Manchester
(Model 8330)
Pellet Stove
OWNER'S MANUAL
Installation & Operating
Instructions
Please read this entire manual before installation and use of this pellet fuel burning room heater.
Failure to follow these instructions could result in property damage, bodily injury, or even death.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION REQUIREMENTS IN YOUR AREA.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
Manchester Pellet Model 8330
Report:
261-S-04b-2
Manual: 6400-40468
R: 2 - 3/2/2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Manchester 8330 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HearthStone Manchester 8330

Summary of Contents for HearthStone Manchester 8330

  • Page 1 Manchester (Model 8330) Pellet Stove OWNER’S MANUAL Installation & Operating Instructions Please read this entire manual before installation and use of this pellet fuel burning room heater. Failure to follow these instructions could result in property damage, bodily injury, or even death. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA.
  • Page 2 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Intentionally Blank Page 2 of 59...

  • Page 3: Table Of Contents

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Table of Contents Introduction ..........................4     Important Notes ..............................4 Specifications ........................6     General Specifications ............................7   Electrical Specifications ............................7 Components ........................... 8  ...

  • Page 4: Introduction

    Your decision to purchase a Hearthstone Manchester Pellet stove reflects a choice to purchase a premium product and a technology which is carbon neutral, meaning that operation of this stove will not introduce any “new”...
  • Page 5 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Introduction Ensure young children are carefully supervised when in the same room as the appliance. Do not place clothing or other flammable material on or near the appliance. Fire Hazard In the unlikely event of a soot, or creosote fire –...

  • Page 6: Specifications

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Specifications Listed as: Pellet-Fired Direct-Vent Fireplace Heater Model: Manchester Pellet (8330) Testing Agency: OMNI-Test Laboratories, Inc. Tested to:  ASTM E 1509-04 Standard Specification for Room Heaters, Pellet Fuel-Burning Type ...

  • Page 7: General Specifications

    116 volts your stove may not work properly. Ensure that the polarity of the electrical receptacle that the stove is plugged into is correct.) Fuse replacement: 3.5 amp minimum to 4 amp maximum rating. Hearthstone PN 7000-185 Watts used (startup) (approx)……………………………….………….300 Watts Watts used (max/high burn) (approx)………………………………….160 Watts...

  • Page 8: Components

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Components Components and features: Maintenance Tool Hopper Door Handle Heat Exchanger Rake Rod (x2) Firebox Baffle Front Door Pellet Door Feed Burn Pot Handle Tube Ash Pan Burn Pot...
  • Page 9 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Components Room Sensor & Thermostat Connectors Fuse Panel Mounting Screws (6) STB Reset Switch Rear Cover Panel Outside Air Inlet Exhaust Vent Motherboard Hopper Housing Exhaust Vent Auger Motor...

  • Page 10: Installation

    We recommend that installation and repair of this Hearthstone pellet stove only by a qualified Hearthstone dealer. We recommend inspection of the stove and venting before use and at least annually by a qualified service person. Periodic cleaning is required throughout the heating season and at the end of each winter for the stove to work safely and efficiently.

  • Page 11: Clearance To Combustibles

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Installation Clearance to Combustibles 1. D = 6” (152mm) minimum (16” (410mm) recommended to allow side door opening for service), E = 2” (51mm), F = 1” (25mm), G = 6” (152mm), H = 24” (610mm), I = 24” (610mm), and J = 2” (51mm).

  • Page 12: Manufactured & Mobile Home Installations

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Installation Manufactured & Mobile Home Installations WARNING: DO NOT INSTALL IN SLEEPING ROOM. CAUTION: THE STRUCTURAL INTEGRITY OF THE MANUFACTURED HOME FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED. Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start or ‘freshen up’...

  • Page 13: Room Sensor Installation

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Installation Room Sensor Installation We recommend you install your Manchester Pellet stove with the provided room sensor for optimum efficiency and comfort. The room sensor is a wired remote temperature probe for the stove’s electronic control system.
  • Page 14 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Installation 3. Remove a small length of the cover from the thermostat wire. Strip approximately ¼ inch insulation off the wires. Insert one wire on each side of the connector – tighten the screws.

  • Page 15: Venting

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting Note: Only 3” or 4” L or PL venting is approved for use on this stove. DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST VENTING SYSTEM OF THIS UNIT.
  • Page 16 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting Warning: Ensure your venting system (chimney connector, and chimney) are in good condition and kept clean. The minimum horizontal clearance to vegetation and other exterior combustibles such as mulch is 36” as measured from the center of the outlet or termination cap.

  • Page 17: Outside Air

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting Outside Air WARNING: CONNECT THE STOVE TO OUTSIDE AIR WHEN REQUIRED! We recommend you connect your Manchester Pellet Stove to an outside air source to achieve the most efficient and productive operation.
  • Page 18 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting NSTALLATION XAMPLE LASS HIMNEY Class A Chimney installed to code 3” L Vent Outside air inlet Use this installation when the pellet stove replaces an existing wood stove with a Class “A” chimney.
  • Page 19 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting NSTALLATION XAMPLE ERTICAL HROUGH THE EILING AND 3” L Vent Outside air inlet Use this vent configuration on new installations where there are limitations to venting out the side wall.
  • Page 20 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting NSTALLATION XAMPLE XISTING ASONRY IREPLACE HIMNEY 3” L Vent Seal flue around L vent with noncombustible material 3” Flex L Vent Typical installation for use with an existing Masonry Fireplace Chimney.
  • Page 21 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting NSTALLATION XAMPLE XISTING ASONRY HIMNEY 4” L Vent Installed into an existing masonry chimney with a full-length 4” L vent liner. Page 21 of 59...
  • Page 22 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting NSTALLATION XAMPLE XISTING ASONRY HIMNEY Approved Liner 3 or 4” L Vent Installed into an existing masonry chimney with no L Vent liner (chimney must have other approved liner in good condition, and a working clean-out).
  • Page 23 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting NSTALLATION XAMPLE ENTING WITH ERTICAL Use these configurations to minimize the chance of smoke spillage in the room during a power outage. This vent configuration will generate its own draft. There must not be any combustible material within 36” of the outlet and the termination must be at least 18”...
  • Page 24 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting NSTALLATION XAMPLE ORIZONTAL ENTING Use of this method is acceptable as long as there is no combustible material within 36” of the termination, and the termination is at least 18” above grade.
  • Page 25 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Venting NSTALLATION XAMPLE ORIZONTAL ENTING Use of this method is acceptable as long as there is no combustible material within 36” of the termination, and the termination is at least 18” above grade.

  • Page 26: Operation

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Operation CAUTION: HOT WHILE IN OPERATION! KEEP CHILDREN, CLOTHING, AND FURNITURE AWAY. CONTACT MAY CAUSE SKIN BURNS. CAUTION: DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE. CAUTION: DO NOT BURN GARBAGE, FLAMMABLE LIQUIDS SUCH AS GASOLINE, NAPHTHA, OR ENGINE OIL.

  • Page 27: Modes Of Operation

    Thermostat – Optional mode. Requires an external milli-volt thermostat sold at your local Hearthstone dealer or hardware store. Automatic – Easiest automatic mode. Requires the use of the Hearthstone’s Room Sensor (included with the stove). Programmable – Best automatic mode. Requires the use of the Hearthstone’s Room Sensor (included with the stove).

  • Page 28: Quick Operations Guide

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Quick Operations Guide Page 28 of 59...
  • Page 29 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 29 of 59...
  • Page 30 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 30 of 59...
  • Page 31 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 31 of 59...
  • Page 32 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 32 of 59...
  • Page 33 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 33 of 59...
  • Page 34 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 34 of 59...
  • Page 35 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 35 of 59...
  • Page 36 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 36 of 59...
  • Page 37 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 37 of 59...
  • Page 38 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 38 of 59...
  • Page 39 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 39 of 59...
  • Page 40 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 40 of 59...
  • Page 41 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Page 41 of 59...
  • Page 42 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Operation Set the Current Time/Date (Programmable Mode) Prog Action 70 F Step 1: From the main display press twice. time Time Step 2: Press the button to enter the menu.
  • Page 43 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Operation Programming the Heating Schedule (Programmable Mode) The stove can be programmed with two different set temperatures, one home and one away. Each of these set temperatures have two different times they can be switched on. The stove can use the same Home and Away time every day of the week or they can be set differently for every day.
  • Page 44 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Operation To Adjust Home and Away Temperature (Programmable Mode) Action Prog Home Step 1: From the main display press to view the set temperature or 70 F Away to view the set temperature.
  • Page 45 To minimize the potential for smoke entering the room Hearthstone suggests installing the unit with a minimum of five feet of vertical venting and the use of outside air intake venting.

  • Page 46: Ash Disposal

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Operation Turning On and Off the Frost Setting Prog Action 70 F Step 1: From the main display press three times. setup setup Step 2: Press the button to enter the menu.

  • Page 47: Maintenance

    WARNING: DO NOT CLEAN THE GLASS WHILE THE STOVE IS BURNING, OR WHEN THE GLASS IS HOT. Proper maintenance is essential to clean and reliable performance of your Hearthstone Stove. Your Manchester Pellet stove requires routine maintenance and care. Ensure your stove is cool to the touch and unplugged during cleaning or service.

  • Page 48: Weekly Or As Needed

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Maintenance Weekly or as Needed Remove ash from firebox 1. Lift burn pot, sweep ashes into ash pan or use an ash vacuum. WARNING! USE OF A REGULAR VACUUM MAY CAUSE A FIRE.

  • Page 49: Yearly Or Every Ton Of Pellets

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Maintenance Yearly or Every Ton of Pellets Top Casting Rear Panel Clean Hopper, Auger & Exterior of Pellet Engine 1. Remove hopper door – vacuum hopper and auger inlet.
  • Page 50 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Maintenance Clean Convection Fan 1. Remove the screen panel (4 screws) – vacuum screen and inside housing, remove any build up from fan blades with soft bristle brush. Remove Screen.

  • Page 51: As Needed

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Maintenance As Needed External Cleaning WARNING: DO NOT CLEAN THE UNIT WHEN HOT OR WHEN ANY SIGN OF COMBUSTION IS PRESENT. External Cleaning - The unit should receive regular cleaning on, under, and around the stove to prevent the buildup of dust and lint.

  • Page 52: Glass Replacement Procedures

    12. After 5 or 6 fires, check the glass retainer screws, and retighten if necessary. Required Glass Kit: Part Number: 90-58901 (Glass with gasket applied). Use only 5mm Ceramic IR, or Neoceram IR glass. Contact your Hearthstone dealer. Page 52 of 59...

  • Page 53: Troubleshooting

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Troubleshooting Most errors and issues are due to a lack of required maintenance, or cleaning. Using the instructions on the following pages should resolve most issues. If an operation error is detected, the user interface flashes, and displays a message.
  • Page 54 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Display Problem Possible Causes Solution Flame Temp sensor in Flame sensor not working Reset the unit using the power switch Sensor – firebox is and contact your dealer if the problem...

  • Page 55: General Issues

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove General Issues: Problem Possible Causes Solution Burn pot is overflowing. Burn pot needs cleaning Remove excess ashes, clinkers, and live coals from burn pot Ignition did not occur Clean burn pot...
  • Page 56 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Problem Possible Causes Solution Low heat output Excessive soot on heat Follow procedure in the Maintenance exchanger section of this manual. Poor quality, or wet pellets Consult your Hearthstone dealer for a...

  • Page 57: Replacement Parts & Optional Accessories List

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Replacement Parts & Optional Accessories List PART PART DESCRIPTION: DESCRIPTION: NUMBER: NUMBER: CASTINGS:* GASKETS: 2010-915 ASH DOOR 3110-056 GASKET: ROPE,1/4”,BLK,AD 2010-997 HOPPER DOOR HANDLE 3110-057 GASKET: ROPE,3/8”,AD,NON-CORE 2310-300 3120-021...

  • Page 58: Safety Label

    Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Safety Label Page 58 of 59...
  • Page 59 Hearthstone Quality Home Heating Products, Inc. Manchester Model 8330 Pellet Stove Customized Set Up Data: Page 59 of 59...
