Superwinch W115 Owner's Manual

115v ac electric winch
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
Enlarged version
O W N E R ' S M A N U A L
INSTALLATION • OPERATION • MAINTENANCE
SAFETY PRECAUTIONS • REPAIR PARTS
W115
115V AC Electric Winch
Model W115
Part No. 1401
READ AND UNDERSTAND THIS MANUAL
BEFORE INSTALLATION AND OPERATION
OF YOUR SUPERWINCH PRODUCT.
Superwinch, Inc.
Superwinch, Ltd.
Winch Drive
Abbey Rise, Whitchurch Road
Putnam, CT 06260
Tavistock, Devon PL 19 9DR
U.S.A.
England
Tel. (860) 928-7787
Tel. +44 (0) 1822 614101
Fax (860) 963-0811
Fax +44 (0) 1822 615204
90-10878 Rev - 05/08/03

Advertisement

loading
Need help?

Need help?

Do you have a question about the W115 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Superwinch W115

Summary of Contents for Superwinch W115

  • Page 1 W115 115V AC Electric Winch Model W115 Part No. 1401 READ AND UNDERSTAND THIS MANUAL BEFORE INSTALLATION AND OPERATION OF YOUR SUPERWINCH PRODUCT. Superwinch, Inc. Superwinch, Ltd. Winch Drive Abbey Rise, Whitchurch Road Putnam, CT 06260 Tavistock, Devon PL 19 9DR U.S.A.
  • Page 2 U N P A C K I N G This carton contains the following items. Please unpack carefully. Thank you for purchasing a W115 winch from Superwinch. It has been Read instructions before beginning. designed and manufactured to provide years of trouble-free operation. We hope you will be pleased with its performance.
  • Page 3 EQUIPMENT FREQUENTLY. A wire rope onto the drum of tie downs. Contact your local FRAYED WIRE ROPE WITH 1. The W115 winch is rated at 1,000 with your hand. Superwinch dealer. BROKEN STRANDS SHOULD BE pounds (454 kg) (single line) 8.

  • Page 4: Operation

    In 7 x 19 cable. Always replace the all installations, the unit must be mounted so that the wire rope wire rope with Superwinch feeds perpendicular to the drum 3 11/16" (94mm) replacement rope, P/N 1527.

  • Page 5: Troubleshooting Chart

    T R O U B L E S H O O T I N G If a problem arises, contact your nearest C H A R T The gearbox and drum bearing are Superwinch dealer or repair center. permanently lubricated with a high performance gear lube. If Symptom...
  • Page 6 R E P L A C E M E N T P A R T S L I S T Reference Number Description Part Number Handsaver/Manual Handle 90-32031 Drum Assembly with Flange attached 90-32038 Perimeter Bearing 90-23137 Carrier Bearing 90-23140 Planetary Gear Builder 90-23138 Nylon Step Washer...
