Summary of Contents for Stewart Filmscreen Corp Cine V
- Page 1 Stewart Filmscreen Corporation Cine Assembly Instructions.
-
Page 2: Table Of Contents
CineV Owner’s Manual Contents To the Owner…………………………………………….1 Preparing the Installation………………………………..2 Frame Assembly and Wall Mount………………………3 Attaching the Screen to the Frame………………………4 Operating the Cine V…………………………………….5 Screen Care and Cleaning……………………………….6 Product Warranty………………………………………..7 Troubleshooting…………………………………………8... -
Page 3: To The Owner
TO THE OWNER Congratulations on your purchase of one of the finest optical viewing screens available anywhere in the world. Please take a moment to review this manual, it will help ensure you many years of trouble-free service from your new Stewart Filmscreen product. -
Page 4: Preparing The Installation
Preparing the Installation Preparation Specifications regarding the individual screen dimensions, weight, mounting type, and controls are provided by the factory when the unit is ordered. Before beginning the installation: ♦ Check the specifications for the frame and the mounting to be used. ♦... - Page 5 CineV Components This section identifies the principal components of the CineV. The unit is shipped in several different sections: the top, bottom and side member sections, top section with a motor assembly on the outside, plus mounting brackets. Figure 1. CineV components, rear view Side view Motors.
-
Page 6: Frame Assembly And Wall Mount
Frame Assembly and Wall Mount Professional mounting techniques should be used. Stewart Filmscreen Corporation cannot be liable for substandard or faulty installations. This section describes assembly and mounting of the CineV frame. Assemble the frame by fitting together the slip joints of the side sections. -
Page 7: Attaching The Screen To The Frame
ATTACHING THE SCREEN TO THE FRAME This section provides instructions for attaching the screen to the frame. Caution ♦ Be sure that your hands and clothing are clean. Use of gloves is recommended. Be careful not to touch or scratch the image surface with fingernails. ♦... -
Page 8: Operating The Cinev
Operating the CineV CineV operation is controlled by a Stewart Filmscreen VICS. Refer to the VICS manual for details. You can use either a hand-held remote control or a wall mounted switch to operate the masks. Caution Keep objects and fingers out of the way of the mask when they are in motion. -
Page 9: Troubleshooting
Troubleshooting With reasonable care, you may expect many years of trouble free use of your Stewart projection screen. Refer to following guidelines if you encounter a difficulty in the operation of your Stewart screen. Problems related to electrical or motor function may require a qualified service or electrician.
