- Page 1 TOTAL VEHICLE TECHNoLOGIES 4.3” GPS Rearview Mirror with Bluetooth User Manual TD43TOUCHPLUS...
- Page 2 Introduction Thank you for choosing a INTRAPHEX product! 1. Visit our website for a copy of this manual www.intraphex.com as well as any updated information on your device. 2. Please be sure to copy the contents of the SD card in case of file corruption, or data loss.
-
Page 3: Table Of Contents
Contents GPS Introduction ............4 Product Appearance..........5 Basic Operation............5 Bluetooth Function ............ 6 Bluetooth Function (continued) ......... 7-9 Settings ..............10-12 Cable Connection............ 13 Technical Parameter Form ........14 GPS Trouble Shooting..........14 T otal Vehicle T echnologies... -
Page 4: Gps Introduction
GPS Introduction INTRAPHEX GPS NAVIGATION Insert supplied SD memory card with map data content, choose navigation, then operate according to menu to start navigation. NAVIGATION FUNCTION This unit receives signals from satellites with the GPS receiver to pinpoint and display your location on the map. The system will calculate the best route automatically after the user sets the destination. -
Page 5: Product Appearance
Product Appearance 1. Handsfree Answer 2. Handsfree End Call 3. Power On/Off 4. Handsfree Shortcut Key 5. Main Menu Basic Operation Turn ON car ignition, GPS mirror will automatically power on. When car ignition is turned OFF GPS mirror will automatically power off. -
Page 6: Bluetooth Function
Bluetooth Function Once a bluetooth phone is paired with this device, you can use this device as a hands-free device to send and receive telephone calls. 1. Pairing To Pair with your mobile phone: • Enter the Bluetooth main menu •... - Page 7 1. Pairing Continued... Enter the pin code • on your mobile phone (default is 8888) and press pair Your Bluetooth should now be paired, the TD43touch will hold • a maxium of 5 Bluetooth profiles and will automatically pair to the first phone available on the list of paired devices, when the TD43touch is turned on Press to delete all paired devices...
-
Page 8: Placing A Call
2. Placing a Call • To place a hands free call simply press the Dial Pad icon • Then dial the desired number and press the green send icon Dial Pad • While in call Press to mute microphone Press to display the dialpad Press to send to mobile phone for privacy... - Page 9 3: Bluetooth Settings Bluetooth Setting: In Bluetooth menu, click “Settings” Bluetooth on the GPS Mirror is always ON, to disconnect Bluetooth you must do so on your mobile phone. To enable auto answer you must the box next to Auto Answer. Click to set PIN code.
-
Page 10: Settings
Settings Click “Settings” in main menu 1. GPS settings Click to set up navigation Click choose “Navigation Autorun at Power on” We suggest to choose this option, when powering on, the system will automatically launch run navigation, otherwise it will not auto run launch the navigation software. Click Search Navigation to find the path of navigation software. -
Page 11: Language Setting
2. Volume set up Click to set up volume 3.Language setting Click to set up language 4. Brightness setting Click to set up brightness T otal Vehicle T echnologies... - Page 12 5. System set up Click to set up system System info: ID: Device hardware ID number VER: Software version number Memory Storage: Built-in RAM size, usable size/total size Available Memory: Built-in Flash size, usable size/total size Touch Screen Calibration: If touch screen becomes less responsive, due to high heat or use, click the button and follow the calibration tutorial seen below by touching each of the “+”...
-
Page 13: Cable Connection
CABLE CONNECTION BT Mic Bracket Location GPS Antenna Green: Reverse (+12V) Black: To Ground Red: ACC (+12V) Yellow: Batt (+12V) Camera Two input AV2 reverse camera input Technical Details T otal Vehicle T echnologies... -
Page 14: Technical Parameter Form
System Parameter GPS Trouble Shooting Problem Probable Reason Solution 1. Power cable not properly 1. Check power cable is connected connected properly Does not work 2. High temperature may cause 2. Power off for a while, device not to work correctly after unit cools, restart it 1. - Page 16 INTRAPHEX a division of TATMAR L.L.C. 8200 Embury Rd., Suite 6 Grand Blanc, MI 48439 USA Tel: +1-810-355-2266 • Fax: +1-866-431-0676 WWW.INTRAPHEX.COM...
