Summary of Contents for AIMON HMA-1
- Page 1 AIMON HMA-1 Headphone Mixer/Amplifier ENGLISH User’s Manual www.tuact.com 2011 All Rights Reserved.
- Page 2 Package Includes: AIMON HP HMA-1 Mixer/Amplifier Fiber optical Cable USB Cable AUX Cable Quick Start Card Introduction: The Aimon HP Mixer/ Amplifier is specifically engineered for serious online gamers in mind. AIMON HP is the only choice when every moment is critical and the communication is the key vital factor that decides winning and losing. If you play fast paced tactical team based games online the AIMON HP gives you a real edge over your competition.
- Page 3 Getting Know about the AIMON HP unit: Master Volume Control/Setup/Power knob Adjust the headphone output volume and settings; Press to select and adjust audio volume, gain and tone; Turn on/Off the Power. Indicator LEDs Indicate selected audio channel, tone and amplifier gain to be adjusted and mode.
- Page 4 Getting Know about the AIMON HP unit: System Diagram: Line In Optical In Coaxial In Optical Out Mic Out Audio In USB Audio engine Decoder Headphone Digital Signal Amplifier Processor Analog mixer Digital mixer Mic In AUX Mic Out AUX Line In Headphone Output Figure 3...
- Page 5 Connect the AIMON HP to console: Connect to PS3: PS3 (Back panel) DIGITAL IN POWER / USB Mic DIGITAL OUT (OPTICAL) Optical Cable PS3 (Front panel) USB Port USB Cable Note: Headset It can also be a separate stand - alone type microphone and a standard stereo headphone Mic In Headphone Out...
- Page 6 Connect to PC as USB sound card or other audio device (optional): You can connect AIMON HP to any audio device that have optical, coaxial or Line Out output. When plugged into the PC USB Port, AIMON HP will work as a sound card with headphone output and microphone input. To USB port as USB sound card To USB port (Power supply) DVD Player...
- Page 7 Setup XBOX360 for AIMON HP: On the XBOX360 main menu: Go to Console Settings-> Audio -> Digital Output: Select the “Digital Stereo” digital output data format. Setup PC or other audio source to for AIMON HP: 1. For AIMON HP working as USB sound card on PC, select the “USB audio device” as your audio output and micro phone input in your device manager window.
-
Page 8: Specifications
USB port must have the power on for the AIMON HP to reset. Support: E-mail: support@tuact.com or visit our web site at www.tuact.com for technical assistance. Limited Warranty: This product is warranted to the ORIGINAL purchaser for the normal intended use for a period of one year from the date of purchase.
