Summary of Contents for HAWQ MINI MEDIAM SPEED DOME CAMERA
-
Page 1: User Manual
MINI MEDIAM SPEED DOME CAMERA User Manual Power Supply DC 12V Factory Configuration: PELCO-D protocol, Baud rate 2400, Address code 1 Please read carefully before using this manual ※... -
Page 2: Table Of Contents
Catalogue C h a p t e r 1 P r o d u c t S u m m a r i z e … … … . . … … … … . … … … … … . … … … … . … … … … . … … … … . … … … … . … … … … … 2 1 . -
Page 3: Chapter 1 Product Summarize
Chapter 1 Product Summarize 1.1 Technical Parameters (standard) Model number 4 INCH MINI MEDIAM SPEED DOME CAMERA Optical focus Image sensor 1/3"CCD Signal mode PAL / NTSC Resolution Resolution 480TVL / 540TVL / 650TVL/ 700TVL 480TVL / 540TVL / 600TVL/650TVL/ 700TVL... -
Page 4: Function Description
Material Aluminum shell, waterproof IP66 Work environment -20℃~+50℃(select temperature control accessories), <95%RH 1.2 Function description 1. Set address coding, baud rate, control protocol Any operation commands the camera has its own objectives address coding, baud rate, control protocol, a single camera only to respond with its own address coding, baud rate, control agreement under the operation of the command. - Page 5 infrared controller, control equipment such as storage and call the preset point, the ball machine to support 256 preset points. 5. Lens Control (1) Zoom control Users can control the keyboard or through the ball machine to adjust the focus of the distance matrix of the host, receive the necessary panoramic images, or is a fine view.
- Page 6 7. Auto Backlight Compensation When the backlight compensation function is open, the camera lens in the light background can be automatically targets the more the dark luminance compensation. On the bright background light adjustment, to avoid the background brightness caused by a mass of light throughout the picture, goals and not identifiable because of the darkness to gain a clear image.
-
Page 7: Chapter 2 Equipment Installation
Chapter 2 Equipment installation 2.1 DIP switch setting Four DIP switch is the baud rate and the control protocol switch. Eight DIP switch is the address code setting switch DIP switch to “ON” means to “1”, DIP switch to "OFF" means "0". The baud rate and control protocol as the following table: PELCO-D Control protocol... - Page 8 … … … … … … … … …...
-
Page 9: Dome Camera Structure Diagram
2.2 Dome camera structure diagram Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 Figure 6... -
Page 10: Bracket Installation Diagram
2.3 Bracket installation diagram Figure 7 Figure 8 Figure 9... -
Page 11: Chapter 3 S Y S T E M O S D M E N U S E T T I N G
Chapter 3 System OSD menu settings 3.1 Power-On Self-Test When power is connected to the dome camera, the camera in horizontal and vertical direction movement, the screen will appear system-related information, the dome camera self-test to complete the following diagram. PELCO-D-2400-001 Display: PELCO-D protocol、Baud Rate 2400、Address code 1 3.2 Preset point setting and calling... -
Page 12: Main Menu
Dial the 95 Presets Enter module menu Redial the 95 Presets Cancel module menu Dial the 83 Presets clear all presets Dial the 98 Presets presets cruise Dial the 99 Presets 360 degree continuing scan 3.4 <MAIN MENU> The dome camera power on and working properly, call the 95 preset points into the module menu, screen display as shown in the Table 3-1. -
Page 13: Chapter 4 S I M P L E Tro U B L E Sh O O T I N G A N D M Ai N T E N An C
HLM LEVEL TABLE 3-1 CAMERA SETTINGS Chapter 4 Simple troubleshooting and maintenance 4.1 Simple Troubleshooting Table Connected the wrong power Corrections cord Electricity without action, no images, light does not shine. IR uniform dome camera To re-set the high-speed dome address code and Power are self-test, address code, the baud rate baud rate... - Page 14 u l i Unable to complete t l i self-test, there are Replacement to meet the requirements of the power images associated with Power is not enough supply, it is best to power the camera on the motor tweet sound near-infrared uniform Image instability Video line c...
-
Page 15: A F T E R S E R V I C
4.2 After Service Dear users, in order to ensure the full enjoyment of your camera services, please read the following products and services charter. (A): IR dome camera company limited warranty and lifetime maintenance services 1. The limited warranty period from the date of sale for 12 months, in the limited warranty period, you will enjoy the products fault free service, delivered or sent by the user's maintenance (improper use of man-made causes of failure or an irresistible. - Page 16 2. A result of improper use or other reasons as well as the failure of products outside the warranty period can be so doing card repair, free of maintenance, only the income component costs. 3. Product required maintenance should be a copy of this card and the invoice with the product delivery of the Company or the local special maintenance department.
- Page 17 Model Number Factory Number Date of manufacture Customer Unit Name Address Telephone Maintenance date Failure condition Maintenance site Maintenance result Remark: ___________________________________________________ ___________________________________________________...
