  • Page 1 Digital-Player 541 User manual soulution nature of sound...
  • Page 3 We understand your eagerness to get started but even though please study this manual step by step before you integrate the Digital-Player 541 in your High Fideli- ty system. This manual contains also useful tips for the optimisation of your overall HiFi-system.
  • Page 4 soulution nature of sound CE-Declaration of Conformity Spemot AG declares that this product is in conformance with the following direc- tives and standards: Low Voltage Directive 2006/95/EG (EN/IEC 60065:2002) Electromagnetic Compatibility 2004/108/EG (EN 55013:2001, EN 55020:2002, EN 61000-3-2:2006, EN61000-3-3:1995) FCC-Notice Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 5: Table Of Contents

    Digital-Player User manual Table of contents Technical Highlights ..................4 Safety advice: ................... 6 Scope of delivery and packing ................ 7 Rear panel ....................7 Front panel ....................10 Program-Mode .................... 15 Remote control ................... 18 Trouble shooting ..................19 Service .......................

  • Page 6: Technical Highlights

    The analog output section is realized in dual mono layout. Drive The Digital-Player 541 uses a top class mechanism of the Esoteric model range. It allows for optimal data read-out of the CD as well as the SACD data.
  • Page 7 Power Supply The Digital-Player 541 has two strictly separated power supply units which are combined with a multistage filtering network for lowest mutual interferences. The supply voltages for the analog section are stabilised in several stages for mini- mal deviations.

  • Page 8: Safety Advice

    soulution nature of sound Safety advice: User manual Follow the safety advices ð Keep this user manual. ð Mains supply Exclusively use 3 phase power cords with ground conductor. Unplug the 541 from the mains in the following cases: before you manipulate with cables ð...

  • Page 9: Scope Of Delivery And Packing

    Digital-Player User manual Scope of delivery and packing Please check the scope of delivery: Digital-Player 541 Remote Control Mains cable User manual Rear panel 4.1.1 Mains (A) Connect the 541 SACD-Player with the mains supply. In standby the 541 has a power consumption of <0.5W (red LEDs in display).
  • Page 10 soulution nature of sound Output (C) Due to the extraordinary load-stability of the output-stage also long cables can be used with no reduction of sound quality. For long cables we recommend using the balanced connectors. For short cable lengths also unbalanced cables represent a high quality connection, top quality cable and optimal layout prerequisite.
  • Page 11 Digital-Player User manual USB Audio (F) The readable file formats depend mainly on the used player software. The following formats can be received by the 541 SACD-Player: File format Bit depth Sampling rate PCM (WAV, AIFF, FLAC; etc.) 16 - 24 bit 32 –...

  • Page 12: Front Panel

    Open (I) The Open button opens or closes the drawer of the Digital-Player 541. If a CD/SACD is playing the first push on the Open button will stop the mechanism, the second push will open the drawer. In Source-Mode DAC the mechanism can not be opened.
  • Page 13 CD/SACD. Never close the drawer by hand. Prog (J) The Prog button switches the Digital-Player 541 between operating-mode and pro- gramming-mode. In the programming-mode you may adjust the Digital-Player 541 to your individual requirements. Select (K) The Select knob controls the functions Track select, Volume Control, Play/Pause, Input-Select and is used for the Programming.
  • Page 14 soulution nature of sound Source Mode: CD/SACD Volume-Mode „ON“ Volume-Mode „OFF“ Track select Track select (5.4.1) (5.4.1) Play/Pause Play/Pause (5.4.3) (5.4.3) Change to Volume- no function Control-Mode Volume-Control no function (5.4.4) Source-Mode: DAC Volume-Mode „ON“ Volume-Mode „OFF“ Input-Select Input-Select (5.4.2) (5.4.2) Change to Volume- no function...
  • Page 15 In Source-Mode CD/SACD pressing the Select knob for less than 0.5 seconds will switch the Digital-Player 541 between Play and Pause. If the drawer is open while pressing the Select knob for less than 0.5 seconds the drawer will be closed and the Digital-Player 541 starts to play track 1 of the inserted CD/SACD.
  • Page 16 The volume as well as the balance setting is only displayed in the Volume-Control- Mode. 5.4.5 Programming: In programming-mode the Select knob is used for the selection of the program- functions and the function values. Display / IR-Receiver (L) The display shows all relevant information for operating your Digital-Player 541. Page...

  • Page 17: Program-Mode

    Digital-Player User manual Program-Mode General The 541 SACD-Player can be adjusted to your individual setup. It is already pro- grammed with default settings. Further programming is not mandatory. We recommend to adjust the Start-Volume and to set the Max-Volume. Function Push on the Prog button activates the Program-Mode.
  • Page 18 soulution nature of sound Program-Functions Function Values Remarks CD/SACD, DAC Defines the source mode. Track, Disc, Defines the repeat mode Random, OFF TRCK-FWD, Defines the time mode TRCK-BWD, DISC-FWD, DISC-BWD 0°, 180° Defines the polarity of the signal 0° = no inversion 180°...
  • Page 19 Digital-Player User manual Function Values Remarks <- 9...0...9 -> Defines the level difference between left and right channel. NORM, LINK NORM ð OFF (Standby) LINK ð Depending on Link System SPDIF,AES/EBU, Defines which input shall be active after Optical, USB, start-up.

  • Page 20: Remote Control

    soulution nature of sound Remote control Taste Pre/DAC-Mode CD-Mode IR-transmitter Operation until 5m distance and angel of ±45°. (2,3) p q Volume +/- DIM /4; Volume-Dim Play/Pause (5/6) t u Select +/- Next / Previous track Enter Function for Program-Mode (De)activates Program-Mode Mute (10)

  • Page 21: Trouble Shooting

    Digital-Player User manual Trouble shooting Error Action Check the cabling to the mains supply. No display Eventually replace the fuse. Check the cabling to the source components and the amplifier. ð No music if proper input has been selected ð if the source component is in MUTE ð...

  • Page 22: Safety Functions

    soulution nature of sound Safety functions Overcurrent For currents > 0.2 Ampere at the output the 541 SACD-Player shuts down automatically. Power supply The power supply is monitored for correct operation. In case of an error the 541 gets shut down automatically. Fuse Model 220-240 V 2A/T 250V micro fuse 5x20mm...

  • Page 23: Specifications

    Digital-Player User manual Specifications Nominal voltage Model 220 – 240 V / 50 – 60 Hz 220 – 240 V Model 100 – 120 V / 50 - 60 Hz 100 – 120 V Power consumption OFF (standby) <0.5 W 50 W Main-Out Output voltage...

  • Page 24: Dimensions

    soulution nature of sound Dimensions Page...
  • Page 26 Spemot AG Industriestrasse 70 CH-4657 Dulliken www.soulution-audio.com info@soulution-audio.com soulution nature of sound part.no. 92142...
