Summary of Contents for adapx Capturx
- Page 1 June 2012...
-
Page 2: Table Of Contents
Table of Contents The Digital Pen, Docking Station, and Capturx Pen Manager...................1 Digital Pen Technical Specifications ............................1 Changing Ink Cartridges................................2 Installing Capturx Pen Manager ..............................2 Setting Up the Digital Pen and Docking Station ........................3 Capturx Pen Manager Features..............................4 Digital Pen Status System Monitoring............................4 Capturx Pen Manager Control Panel............................5... -
Page 3: The Digital Pen, Docking Station, And Capturx Pen Manager
Charging time approximately 2.5 hours (150 min), from 0% to 100% via the USB adapter. The digital pen can endure a standby time (without cap) of 10 hours. The Capturx pen can be used for 2 hours (120 minutes) continuously, and holds up to 50 pages of ... -
Page 4: Changing Ink Cartridges
Install Capturx Pen Manager from the product CD, register the Capturx software product, and activate the digital pen. For additional help, contact Adapx Technical Support at techsupport@adapx.com. NOTE: Although the user interface is in U.S. English, Capturx Pen Manager can install and run on any Windows-supported locale. Page 2 Rev. 06-12... -
Page 5: Setting Up The Digital Pen And Docking Station
When your pen is uncapped, it is using power. To prevent your battery from running low, do not leave the cap off the pen for extended periods of time. Keep the pen cap in a safe place. ©2012 Adapx www.adapx.com tech.support@adapx.com 877-232-7903 Page 3... -
Page 6: Capturx Pen Manager Features
Digital Pen Status System Monitoring When you install Capturx Pen Manager, the feature is added to the list of applications active on your system. If its icon does not appear in the default view of your system tray, you can drag-and-drop the icon from the Show hidden icons window to the system tray. -
Page 7: Capturx Pen Manager Control Panel
Capturx Pen Manager Control Panel Once you configure the digital pen and Capturx Pen Manager to suit your work style, the Pen Manager runs in the background. Its control panel is seldom required for everyday operation. 1. Pen Information Tabs Tabs separate Capturx Pen Manager options for each individual pen. - Page 8 Adapx to identify your organization’s account. You may be asked to supply this serial number when ordering additional Capturx products and dot pattern refills. Capturx will select the first pen that you dock as your Customer Reference Pen. After docking other pens, you may select one of them as your Customer Reference Pen.
- Page 9 Adapx Technical Support for assistance. An activated pen is required to print unique pattern from Capturx applications, as well as export the pen’s ink data to other locations and other users. Unactivated pens can only be used with Capturx for Microsoft Office OneNote.
-
Page 10: Destinations For Digital Pen Data
9. Digital Ink Destination: URL, Email, or Folder You can send your stored ink to an email recipient, to a Capturx-enabled server, to a folder on your local PC, or to a network location by entering the email recipient address, local directory path, server URL, or network URL in the Destination field and selecting the Enable checkbox. -
Page 11: Opening Xid Files
Opening XID Files To open an XID file that is attached to an email or saved to a network location, you must have Capturx Pen Manager installed on your PC, the file or site that was the source of the printout, and the Capturx application that created the printout. - Page 12 Close the Stored Ink Records dialog. NOTES: Ink records for Capturx for Microsoft Office OneNote and Capturx Markup for PDF are processed and imported automatically and cannot be previewed. Ink records for Capturx for ArcGIS must be processed from within ArcGIS.
-
Page 13: Troubleshooting Digital Ink Processing Errors
Troubleshooting Digital Ink Processing Errors If ink records do not process successfully, you can still use Capturx Pen Manager to route their data or to remove the record from the digital pen. 1. If an error occurs while processing an ink record, a dialog will note the number of pages imported and the number of errors. -
Page 14: Updating Capturx Pen Manager
Updating Capturx Pen Manager To check if Adapx has released a new version of Capturx Pen Manager, or any other Capturx software: 1. Click the arrow next to the version number in the bottom right corner. 2. Click Check for Updates. A message will confirm the status of your search, if you have the most current versions of Capturx software, or indicate new versions. -
Page 15: Appendix A: Security Settings
Limited privilege users will always have a password on any pens docked on their workstation. After the password is set, the Capturx Pen Manager user interface reflects that the password cannot be removed by disabling the Delete button. To allow password deletion and enable the Delete button, the registry key will need to be removed or set again to false. -
Page 16: Disable Bluetooth On Each Pen Docking
Capturx Pen Manager auto-update.. When set, the menu next to the version at the bottom of Capturx Pen Manager window is disabled, and the end user will not be able to manually check for Capturx updates. Automated checking for updates is disabled as well. -
Page 17: Set A Minimum Number Of Characters For The Pen Password
For passwords with at least one non-English character, the maximum password length is 11 characters. If the key is set to zero, then Capturx Pen Manager behaves as if no minimum has been set. If the key is set to a number greater than 22, then 22 will be used.
