accordingly, being careful to not cut yourself on the glass chips or
fragments. The tempered glass wheels should not break or present a
safety risk when used under normal conditions.
For best results, use only PSA Abrasive disks recommended by
WORK SHARP™.
• WARNING. The use of any accessory or attachment other than one
recommended in the instruction manual may present a risk of per-
sonal injury.
• HAVE YOUR TOOL REPAIRED BY A QUALIFIED PERSON. This
electric tool complies with the relevant safety rules. Repairs should
only be carried out by qualified persons using original spare parts;
otherwise this may result in considerable danger to the user.
• LATEX ALLERGY. The provided Crepe Stick used to clean the PSA
Abrasives is a natural latex product. If you have a latex allergy, do
not touch or handle the Crepe Stick. It has been bagged to protect
against allergic reaction.
• SAVE THESE INSTRUCTIONS AFTER READING.
For Service Contact:
Professional Tool Manufacturing, LLC
Work Sharp
210 E. Hersey St.
Ashland, OR 97520
USA
Phone: 1-800-597-6170
FAX: 541-552-1377
Email: tech@worksharptools.com
www.worksharptools.com www.worksharptools.com
WARNING:
Some dust created by power sanding, grinding, miscellaneous
construction activities, as well as contents from the machine in-
cluding the molding, wiring, grinding wheel, or any other parts
may contain chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm and can be haz-
ardous to your health.
WARNING:
Keep your Work Sharp unit and the work space clean for best
performance and safety. Do not let sharpening debris accumu-
late on, in or around the Work Sharp Wood Tool Sharpener. Ac-
cumulated fine metal sharpening debris can be very hot and may
present a fire danger if the machine or your workspace is not
properly cleaned and maintained. Accumulated sharpening de-
bris can also degrade the life of your Work Sharp unit and cause
premature wear on some components.
If sharpening debris has accumulated, do not immediately throw
it into a trash receptacle without ensuring the debris is com-
pletely cool and free of heat. Improperly disposing of the ac-
cumulated sharpening debris may present a fire risk. The Work
Sharp Wood Tool Sharpener has been designed to suspend the
sharpening debris as long as possible and disperse the debris
onto the workspace behind the tool. This maximizes the oppor-
tunity to cool the sharpening debris being produced. Do not col-
lect the sharpening debris during sharpening. This increases the
risk of heat build up in the debris and the potential for fire.
www.worksharptools.com
Getting to Know
1
Your Tool
WORK SHARP
The Wood Tool Sharpener & Hone
Tempered Glass
Tool Rest
Wheel
Top Knob
Wheel Direction
Indicator
2" Sharpening Port
and Heat Sink
Sharpening
Port Fence
Bevel Angle
Selection Lever
Bench Mounting
Tabs
Tool Specs
Motor 1 ⁄ horsepower induction
5
Wheel Speed 580 RPM (gear reduced)
Wheel Material 150mm tempered float glass
Tool Construction Cast-aluminum top; sheet-metal housing; impact and vibration-resistant, tool-grade plastic base
Cooling System Heat sink with routed airflow
Power Connection
Industrial grade switch with safety lockout; grounded 6' power cord
Abrasives 150mm and 2" premium, durable PSA (Pressure Sensitive Adhesive) ceramic oxide and aluminum oxide
abrasives (Also accepts standard 6" abrasives. Trimming is required to fit 150mm tempered glass wheel.)
Honing
150mm Micro-Mesh™ 3600 cushioned abrasive (6 µ micron)
(Leather disk and honing compound accessory available.)
™
Wheel Shroud
Skew Cam
Adjustment Lever
Fence Adjustment
Knob
T-Slots for mounting
Angle Indicator
accessories
Hub
Power Switch
Underside Port
T-Slots for mounting
accessories
6' Power Cord

Bench Mounting
Tabs
