  • Page 1 IAP 4 Owner’s Manual Illusonic...
  • Page 3 Illusonic IAP 4 Owner’s Manual...
  • Page 4 Illusonic IAP 4 Version 1.0.0 Published by Illusonic GmbH Illusonic GmbH, registered offices: Bahnstrasse 23, 8610 Uster, Switzerland www.illusonic.com Illusonic is a registered trademark of Illusonic GmbH Copyright c Illusonic GmbH, 2011–2014 All rights reserved Printed in Switzerland...

  • Page 5: Important Information

    Illusonic IAP 4 Important Information FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 6: Safety Notice

    Illusonic IAP 4 Safety Notice Make sure to respect the following rules: – Install the Processor on a stable base. – Do not install the Processor near water. – Do not expose the Processor to any kind of liquid. – Do not install the Processor near any heat source or in direct sun light.

  • Page 7: Table Of Contents

    Illusonic IAP 4 Contents Important Information FCC Notice ..........
  • Page 8 Illusonic IAP 4 2+2H (3D) ..........

  • Page 9: Introduction

    DAC, an analog pre-amplifier, a phono stage, an equalizer, and a processor. Illusonic Audio Processors integrate these functionalities - because they be- long together from a quality, technical, and usage perspective. The number of signal transmissions and conversions (AD, DA, digital clock sync) are minimized.

  • Page 10: How To Use This Manual

    Illusonic IAP 4 Chapter 1 Introduction How To Use This Manual – The manual is structured to be read through from beginning to end. – In case you read the manual only punctually, there are many pointers within the text, referring to related information and chapters. Detailed contents in the beginning and an index in the end help you find desired...

  • Page 11: Iap 4 Overview

    Illusonic IAP 4 Chapter 1 Introduction IAP 4 Overview Inputs IAP 4 can connect to a variety of sources. There is usually no need for a device between the source and IAP 4. In addition to conventional analog and digital inputs, IAP 4 features a phono stage, USB audio, network media rendering, and four HDMI inputs with multi-channel support.
  • Page 12 Illusonic IAP 4 Chapter 1 Introduction Volume Control In order to be able to connect directly to power amplifiers or active loud- speakers, IAP 4 features volume control, implemented digitally. Volume con- trol is applied just before the DACs using 32 bit floating point arithmetic, followed by a dithering process.

  • Page 13: Tone Control

    Illusonic IAP 4 Chapter 1 Introduction Tone Control While room equalization has the goal to mitigate dominant characteristics of your room, tone control is used to subjectively adjust the level of low and high frequencies. Not bass and treble gain can be adjusted, but also the corresponding frequencies.
  • Page 14 Illusonic IAP 4 Chapter 1 Introduction Surround Loudspeakers When IAP 4 receives surround channels via HDMI, it will reproduce them over the surround loudspeakers. For stereo audio, IAP 4 can generate sur- round channels, which are used to render room information in the recording more naturally.
  • Page 15 Illusonic IAP 4 Chapter 1 Introduction Double Amping and Cross-Overs For systems using two amplifiers for each stereo channel, the “2+2” loud- speaker setup gives out left and right twice. Different gain, delay, and equal- izers can be applied to each channel. Gain, delay, equalizers, and polarity can also be used to implement and optimize cross-over filters.
  • Page 16 Softwares The latest versions of IAP Controller and IAP Calibration softwares can be downloaded from the Illusonic web site. Both, Windows and OS X ver- sions are available. IAP Controller presents all IAP 4 parameters for comfort- able setup. IAP Calibration makes multi-point room measurement easy and helps setting up calibration related parameters (channel gain/delay, equaliz- ers, cross-overs, bass management).

  • Page 17: Getting Started

    Illusonic IAP 4 Chapter 2 Getting Started Getting Started Step 1: Unpacking Unpack IAP 4. Store the packaging for future transportation. The package contains: – IAP 4 unit – AC power cable – Remote control – This user manual Step 2: Installing the AC Power Cable 1.

  • Page 18: Step 3: Choosing A Loudspeaker Setup

    Illusonic IAP 4 Chapter 2 Getting Started Step 3: Choosing a Loudspeaker Setup You need to decide which loudspeaker setup you use and connect the amplifiers/loudspeakers to IAP 4. Follow Chapter 4 to: – Learn about the supported loudspeaker setups.

  • Page 19: Step 4: Connecting Audio/Video Devices

    Illusonic IAP 4 Chapter 2 Getting Started Step 4: Connecting Audio/Video Devices Connect audio and video devices to any of the above shown connectors: 1. HDMI sources, such as Blu-ray players, game consoles, and set top boxes. 2. Digital audio sources, such as CD players.

  • Page 20: Step 5: Using Iap

    Illusonic IAP 4 Chapter 2 Getting Started Step 5: Using IAP 4 1. Push the rotary to switch IAP 4 on. 2. Select an input source, using the < > buttons below the display. 3. Adjust the volume by turning the rotary control on the right.

  • Page 21: Advanced Setup

    Illusonic IAP 4 Chapter 2 Getting Started Advanced Setup For reaching excellence of sound, it is often necessary to consider room acoustics and to adapt IAP 4 to the room and loudspeakers: – If necessary, acoustically treat your room. – If you use subwoofers, configure bass management (Chapter 7).
  • Page 22 Illusonic IAP 4 Chapter 2 Getting Started...

  • Page 23: Usage

    Illusonic IAP 4 Chapter 3 Usage Usage Front Panel and Remote Control Display Rotary (Turn) Select (Rotary Push) < Menu > IR Receiver Standby LED IAP 4’s front panel has a display, showing the current state of the device, and a number controls:...

  • Page 24: Back Panel

    Illusonic IAP 4 Chapter 3 Usage Back Panel Power and Control Connectors 1. AC Power Before connecting a power cable here, make sure that the indicated voltage corresponds to your AC power voltage. Make sure to use 3 terminals (phase, neutral, and earth) power cables with ground conductor.

  • Page 25: Input Connectors

    Illusonic IAP 4 Chapter 3 Usage Input Connectors 1. HDMI 1–4 These are four HDMI connectors for audio/video sources, such as Blu-ray players, game consoles, and set top boxes. Up to 8-channel/192 kHz/24 bit audio over HDMI is supported. Most Blu-ray players decode Dolby Digital, Dolby True HD, DTS, and DTS HD and deliver the decoded 2.
  • Page 26 Illusonic IAP 4 Chapter 3 Usage Output Connectors 1. HDMI Out Typically, a TV or projector is connected to the HDMI output. The video signal is passed through from the selected HDMI input, while the audio By default, no video signal is given to the HDMI is removed.

  • Page 27: Common Usage

    Illusonic IAP 4 Chapter 3 Usage Common Usage In normal operation mode, the display shows the currently active Sound If you are not in normal operation mode, push Menu for two seconds to return to normal operation mode. Settings (Preset), input source, and volume level. For example:...

  • Page 28: Sound Settings (Presets)

    OTHER SETTINGS PRESET 4 PASSTHROUGH ILLUSONIC PROCESSING Illusonic Processing Choose Illusonic Processing On to apply Illusonic signal processing. When ILLUSONIC PROCESSING Off, no processing is applied and the parameters are not shown. Note that < > ON/OFF parameters which do not apply will not show (e.g. if there is no center chan- IMMERSIVE AUDIO nel, Center will not be shown, etc.).
  • Page 29 Illusonic IAP 4 Chapter 3 Usage Immersion Immersion determines how much listeners are immersed into sound (in psy- choacoustic terminology “enveloped”). Physically, this setting relates to how strong diffuse sound in the recording is reproduced. Brilliance By its default value, “Brilliance Off”, Immersion is created by concert hall type diffuse sound, extracted from the input signal.

  • Page 30: Menu Mode

    Illusonic IAP 4 Chapter 3 Usage Other Settings OTHER SETTINGS NAME A number of other settings are available for each preset. MUSIC IMMERSIVE AUDIO GAIN/DEL TRIM Name You can customize each preset’s name. Rotary (Push) toggles between IMMERSIVE AUDIO EQUALIZER the letters and Rotary (Turn) selects a specific letter or blank.
  • Page 31 Illusonic IAP 4 Chapter 3 Usage The figure on the left illustrates the menus of IAP 4. These are described in PRESET 1 detail in the following chapters: HDMI 1 -40.0 dB – Chapter 4 (Menu: Speaker Setup) Menu In this menu you configure the Processor for your specific loudspeaker setup.

  • Page 32: Cleaning

    Illusonic IAP 4 Chapter 3 Usage Cleaning Use a dry towel of cloth for cleaning. Never use any solvent or liquids, as they may damage the surface treatment or may penetrate into the IAP 4. Maintenance and Service IAP 4 contains no user serviceable parts. Do not try to open, repair, or modify the Processor by yourself.

  • Page 33: Menu: Speaker Setup

    Illusonic IAP 4 Chapter 4 Menu: Speaker Setup Menu: Speaker Setup It is crucially important that you tell IAP 4, as explained in this chapter, what the loudspeaker setup connected to it is. MENU SPEAKER SETUP MENU INPUTS MENU INPUTS...

  • Page 34: Stereo)

    Illusonic IAP 4 Chapter 4 Menu: Speaker Setup 2 (Stereo) This is a conventional stereo setup with two full-band loudspeakers. 2.1 (Stereo + Subwoofer) This is a stereo setup with an additional subwoofer. A subwoofer may be used to: – Extend the bass of the left and right loudspeakers with bass management (Chapter 7).

  • Page 35: Stereo + 2 Subwoofers)

    Illusonic IAP 4 Chapter 4 Menu: Speaker Setup 2.2 (Stereo + 2 Subwoofers) This is a stereo setup with two subwoofers. Subwoofers may be used to: – Extend the bass of the left and right loudspeakers with bass management (Chapter 7).

  • Page 36: Stereo+Center)

    Illusonic IAP 4 Chapter 4 Menu: Speaker Setup 3 (Stereo+Center) This is a stereo setup with an additional center loudspeaker. A center loud- speaker may be used to: – Reproduce the center channel of multi-channel recordings and movies. – Reproduce the phantom center of stereo recordings. This reduces inter- ferences between left and right and stabilizes the sound stage outside of the sweet spot.

  • Page 37: Surround)

    Illusonic IAP 4 Chapter 4 Menu: Speaker Setup 4 (Surround) This setup adds two surround loudspeakers to stereo. Surround channels may be used to: – Reproduce the surround channels of multi-channel recordings and movies. – For stereo audio, IAP 4 can generate surround channels, immersing lis- teners, not only in the sweet spot.
  • Page 38 Illusonic IAP 4 Chapter 4 Menu: Speaker Setup...

  • Page 39: Menu: Inputs

    Illusonic IAP 4 Chapter 5 Menu: Inputs Menu: Inputs MENU INPUTS MENU SHOW / HIDE INPUTS MENU NAME INPUTS MENU INPUT INPUTS MENU HDMI OUTPUT INPUTS MENU DELAY INPUTS MENU GAIN INPUTS MENU PRESET INPUTS MENU USB AUDIO CLASS INPUTS...
  • Page 40 Illusonic IAP 4 Chapter 5 Menu: Inputs By default, “Off”, on non-HDMI inputs no video is HDMI OUTPUT given to the HDMI output. Alternatively, for each non-HDMI input, you can choose which HDMI input shall be given to the HDMI output.

  • Page 41: Menu: Outputs

    Illusonic IAP 4 Chapter 6 Menu: Outputs Menu: Outputs Note that Loudspeaker Setup (Chapter 4), Bass Management (Chapter 7), and Equalizer (Chapter 8) are other menu which relate to IAP 4’s outputs. MENU OUTPUTS MENU GAIN TRIM PRESET MENU DELAY TRIM...
  • Page 42 Illusonic IAP 4 Chapter 6 Menu: Outputs Optionally, you can choose to apply a subsonic high- SUBSONIC FILTER pass filter, to reduce strain by subsonic frequencies on large loudspeakers and subwoofers. By default, a limiter is active on each output channel LIMITER (“All”), to make sure hard clipping does not occur.

  • Page 43: Menu: Bass Management

    Illusonic IAP 4 Chapter 7 Menu: Bass Management Menu: Bass Management In addition to setting up bass management, as described in this chapter, you can use gain/delay trim (Chapter 6) and equalizers (Chapter 8) to Introduction calibrate and fine-tune your system.

  • Page 44: Bass Management Use Cases

    Illusonic IAP 4 Chapter 7 Menu: Bass Management Bass Management Use Cases Using Full-Range Loudspeakers A straight forward loudspeaker setup uses for each main loudspeaker a large loudspeaker. Optionally, a subwoofer is used to play the low frequency effects (LFE) channel (the “.1” of 5.1 and 7.1 content).
  • Page 45 Illusonic IAP 4 Chapter 7 Menu: Bass Management Using a Mix of Full-Range and Small Loudspeakers For each main loudspeaker, you can select whether it is a large or small loudspeaker. If a subwoofer is used, then the low frequencies of all small...

  • Page 46: Bass Management Menu

    Illusonic IAP 4 Chapter 7 Menu: Bass Management Bass Management Menu MENU BASS MGMT MENU LOUDSPEAKERS BASS MANAGEMENT MENU CROSS OVER 1 BASS MANAGEMENT MENU CROSS OVER 2 BASS MANAGEMENT BASS GAIN TRIM In addition to the choice of large/small for each loudspeaker, the bass man- agement cross-over filter parameters have to be set to match the used loud-...

  • Page 47: Menu: Equalizer

    Illusonic IAP 4 Chapter 8 Menu: Equalizer Menu: Equalizer In addition to fine-tuning your system with equalizers, as described in this chapter, use gain and delay trim (Chapter 6) to calibrate the level and gain for each Introduction loudspeaker). When measuring your sound system, you can...
  • Page 48 Illusonic IAP 4 Chapter 8 Menu: Equalizer Select in this sub-menu the loudspeaker channel SELECT (FL, FR, ...) and one of the ten available equalizers. EQ 1 Sub-menus Type, Parameters, and Copy EQ To ap- ply to the channel and equalizer selected here.

  • Page 49: Equalizer Types And Parameters

    Illusonic IAP 4 Chapter 8 Menu: Equalizer Equalizer Types and Parameters A variety of filters can be used to modify the frequency response of each loudspeaker signal in a flexible way to achieve a desired equalization. All filters are implemented as minimum phase filters to minimize delay and tem- poral artifacts.
  • Page 50 Illusonic IAP 4 Chapter 8 Menu: Equalizer – High Pass The high-pass filter maintains high-frequencies and attenuates 0 dB frequencies below the cutoff frequency f with 12 dB per octave. 3 dB – Low Shelving The low shelving filter applies a gain to amplify/attenuate low frequencies...

  • Page 51: Menu: System

    Illusonic IAP 4 Chapter 9 Menu: System Menu: System MENU SYSTEM MENU DISPLAY SYSTEM MENU REMOTE PAIRING SYSTEM MENU MEASUREMENT SYSTEM MENU FIRMWARE VERSION SYSTEM MENU NETWORK SYSTEM MENU STANDBY LED SYSTEM FACTORY DEFAULT The System menu features various general settings. The figure above illus- trates the System menu and selection of its sub-menus.
  • Page 52 Illusonic IAP 4 Chapter 9 Menu: System Here you can select a loudspeaker channel which MEASUREMENT will be used to reproduce the left channel of the se- lected input source. Typically, this menu is used for: Gain/delay trim, equalizers, and bass management are applied depending on whether they are switched –...

  • Page 53: Software Tools

    Software Tools Software Tools On our web-site www.illusonic.com you can download IAP Utilities for Win- dows and OS X. Follow the instructions, included with IAP Utilities, to install and operate the software. A USB cable is required to connect IAP 2 to your PC/Mac.

  • Page 54: Iap Calibration

    Illusonic IAP 4 Chapter 10 Software Tools 10.2 IAP Calibration With IAP Calibration you can measure your system and set gain/delay trim automatically. Visualizations of your room’s response for each loudspeaker help greatly to set IAP 4’s equalizers to correct issues of your room and setup.

  • Page 55: Specifications

    Illusonic IAP 4 Chapter 11 Specifications Specifications 11.1 Technical General User control rotary control with push function, three buttons Remote control compatible with “Apple Remote” infrared remote control, support for pairing, codes for automation systems Display graphical VFD display with 160 32 resolution...
  • Page 56 Input formats stereo, Lt/Rt, 5.1, 7.1, 50 HDMI 8-channel LPCM formats Output formats 2, 2.1, 2.2, 3, 3.1, 2+2, 4, 2+2H Illusonic Processing center, depth, immersion, brilliance, environment, matrix on/off Tone Control bass and treble with gain and frequency parameters...

  • Page 57: Index

    44 Dolby True HD, 23 bass management, 13, 41 double amping, 13, 33 IAP Utilities, 51 bass gain trim, 44 DTS, 23 Illusonic Processing, 26 cross-over, 44 DTS HD Master Audio, 23 Brilliance, 27 large, 44 Center, 26 small, 44...
  • Page 58 41 sub overhead, 39 softwares, 14, 51 XLR out, 24 Overview, 9 Sound Settings, 25, 26 loudspeaker cross-over, 13 Illusonic Processing, 26 PC, 51 loudspeaker setup, 31 other settings, 28 phono input, 23 options, 32–35 tone control, 27 polarity, 40 low pass equalizer, 47 specifications, 53...
