XM XMC050 User Manual

Satellite radio bluetooth remote control

Hide thumbs

Table Of Contents

Welcome

Thank you for purchasing a Heads Up Technologies XMC050

Satellite Radio Bluetooth System. Your XMC050 gives you access to

over 150 XM Satellite Radio channels of music, news, sports, traffic

! ! ! !

WARNING: When using this product it is always important to

maintain safe aircraft operation.

this device not expressly approved by the manufacturer could

void the user's authority to operate the equipment.

& weather, talk, comedy and more coast to coast.

Changes or modifications to

Table of Contents

Need help?

Do you have a question about the XMC050 and is the answer not in the manual?

Questions and answers

Summary of Contents for XM XMC050

Page 1 Welcome Welcome Thank you for purchasing a Heads Up Technologies XMC050 Satellite Radio Bluetooth System. Your XMC050 gives you access to over 150 XM Satellite Radio channels of music, news, sports, traffic ! ! ! ! WARNING: When using this product it is always important to Changes or modifications to maintain safe aircraft operation.
Page 2 © 2005 Heads Up Technologies Inc. All rights reserved. About XMC050 XMC050 is the latest in the acclaimed line of electronics from Heads Up Technologies and XM Satellite Radio which represents the best in aviation satellite radio technology. XMC050 uses two new technologies –...
Page 3 Up is based in Dallas, Texas – but serves the world. About XM One big idea can change everything. And XM Satellite Radio is one big idea: Radio to the Power of X®. America’s most popular satellite radio service offers over 150 digital channels of sheer variety: music, sports, talk, comedy, drama, news, traffic and weather, kids programming, and more.
Page 4: Table Of Contents
These services are available for a low monthly subscription, and additional devices may qualify for a reduced subscription fee through the XM Family Plan. Table of Contents...
Page 5 TROUBLESHOOTING ..............34 XM SATELLITE RADIO LIMITED CONSUMER WARRANTY ..35 Getting Started: Activating the receiver To quickly begin enjoying XM Satellite Radio, follow these simple steps: - Locate the identification label on the receiver. On the label is the two-digit receiver identification number. Write the number Here (Do...
Page 6 - Activate your receiver with XM Satellite Radio by using the installation instructions that came with your receiver. - Press the power button to turn your XMC050 on and verify that it is playing channel 1, the XM Preview Channel.
Page 7: Xmc050 Case
XMC050 to provisions in the seatback (fabric loop inside the seat pocket) or other suitable location. A clip that can be used to attach the XMC050 to fabric, vinyl or leather pouches, pockets and belts. Taking Care of Your XMC050...
Page 8: Battery Installation
Battery Installation The XMC050 requires three AAA batteries to operate. Please note proper battery orientation. Battery life is affected by usage. XMC050 Controls...
Page 9: Xmc050 Display Screen
XMC050 Display Screen While tuned to an XM channel, the XMC050 default display contains information about that channel and the XMC050 settings.
Page 10: Xmc050 Function Buttons
XMC050 Function Buttons Controller power. Turns the XMC050 on or off. Receiver Select. Searches for and sets the receiver ID. FOR MAINTAINENCE USE ONLY! Password is FOR MAINTAINENCE USE ONLY! Password is FOR MAINTAINENCE USE ONLY! Password is FOR MAINTAINENCE USE ONLY! Password is required for use.
Page 11 available categories. Use the ‘Channel List Up and Down’ buttons to scroll through channels within a category. Press ‘Channel List Enter’ button to select channel. Audio Mute. This button mutes and unmutes the audio output. Channel Mode Key – Provides selection between “Direct”...
Page 12: Basic Operations
Turning the XMC050 On and Off Turning the XMC050 On and Off Press the button on the XMC050. When first turned on, the receiver will power up in mute mode, and remain muted until a connection is established with the remote. After the connection is established the volume level and channel are changed to previous settings.
Page 13 3. Press and hold the number key corresponding to the preset you would like to set. The upper right corner of the display will change to indicate the preset channel “A-1”. 4. When you first get your XMC050, all presets go to Channel 1.
Page 14 Selecting channel presets Selecting channel presets Selecting channel presets Selecting channel presets Press the button until an A or B appears in the upper right corner of the display. Press the number key corresponding to the desired preset. Select a channel by category Select a channel by category Select a channel by category Select a channel by category...
Page 15 Pressing lets you change what is shown on your three-line XMC050 display during normal listening from among options: • Display mode 1 (factory default): Shows the channel name and channel number on the first line, the artist name on the second line...
Page 16 Audio Level to adjust the XMC050 audio-output level if it is too high, causing distortion, or if too low. Most users will not need to change this level from the factory setting. You should set the volume using the audio system connected to your XMC050.
Page 17: Troubleshooting
Troubleshooting Your XMC050 has been designed and built to provide you with trouble-free performance. If it does not appear to be functioning correctly, please follow these troubleshooting steps: 1. Make sure the batteries are charged and properly installed.
Page 18 This is normal on many talk and news channels. Also, this information may not yet be in the channel lineup for some selections. The audio on the XM instant Nothing is wrong with your traffic and weather channels receiver. These channels use...
Page 19 XM channels. than the main XM channels in order to provide many different dedicated city channels. Contacting Product Technical Support and Customer Service Contacting Product Technical Support and Customer Service...
Page 20: Xm Satellite Radio Limited Consumer Warranty
The XM radio/weather receiver is covered for a period of 2 years for parts or labor. The XM radio/weather receiver is covered for a period of 2 years for parts or labor.
Page 21 Heads Up label or logo, or the rating or serial number, has been removed from your Heads Up label or logo, or the rating or serial number, has been removed from your Heads Up label or logo, or the rating or serial number, has been removed from your Heads Up label or logo, or the rating or serial number, has been removed from your Heads Up product, or if, in the sole opinion of Heads Up, your Heads Up product has Heads Up product, or if, in the sole opinion of Heads Up, your Heads Up product has...
Page 22 Rev. 7/19/2005...
