Dizmax Technology DOP2012F Manual

3- AXIS DOME CAMERA
DOP2012F
MANUAL
◐ PR ECAUTION
1 . Do not ins tall the camera outdoors.
2. Choose a n ideal location for the camera, since a c amera unit must
be protected against moisture and vibration.
3. Be careful not to scratch the camera unit, especially lens or dome cover.
4. Use the camera within the temperature(- 10
5. Handle with care. Dropping it can cause serious damage to the camera.
6. Avoid any direc t sun light toward the lens.
7. Use the AC adaptor 12V DC 300mA regulated.
◐ FE ATURE S
1 . This camera is incredibly flexible to install with its 3- axis camera con-
struction, which makes the camera ceiling, wall or slope mountable.
2. Compact size dome cover(85 phi)
3. RS- 485 interface(Pelco- D, Pelco- P protocol support) - Option
4. Advanced High Resolution(700 TV- Line) - Option
5. Support 4 different privacy zone
6.DWDR(Digital Wide Dynamic Range)
7. Multi function : High Light Mask, Lens Shading Compensation, Impact
Detection(Option), Motion Detection
8. Multi- language full OSD support
◐ HOW TO INSTALL
1. Opening the dome : Pushing the latch button.
< Caution >Remove the protection sheet after installing.
P ROTE CTION S HEET
LATCH BUT TON
2. Removing the dome
button, it is unlocked and you can lift the dome.
3. C amera installation
(1 ) Fix the camera setwith the supplied screws on ceiling or wall mount.
If you don't use supplied screws, the camera may fall off.
(2) Please refer to '4. Camera angle adjustment' regarding adjust
camera angle.
(3) Lens adjustment(Vari- focal Lens only)
By turning the "Tele- Wide" knob,
you can acces s a ra nge of focal
lengths within specified limits.
Since then, by turning the "Near- Far"
knob, you can set the focus toward
~ +50 ).
the wanted object.
(4) Re- as semble the camera.
<Ceiling mount>
S CR EW TP13.5x20 2EA
<Wall mount>
SC RE W TP13.5x20 2E A
:
Lift the dome. When you push the latch
:
4. C amera angle adjustment :
(1) Pan a djustment : Gras p the disk of camera and then adjust
direction to the right or left(- 180 ~ 180 ) ˚
(2) Tilt adjustment : Grasp the lens cover of camera and then
adjust direc tion to the up or down(6 ~ 90 ) ˚
(3) Roll a djustment : Gras p the camera holder and then rotate
(- 1 78 ~ 178 ) ˚ ˚
<Caution> If you try to adjust the camera out of limited angle, it might cause
trouble s and damage to camera.
R
L
U
ROTATION
D
DIMENSION
Ø 85
Ø 1 10
ASSEMBLY
HARNESS
If the product is to be put out of operation definitively,
take it to a local recycling plant for a dis posal which
is not harmful to the environment.
˚
˚
LE NS C OVER
DISK
CAMER A HOLDER
Ø 84
BODY
DOME COVER
INNER DOME COVER
BOARD CA MER A AS S ' Y
SC RE W
SC RE W
C ONTR OL PCB
PUSH BUTTON
DISK
BA SE
CABLE
