- Page 1 OVR 4100S/8100S/6100SN v1.0 User Manual ─ ─ ─ ─ 4/8/16CH H264 DVR ─ ─ ─ ─ USER GUIDE Unit 3, 3-5 Gilda Crt Mulgrave VIC 3170 T: 1300 688 788 www.omnivision.net.au info@omnivision.net.au Information contained in this document is subject to change without notice.
- Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. NOTE: This equipment has been tested and found to comply with the limits for a class digital device, pursuant to part 15 of the FCC Rules.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER 1 PANEL LOCATION ..................1 1-1 FRONT PANEL CONTROLS ..................1 1-2 16CH REAR PANEL CONNECTORS ................. 2 1-4 8CH REAR PANEL CONNECTORS ................3 1-5 4CH REAR PANEL CONNECTORS ................4 CHAPTER 2 LIVE, PLAYBACK AND PTZ OPERATIONS..........5 2-1 LIVE M ........................ - Page 4 5-1 I ......... 41 NSTALLING AND USING THE REMOTE DESKTOP CLIENT 5-2 R IE ................43 EMOTE MONITORING THROUGH 5-3 R ..............45 EMOTE ESKTOP OFTWARE PERATION CHAPTER 6 SPECIFICAITONS ..................46 CHAPTER 7 MOBILE APPLICATION INSTALLATION AND USAGE ...... 49 7-1 M ..
- Page 5 NSTRUCTION ........................90...
-
Page 6: Chapter 1 Panel Location
In LIVE or PLAYBACK mode, enlarge the display of a channel. ⑪ ZOOM Auto Sequence display. ⑫ AUTO In LIVE mode, press to display menu. In PLAYBACK mode, press to pause ⑬ MENU playback. Input sensor for the remote control. ⑭ IR Sensor Omnivision Pty Ltd Page 1 of 98... -
Page 7: 16Ch Rear Panel Connectors
Socket for a DC 12V input. DC 12V ⑭ External SATA hard disks port for expanding recording space. e-SATA ⑮ (ZA series only) HDMI port. HDMI ⑯ VGA port. (depends on model) VGA2 ⑰ Omnivision Pty Ltd Page 2 of 98... -
Page 8: 8Ch Rear Panel Connectors
BNC port for the main monitor. You can switch to SPOT MAIN monitor ⑪ monitor by GUI setting. USB port (Device USB Mouse) ⑫ EXTERNAL I/O port (see below for pin definition) EXTERNAL I/O ⑬ DB 25 DEFINITION Omnivision Pty Ltd Page 3 of 98... -
Page 9: 4Ch Rear Panel Connectors
BNC port for the main monitor. You can switch to SPOT MAIN monitor ⑪ monitor by GUI setting. USB port (Device USB Mouse) ⑫ EXTERNAL I/O port (see below for pin definition) EXTERNAL I/O ⑬ DB 25 DEFINITION Omnivision Pty Ltd Page 4 of 98... -
Page 10: Chapter 2 Live, Playback And Ptz Operations
In AUTO mode, all available channels will be cycled through in full screen. DVR1,2,3,4 Switch DVR ID1~4 Note ： ： ： ： 4 CH will show quad display; 8 CH will show quad and 9-channel display. Omnivision Pty Ltd Page 5 of 98... - Page 11 LOCK, activate the key lock. Full screen display. Quad display. 9-channel display. 13-channel display. 16-channel display. Note ： ： ： ： 4 CH will show quad display; 8 CH will show quad display and 9-channel display. Omnivision Pty Ltd Page 6 of 98...
- Page 12 Lower right of each CH will show the current time Icon Description Image quality (High/Low) Full screen Record Snap shot Record and snap shot file saving path setup Enable / Disable Shortcut Toolbar Omnivision Pty Ltd Page 7 of 98...
-
Page 13: Playback Mode
Fast forward. Each press increases the speed to the next level. There are six speeds: 2x, 4X, 8X, 16x, 32X and 64X. Stop playback. Table 2-2.2 The mouse operation under the PLAYBACK mode. Omnivision Pty Ltd Page 8 of 98... - Page 14 Frame by frame playback Full screen display Quad display 9-channel display 16-channel display Zoom-in display Note 4 CH will show quad display; 8 CH will show quad display and 9-channel display. ： ： ： ： Omnivision Pty Ltd Page 9 of 98...
-
Page 15: Ptz Mode
Press “PLAY” key first then two-digit number, PTZ will go to the Number correspondent preset number location. Set current PTZ location as the start of line-scan. ＊ FREEZE Activate auto line-scan. ＊ Set current PTZ location as the end of line-scan. ZOOM ＊ Omnivision Pty Ltd Page 10 of 98... - Page 16 , Customized function 「 」 。 * PTZ communication protocols differ from manufacturer to manufacturer and are not co mpatible 100%. Therefore, some of these functions may be unavailable in some PTZ pr otocols Omnivision Pty Ltd Page 11 of 98...
-
Page 17: Chapter 3 Main Menu Setup
Press to cancel the setup, and re-choose the login account. Delete the last character. Enter to identify the password. It will enter the set up menu, If the password is verified. Space key Omnivision Pty Ltd Page 12 of 98... - Page 18 Back to Upper level of menu without saving ENTER Enter the menu, or display virtual keyboard PS. All new HDD’s needs to be initialized before recording can be started please refer to “3-9 UTILITY SETUP” for detail. Omnivision Pty Ltd Page 13 of 98...
-
Page 19: Record Setup
Setup the video preservation period. Recorded video will be Video Preservation deleted automatically after expiry of preservation period. Quality & Frame Rate Setup the quality and frame rate for each channel under normal Setup recording and event recording type. Omnivision Pty Ltd Page 14 of 98... -
Page 20: 3-1.1 Quality & Frame Rate Setup
You can setup quality and FPS separately for record type. Check/uncheck the box enable/disable selected channel recording Quality Select quality: Lowest/ Low/ Normal/ High/ Highest Select recording frame rate. Auto Assign each channel with its maxima accessible fps Omnivision Pty Ltd Page 15 of 98... -
Page 21: Event Setup
OVR 4100S/8100S/6100SN v1.0 User Guide 3-2 EVENT SETUP Item Description Motion Setup Enter to set up motion detection Sensor Setup Enter to set up sensor detection 3-2.1 MOTION SETUP Omnivision Pty Ltd Page 16 of 98... - Page 22 All Area Detection Select entire screen as detection area. Mask All Area Deselect entire detection area. Continue Continue setup Exit & Save Save setup and leave Exit & Discard Cancel setup and leave Omnivision Pty Ltd Page 17 of 98...
-
Page 23: 3-2.2 Sensor Setup
S ensor is deactivated, and will not be turned on/off. ： Note ： ： ： ： 4 CH DVR will display 4 channels and 8CH DVR will display 8 channels. Omnivision Pty Ltd Page 18 of 98... -
Page 24: Schedule Setup
Each page provides 10 schedules for setup. 5 pages in total. Holiday Setup Enter to setup holiday, up to 50 days, other than weekends. View Event/ Motion/ View Normal/ Motion / Sensor Setup Sensor Setup Omnivision Pty Ltd Page 19 of 98... -
Page 25: 3-3.1 Schedule Record Setup
The system can have many different schedules based on different criteria’s. 3-3.2 Holiday Setup Since holidays are different in each country and region, you can setup the holidays for your location accordingly. Omnivision Pty Ltd Page 20 of 98... -
Page 26: Camera Setup
255. The default value is 128. ( This function is not supported on PAL systems) Name Set up name of each channel Audio volume for CH1 under LIVE mode and recording mode can be Volume adjusted. Omnivision Pty Ltd Page 21 of 98... -
Page 27: Account Setup
Letters can be mixed with capitals or lowercases. Permissions Set up Permissions for each user Change Admin Change administrator’s password Password Picture Change user’s picture Omnivision Pty Ltd Page 22 of 98... -
Page 28: 3-5.1 Permission Setup
3-5.2 User Picture Setup Here the user icon for the user can be changed. Select the desired picture from the HD D and select OK to change the user icon with that picture. Omnivision Pty Ltd Page 23 of 98... -
Page 29: Networking Setup
Enter to set up mail 3-6.1 NETWORKING SETUP There are three ways to connect to the network as follows. 3-6.1.1 DHCP When DHCP is selected, IP address will be assigned by the DHCP server automatically. Omnivision Pty Ltd Page 24 of 98... - Page 30 Enter DNS address provided by ISP/ Network Administrator (Note: The correct DNS address must be entered for DDNS function). 3-6.1.3 ADSL Select ADSL if you require the system to manage your ADSL connection, the following information is required. Omnivision Pty Ltd Page 25 of 98...
-
Page 31: 3-6.2 Http Setup
Enter a valid port value from 1 up to 65000. The default value is 80. Auto Assign each channel with its maximum accessible fps Chanel number Quality Setup the transmission quality (below basic, basic, normal, high, and highest). Setup transmission FPS Omnivision Pty Ltd Page 26 of 98... -
Page 32: 3-6.3 Ddns Setup
User Name Enter user name. Password Enter password. 3-6.4 Mail Setup When an event occurs (VLOSS, MOTION, SENSOR) an email can be sent to an email address or a group of email addresses automatically. Omnivision Pty Ltd Page 27 of 98... -
Page 33: Ptz & Rs485 Setup
3-7 PTZ & RS485 SETUP The DVR allows users to control the PTZ cameras attached to the system. To enable this function, a RS-485 cable should be connected to the RS-485 port of the DVR. Omnivision Pty Ltd Page 28 of 98... -
Page 34: System Setup
4. The corresponding DVR number needs to be selected from the remote to control that system. Display Setup Enter to set up Display Date/Time Setup Enter to set up Date/Time Enter to set up Buzzer & Relay Device Setup Omnivision Pty Ltd Page 29 of 98... -
Page 35: 3-8.1 Display Setup
Show Channel Name Turn On / Off channel name display Deflicker(only for CRT monitor) Border Color Set up the color of border in LIVE , PLAYBACK mode. R ed, （ Green, Blue ） Omnivision Pty Ltd Page 30 of 98... -
Page 36: 3-8.2 Date/Time Setup
Set up GMT and Daylight Saving Time. Internet Time Setup Setup automatic synchronization with internet time server 3-8.2.1 CHANGE DATE & TIME Setup date and time of the DVR manually according to user’s local time. Omnivision Pty Ltd Page 31 of 98... - Page 37 Synchronize your DVR time with internet time server. Item Description Tick to enable DVR automatic synchronization function. When Automatic this option is selected, DVR will automatically synchronize the Synchronization time upon rebooting or by every 24 hours after booting. Omnivision Pty Ltd Page 32 of 98...
-
Page 38: 3-8.3 Buzzer & Relay Setup
Enable/Disable buzzer operation when the alarm is triggered for Buzzer sensor, motion and vloss (Video Loss). Enable/Disable the signal to be sent to the RELAY OUT blocks Relay when the alarm is triggered for sensor, motion and vloss. Omnivision Pty Ltd Page 33 of 98... -
Page 39: 3-8.4 Spot Setup
SPOT mode. User can monitor every channel in the SPOT mode. Item Description The duration time in seconds for the interval between channels under Interval (Seconds) SPOT mode. Skip Video Loss Whether to skip channels without video signal. Channel Omnivision Pty Ltd Page 34 of 98... -
Page 40: Utility Setup
System will reboot automatically when the upgrade is completed. Notice! DO NOT TURN OFF POWER OR UNPLUG USB DEVICE DURING THE UPGRADE as it may cause incomplete firmware upgrade and damage to the DVR. Omnivision Pty Ltd Page 35 of 98... -
Page 41: Diagnostic
USING means the HDD is being used for recording Status GOOD/BAD means the HDD has a known/unknown format for the DVR. (Note: Please initialize your newly-installed HDD before using it.) Format Time The latest format time of HDD Omnivision Pty Ltd Page 36 of 98... -
Page 42: Chapter 4 Backup & Search
Be sure to calculate the size of backup file BEFORE starting the backup. Note! Do not unplug the USB device or turn off the DVR during the backup process to avoid unrecoverable errors. Omnivision Pty Ltd Page 37 of 98... -
Page 43: Search Menu
P.S. Event Records will still be generated even when a hard disk is not installed or the record function is not activated. However, the recordings can’t be viewed when opted to do so. Omnivision Pty Ltd Page 38 of 98... - Page 44 Only checked events and channels will be shown in event search. Note 4 CH DVR will display 4 channels and 8CH DVR will display 8 channels. ： ： ： ： Omnivision Pty Ltd Page 39 of 98...
- Page 45 Select the “date” to display recording times for that specific date with a time bar. You can change time (hour/minute/second) or select a specific time on the time bar by mouse clicking on the time bar, and then press “ok”. DVR will playback the selected recording data. Omnivision Pty Ltd Page 40 of 98...
-
Page 46: Chapter 5 Remote Software Installation And Setup
Default user name and password is admin/123456. For information about setting up user accounts and passwords, please refer to “3-5 Account Setup. “ Step Three: Click on the download link to start downloading the AP software. Omnivision Pty Ltd Page 41 of 98... - Page 47 (IP, Port, Username and Password) or choose “Play Recorded File” to open backup files in your PC. Step Six: Select OK and you will be logged into the system if authorized. Omnivision Pty Ltd Page 42 of 98...
-
Page 48: Remote Monitoring Through Ie
Step Two: The system authentication window will be displayed. Please enter the user name and password for the system. Default user name and password is admin/123456. For information about setting up user accounts and passwords, please refer to “3-5 Account Setup. “ Omnivision Pty Ltd Page 43 of 98... - Page 49 ActiveX component. Please refer to Appendix I for Remote Monitoring IE ActiveX Control Installation Instruction. Step Four: DVR images appear. Note 4 CH DVR will display 4 channels and 8CH DVR will display 8 channels. ： ： ： ： Omnivision Pty Ltd Page 44 of 98...
-
Page 50: Remote Desktop Software Operation
Mobility Radeon Xseries, Mobility Radeon HD series, or FireGL V series etc. Or visit: http://en.wikipedia.org/wiki/Comparison_of_ATI_graphics_processing_units SiS: SiS 67Xseries, or SiS 77Xseries etc. Or visit: http://www.sis.com/support/support_compare.htm Intel: 91Xseries, 94Xseries, 96Xseries, G3Xseries, or G4Xseries, etc. Or visit: http://en.wikipedia.org/wiki/Intel_GMA Omnivision Pty Ltd Page 45 of 98... -
Page 51: Chapter 6 Specificaitons
704 X 576, 704 X 288, 352 X 288 (PAL) Resolu tion (P 352 x 240 (NTSC), ixel) (Network) 352 x 288 (PAL) Picture quality 5 levels (Highest, High, Normal, Basic, Below Basic) Omnivision Pty Ltd Page 46 of 98... - Page 52 SB DVD±RW (Not Supplied)/ SATA DVD / USB DVD±RW ±RW (Not Supplied) / S ATA DVD±RW (Op tional) Alarm Motion Detection Detected Frames: Unlimited / Channel Sensitivity : 10 levels for each channel Area : Programmable individually Omnivision Pty Ltd Page 47 of 98...
- Page 53 ( Max. 1 Device) ( Max. 4 Device) System Upgrade via USB / Network Hard Key Front Panel Pan/Tilt/Zoom Con Control From RS485 Interface trol ( Pelco P, Pelco D, Samsung, LG, LiLin ) Table 6-1 Omnivision Pty Ltd Page 48 of 98...
-
Page 54: Chapter 7 Mobile Application Installation And Usage
You can remotely monitor all channels of the DVR through your mobile device. The required mobile application for your mobile devises operating system can be found on the user manual CD or by contacting Omnivision Technical services. Currently applications are available for Windows mobile 5.0 and above, Symbian OS, iPhone and Android based devises. -
Page 55: 7-1.2 Mobile Application Operation
Live image will show up after a successful connection. PS. Live images can not be displayed in your mobil e when the recoding is turned off in the local DVR. Omnivision Pty Ltd Page 50 of 98... -
Page 56: 7-1.3 Live Monitoring Operation
“Delete” command can be used to remove the DVR information if it is no longer useful. Select the DVR on the name list then choose “Delete” 7-1.3 Live Monitoring Operation This paragraph describes operations under the LIVE monitoring mode in your mobile device. Omnivision Pty Ltd Page 51 of 98... - Page 57 There will be 5 levels for you to choose: Low 、 Normal M iddle H igh and Highest. 、 、 7-1.3.3 Channel Display Select “Single” in the “Menu”, all the channels of your DVR will be displayed in the menu. Omnivision Pty Ltd Page 52 of 98...
- Page 58 Triggered and Video loss. Graphical icons below will be shown on the status: : Motion detected : Sensor triggered : Video loss Select the “Alarm” under the “Menu” to switch this function on or off. Omnivision Pty Ltd Page 53 of 98...
-
Page 59: Mobile Application Installation And Operation For Windows Mobile System
User Manual CD (that packed with the DVR) by using a Bluetooth link or USB cable. Step 2: Install the application software “H264Pocket.CAB” in to your mobile device. Omnivision Pty Ltd Page 54 of 98... -
Page 60: 7-2.2 Mobile Application Operation
Choose the DVR for which the login information needs to be Modify DVR Login Modify modified the press “Modify”, press "OK” when finished Information modifying to save changes. Delete DVR Login Delete Choose DVR and press "Delete” to delete the DVR info. Information Omnivision Pty Ltd Page 55 of 98... -
Page 61: 7-2.3 Using The Mobile Application
If the channel video with sound input, turn this Sound Sound option to hear the real sound You can choose one channel to display in full Full Screen Full screen display screen by check this function. Omnivision Pty Ltd Page 56 of 98... -
Page 62: Mobile Application Installation And Operation For Blackberry System
Download the latest version of Blackberry Desktop Manager and install it in your PC Step 2: Connect Blackberry USB transmission cable to Blackberry and PC. Activate Blackberry Desktop Manager on PC and it will automatically connect to Blackberry momentarily. Omnivision Pty Ltd Page 57 of 98... - Page 63 Step 3 E xecute “Application Loader” ： Step 4: Execute “Add/Remove Applications” Step 5: Copy "codname.alx” and “codname.cod” which can be found on the User Manual CD (packed with the DVR) to the PC. Omnivision Pty Ltd Page 58 of 98...
-
Page 64: 7-3.2 Mobile Software Operation
In order to connect to a DVR, the DVR information needs to be loaded on to the mobile device. Select “option” → “Add”, and then enter the information required (“DVR IP”, “port”, “user name” Omnivision Pty Ltd Page 59 of 98... - Page 65 Before connecting to the DVR, there might be a packet download confirmation message which appears on some mobile devices. Press “Yes.” (The data usage may incur a fee which will depend on your mobile service provider.) Omnivision Pty Ltd Page 60 of 98...
- Page 66 If the connection is successful DVR image appears. Note I f the recording function is not turned on in the DVR, that channel will not be ： ： ： ： available for live monitoring. Omnivision Pty Ltd Page 61 of 98...
- Page 67 “Option” → “Modify” for editing the existing data. Press “OK” when it’s finished. 7-3.2.4 Delete Existing DVR Record (Connection Information) If connection information for a DVR is no longer needed, please select the DVR. Press “Option” → “Delete” to delete the DVR connection information. Omnivision Pty Ltd Page 62 of 98...
-
Page 68: 7-3.3 Live Image Operation
Fit Screen Image appears to be the most optimized size according to the screen. 7-3.3.3 Image Rotation There are two options for live image display. Display the image without any rotation, or rotate Omnivision Pty Ltd Page 63 of 98... - Page 69 Motion Detection, Sensor Detection, Video Loss …etc. occurs, there will be alarm sound and alarm images appear on the status. Icon Description Motion Detection Sensor Detection Video Loss Press “Alarm” in menu, there will be options, “Alarm OFF” and “Alarm ON” available to choose from. Omnivision Pty Ltd Page 64 of 98...
-
Page 70: Mobile Application Installation And Operation For Apple Iphone
Click the “FREE APP” button to download the file to your PC or devise. Step 3: You will find the downloaded file on the directory of Application. If you install the application on your mobile skip directly to step. Omnivision Pty Ltd Page 65 of 98... - Page 71 Applications” & “Scdvr” and click “Sync” button. The device ID differs from iPhone to iPhone ＊ Step 5: After finishing the sync, you will find the Scdvr Icon on your iPhone Select that to launch the application. Omnivision Pty Ltd Page 66 of 98...
-
Page 72: 7-4.2 Mobile Software Operation
You can resize the size of the live image by zooming in and out the live feed using normal iPhone hand controls (hand movements which is performed to zoom in and out an image). 7-4.3.3 Live image rotate The live image will automatically rotate according to your normal iPhone movements. Omnivision Pty Ltd Page 67 of 98... -
Page 73: Mobile Application Installation And Operation For Android Phones
Internet needed for Mobile device operation platform (GPRS/ 3G/ Wifi…etc.) Follow the following instructions to install the mobile application on your android devise. Step 1. Open App market in your phone. Step 2. Search for the mobile application “Bubo Budo”. Omnivision Pty Ltd Page 68 of 98... -
Page 74: 7-5.2 Mobile Software Operation
Step 4. Choose “BuboBubo” and click “Install” button. When the installation is complete tap on the icon to launch the application. 7-5.2 Mobile Software Operation When the application is opened for the first time, there will be a empty record (dvr1) by default. Omnivision Pty Ltd Page 69 of 98... - Page 75 Save : Save the record Clear : Clear up all fields Cancel: Do nothing and return the list Delete: Delete this record. Omnivision Pty Ltd Page 70 of 98...
-
Page 76: 7-5.3 Live Image Operations
Click on the Ch icon and choose other c hannels Click on the Quarter icon for quad view, (only supported with JPEG) Click on the Login icon, return to login lis Omnivision Pty Ltd Page 71 of 98... - Page 77 User Guide When in Landscape mode, the toolbar is hidden by default, tap on the screen to get th e tool bar. Taping on the screen again will hide the tool bar again. Omnivision Pty Ltd Page 72 of 98...
-
Page 78: Chapter 8 Cms Installation And Usage Guide
4. Select “Next”, and then select “Browse” to change installation path if needed. To check available space on the hard disk, please select “Disk Cost” and then please select “Next” to go to the next step. Omnivision Pty Ltd Page 73 of 98... - Page 79 OVR 4100S/8100S/6100SN v1.0 User Guide 5.”Confirm Installation” window shows. Select ‘Next’ then the installation starts. 6. Select ‘Close’ to finish installation when the “Installation Complete” window is show Omnivision Pty Ltd Page 74 of 98...
-
Page 80: Cms Login And Environment
Live image display area. See “8-5 Main Display” for detail. 4 Display Modes Different display modes supported by CMS. A set of 10 operations are provided by CMS. See “8-6 Operation 5 Operation Bar Bar” for detail. Omnivision Pty Ltd Page 75 of 98... - Page 81 Step 1: When in Windows go to the “Windows” folder and then the folder “Systme32” (Eg:C:\Windows\System32) Step 2: Locate file, “iCMS.dat” and delete it. Step 3: Restart CMS. Log-in successfully. Omnivision Pty Ltd Page 76 of 98...
-
Page 82: Dvrs, Groups & Events
“8-6.3 Group Administration” for further information. Left-clicking on a connected DVR will expand/collapse status of all its channels as below: Icon Description Video Loss Motion Detected Sensor Triggered Omnivision Pty Ltd Page 77 of 98... -
Page 83: Roup
Takes a snapshot of the current image and saves it in the local PC storage. To view all the snapshots you’ve taken, Snapshot please go to” Snapshot” button located in the operation bar . See “8-6.5 Snapshot data” for detail. Omnivision Pty Ltd Page 78 of 98... -
Page 84: Main Display
A udio signal is On 「 」 A udio signal is Off 「 」 Turn on/off by clicking on the graphical icon, please note that the application can only h andle one audio channel at a time. Omnivision Pty Ltd Page 79 of 98... -
Page 85: 8-5.2 Emap Display
“No eMaps” will be shown. Please check “8-6.4 eMAP administratio n” for setup information. Omnivision Pty Ltd Page 80 of 98... -
Page 86: 8-5.3 Ptz Control
P TZ communication protocols differs from manufacturer to manufacturer and not all PT ＊ Z functions listed here are implemented by all the manufactures. Therefore, some of the se functions may be unavailable. Omnivision Pty Ltd Page 81 of 98... -
Page 87: Operation Bar
HDD Playback. Please see “8-6.6 HDD Play” File Playback. Please see “8-6.7 File Play” Event Playback. Please see “8-6.8 Event Play” Snapshot Data. Please see “8-6.9 Snapshot” Recording Data. Please see “8-6.10 Recording” Omnivision Pty Ltd Page 82 of 98... -
Page 88: 8-6.1 User Administration
Address: DVR IP Address Port: DVR Network Port Channel: DVR Camera Number DVR Login Name DVR Login Password Password: Description: Other Description Camera Description: Camera Description From DVR: Load Camera name from DVR Omnivision Pty Ltd Page 83 of 98... -
Page 89: 8-6.3 Group Administration
7. You can ‘Select’ again to add other channels, but then any un-saved channel locations will be lost. 8. Click “OK” to save the setup. Omnivision Pty Ltd Page 84 of 98... -
Page 90: 8-6.4 Emap Administration
3. Drag channels in the left lower corner onto any place in the picture. 4. To delete a channel already on the picture, right click the channel and click ‘Remove’. 5. Click OK to save. Omnivision Pty Ltd Page 85 of 98... -
Page 91: 8-6.5 Remote Play
Pause. Fast forward. Fast rewind. Select the size of the clip you want to watch by selecting the number of minutes and seconds, Then Press the butt on to start playing that clip Omnivision Pty Ltd Page 86 of 98... -
Page 92: 8-6.6 Hdd Playback
You can play backed up .irf files using the “File Play” function of the CMS. It allows yo u to change the display mode, forward or rewind the file and file navigation using the dr ag able navigation bar. Icon Description Start Playback. Pause. Stop playback. Fast forward. Fast rewind. Omnivision Pty Ltd Page 87 of 98... -
Page 93: 8-6.8 Event Playback
This function will display all the snapshots you’ve taken using the CMS. You can review, delete or save the images as other files, here. *The date and time shown on the snapshot in the date and the time the snapshot was taken. Omnivision Pty Ltd Page 88 of 98... -
Page 94: 8-6.10 Recording Data
2. You can choose the display mode. 3. Time bar will be shown at right lower corner; please drag the time bar to navigate to a specific recording time you’d like to view. Omnivision Pty Ltd Page 89 of 98... -
Page 95: Appendix I Remote Monitoring Ie Activex Control Installation I
1. When remote monitoring on IE for the first time, an alert message occurs “Install ActiveX control” on the tool bar. 2. Click at this alert message and select “Install ActiveX Control” 3. “Do you want to install this software” alert pops up. Select “Install” Omnivision Pty Ltd Page 90 of 98... - Page 96 5. If message, “Your security Settings do not allow web sites to use ActiveX controls installed on your computer.” pops on when logging in, please follow the next instruction. 6. First select “Tools” on the tool bar and then select “Internet Options” Omnivision Pty Ltd Page 91 of 98...
- Page 97 8. Enter the DVR address (The address shown below is a demonstration only. You need to input the correct address of the DVR according to your setup.) into the blank text box shown in picture, and then press “add.” Omnivision Pty Ltd Page 92 of 98...
- Page 98 OVR 4100S/8100S/6100SN v1.0 User Guide 9. Newly added website will appear under the trusted web sites list. Press close. 10. Go back to IE window, press refresh button or F5. Omnivision Pty Ltd Page 93 of 98...
