Model: 87103
Microwave Oven
User's Manual
Please read these instructions carefully before installing and operating the oven.
Record in the space below the SERIAL NO. found on the nameplate on your oven and retain
this information for future reference.
SERIAL NO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 87103 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kenmore 87103

Summary of Contents for Kenmore 87103

  • Page 1 Model: 87103 Microwave Oven User's Manual Please read these instructions carefully before installing and operating the oven. Record in the space below the SERIAL NO. found on the nameplate on your oven and retain this information for future reference. SERIAL NO.

  • Page 2: Table Of Contents

    Do not attempt to operate this oven with the door-open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.

  • Page 3: Precautions To Avoid Possible Exposure To Excessive Microwave Energy

    Do not use straight-sided containers with narrow necks. After heating, allow the container to stand in the microwave oven for a short time before removing the container. Use extreme care when inserting a spoon or other utensil into the container.

  • Page 4: Save These Instructions

    The electrical requirements are a 120 volt 60 Hz, AC only, 15 amp. It is recommended that a grounding plug and a 3-slot receptacle that will accept the plug on the microwave oven. The marked rating of the extension cord shall be equal to or...

  • Page 5: Limited Use

    RADIO OR TV INTERFERENCE Should there be any interference caused by the microwave oven to your radio or TV, check that This section lists which utensils can be used in the microwave, which ones have limited use for short periods, and which ones should not be used in the microwave.

  • Page 6: Cooking Techniques

    Use only small amounts of aluminum TEST MICROWAVE OVEN USE: Fill a 8 oz (250ml) glass measure with water and place it in the microwave oven along with the container to be tested;...

  • Page 7: Specifications

    Power Consumption: Output: Operation Frequency: Outside Dimensions(H×W×D): Oven Cavity Dimensions(H×W×D): Oven Capacity: Cooking Uniformity: Net Weight: Model: 87103 120V~60Hz, 1200W (MICROWAVE) 1000W 2450MHz 12×20 11/16×17 7/8 ×13 ×14 1.0cu.ft Turntable System (Φ12 Approx.

  • Page 8: Speed Defrost

    MENU ACTION SCREEN Cooking time, power, indicators and present time are displayed. QUICK COOK BUTTONS Instant settings to cook popular foods POWER Use to set power levels other than high. TIMER Timer functions independently, even while a cooking program is in process. COOK Use for multi-stage cooking.
  • Page 9 SIGNALS DURING OVEN SETTINGS ONE SIGNAL: Oven accepts the entry. TWO SIGNALS: Oven does not accept the entry, check and try again. ETTING THE CLOCK Touch CLOCK pad. Use the number pads to enter the correct time. You must touch at least three numbers to set the clock(one for hour and two for minutes).
  • Page 10 Touch COOK then enter proper cooking time and (lower) power level. (Most 2-stage recipes use lower power for second stage.) Touch START. NOTE: After total time has elapsed, 4 signals sound and END appears in display. Touch STOP/RESET or open oven door to clear END before starting another cooking function.

  • Page 11: Setting Child Lock

    ·Let meat stand few minutes before carving. EFROST BY WEIGHT Touch DEFROST BY WEIGHT pad. Enter weight. Touch START pad. NOTE: ·Weight must be in pounds and ounces. Ounce weights less than 10 must be preceded by a 0. If label gives weight in pounds only, change the fraction of a pound to ounces using the chart given above.

  • Page 12: Pizza

    For the large 8 to 10 oz. potatoes: Touch POTATO twice. Enter number of potatoes by touching number pads from 1 to 4. Cooking times for large potatoes are as follows: 1 potato 6 min. 25 sec. 2 potatoes 12 min. 00 sec. 3 potatoes 17 min.

  • Page 13: Cleaning And Care

    If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may occur when the microwave oven is operated under high humidity conditions. In such case, it is normal.

  • Page 14: Warranty

    WARRANTY This product carries a warranty that it will be free from defects in material and workmanship for a period of one year from the date of purchase. NOTE: This warranty does not cover damages resulting from accident, misuse or abuse, lack of reasonable care, the affixing of any attachment not provided with the product, loss of parts, or subjecting the appliance to any but the specified voltage.
