Class H Fitness Product
Model No. WETL1214.0
Serial No.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8JG
UK
csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo WETL1214.0
Summary of Contents for Weslo WETL1214.0
- Page 1 Class H Fitness Product Model No. WETL1214.0 USER’S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call:...
-
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 11. If an extension cord is needed, use only a 3- that all users of this treadmill are adequately conductor, 1mm (14-gauge) cord that is no... - Page 4 DANGER: other than the procedures in this manual Always unplug the power should be performed by an authorised service cord immediately after use, before cleaning representative only. the treadmill, and before performing the main- tenance and adjustment procedures de- 23. This treadmill is intended for in-home use scribed in this manual.
-
Page 5: Before You Begin
The model number of the treadmill the convenience and privacy of your home. And when is WETL1214.0. The serial number can be found on a you’re not exercising, the unique SPORT 100 treadmill decal attached to the treadmill (see the front cover of can be folded up, requiring less than half the floor this manual for the location of the decal). -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Place a mat under the treadmill to protect the floor during assembly. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until as- sembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 2. Identify the Left Upright (32) and the Right Upright (37), which has a large round hole near the lower end. See drawing 2a. Make sure that there are two U-nuts Hole (93) in the lower end of each Upright (32, 37). 32, 37 See drawing 2b.
-
Page 8: Right Handrail (5) As Shown
5. Identify the Right Handrail (5), which has a large hole in the left side. Feed the Wire Harness (53) into the hole in the bottom of the Right Handrail and out of the large hole in the side. Note: It may be helpful to use needlenose pli- ers to pull the Wire Harness out of the hole. - Page 9 7. Place the Console Base (45) on the Right Handrail (5) and the Left Handrail (not shown). Attach the Console Base with four 3/4” Screws (77) (only two Screws are shown). Do not tighten the Screws yet. Insert the Wire Harness (53) through the two indicated plastic ties on the Console Base (45).
- Page 10 10. Set the Console (2) on the Console Base (45). Insert the excess Wire Harness (53) into the large hole in the side of Ties the Right Handrail (5). Securely tighten the plastic ties on the bottom of the Console Base to prevent the Wire Harness from slipping.
-
Page 11: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT , a high-performance lubricant. IMPOR- Your treadmill features a walking belt coated with PERFORMANT LUBE TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear. - Page 12 CONSOLE DIAGRAM Note: If there is a thin sheet of plastic on the console, remove it. Clip the clip onto the waistband of your clothes. CAUTION: Before operating the Next, insert the key fully into the console. After a mo- console, read the following precautions.
- Page 13 To stop the walking belt, press the Stop button. a secure place. Move the on/off switch near the The elapsed time will begin to flash in the Time power cord to the off position and unplug the display. power cord. Note: During the first few minutes that the tread- HOW TO CHANGE THE INCLINE OF THE TREADMILL mill is used, inspect the alignment of the walking...
-
Page 14: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right. - Page 15 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.
-
Page 16: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: The power does not turn on SOLUTION: a. - Page 17 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 5–7 cm come damaged.
-
Page 18: Conditioning Guidelines
CONDITIONING GUIDELINES Aerobic Exercise WARNING: Before beginning If your goal is to strengthen your cardiovascular sys- this or any exercise program, consult your tem, your exercise must be “aerobic.” Aerobic exercise physician. This is especially important for in- is activity that requires large amounts of oxygen for dividuals over the age of 35 or individuals prolonged periods of time. - Page 19 EXERCISE FREQUENCY tween workouts. After a few months, you may com- plete up to five workouts each week if desired. The key To maintain or improve your condition, complete three to success is to make exercise a regular and enjoyable workouts each week, with at least one day of rest be- part of your everyday life.
- Page 20 NOTES...
-
Page 21: Part List
PART LIST—Model No. WETL1214.0 R0305A Key No. Qty. Description Belly Pan Upright Spacer Hood Motor Tension Washer Console Left Foot Rail Motor Belt Wheel Nut Left Handrail Belt Guide Right Handrail Motor Nut Motor Isolator Right Foot Rail Motor Crossbar... -
Page 22: Exploded Drawing
EXPLODED DRAWING—Model No. WETL1214.0 R0305A... - Page 23 EXPLODED DRAWING—Model No. WETL1214.0 R0305A...
-
Page 24: Ordering Replacement Parts
When ordering parts, please be prepared to give the following information: • the MODEL NUMBER of the product (WETL1214.0) • the NAME of the product (WESLO SPORT 100 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
