Ensure that a fuse or circuit breaker no larger than 120 VAC 15A or 240 VAC 6A is used on the phase conductors (all current-carrying conductors). DO NOT allow anything to rest on the APL1400-200 interconnect cables. DO NOT locate APL1400-200 where people may walk on the cables.
Plug-and-Play simplicity utilizing the existing electrical wiring facility as the network infrastructure connections. The APL1400-200 enables IP Cameras, Video Servers, POS, Media Converters, Printers, Digital Signages and Network Equipments for easy broadband access in a tight cluster space. The APL1400-200 NetBridge can be quickly installed for commercial applications require high ™...
APL1400-200 User’s Manual Version 1.1 1.2. Product Kit Before starting installation, please make sure the APL1400-200 package includes the following five items: 1) Quick Installation Guide 2) APL1400-200 unit 3) CD-ROM (containing Ultra NetBridge Utility for Windows and User’s Manual).
Step 1 Plug the included Ethernet network cable into the computer’s Ethernet port. Step 2 Plug the other end of this cable into the Ethernet port of APL1400-200. Step 3 Plug the electrical cable into to the electrical port of APL1400-200.
Below is a typical POS Application Diagram. 1.5.1. Multiple Connections With APL1400 The APL1400-200 NetBridge™ is designed specifically for small cluster networking applications by providing four MDI/MDIX auto detection RJ-45 ports that can connect to any 10/100Mbps...
Page 9
APL1400-200 User’s Manual Version 1.1 Step 1 Plug the included Ethernet CAT5 cable into the computer’s Ethernet port. Step 2 Plug the other end of the CAT5 cable into the Ethernet port on APL1400. Step 3 Repeat the Step 1 to Step 2 for the rest of computers you want to connect to Electric ○...
APL1400-200 User’s Manual Version 1.1 1.5.2. Front Counter Multiple Connections with APL1400 Step 1 Plug the included Ethernet network cable into the credit card terminal’s Ethernet port. Step 2 Plug the other end of this cable into the Ethernet port of APL1400.
Page 11
APL1400-200 User’s Manual Version 1.1 Step 5 Plug the power plug into the AC socket on the wall. Step 6 Check the LED indicators on the APL1400. (Only available for UltraSpeed™ Series products) Test the network quality by identifying the LED Status:...
APL1400-200 User’s Manual Version 1.1 2. Software Installation Please follow the steps described in this section to install your Ultra NetBridge Utility. ™ 2.1. System Requirements Before installing Ultra NetBridge Utility, make sure the PC meets these requirements for ™...
Page 13
APL1400-200 User’s Manual Version 1.1 Next screen allows you to select the installation folder for the application. Click “Next>” to start the installation: Please wait for Installation progress bar finish. Press “Cancel” button to abort the installation process.
Page 14
APL1400-200 User’s Manual Version 1.1 Utility has been installed. Press “Finish” to start the application: Run the Utility After installed the utility, please run the utility from Start / Programs or double-click the Ultra NetBridge Utility icon as shown in Figure 2.2. There is utility user guide which has ™...
APL1400-200 User’s Manual Version 1.1 3. Web Configuration The APL1400-200 UltraSpeed NetBridge provides Web based configuration by your PC Web ™ ™ browser, such as Microsoft Internet Explorer. This approach can be adopted in any MS Windows, Mac or UNIX based platforms. You can configure the NetBridge ’s IP address using the Ultra...
APL1400-200 User’s Manual Version 1.1 If the password is correct, the web appearance will be changed as shown in Figure 3.1.2. As listed in its Connection Info page, there are several options for system administration. Figure 3.1.2 Connection Info Page 3.2.
APL1400-200 User’s Manual Version 1.1 3.3. Configuration The Configuration page displays the current settings of the NetBridge including Security, Network, ™ VLAN, QoS, System Information. Figure 3.3 Connection Info Page...
APL1400-200 User’s Manual Version 1.1 3.3.1. Security Page The Security page enables you to modify the Network Identifier, Encryption Key and the Mac mode. displays the current settings of the NetBridge including Security, Network, VLAN, QoS and System ™ Information.
APL1400-200 User’s Manual Version 1.1 3.3.2. Network Page The Network page enables you to modify the network settings of the NetBridge ™. Figure 3.3.2 Network Page...
APL1400-200 User’s Manual Version 1.1 3.3.3. VLAN Page The VLAN page enables you to modify the VLAN configuration of the NetBridge ™ Figure 3.3.3 VLAN Page...
APL1400-200 User’s Manual Version 1.1 3.3.4. QoS Page The QoS page enables you to modify the QoS configuration of the NetBridge ™ Figure 3.3.4 QoS Page...
APL1400-200 User’s Manual Version 1.1 3.4. Change Password You can change the administration password for the NetBridge in the Change Password page. ™ Figure 3.4 Change Password Page...
APL1400-200 User’s Manual Version 1.1 3.5. Firmware Upgrade You can upgrade the firmware for the NetBridge in the Firmware Upgrade page. ™ Figure 3.5 Firmware Upgrade Page...
APL1400-200 User’s Manual Version 1.1 3.6. Factory Reset You can reset the NetBridge to the factory default settings from the Factory Reset page. ™ Figure 3.6 Factory Reset Page...
APL1400-200 User’s Manual Version 1.1 3.7. Reboot You can reboot the NetBridge remotely from the Reboot page. ™ Figure 3.7 Reboot Page 4. Default Settings Administration Password: admin IP Address: 0.0.0.0 Network Identifier: Electric-Connect Mac Node: Client...
