Read and understand all safety precautions in this manual before operating. Failure to
comply with instructions in this manual could result in personal injury, property damage and/or voiding of your
warranty. The manufacturer WILL NOT be liable for any damage because of failure to follow these instruc-
tions.
Lisez et veillez à bien comprendre toutes les consignes de sécurité de ce
manuel avant d'utiliser l'appareil. Toute dérogation aux instruc ions contenues dans ce manuel peut entraîner
l'annulation de la garantie, causer des blessures et/ou des dégâts matériels. Le fabricant NE SAURA être
tenu responsable de dommages résultant de l'inobservation de ces instructions.
Lea y comprenda todas las precauciones de seguridad contenidas en este manu-
al antes de utilizar esta unidad. Si no cumple con las instrucciones de este manual podría ocasionar lesiones
personales, daños a la propiedad y/o la anulación de su garantía. El fabricante NO SERÁ responsable de
ningún daño por no acatar estas instrucciones.
200-2514, Rev. A
Advertisement
Related Manuals for Coleman powermate 024-0175CT
Summary of Contents for Coleman powermate 024-0175CT
- Page 1 Read and understand all safety precautions in this manual before operating. Failure to comply with instructions in this manual could result in personal injury, property damage and/or voiding of your warranty. The manufacturer WILL NOT be liable for any damage because of failure to follow these instruc- tions.
-
Page 2: Safety Guidelines - Definitions
S F T SAFETY GUIDELINES - DEFINITIONS D L NES This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recog- nize this information, we use the following symbols. Please read the manual and pay attention to these sections. - Page 3 RISK OF INJURY. When servicing a tool, use only identical replacement parts. Use only authorized parts. Use only the lubricants supplied with the tool or specified by Coleman Powermate. AIR SOURCE SAFETY RISK OF BURSTING AND/OR INJURY. Never connect to an air source that is greater than 90 psi.
-
Page 4: User Maintenance Instructions
TYPICAL INST ALLAT O TION Figure 1 Description Description Description Description Air hose In-line Oiler Quick Coupler Female Connector In-line Filter Air Hose Male Connector Spray Gun Tee Fitting Whip Hose Air Tool OPERA TING INSTRUCTIONS PE A I S RU To begin using the tool: Figure 2 As a standard prac ice, drain water from the air compressor... -
Page 5: Troubleshooting Guide
Disconnect he air tool from the air supply. Turn the tool upside down and while depressing the trigger, add 4-6 drops of Coleman Powermate® air tool oil #018-0059SP or SAE10 nondetergent oil into he air inlet. NOTE: Depressing the trigger helps circulate the oil in the air motor. -
Page 6: Warranty
Coleman® and are registered trademarks of The Coleman Company, Inc. used under license. Coleman® et sont des marques déposées de The Coleman Company, Inc. utilisées sous licence. Coleman® y son marcas comerciales registradas de The Coleman Company, Inc. utilizadas bajo licencia.
