VT1602-L/VT2216-L
LCD TV display
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
www.viewsonic.com in English, or in specific languages using the Regional selection
box in the upper right corner of our website. "Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual"
Model No. VS15770/VS15772
Advertisement
Table of Contents
Related Manuals for ViewSonic VT2216-L
Summary of Contents for ViewSonic VT2216-L
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http:// www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
-
Page 2: Table Of Contents
Installing the LCD TV ....................2 Installing the Stand ..................... 2 Disconnecting the Stand ..................2 Mounting ViewSonic LCD TV to the wall ............3 Wall Mount Kit Specifications (VESA) ..............4 Front View of the Product ..................5 Rear View of the Product ..................6 Connecting the LCD TV ...................7... -
Page 3: Compliance Information
Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Declaration Of Rohs2 Compliance
Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Substance Actual Concentration Concentration Lead (Pb) 0.1% < 0.1% Mercury (Hg) 0.1% < 0.1% Cadmium (Cd) 0.01% <... -
Page 5: Copyright Information
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission from ViewSonic Corporation. Product Registration To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. For Your Records Product Name: VT1602-L/VT2216-L... -
Page 6: Important Safety Instructions
Important Safety Instructions AC power Cord Keep the following guidelines to protect the AC power cord from being damaged. If the AC power cord is damaged, it may result in a fire or an electric shock. Stop using it and ask your dealer or ViewSonic service center to exchange it. • Do not place the TV where the power cord is subject to wear or abuse. • Do not pinch, bend, or twist the cord excessively. • The core lines may be bared and cut, causing a short- Dangerous Voltage: The lightning flash with circuit, and resulting in a fire or an electric shock. arrowhead symbol, within an equilateral triangle, • Do not convert or damage the power... -
Page 7: Carrying The Tv
• When using headphones, adjust the volume to appropriate Disclaimer levels, or hearing damage may result. Some chemical cleaners have been reported to damage the screen and/or case of the LCD TV. ViewSonic will not be liable for damage resulting from use of these cleaners. ANTENNAS Outdoor antenna grounding CARRYING THE TV If an outdoor antenna is installed, follow the precautions below. - Page 8 • Do not let this TV get wet. Never spill liquid of any kind on the TV. If water penetrates into the product, unplug the power cord and contact ViewSonic. • Do not operate the TV when wet. It may result in electric shock or damage to the TV.
-
Page 9: Lcd Screen
LCD SCREEN SERVICING • Although the LCD screen is made with high precision Do not attempt to repair the TV yourself, technology and has effective pixels of 99.99% or more, since opening the cabinet may expose you black dots or bright points or light (red, blue, or green) may to dangerous voltage or other hazards. -
Page 10: Getting Started
(for US model) ViewSonic CD ViewSonic Quick Start Guide (User Guide) The photos of the accessories are for reference only, the color of the remote control, the type of power cord are variable based on the actual models. -
Page 11: Installing The Lcd Tv
Installing the Stand Figure 1 Figure 2 Figure 3 (VT2216-L ) (VT1602-L ) 1. Carefully place the TV screen side down on a cushioned surface to protect the screen from damage. (see Figure 1) 2. Attach the foot stand and secure it with the included screws. Please fasten with a cross screw driver. -
Page 12: Mounting Viewsonic Lcd Tv To The Wall
• Install the wall mount plate to the LCD TV using screws NO LONGER than 12mm, as longer screws found in universal (non-ViewSonic) wall mount kits may damage the power supply causing the unit to fail. The wall-mount screw type is M4 x L12. -
Page 13: Wall Mount Kit Specifications (Vesa)
LCD TV 75 x 75 mm M4 x L12 • ViewSonic provides the standard dimensions for wall mount kits as shown in the table above. • To find the perfect mount, please browse www.viewsonic.com or call our service team: United States 1-800-688-6688, Canada 1-866-463-4775, Europe +44 (0) 207 382 8250. • When purchasing our wall mount kit, a detailed install manual and all parts necessary for assembly are provided. -
Page 14: Front View Of The Product
Getting Started Front View of the Product Item Icon Description LED Indicator Blue indicates power on. Red indicates standby mode. Remote Control Receive IR signals from the remote control. Receiver Decrease the volume. VOL - Move to the left or adjust the setting on the OSD menu. Volume Increase the volume. -
Page 15: Rear View Of The Product
Getting Started Rear View of the Product AUDIO IN PC/VGA IN DIGITAL PC/VGA AUDIO AUDIO VIDEO IN Item Description Power (AC input) Connect to the AC input power source. Connect to USB devices, such as USB flash drive. Connects to the audio jack on the digital/standard 5.1 audio Digital Audio out. -
Page 16: Connecting The Lcd Tv
Getting Started Connecting the LCD TV Cable System or VHF/UHF Antenna System Enjoy the high-definition and standard-definition digital programming along with standard-definition analog programming. ☼ • This TV is capable of receiving unscrambled digital programming for both cable and external VHF/ UHF antenna. • We strongly recommend that you connect the antenna/cable input using a 75-ohm coaxial cable (not supplied) to ensure the best picture quality. - Page 17 Getting Started DVI Connection HD cable box / HD satellite box COMPONENT LINE OUT VIDEO OUT Rear side of the TV DVI-HDTV OUT PC/VGA IN PC/VGA AUDIO VIDEO AUDIO HDMI OUT Audio cable CATV / Satellite antenna cable DVI-to-HDMI cable DVI-to-HDMI cable DVI-to-HDMI adapter Audio cable...
-
Page 18: Antenna Cable
Getting Started YPbPr or Component Connection HD cable box / HD satellite box COMPONENT LINE OUT Rear side of the TV VIDEO OUT DVI-HDTV OUT DIGITAL AUDIO IN PC/VGA IN PC/VGA AUDIO AUDIO VIDEO IN AUDIO VIDEO HDMI OUT Component CATV / Satellite cable antenna cable... -
Page 19: Personal Computer
Getting Started Programming your Cable or Satellite Box remote Refer to the user manual from your service provider to determine the setting. If it requires: • 3 digits, please try “566”, “565”, “556”, or “688”. It usually works with DISHNetwork. • 4 digits, please try “0054”. It usually works with Cox. • 5-digits, please try “11454”, “11054”, or “10690”. -
Page 20: Using The Tv Features
Using the TV Features Remote Control and TV Controls Inserting Remote Control Batteries 1. Remove the battery cover by pulling then lifting the knob on the cover. 2. Insert the batteries, corresponding to the (+) and (-) markings on the battery compartment. 3. - Page 21 Using the TV Features Button Description 0~9, - Press the respective button to select a channel. number After you input the channel numbers, press buttons ENTER to direct to the channel immediately, or wait for 3 seconds to change automatically. - VOL + Press to adjust the volume. Press this button to show Favorite List and select your favorite channels that have already been stored.
- Page 22 Using the TV Features Button Description 13 RETURN Press to return to the previous channel. Press to select the Closed Caption menu in the 14 C.C TV or AV mode. 15 ▼ CH ▲ Decrease or Increase the channel number Press to display the Electronic Program Guide 16 GUIDE (EPG).
-
Page 23: Operation
TVs. If you cannot achieve that signal level with your antenna or cable, your HDTV might lose picture or sound. j ViewSonic wants to help you save energy! This HDTV meets the ENERGY STAR® guidelines under the default picture setting called POWER SAVING. Changing this setting or enabling other options will increase power consumption which could possibly exceed the guidelines of ENERGY STAR®. - Page 24 Using the TV Features Changing Channels 1. Using Channel Buttons Press ▼CH▲ to change channels, and the TV changes the available channels in sequence. 2. Using Number Buttons (1) ATV The “-” has no function in ATV mode. Directly press the number buttons to select channels. (2) DTV Use “-” to select the sub channel in DTV. For example: Your sub channel number is 80-3. Press 8 → press 0 → press “-” → press 3. j Return to the previous channel, press RETURN. Adjusting the Volume Press VOL +/- to adjust volume. To turn off the volume, press MUTE.
- Page 25 Using the TV Features Selecting the Input Source To select the TV or other external input sources connected to the 1. Press INPUT on the remote control. 2. Press ▲ or ▼ to select the desired input source. 3. To confirm the selection, press ENTER. Media Favorite Channel Setting To set your favorite channel into memory: 1.
- Page 26 Using the TV Features Using the Parent Controls With PARENT CONTROL, you can block television and movie programming based on Movie and TV ratings. Password is required to access the PARENTAL CONTROL menu. The default is “0000”. To manage programs using the US Ratings system: 1. Press MENU to display the OSD main menu. 2. Press ◄ or ► to select Lock menu, then press ENTER to enter the menu. 3. Enter the password. 4. Press ▲ or ▼to select System Lock, then press ◄ or ► to select On. 5. Press ▲ or ▼ to select US Rating, then press ► to enter the US rating submenu.
- Page 27 Using the TV Features TV Rating 1. Press ▲ or ▼ to select TV Rating, then press ► to enter its submenu. 2. Press ▲ or ▼ to select your desired TV ratings level and press ◄ or ► to select the desired content check box. The TV ratings level and content are defined as following: TV ratings level TV ratings content • TV-Y (all children) • D (suggestive dialog) • TV-Y7 (older children) • L (adult language) • TV-G (general audience) • S (sexual situations) • TV-PG (guidance suggested) • V (violence) • FV (fantasy violence) • TV-14 (strongly cautioned) • TV-MA (mature audience)
- Page 28 Using the TV Features Canada English 1. Press ▲ or ▼ to select Canada English, then press ► to enter. 2. Press ◄ or ► to select your desired Canadian English rating level. The Canadian English rating levels are defined as following: • C (children) • C8+ (children eight years and older) • G (general programming, suitable for all audiences) • PG (parental guidance) • 14+ (viewers and older) • 18+ (adult programming) 3. Press ENTER to lock / unlock your selection. 4. Press EXIT to exit the menu. Canada French 1. Press ▲ or ▼ to select Canada French , then press ► to enter.
- Page 29 Using the TV Features Changing Password To change a new password: 1. Press MENU to display the OSD main menu. 2. Press ◄ or ► to select Lock menu, then press ENTER to enter the menu. 3. Enter the password. 4. Press ▲ or ▼to select Change Password, then press ► to enter its submenu. 5. Enter the old password on Old PIN. 6. Enter your new password on New PIN. 7.
- Page 30 Using the TV Features Customizing PC Display Connect the PC and your TV using the VGA cable. See “Personal Computer” on page 10. 1. Press INPUT to display the Source Select menu. 2. Press ▲ or ▼ to select PC, then press ENTER to confirm the setting. 3. Press MENU to display the OSD main menu. 4. Press ◄ or ► to select Setup menu, then press ENTER to enter the menu.
- Page 31 Using the TV Features Playing Music 1. Press ◄ or ► to select Music, then press ENTER. If there are several folders, press ▲ or ▼ to select the desired folder, then press ENTER to view the subfolder content. 2. Press ▲ or ▼ to select a song, then press ENTER to play. An automatic playback begins from the selected song. 3. During the playback, do the following: • To pause the playback, press ◄ or ► to select icon, then press ENTER. Press ◄ or ► to select icon, then press ENTER to resume. • To fast reverse the playback , press ◄ or ► to select icon, then press ENTER.
- Page 32 Using the TV Features Viewing Photos 1. Press ◄ or ► to select Photo, then press ENTER. If there are several folders, press ▲ or ▼ to select the desired folder, then press ENTER to view the subfolder content. 2. Press ▲ or ▼ to select a photo, then press ENTER to view the photo in full screen. • Press EXIT to stop the slide show. Menu item Description Slideshow Interval Set the interval time between each slide displays (3 S / 5 S / 10 S / 30 S / 1 Min / 30 Min).
- Page 33 Using the TV Features Adjusting On-Screen Display (OSD) Settings 1. Press MENU to display the OSD main menu. 2. Press ◄ or ► to select the main menu, then press ENTER to enter the selected menu. 3. Press ▲ or ▼ to select the menu item, then press ◄ or ► to adjust or select the setting. When selecting a menu item with a submenu ( ), press ► or ENTER to enter its submenu. ► ► (“...
- Page 34 Using the TV Features Sound Menu Menu item Description Sound Settings Apply a preset audio option optimized for different sounding conditions (Standard / Music / Movie / Sports / User ). j If Sound Mode is set to User, you can adjust the following settings: • Bass: Adjust the bass level to your preference. • Treble: Adjust the treble level to your preference. • Balance: Adjust the sound balance between the left and right speakers. Configures the multi-track sound. It is only available in ATV. Press ◄ / ► button to select (Mono/Stereo/SAP).
- Page 35 Using the TV Features Setup Menu Menu item Description Menu Language Select to display all on-screen menus in your language of choice: English / French / Spanish Transparent Adjust the transparency of the OSD (on screen display) menu.Press◄ / ►button to select. (0%,25%,50%,75%,100%.) OSD Timeout Adjust the duration of the OSD (on screen display) menu. Press ◄ / ► button to select.(5 Sec.,15Sec.,30 Sec.,45Sec.,60Sec.) Closed Caption Adjust Closed Captioning settings. j Only available under TV and AV source • CC Mode: Adjust the bass level to your preference. Press ◄ / ► button to select(CC Off / CC On / CC OnMute).
- Page 36 Using the TV Features Setup Menu Menu item Description Closed Caption • FG Color: Adjust the color of the digital Closed Captioning font. Press ◄ / ► button to select(Default/ Black / White / Red / Green / Blue / Yellow / Magenta / Cyan). • BG Color: Adjust the color of the digital Closed Captioning font. • FG Opacity:Adjust the transparency of the digital Closed Captioning font. Press ◄ / ► button to select(Default / Solid / Flashing / Translucent). • BG Opacity: Adjust the digital Closed Captioning background transparency. Press ◄ / ► button to select(Default / Solid / Flashing / Translucent). Over Scan Press ◄ / ► button to select(On / Off).
- Page 37 Using the TV Features Lock Menu Menu item Description Enter Password Enter your 4-digital password. Default password is 0000,and if forget what you set, please call the service center. Change Allows to set the password. Use the function, Password must enter a four-digit password. The factory password is 0000. Other Settings Set the parameter of audio only, no signal power off and no operation power off.
- Page 38 Using the TV Features Channel Menu (Only available on TV source) Menu item Description Air/Cable Allows selection between CATV cable and antenna signal sources: AIR/Cable Auto Scan Automatically search for channels. Press ENTER / ► button to enter. Favorite Add channels to create a favorite list. Press ►button to enter. Channel List Display your program list. Press ►button to enter. Show/Hide Show or hide your program list. Press ►button to enter. Channel Show the channel number Numbe Channel label...
- Page 39 Using the TV Features Hospitality Menu 1. Press MENU and 9, 9, 3 button on the remote controller to display the Hospitality menu. 2. Press ▲ or ▼ to select the menu item, then press ◄ or ► to adjust or select the setting.When selecting a menu item with a submenu ( > >), press ► or ENTER to enter its submenu. 3. Press MENU to return to the previous menu or press EXIT to exit the menu. Menu item Description EEPROM Init Clean up the setting to its initial value.
-
Page 40: Other Information
Other Information Troubleshooting Please contact ViewSonic service team directly if you have questions, service needs, or require technical assistance related on the use of your television. Contact ViewSonic Service Team at: http://www.ViewSonic.com Or call our service team: United States 1-800-688-6688... - Page 41 Other Information Problem Possible Solution Remote control unit does not • Make sure the batteries are inserted correctly. operate • Batteries could be weak or dead. Replace with new batteries. • Check if there is a fluorescent light illuminated near the remote control sensor. • The path of the remote control beam may be blocked. Make sure the path is clear and that the remote control is aimed at the remote control sensor on the TV.
-
Page 42: Specifications
Other Information Specifications Model VT2216-L VT1602-L Screen Size 21.5” Full HD 60Hz 15.6” HD 60Hz (LED Backlight) Aspect Ratio 16:9 16:9 Television System ATSC / 64 & 256 QAM / ATSC / 64 & 256 QAM / NTSC-M NTSC-M Program Coverage... -
Page 43: Customer Support
Latin America C= http://www.viewsonic.com/la/ www.viewsonic.com/la/ soporte@viewsonic.com (Mexico) soporte/servicio-tecnico Nexus Hightech Solutions, Cincinnati #40 Desp. 1 Col. De los Deportes Mexico D.F. Tel: 55) 6547-6454 55)6547-6484 Other places please refer to http://www.viewsonic.com/la/soporte/servicio-tecnico#mexico C= http://www.viewsonic.com/la/ Latin America (Peru) www.viewsonic.com/la/ soporte@viewsonic.com soporte/servicio-tecnico... -
Page 44: Limited Warranty
Replacement product or parts may include remanufactured or refurbished parts or components. How long the warranty is effective: ViewSonic LCD TVs are warranted for 3 years for all parts excluding the light source and 3 years for labor from the date of the first customer purchase. Who the warranty protects: This warranty is valid only for the first consumer purchaser. -
Page 45: Mexico Limited Warranty
Replacement product or parts may include remanufactured or refurbished parts or components. How long the warranty is effective: ViewSonic LCD TVs are warranted for 3 years for all parts excluding the light source and 3 years for labor from the date of the first customer purchase. Who the warranty protects: This warranty is valid only for the first consumer purchaser. - Page 46 FOR USA SUPPORT: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 381 Brea Canyon Road, Walnut, CA. 91789 USA Col 20 de Noviembre Tel: 800-688-6688 (English); 866-323-8056 (Spanish); Tijuana, Mexico E-Mail: http://www.viewsonic.com 4.3: ViewSonic Mexico Limited Warranty LTV_LW02 Rev. 1A 06-25-07...
