English TABLE OF CONTENTS 1. PACKAGING DIMENSIONS AND CONTENTS 2. SPECIFICATIONS 3. MAIN CONTROLS AND NORMAL OPERATIONAL SIGNALS 4. SAFETY RULES 5. PRELIMINARY OPERATIONS 6. STEAM: GETTING STARTED 7. STEAM: START UP, REGULAR OPERATION AND SHUTTING DOWN 8. STEAM: WORKING WITH THE SANDBLASTING KIT 9.
Page 5: Packaging Dimensions And Contents
English 1. PACKAGING DIMENSIONS AND CONTENTS PACKAGING DIMENSIONS L=70cm W=106cm H=102 Detergent container support bracket + N°2 8x30 screws + N°2 D8 washers 5L detergent container Gun (M22 F fitting) Teflon nozzle with M22 adaptor STEAM 10m hose with rubber burn protection Sandblasting kit (for steam - sold separately) 10m HP R1 hose PRESSURE...
Page 6: Specifications
English 2. TECHNICAL SPECIFICATIONS The technical specifications are written in the metal plaques as shown below, as well as the serial numbers of the machine and the boiler which will identify them uniquely. These serial numbers must be given to the reseller or the manufacturer as well whenever assistance is requested for the steamer.
Page 7 English 3. MAIN CONTROLS Fig 1 Main Switch START STEAM OUTLET Steam/Pressure PRESSURE WASHER OUTLET washer controls Steam pressure gauge Cold water pressure gauge High voltage connection Normal functioning ON Burner ON Indicator lights Water pump ON Diesel shortage Main alarm: See troubleshooting (section 14) Dry/wet regulation...
Page 8 English INDICATOR LIGHTS LIGHT MEANING Machine is in state of stand-by, the machine is waiting for the selection of the operation mode: “SELF-CLEANING/DESCALING” (see par. 9) or “REGULAR OPERATION MODE” (see par. 7) Slow blinking SELF-CLEANING/DESCALING mode Fast blinking Continuous beep Continuous light The boiler is filling with water.
Page 9: Safety Rules
4. SAFETY RULES KEEP THIS INSTRUCTION MANUAL Before starting any operation with ASTRA STEAMER HYBRID read the following instructions carefully. Store the manual for later use or for subsequent owners. The manufacturer is not responsible for any damage caused by improper use of the machine or noncompliance with the instructions.
Page 10 Do not attempt to connect tubes to the boiler exhaust. If an extension of the exhaust is needed please refer to the Idromatic PN 15.226 extension or contact Assistance for more information. High-pressure jets can be dangerous if improperly used. The jet may not be directed at persons, animals, live electrical equipment or at the appliance itself.
Page 11 Handle the steam gun, nozzles and wands (and relative couplings) with care as they can reach high temperatures. Do not leave ASTRA STEAMER HYBRID unattended while still pressurized and hot. The proper shut down and drainage operations must be performed.
Page 12 English OPEN Figure 02 Figure03 Figure 04 Figure 05 Figure 06 Figure 07 Figure 08...
Page 13: Preliminary Operations
English 5. PRELIMINARY OPERATIONS IDROMATIC is not responsible for any accidents caused by improper handling/non-compliance with the instructions for use. a. VERIFY THE CONDITIONS OF THE MACHINE: Before unpacking make sure all the components are present and in good condition. In case of transport damage inform the vendor immediately.
Page 14 English 6. WORKING WITH STEAM – GETTING STARTED a. CONNECT THE STEAM HOSE TO THE MACHINE: Raise the burn-saver metal door 2 (fig.05) and connect the steam hose to the LEFT outlet 3 (fig. 05) tightening the nut using a 19mm wrench. Cover the coupling with the rubber protective cover 4 (fig.05).
Page 15 10cm from the surface to be cleaned. Do not point the steam jet towards face and/or body parts even if protected. During regular operation ASTRA STEAMER HYBRID will automatically maintain working conditions (temperature and pressure) by turning on the water pump...
Page 16 In case of fuel shortage the machine will start to produce white smoke. If the machine is not refilled with fuel the ASTRA STEAMER HYBRID will be shut down by the IDROMATIC flame failure control. The recharge of fuel must be done with the main switch 1 (fig.02) in OFF position ;...
Page 17 English 8. WORKING WITH STEAM – USING THE SANDBLASTING KIT* If you have purchased the optional Steam Sandblasting kit please follow these instructions carefully. a. CONNECT THE SANDBLASTING LANCE TO THE STEAM GUN: Screw in the sandblasting lance when the machine has reached nominal operating pressure (9bar). b.
Page 18: Pressure Washer: Getting Started
English 9. WORKING WITH THE PRESSURE WASHER – GETTING STARTED a. CONNECT THE R1 PRESSURE HOSE TO THE MACHINE: Before doing so purge the hose of any impurities by allowing a stream of water from the tap to flow through it. This prevents the nozzle from being blocked by dirt and compromising the functioning of the machine.
Page 19  Store the power cord in a safe place. Store ASTRA STEAMER HYBRID leaving the boiler drainage valve 8 (fig.02) open. If storing the machine in areas with freezing temperatures: If the machine is stored in areas that can be subject to freezing temperatures (0°C/32F ) make sure that, after having properly emptied the machine (see section...
Page 20: Maintenance Plan
English MAINTENANCE – IMPORTANT SAFETY PRECAUTIONS It is strictly forbidden to operate or repair the ASTRA STEAMER HYBRID without burn proof safety gloves and appropriate ear protection. Any maintenance (cleaning) operation must be done only after the following operations have been performed: ...
Page 21 English 12. MAINTENANCE FOR STEAM - DESCALING Figure 09 Figure 10 Figure 11 After the machine has cooled down to an acceptable temperature, connect the steam hose (see section 7b). Remove the placeholder screw 12 (fig.09) to remove the protective cover. Plug the machine into the outlet.
Page 22 English Rotate the knob 1 (fig.01) to (DO NOT ROTATE TO ), then toggle the cleaning program switch to “ON” 14 (fig.11). When the descaling product begins to flow through the steam hose rotate the knob 1 (fig.01) and toggle the cleaning program switch to the OFF position Wait approximately two hours and repeat the drainage procedure as described in section 12b.
Page 23 English Clean the tips of the sensors with descaling product, removing all limescale residue. If the sensors have rust on the tips, remove with sandpaper. Replace the sensors, making sure to tighten the nuts with 20Nm torque. Replace the connectors on the sensors, making sure the black connector corresponds to the top sensor the red connector to the bottom sensor.
Page 24 English 11.2 CLEANING THE SOLENOID VALVE FILTER (Y FILTER): Toggle off all switches and unplug ASTRA STEAMER EVO. After the machine has cooled down remove the protective cover by removing the placeholder screw 12 (fig.09). b. Unscrew the nut 18 (fig.13) using a M20 wrench (see fig 13). Remove the mesh component and clean it using a pressurized air cleaner.
Page 25 English 16. MAINTENANCE FOR STEAM – ADJUSTING/CLEANING THE SPARK ELECTRODES Figure 15 Figure 16 Figure 17 Figure 18 If an excess of smoke is present or the “no spark” warning lights up (ERROR 2, see troubleshooting), verify the state of the spark electrodes following the following steps: Toggle off all switches and unplug ASTRA STEAMER EVO.
Page 26 English Using a gauge, verify the gap between the nozzle and the edges of the electrodes. If necessary, adjust using pliers. Replace the combustion head; make sure to fix the 3 screws using a star point screwdriver. Replace the fuel hose and secure the nut tightly. Replace the photovoltaic cell.
Page 27: Troubleshooting
English 18. TROUBLESHOOTING PROBLEMS WHILE USING STEAM Meaning What to do - Check the power cord and verify that the sensors are connected properly. Water sensors - If problem persists see section 13. - If problem persists call Assistance. - See section 6g Flame failure - If problem persists see section 15 e 16 (burner error)
Page 28 1 step2 Verify that the nozzle is the Replace the nozzle. nozzle supplied by IDROMATIC and that it is not worn out. There is an air leak somewhere Check inlet line - verify the The water pump does not reach in the inlet line.
Page 29: Wiring Diagram
English 19. WIRING DIAGRAM...
Page 30: Declaration Of Conformity
Web: http://www.idromatic.it REA MN-223709 / C.F. / P.Iva IT 02096330200 Cap. Soc. € 65.000,00 i.v. Name and postal address of IDROMATIC S.r.l. manufacturer: Via F. Petrarca 127 46030 BORGOFORTE (MN) ITALY The upper signed Company declares under its sole responsibility that items of equipment specified below have been designed ,...
Page 31 1. Damages due to unauthorized tampering, modification and/or repair by third parties 2. Damages due to unsuitable use not in compliance with the user manual 3. Damages due to Acts of God or any events beyond the control of Idromatic (ex. Damages due to extreme weather conditions) 4.
Page 32: Safety Statement
In case any customers are interested in purchasing a new valve please refer to your local IDROMATIC distributor. Idromatic does not hold itself liable for any malfunctions due to excess boiler pressure after this period has passed. Please make sure your machine is suitably protected.
