Summary of Contents for TYG LSA22BC08
- Page 1 COMPACT ACTIVE SPEAKER SYSTEM COMPACT ACTIVE SPEAKER SYSTEM USER'S MANUAL USER'S MANUAL LSA22BC08...
- Page 3 Active Speaker System Important instruction of safety issues and symbols 1. Read these prescriptions. 2. Keep this user manual. 3. Pay attention to all the notices. 4. Comply with these rules. 5. Warning: in order to avoid fire or hit by the thunder, do not put the devices in the rain or in the wet environment.
- Page 4 Email: info@tygglobal.com Important precaution The design of the TYG products has already taken the safe requirement into consideration and all the finished products have been tested under the requirements of the government before sale. However, as there is dangerous high voltage and electricity in the products, users must read the notice in this manual.
-
Page 5: Product Introduction
Active Speaker System Product Introduction Introduction ： LSA22BC08 1) Full range active speaker with three units and two frequencies. 2) High SPL and high performance 3) Two 8-inch and high-efficiency units for bass. 4) One 1.33 inch titanium compressed driver. - Page 6 Active Speaker System Rear panel function introduction Rear panel function introduction Clip Indication Lamp Signal Indication Lamp XLR balanced signal input socket Pin 2 connects anode (HOT), Pin 3 connects cathode (COLD), Pin 1 connects shield (GOUND). Advise: No matter how long the distance is, the balanced connection method is advised.
-
Page 7: System Connection Instructions
Active Speaker System System Connection Instructions LSA22BC08 Connection Example Signal Input Connection -1 Input Connection -2 CLIP CLIP Input Connection Input Connection XLR INPUT XLR INPUT SENSITIVITY:0.775V SENSITIVITY:0.775V XLR: XLR: PIN1= PIN1= PIN2= + XLR Connects with mixer. XLR Connects with... -
Page 8: Installation Instructions
Picture 2 Installation Guide Map -2 Installation Instruction 1.LSA22BC08 can be installed as Picture 3 with the vertical frame 2.LSA22BC08 can be installed as Picture 4 with the hexagonal annular frame. Wall Picture 3 Picture 4... - Page 9 Active Speaker System Product Dimensions LSA22BC08 speaker dimension 250mm Front view Left view Top view...
- Page 10 Active Speaker System Notices on the Maintenance Notices on the maintenance: Notice 1. The grill is fixed by the screws on both sides, and it can be disassembled through drawing the screws. Please take the grill off the speaker gradually and when assemble it, please make sure the grill has connected with speaker very well before installing the screws.
- Page 11 Active Speaker System Product Testing Graph...
-
Page 12: Specification
Active Speaker System Specification Model LSA22BC08 Output Power HF50W/LF200Wx2 Driver HF: 1 x 1.33 inch Compression driver LF: 2 x 8 inch bass Frequency Response 70Hz-18kHz Effective frequency 60Hz-20kHz MAX SPL at 1m 119dB Crossover Frequency 2.5kHz Point angle H=90... - Page 13 Active Speaker System Malfunction Elimination Malfunction Elimination No reaction Confirm the AC power wire connect to the socket with electricity. Detect the power supply by other equipment, such as lamp. 2) No sound, but power indicator green LED is on Confirm the input sound source.
- Page 14 You” or “Your” ) for the time periods and as set forth below. Under this Limited Warranty, TYG will, at its option, (i) repair the product using new or refurbished parts or (ii) replace the product with a new or refurbished product.
- Page 16 TYG reserves the right to make changes in specifications or products without prior notice.
