Summary of Contents for Centrix SA1DK
- Page 1 SA1DK Instruction Manual...
-
Page 2: Table Of Contents
Changing the Model of Operation ...................11 Request To Exit (REX) Button ..................12 1) Electric Lock Strike Required Case and Back Tamper ....................12 Fail Safe (Power to Lock) or Fail Secure (Power to Open) BL-D40 External Sounder ....................13 2) Power Supply with Backup Battery PROGRAMMING THE SA1DK ....................14 12 to 16V DC (From a Regulated Power Supply) Entering Programming Mode ..................15 Exiting Programming Mode .....................15 3) Request To Exit (REX) Button 1 Changing the Open Code 1 .....................16 Normally Open Type- Switch is closed when pressed 2 Changing the Open Code 2 ....................16... -
Page 3: Technical Specifications
Technical Specification Key Features Electrical Characteristics Here are some of the SA1DK’s key features: Operating Voltage Range : 12 to 16V DC From a Regulated Power Supply • Built in Keypad for PIN code entry • Internal Buzzer Maximum Input Current : • Comes with security screw and security screw tool Standby : 20mA Not including attached devices • Two Status / Programming Interface LED’s Max : 60mA Not including attached devices • Three User Levels • (Normal User, Secure User, Master User) Relay Outputs : • Three Modes of Operation Lock Strike Relay Electronic, 3.5A • (Normal Mode, Bypass Mode, Secure Mode) -
Page 4: Installation
Installation Mounting the SA1DK Controller 1) Before starting, select the location to mount the SA1DK controller. This location should be at shoulder height and on the same side as the door handle. 2) The SA1DK is designed to be easily mounted to a US Gang Box. Remove the Bezel Screw. Terminal Blocks (Use the diagram below to help you locate the Bezel Screw) Mounting Hole Mounting Hole Mode LED Door LED 4) Pass the wires through the exit/entry holes and attach them to the controllers terminal blocks as shown in the wiring diagrams. (Wiring diagrams for common installations can be found on pages 9 to 11). 3 x 4 Matrix Keypad 5) Replace the controller’s bezel and replace the factory default screw with the security screw that is provided in the Installation Kit. A security screw tool is also provided in the Installation Kit. Bell Button Bezel Screw 3) Screw the controller onto a US Gang Box through the two Mounting Holes provided. (See diagram on the next page to help you locate the US Gang Box mounting holes) -
Page 5: Wiring Diagrams
Wiring Diagrams Normal, Secure & Master Users The SA1DK accepts up to 500 users and provides entry via the use of PIN codes. Each user is Wiring the Lock Strike Relay and REX provided with two code memory slots, Memory Slot 1 (Primary Code) and Memory Slot 2 (Secondary Code). The way in which the two memory slots are programmed determines a users access level and also determines the way in which the SA1DK grants access in its three Modes of Operation. There are three user levels: Normal User A Normal User only has a Primary Code and is only granted access when the SA1DK is in Normal or Bypass Mode. Secure User A Secure User must have a Primary and Secondary Code programmed, the two codes must not be the same. The Secure User can gain access when the SA1DK is in any of its three Modes of Operation. In Normal Mode the Secure User must use their Primary SA1DK Code to gain entry. In Secure Mode the Secure user must present both their Primary and Secondary Codes in order to gain entry. Master User A Master User must have both Primary and Secondary Codes programmed with the same PIN code. The Master User can gain access during any Mode of Operation by presenting their PIN code to the controller. (The Master User is convenient but is less... -
Page 6: Modes Of Operation
Modes of Operation Changing the Modes of Operation The SA1DK has 3 Modes of Operation: Changing from Normal Mode to Secure Mode : 1) Normal Mode The default factory setting for the Normal / Secure Code is 3838 • Mode LED is green 1) Enter the 4-digit Normal / Secure Mode Normal Mode is the default mode. In normal Mode the door is locked until a Primary Code • Mode LED will Flash red is presented to the controller. Special codes such as “Open Code 1” and “Open Code 2” are active in Normal mode. (See Page 16 for more information on Open Code 1 & Open 2) Press the “#” key to confirm the Mode Change Code 2). • Mode LED is red 2) Bypass Mode •... -
Page 7: Request To Exit (Rex) Button
This provides a more secure link between the Controller and the BL-D40. If the BL-D40 Case and Back Tamper receives any unrecognized codes on its communication line or communication between the controller and the BL-D40 are severed, the Strobe with flash repeatedly until the communication problem has been resolved. If the case of the controller is opened or the controller is removed from the wall, a tamper event is triggered and a coded tamper signal is sent to a BL-D40, PS-X41 Series or PS-x42 Series Power Supply, or other compatible device. If the BL-D40 External Sounder, PS-X41 Series or PS-X42 Series Power Supplies receive a Tamper Event Signal, they will activate a Siren and if available a Strobe Light. The Siren time can be easily programmed in the SA1DK from 0 to 9 minutes. Clearing a tamper event is done by entering a valid user or Open Code that will open the Lock Strike Output in the current Mode of Operation. For example, while in Secure Mode, using the Open Code to clear tamper event will not work because the Open Code does not work is Secure Mode. However, applying a Master Code or Secure Code will clear the tamper event in Secure Mode. -
Page 8: Programming The Sa1Dk
Programming the SA1DK Entering Programming Mode Programming the SA1DK is done solely via the unit’s keypad driven Programming Menu System. 1) Press the “#” key for 2 seconds To reach the Programming Menu System the SA1DK must first be placed into Programming Mode. • Mode LED will turn off See “Entering Programming Mode” on Page 15 for more information. • Door LED will turn red During the SA1DK’s manufacturing process certain codes and settings are pre-programmed. These 2) Enter your 4-digit Programming Code settings are the called the “Default Factory Settings”. The table below shows the names of all the SA1DK Menus. It also shows of all the SA1DK’s default factory codes and settings. If the Programming Code is valid the door LED will turn green and the SA1DK will be in Programming Mode. Note : - The SA1DK must be in Norma Mode to enter the Programming Mode Programming Menu - The factory default Programming Code is 1234 - If a Programming Code is not entered within 5 seconds, the SA1DK will return to Normal Factory Menu Description Menu Number Mode Settings 2580 Change Open Code 1 0852 Change Open Code 2 Exiting Programming Mode 1234... -
Page 9: Changing The Open Code 1
Changing the Open Code 1 The Open Code 1 is mainly used as a method to quickly test the Lock Strike Relay during installation. 1) Enter Programming Mode The Default factory Setting for the Open Code 1 is 2580. When the first user is added to the 2) Press “2” to enter Menu 2 controller, the default Open Code will automatically be deleted, ready for a new Open Code 1 to be re-entered. • The Mode LED will turn orange 1) Enter Programming Mode 3) Enter the new 4-digit code you wish to set as Open Code 2 2) Press “1” to enter Menu 1 • The Mode LED will turn red 4) System returns to Normal Mode • You will hear 3 beeps • The Door LED will turn off 3) Enter the new 4-digit code you wish to set as Open Code 1 • The Mode LED will turn green 4) System returns to Normal Mode Note:... -
Page 10: Changing The Normal / Secure Code
Changing the Normal / Secure Code 1) Enter Programming Mode a) Disable Bypass Code - Disable Door Chime Enter the 4-digit code 0000 2) Press “4” to enter Menu 4 • The Mode LED will flash red b) Disable Bypass Code - Enable Door Chime Enter the 4-digit code 0001 3) Enter the new 4-digit code you wish to set as Normal / Secure Code c) Enable Bypass Code - Disable Door Chime 4) System returns to Normal Mode Enter any 4-digit code ending with 0 • You will hear 3 beeps • The Door LED will turn off d) Enable Bypass Code - Enable Door Chime • The Mode LED will turn green... -
Page 11: Setting Fail Safe / Secure Operation
Setting Fail Safe / Secure Operation Enrolling Primary & Secondary Codes Setting Tamper Siren Time Primary Codes Setting the Lock Strike Release Time - Primary Codes can only be enrolled to an empty User Slot, i.e a slot where there is no existing Primary Code. 1) Enter Programming Mode - Primary Codes must be unique, i.e. one users Primary Code may not be the same as another users Primary Code. - Primary Codes cannot be the same as any system codes, such as the Normal / Secure 2) Press “6” to enter Menu 6 Code or Open Code. • The Mode LED will flash green - Users who hold a Primary Code can gain entry only during Normal Mode. Secondary Codes 3) Construct the 4-digit code using the instructions below : - Secondary Codes can only be enrolled to User Slot that already has a Primary Code First Digit enrolled but no Secondary Code. - Page 12 2) Press “7” to enter Menu 7 • The Mode LED will flash orange 2) Press “7” to enter Menu 7 • The Mode LED will flash orange 3) Enter the 3-digit User Slot number between 001 to 500 that you wish to enroll a Primary or Secondary code to. 3) Enter the 3-digit User Slot number 000 For example, the User Slot 003 represents User #3. 4) a. If the selected slot has no Primary Code, • The Door LED will flash orange the Mode LED will flash green, indicating that the controller is ready to accept a Primary Code. The controller is now waiting for the Primary Code of the User you want to add a b. If the selected slot already has a Primary Code Secondary Code to. but no Secondary Code, the Mode LED will flash red, indicating that the controller is ready to accept 4) Enter the 4-digit PIN Code of the Primary Code belonging to the user you want to add a a Secondary Code. Secondary Code to. c. If the selected slot already has a Primary and Secondary Code, you will hear a long beep and the controller will return • The Mode LED will flash red to Normal Mode. 5) Enter the 4-digit PIN that you want to assign as the Primary or Secondary Code for this slot If the Primary Code entered is not valid, you will hear a long beep and the SA1DK will number. continue to wait for a valid Primary Code. If the PIN that is entered is valid the Mode LED will stop flashing and then the controller is ready 5) Enter the 4-digit PIN CODE to be used as the Secondary Code. for you to enter the next 3-digit slot number (refer to step 3) that you want to assign a code to, or press the “#” key to move to the next slot number (refer to step 4). If you do not wish to continue If the Secondary Code is valid the Controller will beep 3 times and return to Normal enrolling codes, press the “#” key for 2 seconds and the controller will return to Normal Mode. Mode. If the Secondary Code is invalid the controller will make a long beep and then the SA1DK will continue to wait for a valid Secondary code to be entered.
-
Page 13: Deleting Primary And Secondary Codes
Deleting Primary and Secondary Codes using the Standard Method 2) Press “8” to enter Menu 8 • The Mode LED will turn red 1) Enter Programming Mode • The Door LED will turn orange 3) Enter the 3-digit User Slot 000 2) Press “8” to enter Menu 8 • The Mode LED will turn red • The Door LED will turn orange • The Door LED will flash orange 3) Enter the 3-digit User Slot codes you wish to delete. • The Model LED will flash red Indicating the controller is waiting for the Programming Code The controller is now waiting for the Primary Code of the User you want to delete. to confirm the deletion. If the User Slot is empty you will hear a long beep and the 4) Enter the 4-digit PIN Code of the Primary Code SA1DK will return to Normal Mode belonging to the User you want to delete. 4) Enter your Programming Code to confirm the deletion. • The Model LED will flash red If the Programming Code is valid, you will hear 3 beeps and the SA1DK will return to Normal Mode. If the Programming Code is valid, you will hear 3 beeps and the SA1DK will return to Normal Mode. If the Programming Code is invalid, you will hear a long beep and the SA1DK will return to Normal Mode. If the Programming Code is invalid, you will hear a long beep and the SA1DK will return to Normal Mode. Note: - It is recommended that a record be kept of added and deleted users so that it will be easier to keep track of which use slots are empty and which user slots are not. Note: - It is recommended that a record be kept of added and deleted users so that it will be... -
Page 14: Return To Factory Default Settings
Return To Factory Default Settings Replacing a lost Programming Code Warning: Note : The SA1DK must be in Secure Mode otherwise this will not work. Make sure that the Mode LED is red before proceeding. You must be very careful before using this command! Doing so will erase the entire memory which includes all User and Special Codes, and return all codes to their factory default 1) Remove power from the SA1DK settings. -
Page 15: Glossary
ASK : An abbreviation of “Amplitude Shift Keying”. Open Code 2 : The 4 digit code used to activate the Lock Strike Relay for testing purposes during installation. Back Tamper : The electronic tamper signal advising the controller that the controller has been removed from the wall. Primary Code : The unique code issued to enable access in Normal Mode. Users with only primary Bypass Code : The 4 digit code used to change the Mode of Operation of the SA1DK from Nor- codes are Normal users. mal to Bypass Mode or vice versa. Programming Code : The 4 digit code required when entering programming mode, deleting users, Bypass Mode : A Mode of Operation where door access is not restricted to valid users. In this and resetting the SA1DK to its factory default settings. mode the door may be released by anyone pressing the bell button. Programming Mode : The mode used when programming the SA1DP system settings.
