600 SERIES
INSTALLATION
&
OPERATING INSTRUCTIONS
Serial Number of Heater: ____________ Model: ___________________
SETTLER
WOODHEATERS ARE AUSTRALIAN OWNED & MANUFACTURED
BY
SHAMIC SHEETMETAL
SHAMIC SHEETMETAL
SHAMIC SHEETMETAL
SHAMIC SHEETMETAL
(AUST.) PTY. LTD.
PO BOX 8, KILSYTH, VIC. 3136
PH: 03 9737 5300 FAX: 03 9761 6455
www.shamicheating.com.au
Revised: 14/05/2013
1
Printed: 20/05/2013
Advertisement
Table of Contents
Related Manuals for Shamic Sheetmetal Settler 600 Series
Summary of Contents for Shamic Sheetmetal Settler 600 Series
-
Page 1: Operating Instructions
INSTALLATION & OPERATING INSTRUCTIONS Serial Number of Heater: ____________ Model: ___________________ SETTLER WOODHEATERS ARE AUSTRALIAN OWNED & MANUFACTURED SHAMIC SHEETMETAL SHAMIC SHEETMETAL SHAMIC SHEETMETAL SHAMIC SHEETMETAL (AUST.) PTY. LTD. PO BOX 8, KILSYTH, VIC. 3136 PH: 03 9737 5300 FAX: 03 9761 6455 www.shamicheating.com.au... - Page 2 SAVE THESE INSTRUCTIONS INSTALLATION AND OPERATION INSTRUCTIONS Have your heater installed by a registered or licensed installer, and advise your insurers for inclusion in your household contents policy. In some states the installer is required to issue a certificate of compliance on the installation; - ensure you obtain this if applicable! SETTLER Woodheaters should not be modified in any way!
- Page 3 INSTALLATION INSTRUCTIONS (FREESTANDING MODELS ONLY) Select the position of your heater carefully, taking into consideration all combustible materials in the roof; eg. ceiling joists, roof trusses, etc. Determine flue location through the ceiling: Position the hearth correctly, then place the heater on the hearth so that the flue spigot on the heater is correctly aligned with the flue location from the ceiling.
-
Page 4: Operating Information
The power cord may be relocated from the right-hand front side of the heater to the left-hand side. Note: This procedure must only be carried out by a licensed electrical contractor. Operating Information Fuel Ignition: A supply of newspapers. Kindling: 10 mm – 20 mm diameter light, split, pieces of wood. Start up wood: 30 mm –... -
Page 5: Paint Curing
Reloading The firebox should be to a minium of 2/3 full, preferably when the fuel has burnt down to a bed of coals. Attempting to reload part way through a burn period risks smoke, coals, or a log rolling from the heater. Before reloading, it is important to position the air inlet control to high. -
Page 6: Maintenance
Maintenance Paint surfaces After the curing process has taken place, little maintenance is required other than dusting off with a cotton cloth. Most marks can be buffed out with a cotton cloth without the need for retouching. NOTE: Do not use abrasive cleaners or harsh solvents (such as methylated spirits). -
Page 7: Baffle Plate Removal
Baffle plate removal The baffle plate is held in place with four locating tabs – 2 either side, front and rear of the firebox. WARNING: ALLOW THE HEATER TO COOL IF HOT BEFORE ATTEMPTING BAFFLE PLATE REMOVAL. Cast Iron Baffles Remove secondary air tube where fitted. - Page 8 TABLE 1: FIREWOOD SPECIES AND THEIR PROPERTIES Firewood Forest Type Heat Density Splitting Ignitability Coals Sparks Avail. Species Avail. (Dry Air) Per Unit Ib/ft3/ Volume Kg/m3 Mallee Roots Mallee Difficult Poor Excellent Good Belah, Buloke Mallee 70 / Good Poor Excellent Limited Box-Ironbark...
-
Page 9: How To Make A Warranty Claim
6. Provide the details that your retailer requests to complete a Warranty Claim Form. This must include the heater model, serial number and installation compliance certificate, if applicable in your State. 7. Your retailer will forward your claim to Shamic Sheetmetal (Aust) Pty Ltd, the manufacturer of the above heater brands 8. - Page 10 See exclusions and qualifications below for further information on product coverage. WARRANTY: Shamic Sheetmetal (Aust) Pty. Ltd, warrants the firebox to be free of defects in materials and workmanship of a period of ten (10) years from the date of purchase.
