Olleh C301N User Manual

100m-level vdsl modem
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Per Model
Class-B
(Broadcasting
Communication
Apparatus and Materials
for Business)
100M-level VDSL Modem
User's Manual
This is an electromagnetic wave shielding apparatus for family
use as Class B and it is intended to be used usually in families
and might also be used everywhere.
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C301N and is the answer not in the manual?

Questions and answers

Summary of Contents for Olleh C301N

  • Page 1 100M-level VDSL Modem User’s Manual Per Model User’s Guide Class-B (Broadcasting This is an electromagnetic wave shielding apparatus for family Communication use as Class B and it is intended to be used usually in families Apparatus and Materials and might also be used everywhere. for Business)

  • Page 2: Introduction Of Product

    C301N User’s Manual Introduction of Product C301N is the 100M-level VDSL (Very high Data rate Subscriber Line) modem that provides the general telephone service and the super-high speed data communication service simultaneously by using the telephone network. C301N provides various multimedia services such as super-high speed internet linkage, internet broadcasting, remote diagnosis, video conference, order-made vided (VOD) and etc.

  • Page 3: Cable Connection

    PC by using Ethernet cable, which is provided with the product.  Linkage of power To link the power adaptor, which is provided by KT, to the power terminal on the backside of C301N and to insert the plug in the consent.

  • Page 4: System Composition

    C301N User’s Manual 2. System composition  Front side Explanation Title Color Operation Function Status that the power is supplied Power (PWR) Green Status that the power is not supplied KT Optical Line Status that VDSL is connected (Normal) Green...
  • Page 5 C301N User’s Manual  Backside Explanation Title Function KIT circuit VDSL circuit Linked to RJ-11 cable that is linked VDSL circuit. (Line) port Telephone Phone linkage Port that links the phone (Phone) port Ground Ground connection connection External ground connection terminal.

  • Page 6: Specifications

    C301N User’s Manual 3. Specifications Item Specifications - ITU-T G.993.2 (VDSL2) - ITU-T G.993.1- 2004 (VDSL) VDSL standards - ANSI T1.424-2004 - ETSI TS 101 270-1 and TS 101 270-2 Modulation DMT (Discrete Multi-Tone) method VDSL2 Transmission Asymmetry: Downward 100Mbps, Upward 100Mbps...

  • Page 7: Product Guarantee

    C301N User’s Manual Product Guarantee Product name VDSL2 modem Model name C301N Certification number UBI- C301N Product number Purchase day Date: Guarantee period 2years Name Address Customer Tel number E-mail Standards for compensation of consumer’s damage The compensation for the consumer’s damage will comply with the regulations for compensation of consumer’s damage announced by Ministry of Finance and Economy.
  • Page 8 C301N User’s Manual Enquiry relative to Use If you have any inconvenience or enquiry during use, please visit the homepage of olleh (http://www.olleh.com) enquire to the buying place or the adjacent center. (No. 100 without area code)
