-Neutral-Reverse Switch”. Page 13 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 14: Accelerator Pedal
The vehicle will not stop automatically when the “Accelerator Pedal” is released. You must depress the “Brake Pedal” in order for the vehicle to come to a stop or to slow down rapidly. Page 14 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 15: Brake Pedal
To slow or stop the vehicle, release the “Accelerator Pedal” and then depress the brake pedal with your foot until the EGC has come to a complete stop or the vehicle has slowed to your desired speed. Page 15 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 16: Park Brake Pedal
The “Park Brake” will release automatically when either the “Accelerator Pedal” or “Brake Pedal” is depressed. The park brake has multiple locking positions and should be firmly pressed and locked to prevent the vehicle from rolling. Page 16 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 17: Light Switch
When the top portion of the switch “O” is depressed the fog lights are off. 2.) ON - When the bottom portion of the switch “I” is depressed, the fog lights are on. Page 17 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 18: Turn Signal Lever Switch
The system DOES NOT have a “self-canceling” feature; return the Lever to the horizontal “OFF” position after completing the intended Turn or Lane Change! (Turn Signal Lever Switch shown in “OFF “position) Page 18 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 19: Hazard Warning Flashers
LED Light to the Left of the Display Panel will flash when the Left Turn Signal is activated • GREEN LED Light to the Right of the Display Panel will flash when the Right Turn Signal is activated  Page 19 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 20: Display Panel
Direction – Monitors the position of the “Direction Control Switch” and shows: • for Forward Drive • for Neutral (as shown above) • for Reverse For additional display features please refer to following section. Page 20 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 21: Important Information
For long battery service life, the vehicle should not be operated when the indicated Charge Level is 20% or less, and need not to be re-charged if the Display Indication is 80% or more. Page 21 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 22 (F) or reverse (R). The car will not move unless you start in neutral (N). [8 ] To proceed to a 2 Screen push center arrow button once. Page 22 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 23 These values will change as soon as you start driving the vehicle. This will also let you monitor and diagnose the condition of the motor and controller . [8 ] To proceed to a 3 Screen push center arrow button once. Page 23 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 24 Drive profile #2 (Drv Select 2) is only used for testing Purpose to see the Range of motor on the controller. Features not used: Seat Hand Brake Inch FWD sw Inch REV sw [8 ] To proceed to a 4 Screen push center arrow button once. Page 24 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 25 This screen displays the acceleration of the vehicle from 0-1000 feet and will automatically record the performance of the vehicle. It also displays the number of hours the vehicle was driven. [8 ] To proceed to a 4 Screen push center arrow button once. Page 25 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 26 Any fault after that might be relevant. To check new faults you need to press the upper twice and the fault will appear (6 Screen). Screen It will give you the date and time the fault first appeared and the explanation what the fault means. Page 26 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 27 Thermal cut back just means the motor is too hot and will reduce the power to protect the motor. [8 ] center arrow button once, Push the this will get you back to main screen Page 27 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 29: Accessory Outlet
The vehicle is equipped with two cup holders that are installed in central divider between front seats. CAUTION! Liquids can damage electrical components and the circuit board. Handle all liquids with care. Do not spray water directly into the upper or lower dash. Page 29 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 30: Safety Belts
Always be sure you and others in your vehicle are buckled up properly. CAUTION! Maximum occupancy is limited to two people (including the driver). Page 30 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 31 A safety belt that is too loose will not function properly. In a sudden stop, you could jerk too far forward, increasing the possibility of injury. Wear your safety belt snugly. Page 31 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 32 Only use when the seat belt is not long enough when it is worn low and snug, and in the recommended seating positions. Remove and stow the seat belt extender when not needed. Page 32 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 33 The child and others could be badly injured. Any child riding in your vehicle should be in a proper restraint for the child’s size. Page 33 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 35 Do not leave it loose in the vehicle. In a sudden stop or collision, it could strike the occupants and cause serious personal injury. NOTE: For additional information refer to www.seatcheck.org or call 1-866-SEATCHECK.. Page 35 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 36 Others may cause damage to the vehicle, and will void warranty. WARNING! Any modifications or alterations to this vehicle could seriously affect its road worthiness and safety and may lead to an accident resulting in serious injury or death. Page 36 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 37: Tires & Wheels
Any accelerated wear of tires may be an indicator of improper alignment or poor driving habits. If uncertain, consult your ACG service provider. NOTE: The vehicle’s tire information can be found on the “Tire Information Label” (See page 39, Figure Page 37 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 38 • Overloading your tires is dangerous. Like under inflation, overloading can cause tire failure. Use tires of the recommended load capacity for your vehicle and Never overload them. Page 38 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 39: Tires
Use only the tire and wheel sizes with load ratings approved for your vehicle. NOTE : The vehicle’s tire information can be found on the “Tire Information Label” (Reproduced below) (The label location on the vehicle is under Certification Label under driver seat). Page 39 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 41: Brakes
Brake fluid may cause damage to painted and finished surfaces. Use caution when refilling the brake fluid reservoir. CAUTION! Use only DOT 4 Brake Fluid from a sealed Container. Clean Filler Cap before removing. Page 41 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 42: Pre-Operation And Daily Safety Checklist
Check battery posts. Wires should be tight and free from corrosion. Charge Batteries fully before first use of the vehicle. Charger Receptacle: Visually inspect for cracks, loose connections, and frayed wiring. Page 42 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 43: Performance Inspection
General: Listen for any unusual squeaks or rattles. Check the vehicle’s ride and performance. Have an American Custom Golf Cars, Inc. distributor or dealer or a fully trained technician investigate anything unusual. Page 43 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 44: Driving Instructions
Driver should always drive vehicle with both hands on steering wheel. 11. To avoid possible serious injury, keep your entire body inside the vehicle when it is in motion. 12. Never leave children unattended in or near the vehicle. Page 44 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 45 18. Drive slowly through turns to avoid overturning the vehicle. 19. Use brakes to reduce speeds when coasting downhill. NOTE: ACG HUMMER H3 is not specially equipped for handicapped persons. Page 45 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 46: Starting The Vehicle
2. Put the “Forward – Neutral - Reverse Switch” in the “Neutral” Position 3. Turn the “Key Switch” to the “OFF” position. Remove key to prevent theft and/or unauthorized use of the vehicle. Page 46 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 47: Batteries
WARNING! – HIGH VOLTAGE The battery pack is at a high voltage. High voltage is always present at the battery terminals. Never touch battery terminals when performing battery maintenance procedures. Page 47 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 48: Battery Inspection & Maintenance
 Look closely for loose or damaged parts.  Battery cables should be intact; broken or frayed cables can be extremely hazardous.  Replace any cable that looks suspicious.  Page 48 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 49 Stud 120-180 in-lbs LT 100-120 in-lbs VRLA Button 90 to 100 in-lbs LT 100-120 in-lbs WARNING! Do not over tighten terminals. Doing so can result in post breakage, post meltdown, or fire. Page 49 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 50: Cleaning
5. Reconnect the clamps to the terminals and thinly coat them with petroleum jelly (Vaseline) to prevent corrosion. 6. Keep the area around batteries clean and dry. CAUTION! Battery acid from cleaning batteries can damage vehicle, driveway or garage floor. Page 50 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 51: Watering
3. Do not use water with a high mineral content. Use only distilled or deionized water only. CAUTION! The electrolyte is a solution of acid and water so skin contact should be avoided. Page 51 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 52 Never add acid to a battery. CAUTION! If necessary only add Water to battery cells. Use of Distilled Water is recommended. Use of contaminated Water can permanently damage the battery. Page 52 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 53: Charging Batteries
• In hot climates, battery self-discharge will increase. • In cold climates, batteries could freeze if not properly charged. If the vehicle will not be used for 10 or more days, leave the car plugged in. Page 53 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 54: Battery Replacement
Contact local and/or state environmental officials regarding disposal information. You can also contact ACG Customer Service at (909) 597-2885 for information. Page 54 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 55 It does not disable the battery pack.  HIGH VOLTAGE will be present at the battery terminals. HIGH BATTERY VOLTAGE ALWAYS PRESENT.  DO NOT TOUCH THE BATTERY TERMINALS. Page 55 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 56: Periodic Maintenance
2. Check battery terminals for tight connections. 3. Visually inspect the tires for wear, damage, and proper inflation. 4. Check for proper operation of parking brake. 5. Check seat belts for proper operation. Page 56 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 57: Monthly Tasks
6. Check brake lines for leaks. 7. Grease the hydraulic disk brake actuator, and check for proper operation of service brake. 8. Check all wheel bearings for looseness or free-play. Page 57 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 58: Cleaning
Rinse promptly after cleaning. Dry the finish with a soft, clean chamois or towel to avoid surface scratches and water spotting. NOTE: To avoid spotting, do not wash your vehicle in direct sunlight. Page 58 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 59 It is recommended to protect the vehicle whenever possible and preferably to store it indoors during extended non-use periods. ACG Custom Vehicle Cover is available at ACG dealerships. Page 59 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 60: Transport Or Towing
CAUTION! TOWING THE VEHICLE IS NOT RECOMMENDED. This vehicle is not designed for dolly towing. Any vehicle failures resulting from dolly towing will not be covered under vehicle warranty. Page 60 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 61: Specifications
Aluminum I-Beam Body One-piece Fiberglass Composite Body Finish Automotive Paint Interior Material Marine-type Vinyl Carpet Marine-type Synthetic Forward Speed <15 mph Braking Distance (at 12 mph) 8 ft. Standard Seating Capacity Page 61 Copyright © 2009-2013 American Custom Golf Cars, Inc.
Page 62 (909) 597-2885 (909) 597-7183 fax www.acgcars.com ACG logo is registered trademark of American Custom Golf Cars, Inc. HUMMER and H3 Are registered trademarks of General Motors Corporation This Manual is effective as of May 15, 2012 Copyright © 2009-2013 American Custom Golf Cars, Inc.
