This symbol is intended to alert the user to the presence of unprotected
"Dangerous voltage" within the product's enclosure that may be strong
enough to cause a risk of electric shock.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
NOTE: This equipment has been tested and found to comply with the limits for a class
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Disposal of Old Electrical & Electronic Equipment
(Applicable in the European Union and other European countries with separate
collection systems)
This symbol on the product or on its packaging indicates that this product shall not be treated as
household waste. Instead it shall be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The recycling of materials will
help to conserve natural resources. For more detailed information about recycling of this product,
please contact your local city office , your household waste disposal service or the shop where you
purchased the product.
DIGITAL VIDEO RECORDER
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
WARNING
1
Advertisement
Table of Contents
Summary of Contents for CMOS DOTCOM ANX-1670
- Page 1 WARNING This symbol is intended to alert the user to the presence of unprotected “Dangerous voltage" within the product's enclosure that may be strong enough to cause a risk of electric shock. This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 2 PRECAUTION All the safety and operating instructions must be read before the unit is operated. • Make sure to switch the power off before you install the DVR. • There is the danger of an electric shock if the DVR is opened by an unqualified service engineer or installer.
-
Page 3: Table Of Contents
CONTENT TABLE OF CONTENTS 1. FEATURE LIST ---------------------------------------------------------------------------------- 2. PACKING DETAIL ------------------------------------------------------------------------------------------ 3. LOCATION AND CONTROL ----------------------------------------------------------------- 3.1 FRONT PANEL CONTROLS ------------------------------------------------------------------------------- 3.2 REAR PANEL CONNECTORS ----------------------------------------------------------------------------- 4. INSTALLATION --------------------------------------------------------------------------------------------- 4.1 TOTAL CONNECTION LAY-OUT ------------------------------------------------------------------------- 4.2 INDIVIDUAL CONNECTION -------------------------------------------------------------------------------- 4.2.1 CAMERA -------------------------------------------------------------------------------------------- 4.2.2 AUDIO ----------------------------------------------------------------------------------------------- 4.2.3 MONITOR ----------------------------------------------------------------------------------------------- 4.2.4 EXTERNAL HDD BAY --------------------------------------------------------------------------... - Page 4 CONTENT 6.3 RECORD --------------------------------------------------------------------------------------------------------- 6.3.1 RECORD SETUP ----------------------------------------------------------------------------------- 6.3.2 RECORD PROGRAM ----------------------------------------------------------------------------- 6.3.3 IMAGE QUALITY -------------------------------------------------------------------------------------- 6.3.4 AUDIO RECORD ------------------------------------------------------------------------------------- 6.3.5 REPEAT RECORD --------------------------------------------------------------------------------- 6.3.6 PLAY MODE ----------------------------------------------------------------------------------------- 6.3.7 BACKUP MODE -------------------------------------------------------------------------------------- 6.3.8 HOLIDAY ------------------------------------------------------------------------------------------------- 6.4 EVENT ------------------------------------------------------------------------------------------------------------ 6.4.1 MOTION DETECTION ----------------------------------------------------------------------------- 6.4.2 EVENT SCREEN MODE ------------------------------------------------------------------------- 6.4.3 EVENT CHECK -------------------------------------------------------------------------------------- 6.4.4 EVENT MESSAGE ---------------------------------------------------------------------------------...
- Page 5 CONTENT 10. HDD INSTALLATION ------------------------------------------------------------------------ 10.1 INTERNAL HDD INSTALLATION ----------------------------------------------------------------------- 10.2 DVD¡ ¾ RW(or CD-RW) installation----------------------------------------------------------------------- -------------------------------------------------------------------------------------- 11. NETWORK VIEWER 11.1 SYSTEM REQUIREMENT -------------------------------------------------------------------------------- 11.2 Be sure to setup THREE of files together when you execute the viewer program PC------ 11.3 INSTALLING THE DVR VIEWER ----------------------------------------------------------------------- 11.4 DVR VIEWER - LAYOUT ------------------------------------------------------------------------------------ 11.5 DVR VIEWER - LIVE MODE -----------------------------------------------------------------------------...
-
Page 6: Feature List
FEATURES Features Chapter 1 Operation Playback, recording, backup and transmission simultaneously Real time single or multi-screen display Pan & Tilt, 2X digital zoom and PIP display Easy operation by IR remote controller, external keypad controller and USB 2.0 Mouse Hidden camera option (covert) User-friendly setup menu and operation Playback Multi-screen playback (Full/4/6/7/9/10/13/16 split) -
Page 7: External Storage
FEATURES External storage Automatic backup to selected backup HDD (Event backup/ Mirroring) Own external storage device to extend the HDD capacity You can install 10 HDDs in 1 external HDD Bay and connect up to 4 Bay with this DVR. (250GB X 40HDDs = 10TB, 500GB X 40HDD = 20TB, 1TB X 40HDD = 40TB) Audio 4 channels audio recording in real time... -
Page 8: Packing Detail
PACKING DETAIL Packing Detail Chapter 2 1. DVR 4. Remote controller 2. Network Viewer Program CD 3. User’s Manual 5. R-HDD Rack Key 6 Rack Mounts 7. AC Adaptor & Power Cord 8. Batteries 9. HDD Screws 10. Audio cable CONTENTS 1. -
Page 9: Location And Control
LOCATION AND CONTROL Location and Control Chapter 3 3.1 FRONT PANEL CONTROLS ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û Name Description ¨ ç USB 2.0 port to use a USB memory stick, Mouse or USB external devices ¨... -
Page 10: Rear Panel Connectors
LOCATION AND CONTROL 3.2 REAR PANEL CONNECTORS ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡ Û ¡... -
Page 11: Installation
INSTALLATION Installation Chapter 4 4.1 TOTAL CONNECTION LAY-OUT DIGITAL VIDEO RECORDER... -
Page 12: Individual Connection
INSTALLATION 4.2 INDIVIDUAL CONNECTION 4.2.1 Camera * Connect a female BNC connector of each camera to a male BNC connector, “CAMERA IN” port. * Connect the looping BNC output to other inputs as required 4.2.2 Audio (*Refer to the specification) Audio Input - AUDIO IN : Connect the RCA Line Jack of the relevant equipment (for example, a camera with a built-in microphone) to the AUDIO IN port... -
Page 13: Monitor
INSTALLATION 4.2.3 Monitor - Connect the female BNC for monitor output. - Connect the male Y/C cable socket for S-VIDEO monitor output. DIGITAL VIDEO RECORDER... -
Page 14: External Hdd Bay
INSTALLATION 4.2.4 External HDD Bay (USB output) INSTALLATION PROCESS. 1) Turn off the power of DVR. 2) Connect the grounding conductor between DVR and external HDD bay. 3) Connect the USB cable between DVR and external HDD bay. 4) Connect the power cords of DVR and each external HDD bay. 5) Plug the power cords of DVR and each external HDD bay. -
Page 15: Usb 2.0 Ports
INSTALLATION 4.2.5 USB 2.0 ports ¡ Û Three USB ports are provided to connect a USB memory stick, One USB port is on the front panel and the other two are on the rear panel. ¡ Û A USB mouse can be connected to one of the ports. You can use the mouse to navigate through the screens and menus much like you would on a computer. -
Page 16: Operation
OPERATION Operation Chapter 5 5.1 FACTORY DEFAULT * 16CH DVR MENU Setup> QUICK SETUP> QUICK SETUP…………………….….…….…..…...OFF IMAGE SIZE……………………….………………..720x240 RECORD FRAME……………………….……….…..60 EVENT……….…………………………...…………...ALL PRE RECORD TIME……….…………...….………..5SEC POST RECORD TIME………………….…...……..10SEC IMAGE QUALITY…..…………………………………FINE AUDIO RECORD…………………………….……….OFF REMOTE CONTROL ID…………….…..……….…..ALL SCREEN> AUTO SEQUENCE QUAD-A~E/ SIX/ SEVEN/ NINE-A~B/ TEN/ THIRTEEN/ SIXTEEN….3SEC ADD AUTO SINGLE….………………..…...OFF AUTO-SINGLE CH1~16………………..…..3SEC... - Page 17 OPERATION BRIGHTNESS ……………………………….…. 50% CONTRAST………………………………….….. 50% HUE ……………………………………………… 50% SATURATION…………………………………... 50% RECORD> RECORD SETUP RECORD PROGRAM..……………………..6 RECORD PROGRAM (Refer to 6.3.2) IMAGE QUALITY RECORD QUALITY………………………..FINE AUDIO RECORD AUDIO 1~4………………..…………………..OFF REPEAT RECORD REPEAT RECORD……..……………………..ON REPEAT RECORD ALARM.……………….…..5% PLAY MODE.…………………………………….…..FRAME BACKUP MODE..……………………………….…..OFF HOLIDAY HOLIDAY RECORD………………………….….OFF HOLIDAY SETUP(MM/DD) ………………..…..00/00...
- Page 18 OPERATION ADVANCED SETUP PASSWORD CHECK…………………….……….OFF SET PASSWORD ADMIN PASSWORD…..…….……….…..11111111 USER1 PASSWORD.…………..…….…..22222222 USER2 PASSWORD.…………..…….…..33333333 USER3 PASSWORD.…………..…….…..44444444 USER4 PASSWORD.…………..…….…..55555555 USER AUTHORITY AUTHORITY U1 U2 OFF OFF OFF OFF SEARCH&PLAY OFF OFF O FF OFF COPY OFF OFF O FF OFF LIVE AUDIO OFF OFF O FF OFF DVR SETUP...
- Page 19 OPERATION SEARCH> CALENDAR SEARCH SEARCH© HDD ID………………………………………. NORMAL CHANNEL…………………………………… TIME SEARCH HDD ID………………………………………. NORMAL CHANNEL…………………..………………. EVENT SEARCH HDD ID………………………………………. NORMAL CHANNEL…………………..………………. EVENT…………………..…………………… BLOCK SEARCH HDD ID………………………………………. NORMAL FILE SEARCH MEDIA……………………………………….. USB_FRONT BOOKMARK SEARCH LOG FILE COPY> COPY MEDIA……………………………………….. USB_FRONT HDD ID………………………………………. NORMAL CHANNEL……………………………………...
-
Page 20: Button Controls
OPERATION 5.2 BUTTON CONTROLS 5.2.1 POWER ON /OFF After the connection of power cord and other devices with this DVR, turn the power on. a. The video signal system (NTSC or PAL) is set to AUTO. b. Power Failure Recovery This DVR automatically reverts back to programmed record parameters upon power restoration. - Page 21 OPERATION 5.2.2.2 Auto Sequence Display <ADD AUTO SINGLE : ON> - Press the AUTO button, each screen display will be automatically switching according to the AUTO SEQUENCE setup. - If you set up “ADD AUTO SINGLE : OFF” in the AUTO SEQUENCE setup menu, the single display will be skipped.
-
Page 22: Record
OPERATION 5.2.3 RECORD Press the REC button and the following message will be displayed as below; MANUAL MODE Press the REC button to begin recording. To stop recording, press the REC button again. The screen will be turned into real time display mode. -
Page 23: Search & Playback
OPERATION 5.2.4 SEARCH & PLAYBACK Press the SEARCH button, the SEARCH menu screen appears. TIME SEARCH If you press the PLAY button in the real time screen mode, playback will be executed from the end of the previous time search and press the desired channel select button. To exit the playback mode and see the live screen again, press LV/PB button. - Page 24 OPERATION 5.2.4.2 SEARCH & COPY At the SEARCH menu; ¨ ç Move the cursor to SEARCH© using button. ¨ è Press the ENTER button and SEARCH© screen appears. ¨ é Select the desired HDD ID using the (-) or (+) button. ¨...
- Page 25 OPERATION 5.2.4.4 EVENT SEARCH At the SEARCH menu; Move the cursor to EVENT SEARCH using button. ¨ ç ¨ è Press the ENTER button and the EVENT SEARCH menu screen appears. ¨ é Select the desired HDD ID using the (-) or (+) button. ¨...
- Page 26 OPERATION ¨ é Select the desired HDD ID using the (-) or (+) button. ¨ ê Move the cursor to the desired position of SEARCH TIME using the buttons, and then set up the desired time using the(-), (+) buttons. ¨...
- Page 27 OPERATION <How to make Bookmark list> Press the “PB/PAUSE” button to playback. ¨ ç ¨ è Find the desired image using the SLOW, FAST, DIR buttons. ¨ é Press the “PB/PAUSE” button to see the still picture of the desired image. ¨...
-
Page 28: Play Button Information
OPERATION 5.2.4.9 LOG FILE At the SEARCH menu; Move the cursor to LOG FILE using button. ¨ ç ¨ è Press the ENTER button and the LOG FILE screen appears. ¨ é Move the cursor to the desired position of SEARCH TIME using the buttons, and then set up the desired time using the(-), (+) buttons. -
Page 29: Digital Zoom
OPERATION <How to playback a section repeatedly> Press the “AUTO” button to set up the A position(starting position) and “(A- )” will be displayed on ¨ ç upper right of the screen. ¨ è And then press the “FREEZE” button to set up the B position(ending position) and “(A-B)” will be displayed on upper right of the screen and played between A to B repeatedly. -
Page 30: Screen Select(Lv/Pb)
OPERATION 5.2.7 SCREEN SELECT(LV/PB) During the playback, press the LV/PB button to convert the screen into real time display mode. (Press this button again to return to the playback mode.) 5.2.8 SPOT MONITOR Spot Monitor Set up the desired mode in “SPOT” of “SCREEN MENU” before executing the SPOT mode. 5.2.8.1 MANUAL MODE Press the “SPOT”... -
Page 31: Copy
OPERATION 5.2.9 COPY Press the COPY button to copy the recorded images into other media and the COPY MENU screen appears. 5.2.9.1 COPY 5.2.9.1-1 COPY TO EXTERNAL HDD At the COPY menu, ¨ ç Move the cursor to COPY using the buttons. - Page 32 OPERATION 5.2.9.1-2 COPY TO USB memory stick At the COPY menu, ¨ ç Move the cursor to COPY using the buttons. ¨ è Press the ENTER button and the following screen appears. ¨ é Select the desired MEDIA using (-), (+) buttons. ¨...
- Page 33 OPERATION 5.2.9.1-3 COPY TO CD-R/ CD-RW/ DVD¡ ¾ RW/ DVD-RAM At the COPY menu, ¨ ç Move the cursor to COPY using the buttons. ¨ è Press the ENTER button and the following screen appears. ¨ é Select the desired MEDIA(INTERNAL CD-RW/DVD) (-), (+) buttons. ¨...
- Page 34 OPERATION 5.2.9.1-5 CONTINUE COPY If the media is full or fail during copying, you can see the following message, “MEDIA FULL OR ¨ ç FAIL PRESS [COPY]” message. ¨ è Press the COPY button and the following screen appears. ¨ é Move the cursor to the CONTINUE COPY and then press the ENTER button.
-
Page 35: Dvr Status
OPERATION 5.2.9.3 MEDIA FORMAT At the COPY menu, ¨ ç Move the cursor to MEDIA FORMAT using the buttons. ¨ è Press the ENTER button and the following screen appears. ¨ é Select formatting media using the (-), (+) button. ¨... -
Page 36: Ptz Control
OPERATION 5.2.11 PTZ CONTROL 5.2.11.1 PTZ control in live view Press the “PTZ” button to control pan, tilt and zoom functions of PTZ camera and the PTZ ¨ ç channel, model name and ID will be displayed on the left side of the monitor as the following picture. -
Page 37: Function Button
OPERATION 5.2.12 FUNCTION BUTTON You need this button to control “USER” mode of RELAY 4 SELECT. Please refer to 6.4.8 RELAY OUTPUT. 5.2.13 AUDIO SELECT < Audio select > You can select audio channels regardless of monitoring screen. Press the “0(audio select)” button and then press the desired number button and you can hear audio of selected channel regardless of monitoring screen. -
Page 38: Remote Controller
OPERATION 5.3 REMOTE CONTROLLER Button Name Description ¡ Û ¡ Û REMOTE Refer to 6.5.6 REMOTE CONTROLLER ID in the system setup CONTROLLER ID Iris close and open of PTZ / ¡ Û (IRIS-/+) Frame by Frame(field by field) playback ¡... -
Page 39: Menu Setup
MENU SETUP MENU setup Chapter 6 ENTRANCE OF THE MENU SETUP Press the MENU button for the desired DVR setting. You can use the mouse instead of buttons on the front panel of DVR. Simply click the desired icon or item in case of using the mouse. If there is no input for 1 minute during the menu screen display, the menu screen will be closed automatically without saving of changed value. -
Page 40: Pre Record Time
MENU SETUP 6.1.4 EVENT Select a kind of EVENT using the (-), (+) buttons. If you want to select all kind of event, choose “ALL” and if you don’t want event recording, choose “OFF”. The default is “ALL”. alarm, loss, motion). NOTE: Divide event type into three classes( 6.1.5 PRE RECORD TIME Select the desired time for pre-recording using the (-), (+) buttons. -
Page 41: Screen
MENU SETUP 6.2 SCREEN To set up the SCREEN menu, ¨ ç Move the cursor to the SCREEN icon using the buttons in the MENU screen. ¨ è Press the ENTER button when the cursor is on the SCREEN icon and the following items appear. 6.2.1 AUTO SEQUENCE At the SCREEN menu, ¨... - Page 42 MENU SETUP [ 16CH DVR ] ¨ é Move the cursor to each single or split channel using the buttons. ¨ ê When the desired channel is selected, change the value of AUTO SEQUENCE duration using the (-), (+) buttons to set the length of time for switching each channel in sequence. * The value is from 1SEC to 60SEC and the default is “3SEC”.
-
Page 43: Display
MENU SETUP 6.2.2 DISPLAY At the SCREEN menu, ¨ ç Move the cursor to the DISPLAY using buttons. ¨ è Press the ENTER button when the cursor is on the DISPLAY and the following items appear. ¨ é To exit this DISPLAY menu, press the ESC button. 6.2.2.1 HDD FREE SPACE At the DISPLAY menu, ¨... - Page 44 MENU SETUP 6.2.2.5 DATE&TIME MODE At the DISPLAY menu, ¨ ç Move the cursor using the buttons to select the DATE&TIME MODE. ¨ è Use the (-), (+) buttons to choose “MM/DD/YY”, “DD/MM/YY” or “YY/MM/DD”. * The default is “YY/MM/DD”. YY/MM/DD : All date and time will be displayed in numbers.
-
Page 45: Title
MENU SETUP 6.2.3 TITLE At the SCREEN menu, ¨ ç Move the cursor to the TITLE using buttons. ¨ è Press the ENTER button when the cursor is on the TITLE and the following 2 pages screen appears. ¨ é Use the buttons to see the next page. -
Page 46: Multi Screen
MENU SETUP 6.2.4 MULTI SCREEN You can select the desired channels and make a 4 split screen and a 9 split screen using this menu. At the SCREEN menu, ¨ ç Move the cursor to the MULTI SCREEN using buttons. ¨... -
Page 47: Covert
MENU SETUP 6.2.5 COVERT At the SCREEN menu, ¨ ç Move the cursor to the COVERT using the buttons. ¨ è Press the ENTER button when the cursor is on the COVERT and the following 2 pages screen appears. ¨ é Move the cursor and select the desired item using the buttons. -
Page 48: Spot
MENU SETUP 6.2.6 SPOT At the SCREEN menu, ¨ ç Move the cursor to the SPOT using buttons. ¨ è Press the ENTER button when the cursor is on the SPOT and the following screen appears. ¨ é To exit this SPOT menu, press the ESC button. 6.2.6.1 SPOT MODE Use the (-), (+) buttons to select the SPOT MODE. -
Page 49: Record
MENU SETUP 6.3 RECORD To set up the RECORD menu, ¨ ç Move the cursor to the RECORD icon using the in the MENU screen. ¨ è Press the ENTER button when the cursor is on the RECORD icon and the following items appear. 6.3.1 RECORD SETUP This menu allows you to configure a weekly recording schedule. -
Page 50: Record Program
MENU SETUP 6.3.2 RECORD PROGRAM This feature uses predefined recording modes to create new ones according with your own needs. This means you can create different programs using existing predefined programs. You can have up to 10 different programs (0~9) available. These programs will be used to set up the recording schedule on the RECORD SETUP menu. - Page 51 MENU SETUP <WHAT DOES THE EACH ITEM MEANS?> 1. REC PROGRAM Shows the current PROGRAM #. Example PROGRAM0. Select the program according with your needs .Predefine programs are from 0 – 9. User can choose the program number to be modified here. 2.
- Page 52 MENU SETUP There are two types of events: SINGLE and COMPLEX. SINGLE EVENT CH ONLY ALL CHANNELS Under the EVENT IPS the DVR will Under the EVENT IPS the DVR will record the channel triggered by any record the channels triggered by any event using the higher IPS on a event with the IPS value predefined or particular channel.
- Page 53 MENU SETUP (b) For SINGLE/ALL CHANNLES • The displayed format is ‘nn/AUTO’. • The value ‘nn’ of a channel is the recording IPS of the channel with an event. and ‘AUTO’ means that the auto-calculated IPS of the channel when event will happen from other channels.
- Page 54 MENU SETUP 10 PREDEFINED PROGRAMS ARE INCLUDED BY DEFAULT. PROGRAMS ARE AVAILABLE FROM 0 - 9. PROGRAM 0. PROGRAM 1 FEATURES. FEATURES RECORDING MODES: RECORDING MODES: NORMAL (Continuous) : 0 ips NORMAL (Continuous) : 4 fps COMPLEX/EVENT CH ONLY 0 15 fps EVENT EVENT...
- Page 55 MENU SETUP PROGRAM 4. PROGRAM 5 FEATURES. FEATURES. RECORDING MODES: RECORDING MODES: NORMAL (Continuous) : 2 ips NORMAL (Continuous) : 1 ips SINGLE /EVENT CH ONLY 15 SINGLE /EVENT CH ONLY 30 EVENT EVENT RESOLUTION . 720 X 240 RESOLUTION . 720 X 240 QUALITY: L/L QUALITY: F/F PRE/POST 5/10...
-
Page 56: Image Quality
MENU SETUP PROGRAM 8. PROGRAM 9 FEATURES. FEATURES. RECORDING MODES: RECORDING MODES: NORMAL (Continuous) : 1 ips NORMAL (Continuous) : 1 ips SINGLE /EVENT CH ONLY 10 i COMPLEX /EVENT CH ONLY 1 i EVENT EVENT RESOLUTION . 720 X 480 RESOLUTION . -
Page 57: Audio Record
MENU SETUP At the RECORD menu, ¨ ç Move the cursor to the IMAGE QUALITY using buttons. ¨ è Press the ENTER button when the cursor is on the IMAGE QUALITY and the following screen appears. ¨ é Select the desired RECORD QUALITY using the (-), (+) buttons. ¨... -
Page 58: Repeat Record
MENU SETUP 6.3.5 REPEAT RECORD At the RECORD menu, ¨ ç Move the cursor to the REPEAT RECORD using buttons. ¨ è Press the ENTER button when the cursor is on the REPEAT RECORD and the following screen appears. ¨ é Use the (-), (+) buttons to set “ON”... -
Page 59: Holiday
MENU SETUP 6.3.8 HOLIDAY At the RECORD menu, ¨ ç Move the cursor to the “HOLIDAY” using buttons. ¨ è Press the “ENTER” button to set up “HOLIDAY” and the HOLIDAY menu screen appears. ¨ é Set up “ON” or “OFF” of HOLIDAY RECORD using the (-), (+) buttons. ¨... -
Page 60: Event
MENU SETUP 6.4 EVENT To set up the EVENT menu, ¨ ç Move the cursor to the EVENT icon using the in the MENU screen. ¨ è Press the ENTER button when the cursor is on the EVENT icon and the following items appear. 6.4.1 MOTION DETECTION At the EVENT menu, ¨... -
Page 61: Event Screen Mode
MENU SETUP 6.4.1.3 AREA SETUP At the MOTION DETECTION menu, ¨ ç Move the cursor to AREA SETUP using buttons. ¨ è Press the ENTER button to set the motion detection area. ¨ é Select the motion detection area using the buttons and then press the ENTER button to save the area. -
Page 62: Event Buzzer
MENU SETUP 6.4.6 EVENT BUZZER At the EVENT menu, ¨ ç Move the cursor to the EVENT BUZZER using buttons. ¨ è Select “ON’ or “OFF” using the (-), (+) buttons to set the event buzzer. 6.4.7 SENSOR INPUT At the EVENT menu, ¨... -
Page 63: Relay Output
MENU SETUP 6.4.8 RELAY OUTPUT At the EVENT menu, ¨ ç Move the cursor to the “RELAY OUTPUT” using the buttons. ¨ è Press the ENTER button when the cursor is on the “RELAY OUTPUT” and the following screen appears. ¨... -
Page 64: System
MENU SETUP 6.5 SYSTEM To set up the SYSTEM menu, ¨ ç Move the cursor to the SYSTEM icon using the in the MENU screen. ¨ è Press the ENTER button when the cursor is on the SYSTEM icon and the following items appear. 6.5.1 HDD At the SYSTEM menu, ¨... - Page 65 MENU SETUP 6.5.1.1 HDD CONFIGURATION At the HDD menu, ¨ ç Move the cursor to HDD CONFIGURATION using the buttons. Press the ENTER button when the cursor is on the HDD CONFIGURATION and the following ¨ è screen appears. ¨ é Use the buttons to move the cursor and use the (-), (+) buttons to change the value.
-
Page 66: Clock
MENU SETUP 6.5.1.3 BACKUP HDD INITIALIZE At the HDD menu, ¨ ç Move the cursor to “BACKUP HDD INITIALIZE” using the buttons. Press the “ENTER” button when the cursor is on the “BACKUP HDD INITIALIZE” and the ¨ è following screen appears. ¨... -
Page 67: Video Standard
MENU SETUP 6.5.2.2 TIME ADJUST At the CLOCK menu, ¨ ç Move the cursor to the TIME ADJUST using the buttons. ¨ è Press the ENTER button when the cursor is on the TIME ADJUST and the following screen appears. ¨... -
Page 68: Language
MENU SETUP 6.5.4 LANGUAGE At the SYSTEM menu, ¨ ç Move the cursor to the LANGUAGE using the buttons. ¨ è Select the desired language using the (-), (+) buttons. * Available languages: ENGLISH, KOREAN, JAPANESE , POLISH, SPANISH, RUSSIAN, CHINESE, TAIWANESE. -
Page 69: Password Check
MENU SETUP 6.5.7.1 PASSWORD CHECK At the ADVANCED SETUP menu, ¨ ç Move the cursor to the PASSWORD CHECK using the buttons. ¨ è Select ON or OFF using the (-), (+) buttons. If you select OFF, password menu won’t work. 6.5.7.2 SET PASSWORD At the ADVANCED SETUP menu, ¨... - Page 70 MENU SETUP 6.5.7.3 USER AUTHORITY At the ADVANCED SETUP menu, ¨ ç Move the cursor to the USER AUTHORITY using the buttons. ¨ è Press the ENTER button when the cursor is on the USER AUTHORITY and the following screen appears.
-
Page 71: Firmware Upgrade
MENU SETUP ¨ é If you want to initialize, move the cursor to “YES” and then press the ENTER button. If not, move the cursor to “NO” and then press the ENTER button. Use the buttons to move the cursor. NOTE: If you do this MENU INITIALIZE, all menu setting values will be factory default. -
Page 72: Link
MENU SETUP 6.6 LINK To set up the LINK menu, ¨ ç Move the cursor to the LINK icon using the in the MENU screen. ¨ è Press the ENTER button when the cursor is on the LINK icon and the following items appear. 6.6.1 NETWORK At the LINK menu, ¨... - Page 73 MENU SETUP 6.6.1.2 IP ADDRESS At the NETWORK menu, ¨ ç Move the cursor to the IP ADDRESS using the buttons. ¨ è Select the desired position using the buttons and set the data value using the (-), (+) buttons. 6.6.1.3 SUBNET MASK At the NETWORK menu, ¨...
- Page 74 MENU SETUP 6.6.1.9 NETWORK FRAME At the NETWORK menu, ¨ ç Move the cursor to the NETWORK FRAME using the buttons. ¨ è Select the value using the (-), (+) buttons. STILL: Transmits only I-Picture of GOP(Group of Picture) to be saved in DVR. MOTION: Transmits all images of GOP.
-
Page 75: Rs232C
MENU SETUP 6.6.2 RS232C At the LINK menu, ¨ ç Move the cursor to the RS232C using the buttons. ¨ è Press the ENTER button when the cursor is on the RS232C and the following screen appears. Use the buttons to choose the item and use the (-), (+) buttons to set the data value. ¨... -
Page 76: Ptz
MENU SETUP 6.6.4 PTZ At the LINK menu, ¨ ç Move the cursor to the PTZ using buttons. ¨ è Press the ENTER button when the cursor is on the PTZ and the following 1 or 2 pages screen appears. ¨... - Page 77 MENU SETUP 6.6.5.2 SMTP SERVER At the E-MAIL menu, ¨ ç Move the cursor to the SMTP SERVER using the buttons to input the e-mail sever address to be used by DVR. ¨ è Press the ENTER button and the following screen appears. ¨...
- Page 78 MENU SETUP 6.6.5.4 USER ID At the E-MAIL menu, ¨ ç Move the cursor to the USER ID using the buttons to input the e-mail account to be used by DVR. ¨ è Press the ENTER button and the following screen appears. ¨...
-
Page 79: Search
MENU SETUP 6.7 SEARCH To set up the SEARCH menu, ¨ ç Move the cursor to the SEARCH icon using the in the MENU screen. ¨ è Press the ENTER button when the cursor is on the SEARCH icon and the following items appear. ** Please, refer to Search &... -
Page 80: Exit
MENU SETUP 6.9 EXIT At the MENU screen, ¨ ç Move the cursor to the EXIT icon using the buttons. ¨ è Press the ENTER button when the cursor is on the EXIT icon and the following items appear. ¨ é Move the cursor to the desired item using the buttons and press the ENTER button. -
Page 81: External Terminal Information
EXTERNAL TERMINAL INFORMATION External Terminal Information Chapter 7 7.1 RS-485 These ports are to control the connected PTZ cameras and can be used to connect the external controller. DESCRIPTION TA(TX+) RS485:Transmit data TB(TX-) RS485: Receive data 7.2 T.ADJ Time adjust input port is high level at normal and check signal every 100ms. -
Page 82: Relayout / Alarm
EXTERNAL TERMINAL INFORMATION 7.3 RELAY OUT For controlling alarm output by relay DESCRIPTION DESCRIPTION NO(Normal Open) NO(Normal Open) ALARM CM(Common) CM(Common) POWER NO(Normal Open) NO(Normal Open) USER V-LOSS NOT USED CM(Common) CM(Common) HDD ERROR 7.4 ALARM DESCRIPTION EXTERNAL ALARM 1 INPUT EXTERNAL ALARM 2 INPUT EXTERNAL ALARM 3 INPUT EXTERNAL ALARM 4 INPUT... -
Page 83: Vga / Serial
EXTERNAL TERMINAL INFORMATION 7.5 VGA This DVR supports 1024 x 768 resolution & 70Hz refreshed rate in NTSC/PAL mode. DESCRIPTION RED(Red Video [75ohm, 0.7Vp-p] ) GREEN(Green Video [75ohm, 0.7Vp-p] ) BLUE(Blue Video [75ohm, 0.7Vp-p] ) 4~12 Reserved HSYNC or CSYNC(Horizontal or Composite Sync.) VSYNC(Vertical Sync.) Reserved 7.6 SERIAL... -
Page 84: Ethernet/Usb
EXTERNAL TERMINAL INFORMATION 7.7 Ethernet / USB For both 10Base-T and 100 Base-TX. DESCRIPTION N/C (Not Connected) N/C (Not Connected) RX-(Receive Data-) N/C (Not Connected) N/C (Not Connected) RX+(Receive Data+) TX-(Transmit Data-) TX+(Transmit Data+) ETHERNET DESCRIPTION USB2 USB DATA - USB DATA + USB1 USER’S MANUAL... -
Page 85: Specifications
SPECIFICATIONS Specifications Chapter 8 ANX-470 ANX-870 ANX-1670 1. VIDEO Input Level 1.0 Vp-p±10% Composite, 75Ω Balanced Video Standard NTSC(525 lines)/ PAL(625 lines)/ AUTO NTSC 120fps 240fps 480fps Display Speed 100fps 200fps 400fps NTSC 720(H) X 480(V) Display Resolution 720(H) X 576(V) Main 1.0Vp-p Composite, 75Ω... - Page 86 SPECIFICATIONS External control (RS-232C) / Serial For debugging : 9 pins male DSUB Terminal Block External control (RS-485) Alarm Input 16CH 4 Relay output : 3 pins terminal block Alarm Output (Normal-Open, Normal-Close, Common) x 4 Ethernet RJ45 connector, 10/100 Mbps 7.
-
Page 87: Camera Integration System
256 CAMERA INTEGRATION SYSTEM < Recording Speed Table > *Note 1, 2 Unit : ips Model 4CH/ 8CH /16CH Recording Speed NTSC 360 x 240 720 x 240 720 x 480 360 x 288 720 x 288 720 x 576 Compression Method MPEG4 RECORDING CONDITIONS (NTSC) -
Page 88: Camera Integration System
SPECIFICATIONS 256 Camera Integration system Chapter 9 Block Diagram USER’S MANUAL... -
Page 89: Hdd Installation
HDD INSTALLATION PROCESS HDD Installation Process Chapter 10 10.1 Internal HDD installation 10.1.1 How to install the internal Hard Disk Drive(s). 1) Unscrew on the top, the side and the rear of this unit as indicated to remove the cover. Caution) Plug out the power cord before addition / removal / change of HDD 2) Remove the upper cover from the unit and unscrew... - Page 90 HDD INSTALLATION PROCESS 4) Place the HDD(s) on the HDD plate and screw as indicated. Put the ring guides same as picture on the rubber before screwing. (Set the master or slave of HDD before fixing the HDD(s) into DVR. Refer to the HDD Jumper Setting Information.) 5) Connect the power and the flat cables as indicated.
- Page 91 HDD INSTALLATION PROCESS 10.1.2 How to install Hard Disk Drive(s) into the removable HDD rack. 1) Grip the strap of removable HDD rack and pull it out. 2) Remove the cover of removable HDD rack and connect the HDD with the cables as indicated. 3) Put the HDD into the rack and close the top cover.
-
Page 92: Dvd¡ ¾ Rw(Or Cd-Rw) Installation
HDD INSTALLATION PROCESS 10.2 DVD¡ ¾ RW(or CD-RW) installation 1) Put out the cables and unscrew to remove the removable HDD rack as indicated. NOTE If you want to install DVD¡ ¾ RW (or CD-RW) into this DVR, you need a USB to IDE interface board. Please ask to a seller. - Page 93 HDD INSTALLATION PROCESS 6) Screw to fix the DVD¡ ¾ RW(or CD-RW) as indicated. 7) Prepare for the USB to IDE interface board and parts ¡ Û to connect it as the picture. ¡ Û ¡ Û ¡ Û ¡ Û ¡...
-
Page 94: Network Viewer
NETWORK VIEWER INSTALLATION Network Viewer Chapter 11 The DVR Viewer is a dedicated client program that connects to, monitors and manages up to 16 DVRs simultaneously. 11.1 SYSTEM REQUIREMENT The DVR Viewer receives, decodes and displays data for up to 16 DVRs or up to 256 cameras simultaneously requiring a powerful personal computer to take full advantage of the program. -
Page 95: Installing The Dvr Viewer
NETWORK VIEWER INSTALLATION 11.3 INSTALLING THE DVR VIEWER Insert the program CD into the CD-ROM or DVD-ROM drive of the computer and locate the SETUP.EXE file. Double-click on the setup file, and the program will start the installation. Click on NEXT. The DVR viewer will be installed in its default folder of C:\Program Files\DVR\DVR-Viewer. -
Page 96: Dvr Viewer - Layout
NETWORK VIEWER INSTALLATION 11.4 DVR VIEWER - LAYOUT Locate the DvrViewer icon on the desktop and double-click on it to run the client software. The program can also be located in START- Programs – DVR-Viewer. When the DVR Viewer is run for the first time, it prompts for the administrator’s password. -
Page 97: Network Viewer Installation
NETWORK VIEWER INSTALLATION 1. DVR LIST The DVR List adds or removes individual DVRs and offers a variety of connection options. DVR List The DVRs that have been added are listed in this box. Connection Type Select the connection type to the DVR. DVR Name Enter the DVR name. - Page 98 NETWORK VIEWER INSTALLATION Use IP Server The DVR can be located on the internet using the MAC address displayed in the status screen. If the MAC address is to be used, “Use IP Server” box must be checked. Domain Name / Use DDNS The DVR can be located on the internet using a domain name, or a web address.
- Page 99 NETWORK VIEWER INSTALLATION 2. DVR SEARCH Within a local area network environment (LAN), it is possible to automatically scan and list available DVRs to be added to the DVR list. Click on DVR SEARCH to open the DVR Search window. Click on SEARCH, and available DVRs will be listed.
- Page 100 NETWORK VIEWER INSTALLATION 3. HDD SEARCH The hard disk drive from the DVR can be directly connected to a PC, where the files can be searched and played back through the DVR Viewer. Click on HDD SEARCH to open the HDD Search window Select a hard disk drive, and then click on OK.
- Page 101 NETWORK VIEWER INSTALLATION If the desired file is not listed in the current folder, then select the folder in which the files are saved by clicking on FOLDER SELECT. Select a file to view, and then click on PLAY to begin the playback. The file can also be played back by double-clicking on it.
- Page 102 NETWORK VIEWER INSTALLATION 5. ARRANGE WINDOW Arrange window button works only in detached window mode (See #9). When viewing multiple DVRs, clicking on ARRANGE WINDOW sort and display all DVR connection windows in a tile format. SINGLE DVR 1 ~ 4 DVRS 5 ~ 9 DVRS 10 ~ 16 DVRS USER’S MANUAL...
- Page 103 NETWORK VIEWER INSTALLATION 6. VIEWER OPTION Viewer option defines the administrative options for the DVR Viewer, such as display options and the IP address of the Dynamic IP Server, and user management to create user name and passwords for additional users to access the DVR Viewer. 6.1 Viewer Option Click on VIEWER OPTION to open the Viewer Option window.
- Page 104 NETWORK VIEWER INSTALLATION To add additional users, click on ADD. Enter the user name, description for the user, password and access privileges, and then click on SAVE to add the new user. The user setting can be modified by highlighting the user and clicking on CHANGE once the changes are made.
- Page 105 NETWORK VIEWER INSTALLATION 9. ATTACH / DETACH WINDOW The channel display window can be attached or detached to the controls by clicking on this button. 10. TIME & VERSION DISPLAY Displays the local time and current DVR Viewer version. 11. CHANNEL DISPLAY SELECTION Any one of the single channels can be viewed in full screen mode by clicking on any channel numbers.
- Page 106 NETWORK VIEWER INSTALLATION 16. PTZ CONTROLLER Pan, Tilt and Zoom cameras can be controlled remotely through the DVR Viewer. Channel select Select the channel in which the PTZ camera is installed. Directional buttons / Autofocus Move the PTZ camera using the directional buttons. Toggle Autofocus on or off by clicking on C.
- Page 107 NETWORK VIEWER INSTALLATION 18.STATUS Displays the current DVR status on System, Record and Network. 18.1 System System status displays the following information: Video type Software version Hardware version Current temperature of the DVR in both Celsius and Fahrenheit Total number of hard disk drives Recording mode of the hard disk drives Total space of fixed hard disk drive Remaining free space of fixed hard disk drive...
- Page 108 NETWORK VIEWER INSTALLATION 19.PRINT In live or playback mode, select any of the channels and then click on PRINT to bring up the screen print window. Zoom in / out Click the + or – button to zoom in and out for the detailed view of the picture. Paper size Select the paper size.
- Page 109 NETWORK VIEWER INSTALLATION 20.COPY The data on the DVR can be downloaded onto the PC using the COPY function. The data can also be backed up directly onto available backup media on the DVR. Available data Displays available data to be downloaded. Hard disk drive selection Select the hard disk drive to download from.
- Page 110 NETWORK VIEWER INSTALLATION 1. MICROPHONE / TALK For the voice communication over the internet, click on the MICROPHONE button and then talk into an available microphone. 2. SPEAKER / LISTEN Listen in on any of the four channels with audio recording over the internet. Bring any one of the channels with audio recording to full screen to listen into a specific channel.
- Page 111 NETWORK VIEWER INSTALLATION 9. RECORD / PLAYBACK BUTTONS The remote playback can be controlled just as on the DVR. The remote playback can be played in normal, slow, and fast modes in both forward and reverse direction. The DVR Viewer can also record the remote transmission onto the computer’s hard disk drive. Record Click on the RECORD button to start recording on to the computer.
-
Page 112: Dvr Viewer - Live Mode
NETWORK VIEWER INSTALLATION 13. FRAMES PER SECOND Displays the frame rate of incoming live stream or playback stream. 14. LIVE / PLAYBACK BUTTON STATUS During live or playback, this window will display the direction and the speed of the playback direction. 15. - Page 113 NETWORK VIEWER INSTALLATION DVR’s local time Displays the DVR’s local date and time Event message Displays the channel’s event messages, alarm and motion. Channel window The DVR channel window can be double-clicked for a full screen mode. The channel window can also be zoomed by dragging the left mouse button over the channel window.
-
Page 114: Dvr Viewer - Playback Mode
NETWORK VIEWER INSTALLATION 11.6 DVR VIEWER – PLAYBACK MODE Any DVRs that are connected online can be accessed to do data search remotely from the DVR and then transmit to the DVR viewer for remote playback. DVR’s playback time Displays the DVR’s playback date and time. Channels without recording show NO IMAGE. Event message Displays the channel’s event messages at the time of the recording. -
Page 115: Time Search
NETWORK VIEWER INSTALLATION 11.6.1 TIME SEARCH Click on TIME to display the Time Search window. The start and the end of the recorded data will be displayed. Select the hard disk drive for the remote playback. unknown, leave the selection to Normal. Select the channel for playback. -
Page 116: Calendar Search
NETWORK VIEWER INSTALLATION 11.6.2 CALENDAR SEARCH Click on CALENDAR to display the Calendar Search window. Dates with recorded data will be highlighted in yellow. Select the year, month, date, and the hour block, and then click on PLAY to begin the remote playback. 11.6.3 EVENT Click on EVENT to display the Event Search window. - Page 117 NETWORK VIEWER INSTALLATION Select the channel for playback. Select the event categories. Select the year, month, day and time for the end of the event list for playback. The list can be advanced to the next 500 lists by clicking on NEXT.
- Page 118 NETWORK VIEWER INSTALLATION 11.6.4 TEXT Click on TEXT to display Text Search window. Select the hard disk drive for the remote playback. unknown, leave the selection to Normal. Select the channel for the text string search. Enter the text string to search. Leave blank for a wild card (all items) search.
- Page 119 NETWORK VIEWER INSTALLATION Select the year, month, day and time for the end of the search time. Click on SEARCH to list data that match the text string. If the text string search was left blank, then it will display all items.
- Page 120 NETWORK VIEWER INSTALLATION 11.6.5 BLOCK Click on BLOCK to display the Logical Block Address Search window. The first 500 data is displayed in chronological order, from the most recent to the oldest. Select the hard disk drive for the remote playback. If unknown, leave the selection to Normal.
-
Page 121: Dvr Palyer - Setup
NETWORK VIEWER INSTALLATION 11.7 DVR PLAYER – SETUP The DVR Viewer can change the settings on the DVR remotely. The features and settings are identical to that of the DVR menu. For more information, please see V. DVR MENU on page. Click on SETUP and the password prompt will be displayed. - Page 122 NETWORK VIEWER INSTALLATION 7. DOWNLOAD Update the DVR’s firmware using the download menu. 8. READ FROM FILE Load DVR settings from a DVR setup file. 9. SAVE TO FILE Save DVR settings to a DVR setup file. 10. LOAD FROM DVR Load current DVR settings.
- Page 123 NETWORK VIEWER INSTALLATION 11.7.2.2 Display HDD Free Space: on / off. HDD Free Space Mode: percent / gigabyte. Record Status: on / off. Clock Display: on / off. Date & Time Mode: YY/MM/DD, MM/DD/YY, DD/MM/YY. Title Display: on / off. Title Mode: text / bitmap.
- Page 124 NETWORK VIEWER INSTALLATION 11.7.2.4 Multiscreen Customize the channels to be displayed in 4E, 6, 7, 9B, 10 and 13 channel view modes. 11.7.2.5 Covert Channels 1 through 16: on / off. Select: live, play, network, LV & PB, LV & NW, PB &...
- Page 125 NETWORK VIEWER INSTALLATION 11.7.3 RECORD 11.7.3.1 Record Schedule Record: click on a hour block and then click Schedule Record on / off. Monday through Sunday: select the record program. Repeat Record: on / off. Repeat Record Alarm: 5% through 10%, off. Backup Mode: mirror, event, off.
- Page 126 NETWORK VIEWER INSTALLATION 11.7.3.3 Holiday Holiday Record: on / off. Holiday Setup: enter the holidays. 11.7.4 EVENT 11.7.4.1 Event Event Check: on / off. Event Screen Mode: screen hold, event full, event multi, event full return, event multi return. Event Message: on / off. Event Message Reset: 1 to 30 seconds.
- Page 127 NETWORK VIEWER INSTALLATION Select the grid size. Use the left mouse button to draw motion detection area and use the right mouse button to erase motion detection area. Use the buttons at the bottom of the screen to set or clear motion detection all area of the screen.
- Page 128 NETWORK VIEWER INSTALLATION 11.7.5 SYSTEM 11.7.5.1 System Video Standard: PAL, NTSC, auto. Language: English, Korean, Japanese, Polish, Spanish, Russian and Chinese. Remote Control ID: All, 11 through 14, 21 through 24, 31 through 34 and 41 through 44. Key Echo: on / off. 11.7.5.2 HDD Select the recording mode for the HDD.
- Page 129 NETWORK VIEWER INSTALLATION 11.7.5.3 PASSWORD Password Check: on / off Passwords: define the DVR access passwords for all users. Authority: define DVR access authority for users 1 through 4. 11.7.6 LINK 11.7.6.1 Network DHCP: on / off. IP Address: enter the IP address. Subnet Mask: enter the subnet mask.
- Page 130 NETWORK VIEWER INSTALLATION 11.7.6.3 RS-485 System ID: select the system ID. Output Mode: select the output mode. Baud Rate: select the communication speed. Data Bit: select the data bit. Parity Bit: select the parity bit. Stop Bit: select the stop bit. 11.7.6.4 PTZ Model: select the PTZ camera model.
- Page 131 NETWORK VIEWER INSTALLATION 11.7.7 DOWNLOAD The DVR’s firmware can be updated from the client software. Please remember that once the upgrade process begins, the connection must not be severed or interrupted. Click on FIRMWARE DOWNLOAD, and the DVR firmware open window will open. Locate the upgrade file and then click on OPEN to begin the upgrade process.
- Page 132 NETWORK VIEWER INSTALLATION Once the download is complete, the DVR will begin flashing the new firmware. Once the upgrade is finished and successful, the DVR viewer will display “DVR Upgraded Successfully!!” Restart the DVR, and the new firmware will be in effect. USER’S MANUAL...
-
Page 133: Appendix
APPENDIX APPENDIX TIME ZONE LISTING GMT-12:00 International Date Line West GMT-11:00 Midway Island, Samoa GMT-10:00 Hawaii GMT-09:00 Alaska GMT-08:00 Pacific Time (US & Canada); Tijuana GMT-07:00 Arizona GMT-07:00 Chihuahua, La Paz, Mazatlan GMT-07:00 Mountain Time (US & Canada) GMT-06:00 Central America GMT-06:00 Central Time (US &... - Page 134 APPENDIX GMT+03:00 Nairobi GMT+03:30 Tehran GMT+04:00 Abu Dhabi, Muscat GMT+04:00 Baku, Tbilisi, Yeveran GMT+04:30 Kabul GMT+05:00 Ekaterinburg GMT+05:00 Islamabad, Karachi, Tashkent GMT+05:30 Chennai, Kolkata, Mumbai, New Delhi GMT+05:45 Kathmandu GMT+06:00 Almaty, Novosibirsk GMT+06:00 Astana, Dhaka GMT+06:00 Sri Jayawardenepura GMT+06:30 Rangoon GMT+07:00 Bangkok, Hanoi, Jakarta GMT+07:00...
Need help?
Do you have a question about the ANX-1670 and is the answer not in the manual?
Questions and answers
