skeye.pos mobile
HW 90396
Version 2.01
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the skeye.pos mobile and is the answer not in the manual?

Questions and answers

Related Manuals for Hoft & Wessel skeye.pos mobile

Summary of Contents for Hoft & Wessel skeye.pos mobile

  • Page 1 HW 90396 Version 2.01 Instruction Manual...
  • Page 2 This document and its contents shall not be reproduced or transferred in any form without express permission. Compensation will be claimed for any infringement. All rights reserved in the event of patenting or registration of utility models. © Höft & Wessel AG 2010 Subject to amendment, errors excepted BDA_skeye.POS_mobile_V201-Admin_EN.doc...

  • Page 3: Table Of Contents

    2. Technical Description ....................17 Views of the skeye.pos mobile ................17 2.1.1 Top View of the skeye.pos mobile ..............17 2.1.2 Top Side View of the skeye.pos mobile ............18 2.1.3 Bottom Side View of the skeye.pos mobile .............18 2.1.4 Rear View of the skeye.pos mobile..............19 2.1.5...
  • Page 4 4.12 Replacing the Cover....................26 5. Desktop Cradle ......................26 Setting up the Desktop Cradle ................26 Placing and Removing the skeye.pos mobile from the Desktop Cradle ....26 LED Function Display of the Desktop Cradle ............26 Connecting the Desktop Cradle to a Desktop PC ..........26 6.
  • Page 5 TABLE OF CONTENTS 9.2.2 Restoring a Backup ..................26 9.2.3 Deleting a Backup...................26 10. Communication/Data Exchange................26 10.1 Driver Installation for Data Synchronization ............26 10.2 Accessing the Internet with a Wireless LAN Card ..........26 10.3 Ethernet Settings....................26 10.4 GSM Settings ......................26 10.5 GPRS Settings ......................26 10.6 WLAN Settings......................26 10.6.1 Switching on the WLAN Module ..............26 10.6.2 Connection with a WLAN-Access Point ............26...

  • Page 6: Introduction

    If you continue to use the device, there is a risk of fire and electric shock. Have the device repaired by the bring-in service. ♦ Please note that the paper cutter on the skeye.pos mobile is sharp and can cause cuts if handled carelessly.

  • Page 7: Safety Instructions For The Battery

    1.1.2 Safety Instructions for the Battery A lithium-ion battery is fitted at the rear of the skeye.pos mobile. The lithium-ion battery is characterized by a high energy density. It is thermally stable, delivers a constant voltage throughout the discharge period and is not subject to a memory effect.

  • Page 8: Safety Notes For The Docking Station/ Battery Charger

    INTRODUCTION Thermal Shock ♦ The battery must not be: • used or charged close to sources of heat such as heaters or open fires! • connected to cigarette lighters and other chargers! • thrown into a fire or heated! • recharged close to open fires or in extremely hot weather! •...

  • Page 9: Safety Instructions For The Power Supply

    INTRODUCTION ♦ If the docking station/battery charger changes shape or colour, generates heat or in any way appears abnormal stop using it. Return it to the distributor or manufacturer from whom you purchased the docking station/battery charger. ♦ Use the docking station/battery charger only with the supplied power supply. The main voltage must correspond to the technical data mentioned on the power supply.

  • Page 10: Safety Notes On The Imager With Led Aimer

    INTRODUCTION Warranty instructions ♦ Only use genuine accessories with your skeye.pos mobile. Failure to comply with this regulation will invalidate the warranty. ♦ Never attempt to open your skeye.pos mobile and/or carry out repairs and/or modifications yourself. The manufacturer accepts no liability for any damage that may be incurred as a result.

  • Page 11: Safety Notes On Radio Transmission

    Radio devices (such as GSM) are subject to certain restrictions when used in proximity to electronic instruments: Switch off the skeye.pos mobile when instructed to switch off your mobile phone (for instance in hospitals, care facilities, planes). ♦ When being in an aircraft completely power off your skeye.pos mobile (see chapter 3.2.).

  • Page 12: How To Secure Your Wireless Network

    INTRODUCTION 1.1.7.1 How to Secure your Wireless Network We have compiled some tips below to make unauthorised access to your WLAN more difficult. a. Change the password of the router or access point (very important). These units are factory-set to a default password. If you do not change this password anybody can re-configure your router or access point.

  • Page 13: Safety Instructions For Data Loss

    Normal Use The skeye.pos mobile is designed for use in commercial environments and is used exclusively for data acquisition and transmission purposes (e.g. for selling goods) inside buildings or vehicles or in outside areas under moderate climatic conditions.

  • Page 14: Explanations For The Instruction Manual

    1.3.2 Contents of the Instruction Manual The instruction manual has been structured in such a way as to allow you start using your skeye.pos mobile quickly. The instruction manual is organized into the following sections: ♦ Introduction ♦ Safety Instructions ♦...

  • Page 15: Purpose Of The Document

    INTRODUCTION Purpose of the Document This user manual provides comprehensive user instructions. Target Audience This documentation is aimed at all users of the skeye.pos mobile. Terminology skeye.pos mobile Versatile mobile terminal suitable for a wide range of HW 90396 applications. Referred to below as the "skeye.pos mobile".

  • Page 16: Product Description

    INTRODUCTION Product Description Operating system: Microsoft Windows CE 5.0 Interfaces: The interfaces provided on the skeye.pos mobile allow the use of a wide range of accessories and options Communication: The device can communicate with other systems in different ways: • Infrared: IrDA 1.0 (SIR=115200 baud) •...

  • Page 17: Technical Description

    TECHNICAL DESCRIPTION Technical Description Views of the skeye.pos mobile 2.1.1 Top View of the skeye.pos mobile Printer Paper Cutter Display with Touch Screen Buttons Shoulder Strap Attachment Slot Fig. 1: Top view of the skeye.pos mobile 2.01 • 25.03.2010 17...

  • Page 18: Top Side View Of The Skeye.pos Mobile

    Top Side View of the skeye.pos mobile Printer Cover Stylus Release Lever Shoulder Strap Attachment Slot Fig. 2: Top side view of the skeye.pos mobile 2.1.3 Bottom Side View of the skeye.pos mobile Shoulder Strap Attachment Slot Fig. 3: Bottom side view of the skeye.pos mobile...

  • Page 19: Rear View Of The Skeye.pos Mobile

    Fig. 4: Rear view of the skeye.pos mobile 2.1.5 Ride Side View of the skeye.pos mobile Magnetic Card Swipe Slot Cut-out for Stylus Microfone IrDA Window Chip Card Imager Reader Slot Headset Connection (lineout) Fig. 5: Right side view of the skeye.pos mobile 2.01 • 25.03.2010 19...

  • Page 20: Views Of The Desktop Cradle

    Top View of the Desktop Cradle Green Yellow Connection to the Function skeye.pos mobile Displays Desktop Cradle Clips Fig. 6: Top View of the Desktop Cradle Function skeye.pos mobile Displays Fig. 7: Top view of the desktop cradle with skeye.pos mobile fitted 2.01 • 25.03.2010...

  • Page 21: Front View Of Desktop Cradle

    TECHNICAL DESCRIPTION 2.2.2 Front View of Desktop Cradle skeye.pos mobile Lever for unlocking the skeye.pos mobile Fig. 8: Front view of the desktop cradle with skeye.pos mobile fitted 2.01 • 25.03.2010 21...

  • Page 22: Rear View Of Desktop Cradle

    TECHNICAL DESCRIPTION 2.2.3 Rear View of Desktop Cradle Power RJ45 connection for Ethernet USB–B type USB–A type Serial Interface Fig. 9: Rear view of desktop cradle; location of connections *The Ethernet connection only works when your device equipment supports this function. 2.01 •...

  • Page 23: User Instructions

    USER INSTRUCTIONS User Instructions Switching On the skeye.pos mobile Note that you can only switch on the skeye.pos mobile after you have inserted a charged battery and locked it in place! Battery Recess Plug-type Battery Plug-type Battery Lock Connection Connection on...
  • Page 24 20 days, it switches to the "Complete Off" status to conserve the floating battery. The skeye.pos mobile cannot be switched on using the yellow button when it is in the "Complete Off" status. To do this, you must reset the skeye.pos mobile.

  • Page 25: Switching Off The Skeye.pos Mobile

    The skeye.pos mobile does not switch to suspend mode if it is executing program processes, for example, when transmitting data or updating master data. In addition to the suspend mode, the skeye.pos mobile can be switched off to 2 further statuses using the "PowerOff" software function.
  • Page 26 Services such as wireless connections must be restarted. Partially Off: The skeye.pos mobile is switched off. The contents of the RAM are deleted. All settings are deleted. When the device is switched on again, Windows is reloaded in the memory and restarted.

  • Page 27: Removing The Stylus

    Only use the stylus supplied to operate the touch screen, as the touch screen may be damaged if you use a different stylus! Stylus Fig. 14: Right side view of the skeye.pos mobile 1. Use your thumb to push the stylus out of the casing. Fig. 15: Detailed side view; removing the stylus Operating the skeye.pos mobile with the Stylus...

  • Page 28: Reading A Magnetic Card

    • warped or • cracked 1. Pull the magnetic card smoothly and at right angles to the skeye.pos mobile from the top to the bottom of the swipe slot. Fig. 16: Reading a magnetic card Fig. 17: Bottom side view magnetic card at right angle to skeye.pos mobile...

  • Page 29: Inserting A Chip Card

    Slot Chip Card Fig. 18: Right side view of the skeye.pos mobile; position of the swipe slot for chip cards 1. Push the chip card all the way to the stop (approx. 1.2 inches or approx. 3 cm) with the chip facing down in the reader slot.

  • Page 30: Scanner Operation

    USER INSTRUCTIONS Scanner Operation When using the scanner, the skeye.pos mobile should be positioned as shown in the following figure: Barcode Abb. 1: skeye.pos mobile, Position beim Scannen The following figures show the positions for directing the scanner beam onto the bar codes.

  • Page 31: Tearing Paper Along The Paper Cutter

    USER INSTRUCTIONS Tearing Paper along the Paper Cutter In order to reduce the weight of the skeye.pos mobile, the printer was not fitted with an automatic cutting device. The paper is extremely robust, which is why it may rip if it is not torn off at the correct angle.

  • Page 32: Maintenance And Support

    MAINTENANCE AND SUPPORT Maintenance and Support Attaching the Shoulder Strap on the skeye.pos mobile Both sides of the skeye.pos mobile are fitted with a shoulder strap attachment slot. Shoulder Strap Attachment Slot Fig. 21: Bottom side view of the skeye.pos mobile 1.

  • Page 33: Attaching The Shoulder Strap (2)

    MAINTENANCE AND SUPPORT Attaching the Shoulder Strap (2) A further variant of the skeye.pos mobile has a receptacle on both sides used for a shoulder strap including key ring. Receptacle for should strap and key ring Fig. 23: Lower side view of the skeye.pos mobile 5.

  • Page 34: Resetting The Skeye.pos Mobile

    3. Press the reset button carefully with very little effort. A reset is performed and the skeye.pos mobile switches on automatically. Another reset button is located under the battery (see next page).
  • Page 35 Battery Eject Button Button Fig. 26: Detail rear view of the skeye.pos mobile with battery removed; location of the second reset button 1. Remove the battery. (see Ch. 4.7, Page 26). 2. Activate the reset button carefully with very little effort. You can use a straightened paper clip or a similar object to do this.

  • Page 36: Resolving Printer Faults

    (see Ch. 4.9.4, Page 26). Replacing the Paper Roll for the Printer When replacing the paper roll, avoid touching the paper cutter on the skeye.pos mobile. The paper cutter is fitted with sharp teeth that could easily cut your fingers. Printer Cover Release Lever Fig.
  • Page 37 MAINTENANCE AND SUPPORT 2. Hold the printer cover at the outer sides and fold it upwards. Printer Cover Paper Compartment Paper Cutter Fig. 28: Inserting the paper roll 3. Carefully remove the empty paper roll from the paper compartment. 4. Insert the new paper roll as shown in Fig. 28. 5.

  • Page 38: Removing The Battery From The Skeye.pos Mobile

    MAINTENANCE AND SUPPORT Removing the Battery from the skeye.pos mobile It is necessary to remove the battery from the skeye.pos mobile in order to: • replace the battery, • access the second reset button, • insert or remove the CF card.
  • Page 39 5. Continue folding the battery upwards and remove it. The battery is now removed. To conserve the floating battery when not in use, the skeye.pos mobile should always be stored with a charged battery fitted! Otherwise the power reserves in the floating battery will be consumed.

  • Page 40: Inserting The Battery Into The Skeye.pos Mobile

    4. Press the battery down so that it sits neatly in the battery recess. The battery is correctly positioned in the battery recess (see the figure below). Battery Lock Battery Fig. 31: Rear view of the skeye.pos mobile; correctly fitted battery 2.01 • 25.03.2010...
  • Page 41 Instructions for Replacing the Battery: If you lock a charged battery within three minutes, you can continue working from the same point after you switch on the skeye.pos mobile again, as is usual after the "Suspend Mode". If the battery is not locked within three minutes, the skeye.pos mobile switches to the "Partially Off"...

  • Page 42: Cleaning

    1. Press the yellow button to switch off the skeye.pos mobile. The display goes out and the skeye.pos mobile switches to "Suspend Mode". 2. Clean the display with screen cleaner and a soft, clean, lint-free cloth. To preserve the surface of the screen, clean the display using a vertical wiping motion! 2.01 •...

  • Page 43: Cleaning The Contacts Of The Card Reader

    MAINTENANCE AND SUPPORT 4.9.3 Cleaning the Contacts of the Card Reader The chip card contacts and the contacts on the magnetic strip reader must be regularly cleaned. Use uncoded moist microfiber cleaning cards for this purpose (Höft & Wessel order number: E29749). Only use freshly unpacked cleaning cards as the cleaning fluid on the card evaporates very quickly.

  • Page 44: Cleaning The Paper Recess, Sensor And Light Barrier

    MAINTENANCE AND SUPPORT 4.9.4 Cleaning the Paper Recess, Sensor and Light Barrier When cleaning, avoid touching the paper cutter on the skeye.pos mobile. The paper cutter is fitted with numerous sharp teeth that could easily cut your fingers. Use only compressed air for cleaning! Do not blow with your mouth as this could blow paper dust into your eyes.

  • Page 45: Inserting The Sim Card

    . It will be locked by Slide the SIM card with the chip pointing down into the card slot pressure. Card Slot Fig. 34: skeye.pos mobile with removed storage battery and security module, location of the GSM card receptacle 2.01 • 25.03.2010 45...
  • Page 46 5. Install the security module. 6. Insert the battery (see chap. 4.8, page 26). 7. Slide the battery lock to the right to this symbol: The battery is now locked and you can switch on the skeye.pos mobile. 2.01 • 25.03.2010...

  • Page 47: Changing The Cf Card

    Battery Lock Eject Button Fig. 35: Rear view of skeye.pos mobile with battery removed; location of the slot for a CF card 3. Press the eject button to the right of the slot. The CF card is ejected and can be removed.
  • Page 48 The CF card is now correctly fitted. 6. Insert the battery (see Ch. 4.8, Page 26). 7. Slide the battery lock to the right to the symbol The battery is now locked and you can switch on the skeye.pos mobile. 2.01 • 25.03.2010...

  • Page 49: Replacing The Cover

    The cover is pushed in flush with the underside of the skeye.pos mobile. The cover has a recessed grip that allows you to push it in and pull it out. If your device is equipped with wireless functions, this cover contains components.

  • Page 50: Desktop Cradle

    DESKTOP CRADLE Desktop Cradle Setting up the Desktop Cradle Cradle with connection for the skeye.pos mobile RJ45 connection Power for Ethernet USB–B type Serial Interface USB–A type Fig. 38: Rear view of desktop cradle; location of connections 1. Connect the power supply to the desktop cradle.

  • Page 51: Placing And Removing The Skeye.pos Mobile From The Desktop Cradle

    Fig. 39: Placing the skeye.pos mobile on the desktop cradle Placing the skeye.pos mobile 1. Check that the skeye.pos mobile contains a battery and that it is locked in place. If so, continue to step 2 If not, insert a battery and lock it in place (see Ch. 4.8, Page 26).
  • Page 52 DESKTOP CRADLE Fig. 40: The skeye.pos mobile correctly positioned on the desktop cradle Removing the skeye.pos mobile Before it can be removed from the desktop cradle, the skeye.pos mobile must be unlocked. Lever Fig. 41: Unlocking 1. Slide the lever to the right.

  • Page 53: Led Function Display Of The Desktop Cradle

    • Indicates that the desktop cradle is ready for operation Red LED • Indicates that the desktop cradle is transmitting data Yellow LED • Indicates that the skeye.pos mobile is correctly positioned Green LED and connected Connecting the Desktop Cradle to a Desktop PC...

  • Page 54: Battery Charger

    Insert the battery in the battery charger in exactly the same way as in the Battery skeye.pos mobile. Position the battery vertically in the area marked, with the rounded side facing downwards. Fold the battery down and press it into place.

  • Page 55: Led Function Display Of The Battery Charger

    BATTERY CHARGER LED Function Display of the Battery Charger Three light emitting diodes (LED) are provided to display the operating states. Yellow Green Fig. 44: Location of the LEDs Red LED • Indicates that the battery charger is ready for operation Continuously lit •...

  • Page 56: Handling The Batteries (Power Management)

    An unused battery must be recharged every three months. After this length of time, the battery is discharged to such an extent due to self-discharging that it can no longer be used to operate a skeye.pos mobile. In terms of maintenance, bear the following points in mind: Good: •...

  • Page 57: Maintaining The Internal Floating Battery

    The internal floating battery requires no maintenance. The skeye.pos mobile automatically charges the internal floating battery. If the skeye.pos mobile is not placed on a desktop cradle for an extended period, the internal floating battery is charged from the battery.

  • Page 58: Storing The Skeye.pos Mobile With The Battery

    An empty floating battery can cause the skeye.pos mobile to malfunction. Discharged floating batteries must be replaced by qualified service personnel. The skeye.pos mobile can be stored in "Complete Off" mode with a charged battery for up to six months without maintenance.

  • Page 59: Influencing The Battery Endurance

    The device switches to "Suspend Mode" default: 2 min (Auto suspend) The times at which the skeye.pos mobile switches from one status to the other can be changed using the "AutoOff" function in the Control Panel. 1. Choose Start ⇒ Settings ⇒ Control Panel ⇒...

  • Page 60: Additional Functions And Settings

    HWImagerTool can be used to scan into any text field (e.g. WordPad). Calmly and angularly hold the skeye.pos mobile in the direction of the barcode to be scanned. A peep indicates that the entry of the barcode has been successful. The distance should amount to about 10 cm.

  • Page 61: Displaying And Hiding The Keyboard

    ADDITIONAL FUNCTIONS AND SETTINGS Displaying and Hiding the Keyboard Displaying: Tap the symbol in the menu bar and select the required keyboard. Hiding: Tap the symbol in the menu bar and select "Hide Input Panel". Hiding the Numerical Keyboard If you select "skeye Keyboard" or "Large Keyboard", you can limit the keyboard to numerical keys (numeric pad) only.

  • Page 62: Setting The Properties Of The Input Panel (Keyboard)

    ADDITIONAL FUNCTIONS AND SETTINGS Setting the Properties of the Input Panel (Keyboard) 1. Choose Start ⇒ Settings ⇒ Control Panel. The "Control Panel" window opens. 2. In the "Control Panel" window, select the "Input Panel" symbol by double-tapping. The "Input Panel Properties" window opens. Fig.

  • Page 63: Calibrating The Touch Screen

    ADDITIONAL FUNCTIONS AND SETTINGS Calibrating the Touch Screen This function is required for fine adjustment of the touch screen, i.e. the more precisely the touch screen is calibrated, the more precisely it reacts. Note the following when calibrating the touch screen: Touch the screen lightly but firmly! Do not pull the stylus across the touch screen! Do not rest your hand on the touch screen!
  • Page 64 ADDITIONAL FUNCTIONS AND SETTINGS 3. Follow the same procedure for the crosses subsequently displayed. After the last cross, the "Apply" inquiry window appears with a timer in the calibration window. 4. Tap on the [Apply] button to confirm. The calibration window is closed and the following confirmation message appears: Fig.

  • Page 65: Setting The Date And Time

    ADDITIONAL FUNCTIONS AND SETTINGS Setting the Date and Time 1. Choose Start ⇒ Settings ⇒ Control Panel. The "Control Panel" menu opens. 2. In the "Control Panel" menu, select the "Date/Time" symbol by double-tapping. The "Date/Time Properties" window opens Fig. 51: The "Date/Time Properties" window 3.

  • Page 66: Entering Owner Properties

    ADDITIONAL FUNCTIONS AND SETTINGS Entering Owner Properties 1. Choose Start ⇒ Settings ⇒ Control Panel. The "Control Panel" menu opens. 2. In the "Control Panel" menu, select the "Owner" symbol by double-tapping. The "Owner Properties" window opens. Fig. 52: The "Owner Properties" window 3.

  • Page 67: Adjusting The Brightness

    ADDITIONAL FUNCTIONS AND SETTINGS Adjusting the Brightness 1. Choose Start ⇒ Settings ⇒ Control Panel. The "Control Panel" menu opens. 2. In the "Control Panel" menu, select the "Backlight" symbol by double-tapping. The "Backlight" window opens. Fig. 53: The "Backlight" window, "Brightness" tab 3.

  • Page 68: Setting The Volume & Sounds

    ADDITIONAL FUNCTIONS AND SETTINGS 8.10 Setting the Volume & Sounds Deactivating sounds will save energy and extend the lifetime of the batteries. 1. Choose Start ⇒ Settings ⇒ Control Panel. The "Control Panel" menu opens. 2. In the "Control Panel" window, select the "Volume & Sounds" symbol by double-tapping.

  • Page 69: Creating An Additional Symbol On The Desktop

    ADDITIONAL FUNCTIONS AND SETTINGS 8.11 Creating an Additional Symbol on the Desktop If particular functions are frequently required, it is useful to store them on the desktop. If a frequently required function is missing from the desktop, proceed as follows: 1.

  • Page 70: Installing Software

    When choosing software, always check that it is compatible with the operating system used. If you intend installing the software permanently on your skeye.pos mobile, you must save it in the "FlashDisk" folder. Otherwise, the data will be deleted, for example, when the device is switched to "Complete Off".

  • Page 71: Data Backup

    For this reason, all important files and programs should be saved in the "FlashStorage" folder. You should therefore back up the data on your skeye.pos mobile as often as possible! We also recommend that you copy important data onto your desktop PC or other storage media such as CDs.

  • Page 72: Sysbackup

    DATA BACKUP SysBackup You can use the "SysBackup" program to • create, • play back and • delete a backup. 9.2.1 Creating a Backup You should copy all important data to the "\FlashDisk" folder or its subdirectories. To ensure that all system settings are not lost after the battery is discharged or the device is switched to "Complete Off", you must save everything.
  • Page 73 DATA BACKUP Fig. 57: The "SysBackup" window with the "Execute backup?" message 3. Confirm the "Execute backup?" message with [Yes]. The SysBackup is executed. On completion, the following message appears. Fig. 58: The "SysBackup" window with the "Backup completed" message 4.

  • Page 74: Restoring A Backup

    DATA BACKUP 9.2.2 Restoring a Backup 1. Open the "SysBackup" program. Fig. 59: The "SysBackup" program 2. In the "SysBackup" window, select the [restore] button by tapping. The "Execute restore?" message appears. Fig. 60: The "SysBackup" program with the "Execute restore?" message 3.

  • Page 75: Deleting A Backup

    DATA BACKUP 9.2.3 Deleting a Backup 1. Open the "SysBackup" program. Fig. 61: The "SysBackup" program 2. In the "SysBackup" window, select the [delete] button by tapping. The "Erase backup files?" message appears. Fig. 62: The "SysBackup" program with the "Erase backup files?" message 3.

  • Page 76: Communication/Data Exchange

    Device Stage ⇒ for Windows 7 These programs are available for free via www.Microsoft.com/getstarted. With this program you can handle the following tasks: adding and removing programs on the skeye.pos station synchronization of files transfer and copying of files 10.2...
  • Page 77 COMMUNICATION/DATA EXCHANGE 1. Double-tap the "CFConfig" symbol on the desktop. The "Interface Config" window opens. Fig. 63: The "Interface Config" window 2. Activate the checkbox "Enable internal Ethernet controller (LAN)" in the "Interface Config" window. 3. Close the "Interface Config" window with [OK]. 4.

  • Page 78: Gsm Settings

    COMMUNICATION/DATA EXCHANGE 10.4 GSM Settings 1. Go to Start ⇒ ⇒ ⇒ ⇒ Settings ⇒ ⇒ ⇒ ⇒ Network and Dial-up Connections This opens the Network Connections window. Fig. 65: Network Connections Window 2. Double click Make New Connection. This will open the „Make New Connection“ dialog box. Fig.
  • Page 79 COMMUNICATION/DATA EXCHANGE This will open the “Modem” dialog box. Fig. 67: Modem Dialog Box 4. Configure the Modem • Under “Select a Modem: “ select COM1: GSM/GPRS • Select [Configure]. This opens the „Device Properties“ dialog box. Fig. 68: Device Properties Dialog Box 5.
  • Page 80 COMMUNICATION/DATA EXCHANGE 6. In the Modem window, tap [Next >]. This will open the „Make New Dial-up Connection“ dialog. Fig. 69: Make New Dial-up Connection window using freenet 7. In the Make New Dial-up Connection dialog box, configure the GSM connection for your Internet Service Provider: •...
  • Page 81 COMMUNICATION/DATA EXCHANGE • User name: Enter the user name for the Internet Service Provider, for instance freenet or (or <no entry> for Vodafone) • Password: Enter the password for the Internet Service Provider, for instance for freenet “mobile” (or <no entry> for Vodafone) •...
  • Page 82 COMMUNICATION/DATA EXCHANGE 15. This will open the „Connecting to GSM“ dialog. Fig. 73: Connecting to GSM dialog box 16. Press [Cancel] (as you do not wish to connect right now). 17. Close the Network Connections dialog box. You will need to manually enter the PIN number for your GSM SIM card using a terminal program.

  • Page 83: Gprs Settings

    COMMUNICATION/DATA EXCHANGE 10.5 GPRS Settings 1. Go to Start ⇒ ⇒ ⇒ ⇒ Settings ⇒ ⇒ ⇒ ⇒ Network and Dial-up Connections This opens the Network Connections window. Fig. 74: Network Connections Window 2. Click Make New Connection. This will open the "Make New Connection" dialog box.. Fig.
  • Page 84 COMMUNICATION/DATA EXCHANGE Configure the GPRS Properties as follows: • Under Select a Modem: "COM1: select GSM/GPRS • Select [Configure]. This opens the „Device Properties“ dialog box. Fig. 77: Device Properties Dialog Box; Port Settings Tab 4. Configure the Port Settings tab as follows: •...
  • Page 85 COMMUNICATION/DATA EXCHANGE Fig. 79 : GPRS Modem Dialog Box 8. Tap the [TCP/IP Settings] button. This will open the „TCP/IP Settings“ dialog: Fig. 80: TCP/IP Settings dialog, General tab 9. Configure the General tab as follows: • Enable Use server-assigned IP address •...
  • Page 86 COMMUNICATION/DATA EXCHANGE Fig. 81: TCP/IP Settings dialog, Name Server tab with Vodafone as example 11. Enter the DNS address and the Alt. DNS for your provider. 12. Close the TCP/IP Settings with [OK]. This will open the "GPRS Modem" window. Fig.
  • Page 87 COMMUNICATION/DATA EXCHANGE Fig. 83: Security Settings Dialog Box 14. In this window, do the following: • Enable Challenge Handshake Authentication Protocol (CHAP) • Enable Microsoft CHAP (MS-CHAP) • Enable Microsoft CHAP, Version 2 (MS-CHAP v2) 15. Close the Security Settings dialog with [OK]. This will open the „GPRS Modem“...
  • Page 88 COMMUNICATION/DATA EXCHANGE Fig. 85: Phone Number tab with Vodafone as example 17. Enter the encrypted string in the phone number field. 18. Close the dialog with Finish. 2.01 • 25.03.2010...

  • Page 89: Wlan Settings

    COMMUNICATION/DATA EXCHANGE 10.6 WLAN Settings 10.6.1 Switching on the WLAN Module To improve the power management, the internal CF slot for WLAN in the mobile terminal is switched off by default. 1. Double-tap the CFConfig icon on your desktop. This will open the „Interface Config“ dialog. Fig.

  • Page 90: Connection With A Wlan-Access Point

    COMMUNICATION/DATA EXCHANGE 10.6.2 Connection with a WLAN-Access Point A double click on the WLAN symbol in Systray opens the relevant WLAN configuration window Fig. 88: IP Information window After opening of the tab „Wireless Information“ all found SSIDs of the access points are listed: Fig.
  • Page 91 COMMUNICATION/DATA EXCHANGE Meaning of the symbols: Symbol Meaning Network not available Available network connected Network available By double click on the requested access point name you reach the WLAN connection configuration dialogue. Fig. 90: Wireless Network Properties window Here, you can configure additional parameters like Ad-hoc mode, encryption methods (WEP, WPA) and possibly necessary encryption keys.
  • Page 92 COMMUNICATION/DATA EXCHANGE After a successful connection the access point entry with the symbol as well as the connections quality should be displayed. Fig. 91: Wireless information Window In case the access point or the connected network server supports the automatic TCP/IP address allocation, this work is done by the WLAN module.

  • Page 93: Setting Of A Static Tcp/Ip Address For The Wlan Module

    COMMUNICATION/DATA EXCHANGE 10.6.3 Setting of a static TCP/IP address for the WLAN module 1. Select Start ⇒ ⇒ ⇒ ⇒ Settings ⇒ ⇒ ⇒ ⇒ Network and Dial-up Connections Dialogue "Network and Dial-up Connections" with further options for WLAN network settings is displayed. Fig.

  • Page 94: Appendix

    APPENDIX Appendix 11.1 Hardware Data • Ergonomically shaped: Equally suitable for left and right- Casing: handed users • Plastic stylus for touch control stored in casing. (stylus) • Fastener for shoulder strap Dimensions: Case dimensions (W x H x D) in mm •...

  • Page 95: Special Commands

    System Special Result Command Reset Resets the skeye.pos mobile. All running programs are terminated. SysBackup Creates a backup of, or restores, all programs and data in the RAM in the flash disk. This is useful, for example, in advance of switching the device to Complete Off.

  • Page 96: Manufacturer's Address

    APPENDIX 11.3 Manufacturer's Address Höft & Wessel AG Rotenburger Str. 20 30659 Hannover Phone. +49 511 6102 0 Fax. +49 511 6102 411 Service-Line. +49 1803 23 28 29 (within Germany 0.09 EUR per min) Web. www.hoeft-wessel.de Mail. info@hoeft-wessel.de 2.01 • 25.03.2010...

  • Page 97: Index

    Calling at any Time 60 Data Loss 13 Creating a New Symbol 69 Desktop cradle power supply 9 Desktop cradle General 6 Placing the skeye.pos mobile 51 Scanner operation 30 Desktop Cradle Setting the Date 65 Connecting 53 Setting the Sounds 68...
