INSTALLER'S INSTRUCTION & USER'S MANUAL
DC INVERTER MULTIPLE ZONE (59)2
SYMPHONY CHOIR
INDOOR UNIT-WALL MOUNT (EW)
WMMS-09EW-V2B(59)2
WMMS-12EW-V2B(59)2
This product is designed and manufactured free from defects in material and workmanship for the normal use and
maintenance. Installation, operation, maintenance and service shall follow professional practices for regular cooling and
heating equipment, NEC, State, City or Local Codes and related manuals from YMGI. Otherwise, damage to equipment or
property even injury to people may occur.
Installer: Currently licensed HVAC technician only. Read manual before installation. Fully fill in warranty registration card.
User: Keep this manual for future maintenance and service use.
Servicer: Use this manual for service reference.
LITERATURE: LIT-WMMS-(59) (2)-EW-DC IVTR-USER MANUAL-201301130
WMMS-18EW-V2B(59)2
WMMS-24EW-V2B(59)2
