- Page 1 Outdoor Intelligent High Speed Dome Camera User Manuel V D3.31SHAN/2009 Please read this manual carefully before installation and keep it for application...
- Page 2 Accessories Wall mount bracket Ceiling mount bracket Pole mount bracket Corner mount bracket Joystick controller Connection adopter...
-
Page 3: Table Of Contents
Catalogue Chapter 1 Product Introduction..............1 Chapter 2 Specification..................3 Chapter 3 Connection & Setup...............4 Chapter 4 Protocol & Address Code Setting............6 Chapter 5 User Manual of the Controller............8 Chapter 6 Guide of OSD Menu Application...........10 Gudie of Camera Module OSD Menu......18 Chapter 7 255 Channels Address DIP Swithch Diagram....19... -
Page 4: Chapter 1 Product Introduction
Product Introduction CHAPTER 1: Product Introduction IR Intelligent high-speed dome camera is one high-tech surveillance & control product with high-reso lution color camera module, omni-direction Pan/Tilt, infrared LED array,multi-functional decoder,CPU processor and memory chip. The product reduces the connection between system components and the ins- tallation process, it extremely improve the stability of the system. - Page 5 Product Introduction Convenient installation and operation *With built-in fan & heater and the weather-proof design, the product is very suitable for application in outdoor environment. *The structure of dome camera meets the demand of IP66 standard. *The design concept of high-speed dome and mounting based on convenient installation. Product Diagram...
-
Page 6: Chapter 2 Specification
Specificaions CHAPTER 2: Specifications 2.1 Configuration of Speed Dome Camera Speed Dome Dimension Product Photo C a m e r a T y p e & S p e c i f i c a t i o n s S e n s o r 1 / 4 "... -
Page 7: Chapter 3 Connection & Setup
Connection & Setup CHAPTER 3 Connection & Setup 3.1 Intelligent speed dome camera connection diagram 3.2 Cable connection; Please check carefully the voltage and current capcity of the electrical power source. The correct power to operate the camera is AC24V / 1.5A; There is one AC24V, 3A PSU in the packing carton of speed dome camera. - Page 8 Connection & Setup RS485 Bus marching resister To the application of system center control, in order to prevent the reflection and interference of RS485 signal and other communication signals, the communication port of farthest equipment from control center should parallel connected with one marching resister.
-
Page 9: Chapter 4 Protocol & Address Code Setting
Protocol & Address Code Setting Chapter 4 Protocol & Address Code Setting Before installation, please check the Communication Protocol, Baud Rate and Address Code of the control main machine in the system. There are two groups dip switch which be used to set protocol, baud rate and address of dome camera. Please set the dip switch consistent with system. -
Page 10: Camera Module Setup
Protocol & Address Code Setting u Camera module setup: ON/OFF CAMERA (Pin 4) (Pin 5) SONY YOKO 1. NTSC/PAL setup: NT/PAL (Pin 6) NTSC/PAL NTSC Intelligent High Speed Dome Camera Address Setup Before the application of high speed pan/tilt dome, the address code should be setup firstly. The add- ress code is decided by the 8 bits dip switch on back panel which adopted with 8421 code. -
Page 11: Chapter 5 User Manual Of The Controller
User Manual of The Controller Chapter 5:User Manual of The Controller All the functions of IR high speed dome camera can be achieved through the control by keyboard. Be- cause the detailed operation from different company is different, if the control system is from other comp any,please control the dome according to the instruction from control system supplier. - Page 12 User Manual of The Controller I.E. To establish No.15 preset point on No.5 camera: Input [5] + [CAM] to select No.5 camera firstly.Zoom out lens then use joystick to move camera to wanted position. Input [F1] + [15] + [PRE] If want to establish different preset point, just change another series number, repeat the above operation.
-
Page 13: Chapter 6 Guide Of Osd Menu Application
Guide of OSD Menu Application CHAPTER 6: Guide of OSD Menu Application Checking before Operation: Checking the cable connection carefully before camera be powered; The camera address ID of the controller must same of the camera address ID. The camera ID can be c- hecked by reading DIP switch on PCB of camera. - Page 14 Guide of OSD Menu Application Using joystick to move the cursor then input [FOCUS+] to selection wanted item. SYSTEM INFORMATION selection is used to check system version information. DISPLAY SETUP selection is used to setup what be shown on screen. DOME SETUP selection is used to setup all functions of speed dome camera.
- Page 15 Guide of OSD Menu Application 1.3 Preset: Function: Up to 127 pieces preset can be set. Beside No.95, all presets can be named as 1---128. With t- he combination of preset key and number key of controller, the preset point setup and call back function can be quickly operated.
- Page 16 Guide of OSD Menu Application 1.5 Group Function: Function: The group function allows running up to 5 groups of preset, swing, pattern in sequence. Every group including preset, swing, pattern, but the total function number can't more than 200 pieces. Throu- gh the OSD menu operation, we can establish, modify, delete groups.
- Page 17 Guide of OSD Menu Application 6.Other Functions: This function can get back the last automatically running ac- Information protection after power off: tion. Beside manual operation, preset, swing, trace recording, pattern all can be get back. ¡ ã ¡ ã ¡...
- Page 18 Guide of OSD Menu Application To move from item to item, use Up/Down of the joystick in the Up/Down or Left/Right. If you want to confirm a menu item, press [Focus+] key. To change a value of an item, use Up/Down of the joystick in the controller. After you change a value, pr- ess [Focus+] key to save it or press [Focus-] key to cancel it.
- Page 19 Guide of OSD Menu Application 12.PTZ Motion setup 13.Park Action Setup MOTION SETUP PARK SETUP 1.REBOOT ACTION 1.PARK ENABLE 2.AUTO FLIP 00:05 2.PARK TIME 3.MOTOR SPEED NORMAL 3.PARK PRESET 4.JOG DIR NORMAL 5.PARK SETUP BACK BACK EXIT MENU EXIT MENU This function enables to locate the camera to spe- The maximum manual speed is listed below w- cific position automatically if operator doesn't o-...
- Page 20 Guide of OSD Menu Application 16.Swing Setup: SWING SETUP 1.SWING NUMBER: 2.1ST POSITION: 3.2ND POSITION: 4.SWING SPEED: 30d/s 5.LOOP COUNTER 6.DIRECTION: LEFT 7.CLEAR SWING: 8.RUN SWING: BACK EXIT MENU SWING NUMBER: 1/8; This P/TZ camera support up to 8 pieces swing scan. This item is used to set the series number of swings.
-
Page 21: Gudie Of Camera Module Osd Menu
Guide of OSD Menu Application Using joystick to move camera to wanted beginning position, and adjusting lens to suitable zoom times, input [FOCUS+] to begin recording, or input [FOCUS-] to abandon. The recording support up to 200 pieces movement command. The total recording number be shown on screen. -
Page 22: Chapter 7 255 Channels Address Dip Swithch Diagram
Guide of OSD Menu Application After the setup of masking of privacy zone, when you move the camera to this position, you will find this zone already be covered by masking. The series number of masking will be shown at the center of maski- ng. - Page 23 Guide of Camera Module OSD Menu We supply one special function with our P/T/Z dome camera----------- the camera module OSD menu operation. You can input [96] + [CALL] to setup camera module OSD menu. Using [ZOOM+] and [ZOOM-] to move the cursor Using [FOCUS+] and [FOCUS-] to select the parameter of camera module Notice: The camera module parameters already be setup well before...
- Page 24 Address DIP Switch Setup Digram CHAPTER 10:255 CHANNELS ADDRESS DIP SWITCH DIGRAM 10 1 9...
- Page 25 10 2 0...
