PROGRAMMING FOR AUTOMATIC HEATER OPERATION
The Monitor GF500 Heating System is capable of providing
up to 4 different temperature settings for 4 different times
of the day. Not all 4 settings have to be used; 2, 3 or 4
settings can be used. A clear understanding of
programming temperatures and time from the previous
pages is needed before programming the automatic
settings. Also, the present time must have been set.
Step 1: Setting the 1 st Time/Temperature
Pressing the Timer Selector Button will illuminate the
Time/Temp Light.
Press the "Time" Button. Set the 1st desired time by
pressing the "Hour" and "Minute" Buttons as described
under, "Setting the Clock". Once the desired time "AM or
PM" is displayed, press the "Set" Button to lock into
memory.
Press the "Temp" button. Set the desired temperature for
the 1st time setting by using the "Up" and "Down"
Buttons. Once the desired temp is displayed, press the
"Set" Button to lock into memory.
Example: 1 st Time / Temp
SAM 60°
Step 2: Setting the 2nd Time/Temperature
Press the Timer Selector Button again and the 2nd
Time/Temp Light will illuminate.
Follow same steps as above, except for 2nd time/temp.
(ie; 2nd 5PM 74 Degrees)
Repeat if a 3rd or 4th setting is desired.
Typical Example of a 4-time/temp selection:
TIME
1st SAM
2nd 5PM
3rd 11PM
4th 5 : 30AM
TEMP
60°
74°
70°
76°
Step 3: Activate Automatic Operation
For the heater to operate on automatic once the settings
are in memory, simply press the "Auto" Button on the
control panel. The "Auto" Light will illuminate to confirm the
heater is in the automatic operation mode. The heater will
now maintain the programmed temp for that time of day.
IMPORTANT: The heater will not operate in automatic
unless the On/Off switch is in the "On"
position.
Step 4: Clearing An Automatic Setting
If you wish to clear any automatic setting, press the Timer
Selector Button to the appropriate setting and press the
"Clear" button. A new setting will need to be entered
otherwise the old setting will return after 30 seconds.
MANUAL OPERATION
To deactivate the automatic operation, simply press the
"Auto" Button. The "Auto" Light will no longer be
illuminated and the heater will run on a manual setting. This
setting will be determined by the previous auto setting for
that time of day, unless reset. The automatic settings will
remain in memory even if the unit is running in manual,
unless there is a power outage for more than 5 minutes.
19
