Summary of Contents for GoShockFree GSFF50
- Page 1 GSFF50 http://stores.ebay.com.au/Goshockfree...
- Page 2 Thanks for purchasing this product. Please read the instructions carefully before using this product. • FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 3 Caution 1. Do not drop, puncture or disassemble the device; otherwise the warranty will be voided. 2. Avoid all contact with water, and dry hands before using. 3. Use the device with care. Avoid pressing hard on the device body. 4.
-
Page 4: Product Description
Product Description This DVR (Digital Video Recorder) is a dual-channel simultaneous video recording product dedicated for the evolving need of recording devices for automobiles. It features superior compact digital audio/video recording and high quality photo taking capability, high speed USB2.0 interface, and parallel battery charging and filming operation. -
Page 5: Specifications
Specifications Image sensor 3.0MP CMOS WXGA HD Video resolution 480P/720P/720P_H Simplified Chinese/ Traditional Chinese/ English/ Language Russian/ Japanese/ Korean/ Italian/ Spanish/ French/ Portuguese/ German Display 2.7" 16:9 TFT display Memory Support up to 32GB Micro SD card Focus 2m-limitless Picture JPEG Built-in microphone USB2.0... - Page 6 Technical Specifications: 1 Charging Indicator 2 MIC light 3 Mode 4 Menu 5 OK/Rec 6 Front Lens 7 On/Off/SOS 8 Down 9 Up 10 Display 11 LENS Aperture 12 Bracket Slot 13 Reset 14 HDMI Slot 15 GPS module 16 GPS slot 17 USB Slot 18 TF/SD card slot 19 Mic...
-
Page 7: Button Functions
Button Functions POWER/SOS Turn on/ turn off/ SOS emergency MENU Opens the device menu MODE Switch between the camera modes available Start/Pause/Confirm DOWN Down /Zoom out Up/ Zoom In Installation & Operation: Mount the device preferably behind the rear view mirror or anywhere which does not restrict the driver’s vision of the road. -
Page 8: Date/Time Setup
Battery: The device includes an in built a 600mAh lithium battery. It will take about 90minutes to charge it completely in off state. The battery can be charged when DVR is in operation. The working current is about 380mA for normal and 580mA for night vision operation. - Page 9 corner of the display will show icon. There are three resolutions 1.3M, 3M, and 5M, for choice. Photo mode works only with the wide angle camera. Playback Mode Within Device: 1. Press “MODE” 3 times from video recording mode to enter the playback mode to check the video images taken.
- Page 10 Playback on PC A CD has been included in the packaging containing the required software to play the video files concurrently with GPS information. Please install this software first before proceeding. Once installed please enter the program by running Once installed the player should load and will look like the image below. Open the folder containing the videos you wish to play back, drag the video into the player.
- Page 11 You will now be able to view your video with speed and location information. To view the map please click the google maps icon selected in red.
