LG-Nortel ELO WR100T
(LNWR100T)
Wireless Broadband Router
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELO WR100T LNWR100T and is the answer not in the manual?

Questions and answers

Summary of Contents for LG-Nortel ELO WR100T LNWR100T

  • Page 1 LG-Nortel ELO WR100T (LNWR100T) Wireless Broadband Router User Guide...
  • Page 2 STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * LG-Nortel will provide warranty service for one year following discontinuance from the active LG-Nortel price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.
  • Page 3 COMPLIANCES Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Table Of Contents

    ABLE OF ONTENTS Introduction ........1-1 About the LNWR100T ........1-1 Features and Benefits .
  • Page 5 ABLE OF ONTENTS ADSL Settings - Fixed-IP xDSL ......4-10 ADSL Settings - PPPoE ....... 4-11 ADSL Settings - PPTP .
  • Page 6 ABLE OF ONTENTS Maintenance ..........4-58 Configuration Tools .

  • Page 7: Introduction

    HAPTER NTRODUCTION Congratulations on your purchase of the LG-Nortel ELO WR100T (LNWR100T). We are proud to provide you with a powerful yet simple communication device for connecting your local area network (LAN) to the Internet. For those who want to surf the Internet in the most s ecure way, this router provides a convenient and powerful solution.

  • Page 8: Features And Benefits

    EATURES AND ENEFITS Features and Benefits • Local network connection via a 10/100 Mbps Ethernet port • DHCP for dynamic IP configuration, and DNS for domain name mapping • Firewall with Stateful Packet Inspection, client privileges, intrusion detection, and NAT •...

  • Page 9: Applications

    NTRODUCTION Applications Many advanced networking features are provided by this LNWR100T: • Wired and Wireless LAN The LNWR100T provides connectivity to 10/100 Mbps devices, and wireless IEEE 802.11g compatible devices, making it easy to create a network in small offices or homes. •...
  • Page 10 PPLICATIONS • DMZ Host Support Allows a networked computer to be fully exposed to the Internet. This function is used when NAT and firewall security prevent an Internet application from functioning correctly. • Security The LNWR100T supports security features that deny Internet access to specified users, or filter all requests for specific services that the administrator does not want to serve.

  • Page 11: Installation

    HAPTER NSTALLATION Before installing the LNWR100T, verify that you have all the items listed under “Package Contents.” If any of the items are missing or damaged, contact your local distributor. Also be sure that you have all the necessary cabling before installing the LNWR100T. After installing the LNWR100T, refer to “Configuring the LNWR100T”...

  • Page 12: System Requirements

    NSTALLATION System Requirements You must meet the following minimum requirements: • An ADSL line installed by your ISP • An ADSL splitter (at least one) • A computer with a CD-ROM drive • Windows (98 or later), MacOS (9.x) • An up to date web browser: •...
  • Page 13 ARDWARE ESCRIPTION The LNWR100T includes an LED display on the front panel for system power and port indications that simplifies installation and network troubleshooting. Figure 2-1. Front LED indicators The power and port LED indicators on the front panel are illustrated by the following table.
  • Page 14 NSTALLATION The following figure and table shows the rear panel of the LNWR100T. Note: Antenna not shown. LAN1 LAN2 LAN3 LAN4 Antenna RJ-45 Reset Power Connector Port Button Connector RJ-45 LAN Ports Figure 2-2. Rear Panel Item Description Power Inlet Connect the included power adapter to this inlet.

  • Page 15: Isp Settings

    ISP S ETTINGS ISP Settings Please collect the following information from your ISP before setting up the LNWR100T: • ISP account user name and password • Protocol, encapsulation and VPI/VCI circuit numbers • DNS server address • IP address, subnet mask and default gateway (for fixed IP users only) Connect the System The LNWR100T can be positioned at any convenient location in your office or home.

  • Page 16: Phone Line Configuration

    NSTALLATION Phone Line Configuration Installing a Full-Rate Connection If you are using a full-rate (G.dmt) connection, your service provider will attach the outside ADSL line to a data/voice splitter. Use a straight through CAT-5 Ethernet cable (RJ-45) to connect the LNWR100T to the cable/DSL modem.
  • Page 17 ONNECT THE YSTEM Installing a Splitterless Connection If you are using a splitterless (G.lite) connection, then your service provider will attach the outside ADSL line directly to your phone system. Use a straight through CAT-5 Ethernet cable (RJ-45) to connect the LNWR100T to the cable/DSL modem.

  • Page 18: Connecting The Lnwr100T To Your Lan

    NSTALLATION Connecting the LNWR100T to your LAN The four LAN ports on the LNWR100T auto-negotiate the connection speed to 10 Mbps Ethernet or 100 Mbps Fast Ethernet, as well as the transmission mode to half duplex or full duplex. Use RJ-45 cables to connect any of the four LAN ports on the LNWR100T to an Ethernet adapter on your PC.

  • Page 19: Connect The Power Adapter

    ONNECT THE YSTEM Connect the Power Adapter Plug the power adapter into the power socket on the side panel of the LNWR100T, and the other end into a power outlet. Check the power indicator on the front panel is lit. If the power indicator is not lit, refer to “Troubleshooting”...

  • Page 20: Configuring The Client Pc

    HAPTER ONFIGURING LIENT After completing hardware setup by connecting all your network devices, you need to configure your computer to connect to the LNWR100T. You can either configure your computer to automatically obtain IP settings (DHCP) or manually configure IP address settings (Static IP). Depending on your operating system see: “Windows 2000”...

  • Page 21: Tcp/Ip Configuration

    TCP/IP C ONFIGURATION TCP/IP Configuration To access the Internet through the LNWR100T, you must configure the network settings of the computers on your LAN to use the same IP subnet as the LNWR100T. The default network settings for the LNWR100T are: IP Address: 192.168.2.1 Subnet Mask: 255.255.255.0 Note: These settings can be changed to fit your network requirements,...

  • Page 22: Windows 2000

    ONFIGURING LIENT Windows 2000 DHCP IP Configuration 1. On the Windows desktop, click Start/Settings/ Network and Dial-Up Connections. 2. Click the icon that corresponds to the connection to your The connection status screen will open. Click Properties.
  • Page 23 TCP/IP C ONFIGURATION 4. Double-click Internet Protocol (TCP/IP). 5. If Obtain an IP address automatically and Obtain DNS server address automatically are already selected, your computer is already configured for DHCP. If not, select these options now and click OK.

  • Page 24: Obtain Ip Settings From Your Lnwr100T

    ONFIGURING LIENT Obtain IP Settings From Your LNWR100T Now that you have configured your computer to connect to your LNWR100T, it needs to obtain new network settings. By releasing old DHCP IP settings and renewing them with settings from your LNWR100T, you can verify that you have configured your computer correctly.
  • Page 25 TCP/IP C ONFIGURATION 3. Type “IPCONFIG /RENEW” and press the Enter key. Verify that your IP Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.2.1. These values confirm that your LNWR100T is functioning correctly. 4.

  • Page 26: Manual Ip Configuration

    ONFIGURING LIENT Manual IP Configuration 1. Follow steps 1-4 in “DHCP IP Configuration” on page 3-3. 2. Select Use the following IP address. Enter an IP address based on the default network 192.168.2.x (where x is between 2 and 254), and use 255.255.255.0 for the subnet mask.
  • Page 27 TCP/IP C ONFIGURATION Disable HTTP Proxy You need to verify that the “HTTP Proxy” feature of your web browser is disabled. This is so that your browser can view the LNWR100T’s HTML configuration pages. To disable the proxy in Internet Explorer, click Tools.

  • Page 28: Windows Xp

    ONFIGURING LIENT Windows XP DHCP IP Configuration 1. On the Windows desktop, click Start/Control Panel. 2. In the Control Panel window, click Network and Internet Connections. 3. The Network Connections window will open. Locate and double-click the Local Area Connection icon for the Ethernet adapter that is connected to the LNWR100T.
  • Page 29 TCP/IP C ONFIGURATION 5. Double-click Internet Protocol (TCP/IP). 6. If Obtain an IP address automatically and Obtain DNS server address automatically are already selected, your computer is already configured for DHCP. If not, select these options now and click OK. 3-10...
  • Page 30 ONFIGURING LIENT Obtain IP Settings from Your LNWR100T Now that you have configured your computer to connect to your LNWR100T, it needs to obtain new network settings. By releasing old DHCP IP settings and renewing them with settings from your LNWR100T, you can verify that you have configured your computer correctly.
  • Page 31 TCP/IP C ONFIGURATION 3. Type “IPCONFIG /RENEW” and press the Enter key. Verify that your IP Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.2.1. These values confirm that your LNWR100T is functioning correctly. Type “EXIT”...
  • Page 32 ONFIGURING LIENT Manual IP Configuration 1. Follow steps 1-5 in “DHCP IP Configuration” on page 3-9. 2. Select Use the following IP Address. 3. Enter an IP address based on the default network 192.168.2.x (where x is between 2 and 254), and use 255.255.255.0 for the subnet mask.

  • Page 33: Disable Http Proxy

    TCP/IP C ONFIGURATION Disable HTTP Proxy You need to verify that the “HTTP Proxy” feature of your web browser is disabled. This is so that your browser can view the LNWR100T’s HTML configuration pages. To disable the proxy in Internet Explorer, click Tools.

  • Page 34: Configuring Your Macintosh Computer

    ONFIGURING LIENT Configuring Your Macintosh Computer You may find that the instructions here do not exactly match your operating system. This is because these steps and screen shots were created using Mac OS 10.2. Mac OS 7.x and above are similar, but may not be identical to Mac OS 10.2.
  • Page 35 ONFIGURING ACINTOSH OMPUTER 3. If Using DHCP Server is already selected in the Configure field, your computer is already configured for DHCP. If not, select this option. 4. Your new settings are shown in the TCP/IP tab. Verify that your IP Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.2.1.

  • Page 36: Disable Http Proxy

    ONFIGURING LIENT Disable HTTP Proxy You need to verify that the “HTTP Proxy” feature of your web browser is disabled. This is so that your browser can view the LNWR100T’s HTML configuration pages. The following steps are for Internet Explorer. Internet Explorer 1.
  • Page 37 HAPTER ONFIGURING THE LNWR100T After you have configured TCP/IP on a client computer, use a web browser to configure the LNWR100T. The LNWR100T can be configured by any Java-supported browser such as Internet Explorer 5.5 or above. Using the web management interface, you can configure the LNWR100T and view statistics to monitor network activity.

  • Page 38: Configuring The Lnwr100T

    ONFIGURING THE LNWR100T Navigating the Web Browser Interface The LNWR100T’s management interface consists of a Setup Wizard, a Home Network Settings section, a Security section and an Advanced Settings section. Setup Wizard: Use the Setup Wizard for quick and easy configuration of your Internet connection and basic LAN settings.

  • Page 39: Making Configuration Changes

    AVIGATING THE ROWSER NTERFACE Making Configuration Changes Configurable parameters have a dialog box or a drop-down list. Once a configuration change has been made on a page, be sure to click the Apply or Save Settings or NEXT button at the bottom of the page to enable the new setting.

  • Page 40: Login Screen

    ONFIGURING THE LNWR100T Login Screen The Login screen automatically appears first. Enter the default password “lgnortel” and then click LOGIN.

  • Page 41: Setup Wizard

    ETUP IZARD Setup Wizard Getting Started The Setup Wizard automatically appears next. The first item in the Setup Wizard is Getting Started. Simply click NEXT to proceed to the following screen and configure your Wireless Settings.

  • Page 42: Wireless Settings

    ONFIGURING THE LNWR100T Wireless Settings Enter your wireless network settings on this page. You must specify a common radio channel and SSID (Service Set ID) to be used by the LNWR100T and all of its wireless clients. Be sure you configure all of its clients to the same value.
  • Page 43 ETUP IZARD Sup e r G Atheros’ Super G is a series of intelligent m echa nisms that engage when a d d itiona l ba ndwidth is availa ble a nd/or need ed. It incr eases the a ctual end user throughput of an 802.11a/b/g network.

  • Page 44: Internet Settings

    ONFIGURING THE LNWR100T Internet Settings Specify the WAN connection type required by your Internet Service Provider. Specify Cable modem, Fixed-IP xDSL, PPPoE xDSL or PPTP. Select your connection type to proceed. Click BACK to go back and change your settings.

  • Page 45: Cable Modem Settings

    ETUP IZARD Cable Modem Settings If the ISP requires you to input a Host Name, type it in the “Host Name” field. The “MAC Address” field will be filled automatically. Click NEXT to proceed, or BACK to change your settings.

  • Page 46: Adsl Settings - Fixed-Ip Xdsl

    ONFIGURING THE LNWR100T ADSL Settings - Fixed-IP xDSL Enter the IP address, Gateway IP address, DNS IP address, and Subnet Mask provided to you by your ISP in the appropriate fields below. Click NEXT to proceed, or BACK to change your settings. 4-10...

  • Page 47: Adsl Settings - Pppoe

    ETUP IZARD ADSL Settings - PPPoE Enter the User Name and Password required by your ISP in the appropriate fields. If your ISP has provided you with a Service Name enter it in the “Service Name” field, otherwise, leave it blank. Leave the Maximum Transmission Unit (MTU) at the default value (1454) unless you have a particular reason to change it.

  • Page 49: Home Network Settings

    ETWORK ETTINGS Home Network Settings Clicking the Home icon at any time, returns you to this home page. The Main Menu links are used to navigate to other menus that display configuration parameters and statistics. 4-13...
  • Page 50 ONFIGURING THE LNWR100T The LNWR100T’s Home Network Settings interface contains four main menu items as described in the following table. Menu Description Status Provides WAN connection type and status, firmware and hardware version numbers, system IP settings, as well as DHCP, NAT, and firewall information.

  • Page 51: Making Configuration Changes

    AKING ONFIGURATION HANGES Status The Status screen displays WAN/LAN connection status, firmware and hardware version numbers, as well as information on DHCP clients connected to your network. You can also view the Security Log. 4-15...

  • Page 53: Lan Settings

    AKING ONFIGURATION HANGES LAN Settings You can enable DHCP to dynamically allocate IP addresses to your client PCs, or configure filtering functions based on specific clients or protocols. The LNWR100T must have an IP address for the local network. The LAN Settings parameters are listed below. Parameter Description Wireless Router IP...
  • Page 54 ONFIGURING THE LNWR100T Parameter Description DHCP IP Address The DHCP IP Address Pool is the range of IP addresses set Pool aside for dynamic assignment to the computers on your network. Start IP This field indicates the first of the contiguous IP addresses in the IP address pool.

  • Page 55: Wan Settings

    AKING ONFIGURATION HANGES WAN Settings Specify the WAN connection type required by your Internet Service Provider. Specify Dynamic IP Address, PPPoE, PPTP or Static IP Address. Select the connection type and click More Configuration. 4-19...

  • Page 56: Dynamic Ip

    ONFIGURING THE LNWR100T Dynamic IP The Host name is optional, but may be required by some Service Provider’s. The default MAC address is set to the WAN’s physical interface on the LNWR100T. If required by your Service Provider, you can use the Clone MAC Address button to copy the MAC address of the Network Interface Card (NIC) installed in your PC to replace the WAN MAC address.

  • Page 57: Pppoe

    AKING ONFIGURATION HANGES PPPoE Enter the PPPoE user name and password assigned by your Service Provider. The Service Name is normally optional, but may be required by some service providers. Enter a Maximum Idle Time (in minutes) to define a maximum period of time for which the Internet connection is maintained during inactivity.

  • Page 58: Pptp

    ONFIGURING THE LNWR100T PPTP Enter the User ID and Password assigned by your ISP in the appropriate fields. Enter the Idle Time Out for the Internet connection. This is the period of time for which the connection to the Internet is maintained during inactivity. The default setting is 10 minutes.

  • Page 59: Static Ip

    AKING ONFIGURATION HANGES Static IP If your Service Provider has assigned a fixed IP address, enter the assigned IP address, subnet mask and the gateway address on this screen. Click Save Settings to proceed, or Cancel to change your settings. 4-23...

  • Page 60: Wireless

    ONFIGURING THE LNWR100T Wireless The LNWR100T can be quickly configured for roaming clients by setting the Service Set Identifier (SSID) and channel number. It supports data encryption and client filtering. To use the wireless feature, check the Enable check box and click Save Settings.

  • Page 61: Channel And Ssid

    AKING ONFIGURATION HANGES Channel and SSID Enter your wireless network settings on this screen. You must specify a common radio channel and SSID (Service Set ID) to be used by the LNWR100T and all of its wireless clients. Be sure you configure all of its clients to the same value.

  • Page 62: Wds

    ONFIGURING THE LNWR100T The Wireless Distribution System (WDS) provides a means to extend the range of a Wireless Local Area Network (WLAN). WDS allows the LNWR100T to establish a direct link to other wireless base stations and allows clients to roam freely within the area covered by the WDS.

  • Page 63: Security

    ECURITY Security The first menu item in the Security section is Firewall. The LNWR100T provides a stateful inspection firewall which is designed to protect against Denial of Service (DoS) attacks when activated. Its purpose is to allow a private local area network (LAN) to be securely connected to the Internet.

  • Page 64: Firewall

    ONFIGURING THE LNWR100T Firewall The LNWR100T’s firewall inspects packets at the application layer, maintains TCP and UDP session information including time-outs and the number of active sessions, and provides the ability to detect and prevent certain types of network attacks. Network attacks that deny access to a network device are called Denial-of-Service (DoS) attacks.

  • Page 65: Schedule Rule

    ECURITY Schedule Rule The first item listed in the Firewall section is Schedule Rule. You may filter Internet access for local clients based on rules. Each access control rule may be activated at a scheduled time. Define the schedule on the Schedule Rule page, and apply the rule on the Access Control page.

  • Page 66: Edit Schedule Rule

    ONFIGURING THE LNWR100T Edit Schedule Rule 2. Define the appropriate settings for a schedule rule (as shown on the following screen). 3. Upon completion, click OK to save your schedule rules, and then click Save Settings to make your settings to take effect. Each access control rule may be activated at a scheduled time.

  • Page 67: Access Control

    ECURITY Access Control Used in conjunction with the Schedule Rule screen, the Access Control screen allows users to define the outgoing traffic permitted or not-permitted. The default is to permit all outgoing traffic. The LNWR100T can also limit the access of hosts within the local area network (LAN).

  • Page 68: Access Control Add Pc

    ONFIGURING THE LNWR100T Access Control Add PC Define the access control list in this page. The settings in the screen shot below will block all email sending and receiving during weekdays (except Friday). Define the appropriate settings for client PC services (as shown above).

  • Page 69: Mac Filter

    ECURITY MAC Filter Use this page to block access to your network using MAC addresses. The LNWR100T can also limit the access of hosts within the local area network (LAN). The MAC Filtering Table allows the LNWR100T to enter up to 32 MAC addresses that are allowed access to the WAN port.

  • Page 70: Parental Control

    ONFIGURING THE LNWR100T Parental Control The LNWR100T allows the user to block access to web sites from a particular PC by entering either a full URL address or just a keyword. This feature can be used to protect children from accessing violent or pornographic web sites.

  • Page 71: Intrusion Detection

    ECURITY Intrusion Detection The LNWR100T’s firewall inspects packets at the application layer, maintains TCP and UDP session information including timeouts and number of active sessions, and provides the ability to detect and prevent certain types of network attacks such as Denial-of- Service (DoS) attacks.
  • Page 72 ONFIGURING THE LNWR100T Network attacks that deny access to a network device are called DoS attacks. DoS attacks are aimed at devices and networks with a connection to the Internet. Their goal is not to steal information, but to disable a device or network so users no longer have access to network resources.
  • Page 73 ECURITY The table below lists the Intrusion Detection parameters and their descriptions. Parameter Defaults Description Intrusion Detection Feature The Intrusion Detection feature of the LNWR100T SPI and Anti-DoS firewall protection limits the access of incoming traffic at the WAN port. When the Stateful Packet Inspection (SPI) feature is turned on, all incoming packets are blocked except those types marked with a check in the SPI section at the top of the screen.
  • Page 74 ONFIGURING THE LNWR100T Parameter Defaults Description Stateful Packet This option allows you to select different Inspection application types that are using dynamic port numbers. If you wish to use Stateful Packet Inspection (SPI) for blocking packets, click on the Yes radio button in the “Enable SPI and Anti-DoS firewall protection”...
  • Page 75 ECURITY Parameter Defaults Description Password Enter your email account password. Connection Policy Fragmentation 10 secs Configures the number of seconds that a packet half-open wait state structure remains active. When the timeout value expires, the router drops the unassembled packet, freeing that structure for use by another packet.
  • Page 76 ONFIGURING THE LNWR100T Parameter Defaults Description Incomplete 300 msecs Length of time before an incomplete TCP/UDP TCP/UDP session is detected as incomplete. sessions detect sensitive time period Maximum Maximum number of half-open fragmentation half-open sessions packets from the same host. fragmentation packet number from...

  • Page 77: Dmz

    ECURITY If you have a client PC that cannot run an Internet application properly from behind the firewall, you can open the client up to unrestricted two-way Internet access. Enter the IP address of a DMZ (Demilitarized Zone) host on this screen. Adding a client to the DMZ may expose your local network to a variety of security risks, so only use this option as a last resort.

  • Page 78: Wireless

    ONFIGURING THE LNWR100T Wireless The LNWR100T can be quickly configured for roaming clients by setting the Service Set Identifier (SSID) and channel number. It supports data encryption and client filtering. To use the wireless feature, check the Enable check box and click Save Settings.

  • Page 79: Wireless Encryption

    ECURITY Wireless Encryption The LNWR100T can transmit your data securely over a wireless network. Matching security mechanisms must be set up on your LNWR100T and your wireless client devices. Select the most suitable security mechanism from the drop-down list on this screen. Parameter Description No WEP, No WPA/WPA2...

  • Page 80: Access Control

    ONFIGURING THE LNWR100T Access Control For a more secure wireless network you can specify that only certain wireless clients can connect to the LNWR100T. Up to 32 MAC addresses can be added to the MAC Filtering Table. When enabled, all registered MAC addresses are controlled by the Access Rule.

  • Page 81: Wep

    ECURITY WEP is the basic mechanism to transmit your data securely over a wireless network. Matching encryption keys must be set up on your LNWR100T and each of your wireless client devices. Parameter Description WEP Mode Select 64-bit or 128-bit key to use for encryption. Key Entry Method Select hexadecimal (Hex) or ASCII for the key entry method.
  • Page 82 ONFIGURING THE LNWR100T You may automatically generate encryption keys or manually enter the keys. To generate the key automatically with passphrase, check the Passphrase box, and enter a string of characters. Select the default key from the drop-down menu. Click APPLY. Note: The passphrase can consist of up to 63 alphanumeric characters.

  • Page 83: Wpa/Wpa2

    ECURITY WPA/WPA2 WPA/WPA2 is a security enhancement that strongly increases the level of data protection and access control for existing wireless LAN. Matching authentication and encryption methods must be set up on your LNWR100T and wireless client devices to use WPA/WPA2.
  • Page 84 ONFIGURING THE LNWR100T WPA addresses all known vulnerabilities in WEP, the original, less secure 40 or 104-bit encryption scheme in the IEEE 802.11 standard. WPA also provides user authentication, since WEP lacks any means of authentication. Designed to secure present and future versions of IEEE 802.11 devices, WPA is a subset of the IEEE 802.11i specification.
  • Page 85 ECURITY 802.1X If 802.1X is used in your network, then you should enable this function for the LNWR100T. This screen allows you to set the 802.1X parameters. 802.1X is a method of authenticating a client wireless connection. Enter the parameters below to connect the LNWR100T to the Authentication Server.
  • Page 86 Parameter Description Server Type Sets the authentication server type. Server IP Set the IP address of your RADIUS server. Server Port Set the connection port that is configured on the radius server. Secret Key The 802.1X secret key used to configure the LNWR100T.

  • Page 87: Advanced Settings

    DVANCED ETTINGS Advanced Settings To configure the advanced settings such as NAT, Maintenance, System settings and UPnP, click Advanced Settings. Note: Changing some of the device settings in the Advanced Settings mode may cause the LNWR100T to become unresponsive. The LNWR100T’s advanced management interface contains 6 main menu items as described in the following table.

  • Page 88: Nat

    ONFIGURING THE LNWR100T The first menu item in the Advanced Settings section is Network Address Translation (NAT). This process allows all of the computers on your home network to use one IP address. Using the NAT capability of the LNWR100T, you can access the Internet from any computer on your home network without having to purchase more IP addresses from your ISP.

  • Page 89: Address Mapping

    DVANCED ETTINGS Address Mapping Network Address Translation (NAT) allows IP addresses used in a private local network to be mapped to one or more addresses used in the public, global Internet. This feature limits the number of public IP addresses required from the ISP and also maintains the privacy and security of the local network.

  • Page 90: Virtual Server

    ONFIGURING THE LNWR100T Virtual Server Using this feature, you can put PCs with public IPs and PCs with private IPs in the same LAN area. If you configure the LNWR100T as a virtual server, remote users accessing services such as web or FTP at your local site via public IP addresses can be automatically redirected to local servers configured with private IP addresses.

  • Page 91: Special Applications

    DVANCED ETTINGS Special Applications Some applications, such as Internet gaming, videoconferencing, Internet telephony and others, require multiple connections. These applications cannot work with Network Address Translation (NAT) enabled. If you need to run applications that require multiple connections, use the following screen to specify the additional public ports to be opened for each application.
  • Page 92 ONFIGURING THE LNWR100T Popular applications requiring multiple ports are listed in the Popular Applications field. From the drop-down list, choose the application and then choose a row number to copy this data into. Note: Choosing a row that already contains data will overwrite the current settings.

  • Page 93: Nat Mapping Table

    DVANCED ETTINGS NAT Mapping Table This page displays the current NAPT (Network Address Port Translation) address mappings. The NAT address mappings are listed 20 lines per page, click the control buttons to move forwards and backwards. As the NAT mapping is dynamic, a Refresh button is provided to refresh the NAT Mapping Table with the most updated values.

  • Page 94: Maintenance

    ONFIGURING THE LNWR100T Maintenance Use the Maintenance menu to back up the current settings, to restore previously saved settings, or to restore the factory default settings. Configuration Tools Check Backup Wireless Router Configuration and click NEXT to save your LNWR100T’s configuration to a file named config.bin on your PC.

  • Page 95: Firmware Upgrade

    AINTENANCE Firmware Upgrade Use this screen to update the firmware to the latest version. Click Browse... to locate the saved file. After locating the new firmware file, click BEGIN UPGRADE. Follow the instructions to complete the upgrade. After restarting, check the Status page to make sure the device is running the new code.

  • Page 96: Reset

    ONFIGURING THE LNWR100T Reset Perform a reset from this screen. To perform a system reset, click the Reboot Wireless Router button in the screen above. The configurations that you have set previously will not be changed back to the factory default settings. Note: You may also use the blue Reset button on the rear panel of the LNWR100T to perform a reset.

  • Page 97: System

    YSTEM System This section includes all the basic configuration tools for the LNWR100T, such as time settings, password settings, and remote management. Time Settings Set the time zone and time server for the LNWR100T. This information is used for log entries and client access control. Check Enable Automatic Time Server Maintenance to automatically maintain the LNWR100T’s system time by synchronizing with a public time server over the Internet.

  • Page 98: Password Settings

    ONFIGURING THE LNWR100T Password Settings Use this page to restrict access based on a password. For security you should assign one before exposing the LNWR100T to the Internet. Passwords can contain from 3 to12 alphanumeric characters and are case sensitive. Note: If your password is lost, or you cannot gain access to the user interface, press the Reset button (colored blue) on the rear panel (holding it down for at least six seconds) to restore the...

  • Page 99: Remote Management

    YSTEM Remote Management By default, management access is only available to users on your local network. However, you can also manage the LNWR100T from a remote host by entering the IP address of a remote computer on this screen. Check the Enabled check box, and enter the IP address of the remote host and click Save Settings.

  • Page 100: Snmp

    ONFIGURING THE LNWR100T SNMP Community Click SNMP and then Community to access the screen below. Use the SNMP configuration screen to display and modify parameters for the Simple Network Management Protocol (SNMP). A computer attached to the network, called a Network Management Station (NMS), can be used to access this information.

  • Page 101: Trap

    SNMP Trap Click SNMP and then Trap. This will load the SNMP trap screen shown below. Parameter Description IP Address Traps are sent to this address when errors or specific events occur on the network. Community A community string (password) specified for trap management.

  • Page 102: Upnp

    ONFIGURING THE LNWR100T UPnP Universal Plug and Play technology makes home networking simple and affordable. This architecture offers pervasive peer-to- peer network connectivity of PCs of all form factors, intelligent appliances, and wireless devices. UPnP architecture leverages TCP/IP and the web to enable seamless proximity networking in addition to control and data transfer among networked devices in the home, office, and everywhere in between.

  • Page 103: Routing

    OUTING Routing This section defines routing related parameters, including static routes and RIP (Routing Information Protocol) parameters. Static Route Click Add to add a new static route to the list. Parameter Description Index Index number of the route. Network Address Enter the IP address of the remote computer for which to set a static route.

  • Page 104: Rip

    ONFIGURING THE LNWR100T RIP sends routing-update messages at regular intervals and when the network topology changes. Parameter Description General RIP Parameters RIP Mode Globally enables or disables RIP. Auto summary If Auto summary is disabled, then RIP packets will include sub-network information from all subnetworks connected to the router.
  • Page 105 Parameter Description Poison Reverse A method for preventing loops that would cause endless retransmission of data traffic. Authentication None: No authentication. Required Password: A password authentication key is included in the packet. If this does not match what is expected, the packet will be discarded.

  • Page 106: Routing Table

    ONFIGURING THE LNWR100T Routing Table Click Routing Table to view the screen below. Parameter Description Flags Indicates the route status: C = Direct connection on the same subnet. S = Static route. R = RIP (Routing Information Protocol) assigned route. I = ICMP (Internet Control Message Protocol) Redirect route.
  • Page 107 PPENDIX ROUBLESHOOTING This section describes common problems you may encounter and possible solutions to them. The LNWR100T can be easily monitored through panel indicators to identify problems. Troubleshooting Chart Symptom Action LED Indicators Check connections between the LNWR100T, the Power LED is •...

  • Page 108: Troubleshooting

    ROUBLESHOOTING Troubleshooting Chart Symptom Action LED Indicators Verify that the LNWR100T and attached device are LAN LED is • powered on. Be sure the cable is plugged into both the LNWR100T • and the corresponding device. • Verify that the proper cable type is used and that its length does not exceed the specified limits.
  • Page 109 ROUBLESHOOTING Troubleshooting Chart Symptom Action Management Problems Be sure to have configured the router with a valid Cannot connect • IP address, subnet mask, and default gateway. using the web browser • Check that you have a valid network connection to the router and that the port you are using has not been disabled.
  • Page 110 ROUBLESHOOTING Troubleshooting Chart Symptom Action Wireless Problems A wireless PC • Make sure the wireless PC has the same SSID settings as the router. See “Channel and SSID” on page 25. cannot associate with the • You need to have the same security settings on the LNWR100T.
  • Page 111 PPENDIX ABLES Ethernet Cable Caution: Do not plug a phone jack connector into an RJ-45 port. For Ethernet connections, use only twisted-pair cables with RJ-45 connectors that conform to FCC standards. Specifications Cable Types and Specifications Cable Type Max. Length Connector 10BASE-T Cat.

  • Page 112: B Cables

    ABLES Each wire pair must be attached to the RJ-45 connectors in a specific orientation. The following figure illustrates how the pins on an Ethernet RJ-45 connector are numbered. Be sure to hold the connectors in the same orientation when attaching the wires to the pins. Figure B-1.

  • Page 113: Pin Assignments

    RJ-45 P THERNET ONNECTION Pin Assignments With 10BASE-T/100BASE-TX cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data. RJ-45 Pin Assignments Pin Number Assignment* * The “+” and “-” signs represent the polarity of the wires that make up each wire pair.
  • Page 114 ABLES Crossover Wiring If the port on the attached device has straight-through wiring (MDI), use crossover cable. Crossover Cable Pin Assignments End 1 End 2 1 (Tx+) 3 (Rx+) 2 (Tx-) 6 (Rx-) 3 (Rx+) 1 (Tx+) 6 (Rx-) 2 (Tx-)
  • Page 115 PPENDIX PECIFICATIONS Standards Compliance CE Mark IEEE 802.3 10 BASE-T Ethernet IEEE 802.3u 100 BASE-TX Fast Ethernet LAN Interface 4 RJ-45 10 BASE-T/100 BASE-TX ports Auto-negotiates the connection speed to 10 Mbps Ethernet or 100 Mbps Fast Ethernet, and the transmission mode to half-duplex or full-duplex WAN Interface 1 ADSL RJ-45 port Indicator Panel...
  • Page 116 PECIFICATIONS Advanced Features Dynamic IP Address Configuration – DHCP, DNS, DDNS Firewall – Client privileges, hacker prevention and logging, Stateful Packet Inspection Virtual Private Network – PPTP, IPSec pass-through, VPN pass-through, VLAN Ping Internet Standards RFC 826 ARP, RFC 791 IP, RFC 792 ICMP, RFC 768 UDP, RFC 793 TCP, RFC 783 TFTP, RFC 1483 AAL5 Encapsulation, RFC 1661 PPP, RFC 1866 HTML, RFC 2068 HTTP, RFC 2364 PPP over ATM Radio Features...
  • Page 117 PECIFICATIONS RF Output Power Modulation Rate-Output Power (dBm) 802.11b - 1Mbps 16 802.11b - 2Mbps 16 802.11b - 5.5Mbps 16 802.11b - 11Mbps 16 Modulation Rate-Output Power (dBm) 802.11g - 6Mbps 15 802.11g - 9Mbps 15 802.11g - 12Mbps 15 802.11g - 18Mbps 15 802.11g- 24Mbps 15 802.11g - 36Mbps 15...

  • Page 118: Specifications

    PECIFICATIONS Environmental LNWR100T complies with the following standards: Temperature Operating 0 to 40 °C (32 to 104 °F) Storage -40 to 70 °C (-40 to 158 °F) Humidity 5% to 95% (non-condensing) Vibration: IEC 68-2-36, IEC 68-2-6 Shock: IEC 68-2-29 Drop: IEC 68-2-32 IEEE Standards IEEE 802.3, 802.3u, 802.11g, 802.1D...
  • Page 119 JAN/2008/ISSUE 1.0...
