- Page 1 FAN500 Fan Module Version 1.00 Edition 1, 05/2013 Quick Start Guide Hardware Installation Guide www.zyxel.com Copyright © 2013 ZyXEL Communications Corporation...
-
Page 2: Related Documentation
IMPORTANT! READ CAREFULLY BEFORE USE. KEEP THIS GUIDE FOR FUTURE REFERENCE. This guide shows how to install the fan module in the Switch. Graphics in this book may differ slightly from your product. Every effort has been made to ensure that the information in this manual is accurate. -
Page 3: Fan Module Installation
H A PT ER Fan Module Installation 1.1 Overview The Switch fan module is at the left on the rear panel. Perform the following procedure to remove the fan module in order to replace the entire fan module. Return any malfunctioning fan modules to the manufacture. - Page 4 Chapter 1 Fan Module Installation Use a screwdriver to loosen the screws on the fan slot cover and remove it if any. Grab the handles of the front panel of a fan module with one hand and place the other hand under it to support it.
-
Page 5: Fan Module Led
Chapter 1 Fan Module Installation 1.1.3 Fan Module LED The following table describes the fan module LED. Table 1 Fan Module LED COLOR STATUS DESCRIPTION FAN OK Green The fan in the fan module is operating properly The power is off or the module is not ready or malfunctioning. Fan Module Hardware Installation Guide... - Page 6 Chapter 1 Fan Module Installation Fan Module Hardware Installation Guide...
