DEC 408sp Installation and programming reference
DTMF Ethernet Converter and Expander module
Installation and programming reference
Features:
• Encrypted Ethernet communication
• 24 hour, two way connection to the Monitoring Station
• DHCP / FixIP
• 2 Server IP or Host Name
• 8 Input, 32 RF devices
• 4 programmable and remotely controlled output
• 4 End User
• Alarm functions
• RF accessoryes
• Local programming through Ethernet port
• Remote programing throug IP networks (Internet)
• Industrial signal transmission through serial port or throug contact inputs
• External security panel serial commonication or dry contact conversion to Ethernet
• E-mail
• Web programming.
1. page
www.skylaboratories.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the DEC 408sp and is the answer not in the manual?

Questions and answers

Summary of Contents for Sky Laboratories DEC 408sp

  • Page 1 DEC 408sp Installation and programming reference DTMF Ethernet Converter and Expander module Installation and programming reference Features: • Encrypted Ethernet communication • 24 hour, two way connection to the Monitoring Station • DHCP / FixIP • 2 Server IP or Host Name •...
  • Page 2 DEC 408sp Installation and programming reference www.skylaboratories.com 2. page...
  • Page 3 DEC 408sp Installation and programming reference Applications: 3. page www.skylaboratories.com...

  • Page 4: Specification

    DEC 408sp Installation and programming reference 1.0. DEC module hardware description 1.3. Outputs: Max output load is 200mA per output 1.1. Main parts: Wiring of the outputs: 1.4. RS 232 connector: Fixing holes Ethernet connector Dec modules are available for serial communication for more RS232 port information please contact your dealer or the manufacturer.
  • Page 5 DEC 408sp Installation and programming reference 3.0. Kiegészítık - Can be used with almost any standard NO/NC contact 3.1. Inovonics EE4000 EchoStream Serial - Screw closure housing and wall tamper Receiver switch provide additional security The serial receiver is a gateway that uses reliable frequency-hopping, spread- •...
  • Page 6 DEC 408sp Installation and programming reference - Neck cord and belt clip included 3.3. Sky-IP Cameras - Fully supervised to help ensure reliability - Weighs less than 1.3oz (40gm) • S940 - 1/3” Sharp color 420TVL • ES1233D - Double-Button Necklace Pendant...

  • Page 7: Installation Of The Board

    DEC 408sp Installation and programming reference 4.0. Installation of the board 5.2. Connection: Connect the computer through Local Area Network 4.1. Fixing and connection. Open an internet browser like Mozzilla Firefox or Internet Exprorer. Type into the browser field the IP address and port (192.168.4.16:808 or default IP:192.168.254.254:8080)
  • Page 8 DEC 408sp Installation and programming reference 6.1.1. Network: 6.0. Programming: This is the position where you may set network parameters. Next time you may connect the panel according to the Change the factory setting by enter into Configure section. parameters you type in.
  • Page 9 DEC 408sp Installation and programming reference External devices: • Test sign interval: 6.1.2. The module is in continous connection with the monitoring station, but sends test signals in periodical • RF devices: time. Enable:Inovonics RF devices. Default: 120 sec Default: Disabled Security: 6.1.5.
  • Page 10 DEC 408sp Installation and programming reference 6.1.6. Camera(s) - 24Hour: This menu is about how to control IP cameras 24 hour zone will activate an alarm , regardless if the system is armed or disarmed. • Force capture: enable - Delayed: Force capture enables continous recording.
  • Page 11 DEC 408sp Installation and programming reference - Exit Time: • Report disabled: Follow the exit time. When exit time starts the output The thickbox is to be used to report disable are not will be activated. Timing of exit delay is not take as used.
  • Page 12 DEC 408sp Installation and programming reference 6.3. RF Devices 6.4. Cameras Adding or deleting RF Wireless Devices Maximum number of 8 cams could be controlled by the control panel. • IP address: 6.3.1. Adding RF Wireless Device This is the IP address of the camera.
  • Page 13 DEC 408sp Installation and programming reference 6.5. Users 6.6. Logs: A rendszer maximum 4 felhasználót kezel. Control panel handles maximum of 4 users. • Time: Event of Time • Type: Event of Type • EQ: Event of Qualifier - New: Alarm or Open •...
  • Page 14 This is a factory pre-set, not changeable serial If you click Contact you may send a pre-addressed message number of the module. to the manufacturer Sky Laboratories. If you need further assistance please send us an e-mail or call us at numbers • Uptime: found on the installation manual.
  • Page 15 DEC 408sp Installation and programming reference Availability: Sky Laboratories Kft. Address: 2146 Mogyoród, Pf.: 16, Kerektó u. 2 Tel.: +36-28-542-250 Fax: +36-28-542-251 E-mail: sales@skylaboratories.com www.skylaboratories.com 15. page...
