Lincoln Electric SP-100T Operator's Manual

Lincoln Electric SP-100T Operator's Manual

Hide thumbs Also See for SP-100T:
Table of Contents

Advertisement

Quick Links

For use with machine Code Number
This manual covers equipment which is no
longer in production by The Lincoln Electric Co.
Speci cations and availability of optional
features may have changed.
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However, your
overall safety can be increased by
proper installation ... and thought-
ful operation on your part. DO
NOT INSTALL, OPERATE OR
REPAIR THIS EQUIPMENT
WITHOUT
READING
MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED
THROUGHOUT. And, most
importantly, think before you act
and be careful.
Date of Purchase:
Serial Number:
Code Number:
Model:
Where Purchased:
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
SP- 100T
10262, 10271, 10480, 10484, 10739 & 10879
THIS
OPERATOR'S MANUAL
• World's Leader in Welding and Cutting Products •
Copyright © 2002 Lincoln Global Inc.
IM564-C
April, 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-100T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lincoln Electric SP-100T

Summary of Contents for Lincoln Electric SP-100T

  • Page 1 For use with machine Code Number 10262, 10271, 10480, 10484, 10739 & 10879 This manual covers equipment which is no longer in production by The Lincoln Electric Co. Speci cations and availability of optional features may have changed. Safety Depends on You...
