- Page 1 AN1001 GSM FIXED WIRELESS TERMINAL USER MANUAL V 4.3 This manual contains important information. Please read before using the equipment. AN1001 GSM FWT User Manual Rev 4.3 April 2010...
-
Page 2: Table Of Contents
Contents 1 Introduction………………………………………………………………3 2 Warning…………………………………………………………………..3 3 Function Description……………………………………………………..4 4 Operation Guide………………………………………………………….5 5 Configuration and Installation……………………………………………6 6 Setting Instructions……………………………………………………….7 7 Technical Data……………………………………………………………8 AN1001 GSM FWT User Manual Rev 4.3 April 2010... -
Page 3: Introduction
Congratulations on choosing an Aristel GSM Fixed Wireless Terminal. Your Aristel Fixed Wireless Terminal ( FWT ) is designed to work on GSM networks . It can be connected to single line telephones ( SLT ) or PABX systems using analogue trunks. -
Page 4: Function Description
6. The equipment should be installed and maintained by a qualified personal. Position the antenna in a location where signal strength is not impaired. 3 Function Description The AN1001 FWT has the following: 1. Standard RJ12 phone socket interface. 2. Caller ID with DTMF. -
Page 5: Operation Guide
Make a call When the correct LEDs are on, and you hear dial tone after you pick up the handset or connect to the PBX trunk, then you can make a call. AN1001 GSM FWT User Manual Rev 4.3 April 2010... -
Page 6: Configuration And Installation
⑤ Using the 2 wire line cord provided, connect the SLT or cordless phone. For PBX working, connect to analogue trunk. If required, ensure that the telephone system’s LCR or ARS has been programmed before making calls. Turn the power switch on.. AN1001 GSM FWT User Manual Rev 4.3 April 2010... -
Page 7: Setting Instructions
6. Setting instructions for AN1001 1. To turn CLI on outgoing calls: Off hook, dial ***99*810529#, after a "DI", dial 0528*1#. “DO” is heard to indicate a successful setting, while “DO Do” to indicate failure. 2. To turn CLI on outgoing calls: Off hook, dial ***99*810529#, after a "DI", dial 0528*0#. -
Page 8: Technical Data
Antenna transmission power: < 3 W Impedance: 50 ohm Working environment: ℃ ~ ℃ Operation temperature: 0 Operation humidity: 45% ~ 95% Non condensing condition Power requirement : 12 volt DC – 1 amp. www.aristel.com.au AN1001 GSM FWT User Manual Rev 4.3 April 2010...
