Summary of Contents for Intuicom RTK Bridge -M Hemisphere Outback A220
- Page 1 ® Intuicom RTK Bridge-M ™ Installation Guide ® Hemisphere Outback A220 Intuicom, Inc. 1880 S Flatiron Court Boulder, CO 80301 (303) 449-4330 www.intuicom.com...
- Page 2 Intuicom reserves the right to make changes to this document without notice. Unless otherwise agreed to in writing, Intuicom assumes no responsibility or liability for the use of this document or for the infringement of any copyright or other proprietary right and Intuicom shall deem nothing contained in this document a warranty or guarantee.
-
Page 3: Requirements For Installation
The Hemisphere Outback A220 smart antenna is typically configured to accept CMR or RTCM format RTK corrections from an Intuicom RTK Bridge-M which in turn has been configured to connect to a GPS/GNSS reference network. The intended audience for this document is a dealer or integrator familiar with the Hemisphere A220 and generally familiar with the Intuicom RTK Bridge-M. -
Page 4: Installation Instructions
Section 3: Installation Instructions 3 Installation Instructions Below is the installation Diagram for the recommended installation of the Intuicom RTK Bridge-M Utilizing the equipment noted above. Diagram 1 Configuration Configure the Intuicom RTK Bridge to connect to GPS/GNSS Reference network and obtain CMR/CMR+ or RTCM correction data stream from an appropriate single reference station, such as a VRS. - Page 5 Section 3: Installation Instructions Using the Intuicom RTK Bridge-M to A220 data/power cable and the null modem adapter, connect the RTK Bridge-M data port to the Serial 2 (B Port) on the A220. Connect setup data/power cabling to the A220 Serial 1 (A Port) and a serial port on a PC running Hemisphere’s Remote Control software.
- Page 6 Section 3: Installation Instructions Select Data Port B by pressing Enter. Set GGA to 1Hz, then press Enter Version 1.0 © 2/2011 Intuicom, Inc.
- Page 7 Section 3: Installation Instructions Scroll up to “Top Menu.” Select by pressing Enter Scroll to System Setup and press Enter Version 1.0 © 2/2011 Intuicom, Inc.
- Page 8 Section 3: Installation Instructions Select Baud Rate and press Enter Set Baud Rate to 38400 for Port B Version 1.0 © 2/2011 Intuicom, Inc.
- Page 9 The A220 should now be configured to send the GGA string to the RTK Bridge–M and receive an RTK correction stream. Confirm fix by launching the SLXMon software included with the Hemisphere A220. (It may take several minutes to achieve an initial fix.) “RTK” should appear in NavMode. Version 1.0 © 2/2011 Intuicom, Inc.
- Page 10 Section 3: Installation Instructions Please contact Intuicom support at (303) 449-4330 with any questions. Version 1.0 © 2/2011 Intuicom, Inc.
