Video Conference Screen
O W N E R ' S
M A N U A L
To the Owner
Installation Instructions
Operating the Screen
Maintenance
VCS-1007
T
: B
.
O T H E I N S TA L L E R
E S U R E T O L E AV E T H I S M A N U A L W I T H T H E O W N E R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCS-1007 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stewart Filmscreen Corp VCS-1007

  • Page 1 Operating the Screen Maintenance VCS-1007 O T H E I N S TA L L E R E S U R E T O L E AV E T H I S M A N U A L W I T H T H E O W N E R...
  • Page 2 Printed in U.S.A. ©2007 Stewart Filmscreen Corporation Stewart Filmscreen reserves the right to make changes to the product specified in this document. From time to time, this document is updated. Current versions of documentation are posted on the Stewart Filmscreen website at www.stewartfilm.com.

  • Page 3: Table Of Contents

    Video Conference Screen O W N E R ’ S M A N U A L Contents To the Owner ........2 Receiving and Removal from Shipping Crate .

  • Page 4: To The Owner

    O THE WNER Congratulations on your purchase of the finest optical viewing screen available anywhere in the world! Please take a moment to review this manual, it will help ensure you many years of trouble-free service from your new Stewart Filmscreen product. About the Video Conference Screen The Video Conference Screen housing consists of an automated electric door, electric retractable projection screen, and electrically operated camera...

  • Page 5: Receiving And Removal From Shipping Crate

    ECEIVING AND EMOVAL FROM HIPPING RATE The Video Conference Screen is large and heavy and requires special attention relating to shipping and transportation. Keep the following information in mind when moving the crate from the truck to the final mounting location. The shipping crate needs to remain flat at all times.

  • Page 6: Preparing The Installation

    REPARING THE NSTALLATION Before proceeding with the installation of this screen, take time to thoroughly read and understand these installation and operation instructions. All electrical wiring installations must conform to local and national codes and should be performed by qualified service personnel. There are no user-serviceable parts contained within the unit.

  • Page 7: Step 1. Hanging The Case

    1. H ANGING THE Professional mounting techniques should be used. Stewart Filmscreen Corporation cannot be liable for substandard or faulty installations. Make sure that you mount the screen so that the electrical box is on the left side (audience left). The Video Conference Screen is fully assembled and ready to install into the ceiling or soffit.

  • Page 8: Step 2. Electrical Connection

    High voltage AC input connection We advise this connection be done by a qualified AV technician or electrician. Stewart Filmscreen Corp. cannot be held liable for faulty or substandard connections. Connect the AC input line to the electrical junction box located on the left end of the housing.
  • Page 9 Low Voltage Control with 3-button momentary wall switch (standard control) A standard Low Voltage Control is sequentially tied to each motor. A 3- button momentary switch can be connected to the switching input terminals. Use 20 - 24 ga. 4-conductor electronic communication wire to connect to the switch input wire located in the switch connection junction box.

  • Page 10: Operating The Screen

    PERATING THE CREEN The factory has secured the screen and camera pod for transportation. Follow the "First time activation" instructions to ensure any packing products and/or system lockdown brackets are completely removed when the door is first opened, before deployment of the screen and camera pod. First time activation 1.

  • Page 11: Adjusting The Screen Extension

    DJUSTING THE CREEN XTENSION The extension and retraction limit switches have been preset at the factory. In general, we advise you to avoid readjusting these switches. In some cases, to enable proper alignment of the displayed image on the screen, you may need to adjust the extension of the screen or the mask. If adjustment to the extension is necessary, carefully follow these instructions.

  • Page 12: Screen Care And Cleaning

    CREEN ARE AND LEANING With reasonable care, you may expect many years of trouble-free use of your Stewart Video Conference Screen. We encourage you to keep your screen clean. To protect your screen when it is not in use, store it in the fully retracted position. Avoid getting any foreign material on the screen, as cleaning may prove very difficult.

  • Page 13: Troubleshooting

    Problem description Probable cause Action to take Door won't open. No AC power available. Check to see if the circuit breaker has switched off. Reset if needed. Screen won't operate. Outboard switching problem. Check outboard switching apparatus. Door not fully opened. Check voltage availability.

  • Page 14: Product Warranty

    RODUCT ARRANTY LIMITED ONE YEAR WARRANTY ON STEWART FILMSCREEN CORP PROJECTION SCREENS SYSTEM STEWART FILMSCREEN CORPORATION (Stewart) warrants its screens to the original purchaser only, to be free from defects in materials and workmanship for a period of one (1) year from the date of purchase by the...
  • Page 15 AINTENANCE OTES...
  • Page 16 www.stewartfilm.com 1-800-762-4999 Fax (310) 326-6870...
